ServiceManual:
EVP-X15P
ProfessionalSpeaker
Enclosures
1
TABLEOFCONTENTS
SPECIFICATIONS------------------------------------------------------------------------------2
SCHEMATICDIAGRAM---------------------------------------------------------------------4
ASSEMBLYSKETCH-------------------------------------------------------------------------3
ASSEMBLYPART LIST--------------------------------------------------------------------5
ELECTRONICS PARTSLIST-----------------------------------------------------------------6
SCHEMATICDIAGRAM(AMP)------------------------------------------------------------7
ASSEMBLYPART LIST(AMP)--------------------------------------------------------------8
ELECTRONICS PARTSLIST(AMP)--------------------------------------------------------9

1.SPECIFICATIONS
2
Systemspecification
SystemType15"2-way
FrequencyResponse+/-3dB45Hz-20kHz
FinishMaterialBlackcarpet
Tripolstand
Stand BottomYes
Stand Top --
Input:
InputASwitchablebalancedmicorlinelevel input
InputBLinelevel input
SpeakerLevelInputNA
InputConnectors
InputACombinedjackand XLR
InputB Combinedjack,XLRand RCASocket
InputSensitivity
Mic5mV
RCA0.5V
LINE0.775V
InputImpedance
Mic470 ohms
LineInputA47k
LineInputB10k ohms
LineOutput
TypeBalancedMaleXLRconnector
LineOutputHigh Pass Filter
MainEQHFshelving +/-12dB@10kHzLFshelving +/-12dB@
80Hz
ActiveCrossover NA
InfrasonicFilter NA
PhaseswitchNA
POWERSECTION
AmplifierPowerContinuous:400WPeak:600w
Extention SpeakerOutputNA
Protection TypeDynamic/AGC
Poweron indicitorRedLED
SystemDynamicAGCactiviteIndicatorYellowLED
ENCLOSURE
Dimention(mm)HxWxD675x460x450
weightNet(kg)29.5kg
weightGross (kg)33.6kg

2.SCHEMATICDIAGRAM
3
C1=4.0uF/250VR3=3OHM/10W
C2=8.2uF/250VR4=4OHM/30W
C3=18uF/250VL1=0.2mH
R2=5.0 OHM/25WL2=0.35mH

3.ASSEMBLYSKETCH
4

4.ASSEMBLYPARTSLIST
5
R/NP/NPARTNAMEDESCRIPTION QUA
1 217-2935000002 LOGO PLATE 1
2 310-2930000001 STEEL GRILLE 1
3 533-5001350801ASCREWSMT(+)5*35 BZn 8
4ZD-64600-01 WOOFER1
5 233-1200750711 PLASTICTUBE2
6 539-4001300803ASCREWSMC(*)5*35 BZn 4
7 253-2929000001 PLASTICHORN1
8 540-6001120306ASCREWSMH6*12NID4
9ZD-53301-01 TWEETER1
10 344-2936000001 CABINET 1
11 328-2643000001 HANDLE1 2
12 328-2921000001 HANDLE2 2
13 226-3800601111 RUBBEROOT4
14 259-2080000001 SUPPORTHOLDER1
15 534-6001400801ASCREWSMK(+)6*40 BZn 4
16 553-4001209061ASCREWS4*20 TA H BZn 10
17 554-4001208061ASCREWS4*20KA H BZn 18
18 ZC-38400-01 AMPLIFIER1
19 537-4002300801ASCREWSMP(+)4*30 BZn 10
20 600-2936000010 CROSSOVERASSEMBLED UNIT1

5.ELECTRONICPARTSLIST
6
R/NP/NPARTNAMEDESCRIPTION QUA
1 053-2935003109 PCB PLATE 1
2 053-2930003109 LEDPCB PLATE 1
3 019-0344122000 YELLOWLED1
4 019-0322122001 GREENLED1
5 079-0020000000 LAMP(SK3)1
6 014-8250411002 CAPACITOR8.2uF/250V1
7 014-4050411002 CAPACITOR4.0uF/250V1
8 014-1860411002 CAPACITOR18uF/250V2
9 001-5009519100 RESISTOR5OHM/25E1
10 001-4000513050 RESISTOR4OHM/30W1
11 001-3009511100 RESISTOR3OHM/10W1
12 080-0300200600 INDUCTANCE0.2mH1
13 080-0600351000 INDUCTANCE0.35mH1

6.SCHEMATICDIAGRAM(AMP)
7

3.SCHEMATICDIAGRAM
4

7.ASSEMBLYPARTSLIST(AMP)
8
R/NP/NPARTNAMEDESCRIPTION QUA
1300-1384020000 ALPANEL 1
2306-1384020000 RADIATOR1
3307-2300500081 COPPERPOST5
4307-2300500241 COPPERPOST2
5310-1385130000 GRILLE 1
6527-3012100811ASCREWS SP(+)3*10 DCHBZn6
7535-3031080801ASCREWSMPW(+)3*8 BZn7
8537-3001080801ASCREWSMP(+)3*8 BZn4
9537-3001140801ASCREWSMP(+)3*14 BZn10
10 537-4001120801ASCREWSMP(+)4*12 BZN8

8.ELECTRONICPARTSLIST(AMP)
9
R/NP/NPARTNAMEDESCRIPTION QUA
088-1384001300 SEMAPHOREPCB 1
1 053-1384001113 PCB PLATE 1
2 001-4703203010 RESISTOR47K1/8WF4
3 001-4701203010 RESISTOR470 ohm1/8WF2
4 001-1003203010 RESISTOR10K1/8WF11
5 001-2003203010 RESISTOR20K1/8WF1
6 001-1002203010 RESISTOR1K1/8WF2
7 001-2203203010 RESISTOR22K1/8WF4
8 006-2201051163 CAPACITORSM22uF50V10%4
9 006-1001051163 CAPACITORSM10uF50V10%6
10 008-4700005004 CAPACITOR47P-50V-J7
11 014-1020211028 CAPACITORMKS2 1NF63V10%1
12 014-2230211028 CAPACITOR22nF63V10%PH=7.5mm 1
13 017-0650000000 ICTL072(CN)1
14 017-1530000000 ICTL074CN1
15 020-5052119425 POTENTIOMETERSRD16K124A068-50KCBX2SII 4
16 051-0500000000 JACKRCAJK0200560N1
17 048-3000000000 JACK NYS143 J3Y1 3pinPCB 1
18 049-2510222016 JACKCXLF-07 2
19 056-4106221100 JACKJS-1001-6(2802-06GS)1
20 089-0500000012 REMOVESWITCHSS-22F20-G12 2
088-1384001000 AMP PCB 1
1 053-1384001110 PCB PLATE 1
2 001-1003205010 RESISTOR10K1/4WF5
3 001-2704205010 RESISTOR270K1/4WF2
4 001-4702205010 RESISTOR4.7K1/4WF4
5 001-2204205010 RESISTOR220K1/4WF2
6 001-2202205010 RESISTOR2.2K1/4WF3
7 001-3903205010 RESISTOR39K1/4WF1
8 001-1005205010 RESISTOR1M1/4WF1
9 001-1004205010 RESISTOR100K1/4WF2
10 001-1501205010 RESISTOR150 ohm1/4WF2
11 001-6801205010 RESISTOR680 ohm1/4WF1
12 001-1002205010 RESISTOR1K1/4WF3
13 001-2002205010 RESISTOR2K1/4WF1
14 001-1802205010 RESISTOR1.8K1/4WF1
15 001-1001205010 RESISTOR100 ohm1/4WF4
16 001-3303205010 RESISTOR33K1/4WF2
17 001-4700205010 RESISTOR47 ohm1/4WF2
18 001-4709205010 RESISTOR4.7 ohm1/4WF2
19 001-1000205100 RESISTOR10 OHM/1/4W1

8.ELECTRONICPARTSLIST(AMP)
10
20 001-0229510050 RESISTOR0.22 ohm5WJ6
21 001-0470308050 RESISTOR4.7 ohm2WJ1
22 005-2001306101 RESISTORPA0631-HA1-B201 1
23 006-1004061194 CAPACITOR10uF100V6
24 006-1001051163 CAPACITORSM10uF50V10%1
25 006-2201051163 CAPACITORSM22uF50V10%1
26 006-1011061143 CAPACITORSM100uF25V10%4
27 006-4704101392 CAPACITOR47 UF/100V10*12.5 2
28 013-1040210801 CAPACITOR104/63V1
29 013-1520210501 CAPACITOR152 63V5%1
30 008-2201050004 CAPACITOR22P/500V10%2
31 008-1512050004 CAPACITOR151/500V10%2
32 014-4730300001 CAPACITOR47N-100V-JCL11 1
33 067-1104148000 DIODEIN4148 5
34 067-2204004000 DIODEIN4004 2
35 067-2205404000 DIODEIN5404 2
36 019-0315132000 LED1
37 018-2905401115 AUDION 2N5401 TO-92 5
38 018-2905551115 AUDION 2N5551 TO-92 4
39 018-1900350113 AUDION MJE350 TO-126 1
40 018-1900340113 AUDION MJE340 TO-126 1
41 018-0101492116 POWERTUBE2SA1492 TO-3P3
42 018-0101859113 AUDION 2SA1859A1
43 018-0303856116 POWERTUBE2SC3856 TO-3P3
44 018-0304883113 AUDION 2SC4883A2
45 018-2800112115 FIELDEFFECT TRANSISTORJ112 TO-92 2
46 026-2794103170 INDUCTANCE2.7UH 1
47 004-6609000000 RESISTOR3-11K1
48 079-0401000000 PROTECTORPTC RXE040 2
49 066-0095010000 SWITCHTO-2P1
50 056-4104221100 JACK DJ2802-4P1
51 056-6104224400 JACK VH3.96 4PIN1
52 056-4105220000 JACKJS-1135-05 1
53 056-0106003300 JACK6PIN3.96PH1
54 277-0100000000 TRANSISTOR BASE3
55 001-4703205010 RESISTOR47K1/4WF1
56 001-6802205010 RESISTOR6.8K1/4WF1
57 001-1503205010 RESISTOR15K1/4WF1
088-9384000400 POWERPCB 1
1 053-9384001604 PCB PLATE 1
2 001-1000203010 RESISTOR10 ohm1/8WF1
3 001-3300103050 RESISTOR33 ohm1/8WJ2

8.ELECTRONICPARTSLIST(AMP)
11
4 001-1001203010 RESISTOR100 ohm1/8WF1
5 001-4702203010 RESISTOR4.7K1/8WF3
6 001-6802203010 RESISTOR6.8K1/8WF1
7 001-1003203010 RESISTOR10K1/8WF5
8 001-3002203010 RESISTOR3K1/8WF1
9 001-2702203010 RESISTOR2.7K1/8WF1
10 001-1803203010 RESISTOR18K1/8WF3
11 001-3303203010 RESISTOR33K1/8WF1
12 001-2203203010 RESISTOR22K1/8WF2
13 001-1005203010 RESISTOR1M1/8WF1
14 001-4704205010 RESISTOR470K1/4WF1
15 001-0220106050 RESISTOR2.2 ohm1/2WJ1
16 001-4703107050 RESISTOR470K1W5%1
17 001-2203208010 RESISTOR22K2W1%1
18 001-0393108050 RESISTOR39K2W5%3
19 001-1004208050 RESISTOR100K2W5%1
20 001-0229810050 RESISTOR BPR56F0.22 5%2
21 004-3307000000 RESISTOR10D-20 3
22 004-3312000000 RESISTORNTC10K1
23 006-1001051163 CAPACITORSM10uF50V10%2
24 006-1011061143 CAPACITORSM100uF25V10%2
25 006-1014081463 CAPACITORSM100uF50V20%1
26 006-2214081443 CAPACITOR220uF25V1
27 006-4711102053 CAPACITOR470uF35V10%10*20mm 2
28 006-4714162593 CAPACITOR470UF/100V16*25 2
29 006-6814253603 CAPACITOR680UF200V25*3 4
30 014-1020100002 CAPACITORAMZ0.001UF50V5%2
31 008-1004005017 CAPACITOR104-Y5P-50V-Z4
32 008-3302040006 CAPACITOR332/400V20%4
33 009-2240507110 CAPACITOR224 50V20%1
34 014-1050411006 CAPACITOR1UF/250V10%2
35 013-3340722502 CAPACITOR0.33uF275V10%1
36 017-0190000000 ICNJM7815FA1
37 017-0200000000 ICNJM7915FA1
38 017-4660000000 ICDT5268SDip 8P1
39 018-3408550115 AUDION SS8550CTO-92 1
40 018-3408050115 AUDION SS8050 TO-92 3
41 018-0502698121 FIELDEFFECT TRANSISTOR2SK2698 TO-247 2
42 034-1119992508 BRIDGERECTIFIERSRBV2510 1
43 056-0106003300 JACK6PIN3.96PH1
44 056-4103221100 JACK DJ2802-3P1
45 056-4105221100 JACK DJ2802-05 1

8.ELECTRONICPARTSLIST(AMP)
12
46 067-1104148000 DIODEIN4148 6
47 067-2200107000 DIODEHER107 3
48 067-2200207000 DIODEHER204 4
49 067-2201620000 DIODEH16C20C1
50 067-2201620001 DIODEH16C20A1
52 067-3305246000 ZENER16V1/2WIN5246 2
53 067-3305235000 ZENER6.8V1/2WIN5235 1
54 080-0210012016 INDUCTANCE13.6MH0.8MM 230V AC2
55 022-1014101245 TRANSFORMER1
56 085-0052800200 PLASTIC CAP2
58 520-3006400000 PLASTICWASHERTW-4 4
61 537-3001120801ASCREWSMP(+)3*12 BZnD6
62 537-3001080801ASCREWSMP(+)3*8 BZnD6
63 307-2300500081 COPPERPOSTM3 5
64 517-3000000300AWASHERM3Zn 10
65 513-3006080300AWASHER8
66 500-3050240800A NUTM3BZn 6
67 306-1385080000 RADIATOR1
68 306-1386200000 RADIATOR1
72 042-1003005000 POWERSWITCH1
73 019-0311122001 LED1
