Wharfedale Pro DP-N Series User manual

DSP Multi-channel Power amplifiers
DP-2200N DP-4100N
DP-4065N DP-4035N
DP-N Series
USER MANUAL

Congratulations on the purchase of your DP-N series professional power amplifier. Wharfedale Pro DP-N
amplifiers are the result of many years of experience in the use, design and manufacture of professional
audio equipment.
We take great pride in engineering and building every Wharfedale Pro product and wish to thank you for
entrusting us with your sound.
From the time Gilbert Briggs built his first loudspeaker in 1932, to the present day, Wharfedale has
maintained the same standard of quality in components, workmanship and performance.
Please take the time to read this manual completely in order to ensure that you get the most from your
DP-N power amplifier.
DP-N series have been engineered for mid sized venues, rental and touring applications.
Enormous output power and stability at 2 ohms are features that already make DP amps special - but DP-N
models also feature Dante ™ connectivity and hugely upgraded DSP functionality.
The DSP now has FIR filtering with 512 taps. This refined and powerful FIR filtering brings linear phase
response to the system, resulting in a more controllable and faithful output.
Input connectivity is now handled by the front panel Dante ™ connectors - allowing the DP-N to be used
in a huge Dante ™ ecosystem. Networked audio, with remote DSP control.
DP-N series also feature a wide range AC power input and are happy with huge voltage fluctuations
between 90 V and 260 V. In addition, DP-N series can drive 70 V or 100 V line systems!
Think dif-FIR-ently about amps!
• Huge Class D power in a 1 U rack
• 2 or 4 discrete amplification channels
• Internal DSP and computer control
• Stable down to 2 Ω. Drive multiple
speakers or line array elements
• FIR filtering with 512 taps
• 90 V to 260 V AC working voltage
• Dante ™ connectivity
• 70 V or 100 V compatible
4 x 1000 W
4 x 1700 W
2 x 2000 W
2 x 3400 W
2 x 5780 W
2 x 2000 W
2 x 3400 W
1 x 4000 W
1 x 6800 W
2 x 4760 W
1 x 9520 W
4 x 650 W
4 x 1100 W
2 x 1300 W
2 x 2200 W
2 x 3740 W
4 x 350 W
4 x 595 W
2 x 700 W
2 x 1190 W
2 x 2020 W
DP-2200N DP-4100N DP-4065N DP-4035N
4 x 2890 W 4 x 1870 W 4 x 1010 W
100 V Hi-Z
8 Ω
4 Ω
2 Ω
8 Ω Bridged
4 Ω Bridged
16 Ω Bridged
70 V Hi-Z
2 x 3400 W
2 x 2400 W
-
4 x 1700 W
- -
-
4 x 1100 W
ABOUT THE DP-N SERIES
INTRODUCTION
FEATURES
For the latest release of the control software for DP-N series, please visit www.wharfedalepro.com
Audinate® is a registered trademark of Audinate Pty Ltd. Dante® is a registered trademark of Audinate Pty Ltd.

1. Dual RJ45 network interfaces: Dante ™ digital audio input interface, network monitoring interface.
2. Cooling vents. Forced airflow from front to back through the air filter.
3. Integrated LCD control screen with backlight.
4. Control knob. Turn to select the DSP menu and press to confirm.
5. Mains Power switch. Used to turn the power on and off. When I is pressed, the power is turned on.
6. Mains Power input. Neutrik powerCon 20 A.
7. Fan. Provides forced ventilation for front to back cooling.
8. Output connectors for connection to passive loudspeakers.
In stereo or single-channel mode, connect the speakers to the socket using the following methods:
In bridge mode, use the following method to connect the speaker to the socket:
9. XLR Balanced signal input connectors.
INTRODUCTION

Output part
DSP SIGNAL FLOW

4 x 350 W
214.0849.0
0.6 1.3
1.6 3.2
2.6 5.2
3.7 7.5
12.66.3
140.0 140.00.0 477.8 120.4
347.2 250.0 97.2 331.8 83.6
574.3 425.0 149.3 509.6 128.4
823.0 666.7 156.4 533.7 134.5
1382.1 1133.3 248.8
110 V220 V
standby
LOAD
4 Ω/CH
1/8 power
1/3 power
8 Ω/CH
4 Ω/CH
8 Ω/CH
Dissipated
Line Current(A)
IN OUT
Power(W)
Thermal Dissipation
kcal/hBtu/h
276.91098.7
0.6 1.3
2.1 4.1
3.4 6.8
4.9 9.7
16.38.1
140.0 140.00.0 477.8 120.4
451.4 325.0 126.4 431.3 108.7
743.2 550.0 193.2 659.5 166.2
1070.0 866.7 203.3 693.8 174.8
1788.6 1466.7 322.0
110 V220 V
standby
LOAD
4 Ω/CH
1/8 power
1/3 power
8 Ω/CH
4 Ω/CH
8 Ω/CH
Dissipated
Line Current(A)
IN OUT
Power(W)
Thermal Dissipation
kcal/hBtu/h
Test signal: Pink Noise, bandwidth limited from 22 Hz to 22 kHz
1/8 power is typical of program material with occasional clipping. Refer to these figures for most applications.
1/3 power represents program material with extremely heavy clipping
*This power is measured by using a 20 ms pulse of 1 kHz sine wave at 1% total harmonic distortion.
SPECIFICATIONS
4 x 1000 W
4 x 1700 W
2 x 2000 W
2 x 3400 W
89.4 V
4 x 2890 W
2 x 5780 W
2 x 2000 W
2 x 3400 W
1 x 4000 W
1 x 6800 W
126.5 V
2 x 4760 W
1 x 9520 W
4 x 650 W
4 x 1100 W
2 x 1300 W
2 x 2200 W
72.1 V
4 x 1870 W
2 x 3740 W
21 dB~39 dB
24 dB~42 dB 19 dB~37 dB
24 dB 21 dB 19 dB
483 x 45 x 376 mm
9.3 kg
-
4 x 1700 W 4 x 1100 W
2 x 3400 W
2 x 2400 W
4 Ω / Bridge
8 Ω / Stereo
4 Ω / Stereo
2 Ω / Stereo
16 Ω / Bridge
8 Ω / Bridge
Output RMS voltage
Gain(Rated Power,1 kHz)
Cross-Talk
Frequency Response
Input Impedance
Main Power
Protection
Size(W×H×D)
Net Weight
Maximum Input Level
Default Gain(Rated Power,1 kHz)
Damping Factor
SNR
THD+N
70 V Hi-Z
100 V Hi-Z
8.7 Vrms(+21 dBu)(Default Gain)
≥90 dB(20 Hz-1 kHz,Below Rated Power,8 Ω)
20 kΩ(Balance),10 kΩ(Unbalance)
≥1000(20 Hz-200 Hz,8 Ω)
90~260 VAC,50/60 Hz
≥105 dB(Default Gain, A weighted,20 Hz-20 kHz,8 Ω)
Typical value:+0,-0.5 dB(10% Rated Power,20 Hz-20 kHz,8 Ω)
Typical value:0.05%(10% Rated Power,8 Ω)
4 x 350 W
4 x 595 W
2 x 700 W
2 x 595 W
52.9 V
4 x 1010 W
2 x 2020 W
17 dB~35 dB
17 dB
DP-4100NDP-2200N DP-4065N DP-4035N
- -
-
Rated Power
(THD=1%,Each channel
works simultaneously
with continuous
sinusoidal 1 kHz)
Power under-voltage protection、Amplifier output DC protection、
Thermal Protection、Temperature Power Control、Overload Power Control
Model
9.1 kg 9.1 kg 8.0 kg

2 x 2000 W
427.91698.0
0.7 1.5
3.2 6.3
5.2 10.4
7.5 15.0
25.112.6
160.0 160.00.0 546.0 137.6
694.4 500.0 194.4 663.6 167.2
1148.6 850.0 298.6 1019.2 256.8
1646.1 1333.3 312.8 1067.3 269.0
2764.2 2266.7 497.6
110 V220 V
standby
LOAD
4 Ω/CH
1/8 power
1/3 power
8 Ω/CH
4 Ω/CH
8 Ω/CH
Dissipated
Line Current(A)
IN OUT
Power(W)
Thermal Dissipation
kcal/hBtu/h
427.91698.0
0.5 1.0
3.2 6.3
5.2 10.4
7.5 15.0
25.112.6
110.0 110.00.0 375.4 94.6
694.4 500.0 194.4 663.6 167.2
1148.6 850.0 298.6 1019.2 256.8
1646.1 1333.3 312.8 1067.3 269.0
2764.2 2266.7 497.6
110 V220 V
standby
LOAD
4 Ω/CH
1/8 power
1/3 power
8 Ω/CH
4 Ω/CH
8 Ω/CH
Dissipated
Line Current(A)
IN OUT
Power(W)
Thermal Dissipation
kcal/hBtu/h
4 x 1000 W

Wharfedale Pro products are warranted of manufacturing or material defects for a period of one
year from the original date of purchase. In the event of malfunction, contact your authorised
Wharfedale Pro dealer or distributor for information.
*Be aware that warranty details may differ from country to country. Contact your dealer or
distributor for information. These terms do not infringe your statutory rights.
WHARFEDALE PRO LIMITED WARRANTY
Audinate® is a registered trademark of Audinate Pty Ltd.
Dante® is a registered trademark of Audinate Pty Ltd.
September 2021
