Wheego 2010 Whip User manual

Owner’s Manual
NOTICE TO FIRST RESPONDERS
The Master Disconnect Button is behind the passenger seat.
Simply push the red button and all power from the battery
pack will be disconnected.

03
WHEEGO Owner’s Manual
Table of Contents
Important Information
Introduction
Vehicle Identication and Specications
Things to Know Before You Operate Your Car
Understanding the Standard Features of Your Car
Understanding the Optional Features of Your Car
Operation and Maintenance
Warranty and Customer Service
Index
Appendix
1
2
3
4
5
6
7
8
9
04
06
07
08
20
20
29
32
32
Customer Service 678-904-4795
Dealer’s Number _______________________

04
1 INTRODUCTION
CONTENTS
1. About this Owner’s Manual
2. Introduction to the Safe Ownership of a WHEEGO
3. Cautions, Warnings and Notes
NOTE: This manual is subject to change. For the latest version please visit wheego.net
and click on Vehicles/Owner’s Manual.
You can be badly injured while working on an electric vehicle. Take your vehicle to your
dealer or call WHEEGO Customer Service at 678-904-4795 Ext. 3 for help.
WARNING
Any modications or alterations to this vehicle could seriously affect its road worthiness
and safety and may lead to an accident resulting in serious injury or death.
ABOUT THIS MANUAL
Thank you for purchasing your Electric Vehicle from WHEEGO. Your vehicle is designed to
operate exclusively on battery power. It is an emission-free vehicle. The ideal application
for a low speed battery-powered electric vehicle occurs when the daily driving pattern is
predictable and the distance is relatively short. WHEEGO’s objectives include customer
safety, product satisfaction and pride of ownership. This Owner’s Manual is designed to
acquaint you with the proper and safe operation of your WHEEGO. Please take the time
to read and understand the manual before operating your vehicle.
Maintenance schedules and general care instructions are included in the Operation and
Maintenance section. This manual is applicable to the following WHEEGO line of vehicles:
Whip 2010 model year.
If questions arise after reading the manual, contact WHEEGO Customer Service at 678-
904-4795 Ext. 3. Please have your Vehicle Identication Number (VIN) and date of
purchase information available.
NOTE: All information and specications in this Owner’s Manual are current at the time of
printing. However, due to WHEEGO’s policy of continuous improvement, we reserve the
right to make changes to the manual, at any time, without written notice or obligation.
INTRODUCTION TO SAFE OWNERSHIP OF WHEEGO LOW SPEED VEHICLES
WHEEGO battery-electric vehicles are different from vehicles you might be accustomed to
owning. Special precautions should be followed when owning and operating a WHEEGO.
Please pay particular attention to the cautions and warnings in this manual, as well as those
placed on the vehicle in various locations.
Electric cars provide a great amount of torque when the accelerator is pressed. This may
cause the car to spin its tires, particularly on wet or slippery pavement. WHEEGO battery-
electric vehicles are designed to meet US Federal Government safety requirements for a
special class of vehicle known as “Low Speed Vehicles.” By this very name, and implicit in
these safety requirements, these vehicles are intended only for use at low speed, up to 25
mph, and on public roads (as governed by individual state laws) where the speed limits are
correspondingly low and do not exceed 35 mph.

05
Specic to WHEEGO models, the following safe habits should always be followed:
• WHEEGO battery-electric vehicles are motor vehicles. For this reason, safety belts
should always be worn by all occupants while the vehicle is in operation.
• The WHEEGO Whip LSV is NOT designed to meet any collision or roll-over
requirements. Therefore, you should always drive your WHEEGO in a safe manner
while being alert to potentially dangerous situations around you. As with all motor
vehicles, never drink alcohol and attempt to drive a WHEEGO. Operate a WHEEGO
only on public or private roads where the speed limits are appropriate for low speed
vehicles (individual state laws vary, so please check with your DMV) and the trafc is
light. You should never operate a WHEEGO in such a way that you obstruct faster
moving trafc. You should be carefuul when crossing a road with a higher speed unit.
State laws vary on road speeds that LSV’s may cross.
• WHEEGO battery-electric vehicles should be recharged from a standard 120VAC 15
amp electrical outlet. Charging from a circuit of lesser capacity and/or using a cord
from an outlet to the WHEEGO that is not sufcient in wire gauge could create a re
hazard. Please consult this manual for the proper extension cord gauge and length.
• The battery pack is what you charge and provides the “energy” to the WHEEGO
electric drive system. The voltage in a WHEEGO battery pack is sufcient to cause
death by electrocution. For this reason, WHEEGO owners should NEVER attempt to
do any maintenance or repair work on their WHEEGO’s electric drive system,
including the battery pack, unless they have had special training.
Please read, understand and abide by the above safety precautions for years of safe
operation and enjoyment of your WHEEGO.
CAUTIONS, WARNINGS AND NOTES
Throughout this Owner’s Manual you will nd the words “WARNING” and “CAUTION.”
These serve as reminders that special attention is required. “WARNING” indicates a direct
hazard, which could result in an accident causing bodily injury. “CAUTION” identies
something that could result in damage to your vehicle. You will also nd information
preceded by the word “NOTE.” Notes are for your information and to make procedures
easier to understand.

06
2 VEHICLE IDENTIFICATION & SPECIFICATIONS
CONTENTS
1. Vehicle Information
2. General Specications
VEHICLE INFORMATION
For all model vehicles, the vehicle identication number (VIN) can be found on the VIN
plate, located on the driver’s side of the dashboard. The VIN indicates the model year,
model type and the serial number of the vehicle. It can also be found on the information
label inside the driver’s door jamb.
NOTE: Record the Vehicle Identication Number in the space provided below for easy
reference:
Vehicle Identication Number (VIN):
__|__|__|__|__|__|__|__|__|__|__|__|__|__|__|__|__|
Key # ___________ (Stamped on Key)
Date purchased: _____ /_____ /_____
GENERAL SPECIFICATIONS WHEEGO WHIP
Motor: AC41 Brushless
Drive System: Single speed front wheel drive transaxle
Tires: 195/50/R15
Battery Pack: 96V AGM Sealed Maintenance-Free Lead-Acid
Onboard Charger: 96V Output Delta-Q Fully Automatic 120v/12A input
Vehicle Width: 63.19 inches
Vehicle Length: 118.90 inches
Vehicle Height: 62.99 inches
Wheelbase: 79.74 inches
Turning Circle*: 362.2 inches
Curb Weight**: 2,475 lbs.
GVWR**: 2,999 lbs.
Payload Capacity: 524 lbs. (options + passengers + cargo)
*The turning circle is the diameter of a circle required to make a U-turn maneuver.
**These weight limits are approximate. The GVWR must not be exceeded. GVWR
is the actual weight of the vehicle including the weight of the entire payload of options,
passengers, and cargo.

07
3 THINGS TO KNOW BEFORE YOU OPERATE YOUR CAR
CONTENTS
1. Driving and Alcohol
2. Safety Information
DRIVING AND ALCOHOL
Your ability to drive your WHEEGO can be seriously impaired with blood alcohol levels
far below the level allowed by law. If you are drinking alcohol, don’t drive. Ride with a
designated non-drinking driver, call a cab, or use public transportation.
Driving after drinking alcohol can lead to an accident. Your perceptions are less sharp,
your reexes are slower, and your judgment is impaired when you have been drinking.
Never drink alcohol and drive.
WARNING
Drinking alcohol can seriously impair your ability to operate this vehicle.
SAFETY INFORMATION
• Read the Owner’s Manual before operating this vehicle.
• Charge the vehicle in a well-ventilated area only.
• Keep children away from the vehicle during charging.
• Batteries can emit explosive hydrogen gases when charging if they are overcharged.
Keep sparks and ames away from the battery area of the vehicle. Tools, wires, and
metal objects can cause sparks and a short to occur if they come into contact with
the battery connections or posts. Follow all instructions carefully when dealing with
batteries.
• The batteries in the WHEEGO are 8 Volt Lead-Acid AGM Batteries. They are
connected in a pack conguration to produce HIGH VOLTAGE DC (Direct Current)
ELECTRIC POWER (96 Volts). These batteries are sealed, maintenance-free, and
are selected specically to optimize the operation and performance of your vehicle.
Never use (or substitute for) any battery other than the original factory approved batteries
that come in your WHEEGO.
Your vehicle is battery powered. If handled improperly, batteries can be dangerous. Follow
the precautions provided in the Operation and Maintenance section of this manual during
charging operations to avoid personal injury or damage to electrical components in the
vehicle.
WARNING
• Electrolytes can leak from damaged or defective batteries. Avoid contact with skin,
eyes, or clothing.
• Batteries contain acid, which can cause severe burns. If battery uid comes in contact
with your skin, ush the affected areas with water for at least 15 minutes and then
seek medical assistance.
• If battery acid is ingested, seek immediate medical assistance.
• Contact with eyes: Flush with water and get medical assistance as soon as possible.
While you are being driven to get medical assistance, continue to rinse your eyes by
using a sponge or soft cloth saturated with water.

08
Battery posts, terminals, and related accessories contain lead and lead compounds.
If you do somehow end up handling the batteries in your vehicle, immediately wash your
hands afterward.
WARNING
Improper handling of high voltage wiring, batteries, or control systems could result in
serious or fatal injury by electric shock. Only qualied technicians should repair or access
high voltage wiring, battery packs, and associated systems.
4 UNDERSTANDING THE STANDARD FEATURES OF YOUR CAR
CONTENTS
INSTRUMENT PANEL
TURN SIGNALS & LIGHTS
The turn signal lever is multi-functional and controls the
turn signals and lights.
For a left turn move the lever down until it clicks.
For a right turn move the lever up until it clicks.
To turn on the taillights rotate the lever knob up one click.
To turn on the headlights rotate the lever knob up one more
click. You should turn off the lights before exiting the vehicle.
If you accidentally leave the lights on, a buzzer will sound to
remind you to turn them off.
HORN
Press one of the buttons on the steering wheel to activate the horn.
Turn Signals/Lights
Horn
Hazard Warning Flashers
Windshield Wipers and Washer
BDI Gauge
Speedometer
Eco-Meter
Key Switch
Fog Lights
a.
b.
c.
d.
e.
f.
g.
h.
i.
Instrument Panel
Console
Foot Pedals
Master Disconnect Button
Safety Belts and Child Restraints
Convenience Items
1.
2.
3.
4.
5.
6.

09
HAZARD WARNING FLASHERS
Your vehicle’s hazard warning asher is an emergency warning
system. When you activate it, front and rear directional signals
will ash intermittently. Use it when your vehicle is disabled on
or near the road. It warns other drivers to steer clear of you and
your vehicle. This is an emergency warning system not to be used
when the vehicle is in motion. To activate the warning ashers,
press the red button on the top of the steering wheel. To turn the
warning ashers off, press the red button again.
WINDSHIELD WIPERS AND WASHER
The wiper lever controls the windshield wipers and washer. Move
the wiper signal lever down to turn on the windshield wipers
(1-click intermittent, 2-clicks low speed, 3-clicks high speed).
Move the wiper lever back up to turn off. Pull the wiper lever
momentarily toward the driver to spray the windshield with uid
from the washer reservoir.
CAUTION
A damaged or worn wiper blade may reduce vision and impair you
from seeing well enough to drive safely. A worn wiper blade could
damage windshield glass. If your wiper blades become damaged
or worn, please replace them immediately.
BDI GAUGE
The BDI (Battery Discharge Indicator) is similar to a fuel gauge on a
liquid (gas-diesel-ethanol) fueled vehicle. It gives the current state
of charge of the battery pack while the key is in the ON position.
The 100% charged position is all the way to the right and the fully
discharged position is to the left. When the indicator reaches the
yellow zone, the battery pack has about 40% remaining charge.
When it reaches the red zone the battery pack has about 30%
remaining charge and the Power Conservation Mode feature will
begin to help economize battery usage for the remainder of the
discharge cycle.
SPEEDOMETER
The Speedometer shows the current driven speed of the vehicle
in both miles per hour and kilometers per hour. Low Speed
Vehicles leave the factory set for a maximum speed of 25 mph
(3200 RPM).
ECO-METER
The Eco-Meter read out initially shows the status of the shifter
(forward, neutral, or reverse). Press the black button to access
the Odometer, Trip Meter, and Miles on Current Charge Meter. All
readouts are in miles. The odometer indicates the total distance
the vehicle has been driven. The Trip Meter is useful for keeping
track of specic distances traveled.
While viewing the Trip Meter, press the button for 3-4 seconds
to reset the Trip Meter. The Miles on Current Charge Meter will
automatically reset each time the vehicle completes a charging
cycle. The Eco-Meter Meter also gives you feedback as to how

10
your driving habits (and the terrain) are affecting the draw on the batteries, which affects
your driving range. There are 5 lights on the meter, and they are in sequence: red, yellow,
green, green, green. When the indicator light is red, there is the most drain on the battery
pack. Alternately, 3 greens lit at the same time means that you are driving in a fashion
that is very economical on the battery pack.
CAUTION
Electrical wiring, circuit boards, and components are located under and behind the upper
and lower dash. Liquids can damage electrical components and the circuit board. Handle
liquids with care. Do not spray water directly into the dash.
KEY SWITCH
When the key is turned clockwise to the rst “ACC” position the
accessory circuits will be on (radio, lights, etc.). When the key
is turned to the second “ON” position the Battery Discharge
Indicator and Eco-Meter will activate and the car can then be
driven. There is no audible sound when the car is on. If the key is
in the “ON” position and a buzzer sounds, then one of the doors is
probably not completely closed. Close the doors and the buzzer
should stop.
CAUTION
Do not leave the key in the “ON” position when not in use. Doing so will discharge the
batteries.
CAUTION
Never turn the key to the “OFF” position while the vehicle is in motion. This could
lead to loss of speed and loss of control of the vehicle. This can cause a
serious accident.
FOG LIGHTS
Below the steering column to the left are 2 switches. The one on the right is the switch
for the Front Fog Lights. When the taillights or headlights are turned on, pressing this
switch will activate the fog lights. The left switch is non-functional.
CONSOLE
a. Ventilation Controls
b. Radio
c. Rear Defroster/Courtesy Light/12v Accessory Jack
d. Forward/Reverse Shifter
e. Parking Brake
f. Cupholders
VENTILATION CONTROLS
There are 3 knobs to control the ventilation system. The left knob controls the temperature.
Turn it counterclockwise to increase the temperature and clockwise to decrease the
temperature. The center knob controls the volume of air. Turn it clockwise to increase
airow and counterclockwise to decrease airow. If the vehicle is equipped with Air
Conditioning, after selecting the volume of air you desire by clicking the center knob,
you may press the center knob to turn on the AC compressor.

11
The temperature knob
on the left must be
turned all the way to
cold while running the
Air Conditioner. Pressing
the center knob a second
time will turn the AC off.
The right knob controls
the airow. By selecting
different positions you
can choose where to have
the air enter the passenger compartment. Below the center knob is a control that slides from left
to right. Moving it to the left position will recirculate the air in the vehicle and moving it to the
right position will allow outside air to enter the vehicle through the ventilation system.
RADIO - JVC AM/FM/CD/USB/MP3 RECEIVER
The ON-OFF button is in the upper left corner of the display. The round knob controls the volume.
Pressing the square button on its left or right sides will change the station tuner. Pressing it on
the top or bottom will scroll through the preset stations. Pressing the SRC button will change
the source (AM/FM/AUX/etc.). The USB input jack will communicate with iPhones, iPods, and
thumb drives. Please refer to the JVC Owner’s Manual for detailed instructions on the use of the
radio.
REAR DEFROSTER/
COURTESY LIGHT/12V
ACCESSORY JACK
Below the radio are
3 console- mounted
accessory buttons. From
left to right they are: rear
defroster, courtesy light,
and 12V accessory jack.
Press the rear defroster
button to turn on the rear

12
window defroster. The indicator light will come on. Press it a second time to turn it off. If the lower
half of the courtesy light button is pushed in, then a courtesy light will come on whenever one of
the front doors is open. To turn this off, push the upper half of this button. The 12 volt accessory
jack can be used to provide power for 12 volt accessories that have a cord with a “lighter plug”
style connector. The maximum power available is 15 amps of 12 volt power.
FORWARD/REVERSE SHIFTER
Forward
With the key turned ON and
the brake depressed, pull up
on the lock ring underneath
the shifter knob and move the
shifter from the neutral to the
forward position. Release the
brake and push down on the
accelerator pedal to move the
vehicle forward with a speed
range of 0-25 MPH. Drive only
on APPROVED TRAFFIC”
routes based on Low Speed
Vehicle (LSV) regulations for
your area.
Reverse
With the key turned ON and
the brake depressed, pull up
on the lock ring underneath
the shifter knob and move
the shifter from the neutral to the reverse position. Release the brake and push down on the
accelerator to move the vehicle in reverse. The top speed in the reverse direction is limited for
safety.
CAUTION
Always bring the vehicle to a complete stop before changing the position of the
forward/reverse shifter. Note that there is no Parking Gear- only Forward, Reverse, and Neutral.
PARKING BRAKE
On the oor between the seats is the hand
actuated parking brake. This brake must
be engaged when parking the vehicle
or prior to exiting the vehicle. Grasp
the brake and pull up to engage. Press
the silver button on the end and lower
the brake handle to release the parking
brake. If the key is OFF or removed
from the key switch and the brake is not
engaged a buzzer will sound.
NOTE: The parking brake is adjustable
and should be checked periodically by
a trained service technician as shown in
the vehicle maintenance schedule.

13
WARNING
• Always turn the vehicle OFF and engage the parking brake prior to exiting the vehicle
or it will roll and may cause damage or injury.
• Leaving children unattended in a vehicle is dangerous. Children should be warned not
to touch the parking brake or the shifter lever. Don’t leave the keys in the ignition. A
child could operate controls or move the vehicle.
• Be sure the parking brake is fully disengaged before driving. Failure to do so can lead
to brake problems due to excessive heating of the rear brakes.
CUPHOLDERS
The oor mounted console has several storage compartments and cupholders.
FOOT PEDALS
a. Brake pedal
b. Accelerator pedal
c. Hood release
BRAKE PEDAL
The brake pedal is located on the driver’s oor to the left of the accelerator pedal. To
slow or stop the vehicle, rmly press the foot brake pedal.
WARNING
Riding the brakes can lead to brake failure and possibly an accident. Driving with your
foot resting or riding on the brake pedal can result in abnormally high brake temperatures,
excessive lining wear, possible brake damage, and reduced driving range. Excessive brake
wear could lead to not having full braking capacity in an emergency.
ACCELERATOR PEDAL
The accelerator pedal is located on the driver’s oor next to the center console and is
used to control your speed. Pressing down on the pedal will increase vehicle speed.
WARNING
Always accelerate slowly to prevent possible injury to yourself or others.
HOOD RELEASE
The hood release is located to the left of the brake
pedal in front of the driver’s door. Pull it toward
you to open the hood.

14
MASTER DISCONNECT BUTTON
The battery pack master disconnect button is located
behind the back of the passenger seat on the front of
the battery pack. Pressing the button will disconnect
the traction battery pack from the vehicle. It should be
used when placing the vehicle in long-term storage, when
transporting the car on a truck or trailer, in case of an
accident, or at any time when you need to isolate the
battery pack from the vehicle for safety or maintenance
purposes. To reconnect the battery pack, pull the button
back out.
SAFETY BELTS AND CHILD RESTRAINTS
a.
b.
c.
d.
e.
f .
g.
h.
i .
The WHEEGO is equipped with safety belts for
driver and passenger.
Research has shown that safety belts save lives.
Safety belts can reduce the seriousness of injuries
in a single vehicle accident. Some of the worst
injuries happen when people are thrown from the vehicle. Safety belts provide protection
and they reduce the risk of injury caused by striking the inside of the vehicle. Everyone
needs to buckle up all the time, even for short trips.
WARNING
• Wearing a safety belt incorrectly is dangerous. Wearing your safety belt incorrectly
could increase your risk for injury in a collision. You could suffer internal injuries or
even slide out of part of the belt. Use the instructions in this manual to insure you and
your passengers are wearing the safety belts properly.
• Two people should never be belted into a single safety belt. People belted together
can crash into one another in an accident, causing injury. Never use a lap/shoulder
belt for more than one person, regardless of the size of the person.
PROPER USE OF YOUR LAP AND SHOULDER BELT
1. Enter the vehicle and sit back.
2. The safety belt buckle is located just behind the outer side edge of the seat. Grasp the
buckle and pull out the belt. Slide the buckle up the webbing as far as necessary to make
the belt go across your lap.
3. When the safety belt is long enough, insert the buckle into the latch until you hear a click.
Proper use of your lap and shoulder belt
Seat belts and pregnant women
Seat belt extender
Child restraint
Infants and child restraints
Tips for getting the most out of your child restraint
Other children and child restraints
Children too large for booster seats
Transporting pets

15
4. Position the lap belt across your thighs and below your abdomen. To remove slack in
the lap belt portion of the belt, pull up on the shoulder belt. A snug belt reduces the risk
of sliding under the belt in a collision. Make sure the button on the latch faces upward or
outward so that you are able to unbuckle your safety belt quickly.
5. Position the shoulder belt on your chest so that it is comfortable and not resting on your
neck. The retractor will withdraw any slack in the belt.
6. To release the belt, push the red button on the latch. If necessary, slide the buckle down
the webbing to allow it to retract fully. A frayed or torn belt could rip apart in a collision
and leave you with no protection. Inspect the belt system periodically, checking for cuts,
frays or loose parts. Damaged parts must be replaced immediately. Do not modify or
disassemble the system. Seat belt assemblies must be replaced after a collision if they
have been damaged (bent retractor, torn webbing, etc.).
WARNING
In a collision, you and your passengers can suffer injuries, including fatalities, if you are
not properly buckled up. You can strike the interior of your vehicle or other passengers,
or you can be thrown out of the vehicle. Always be sure you and others in your vehicle
are buckled up properly.
WARNING
Maximum occupancy is limited to 2 people (including the driver) in the WHEEGO.
WARNING
• A belt that is buckled into the wrong latch will not function or protect you properly.
The lap portion of the safety belt could ride too high on your body, possibly causing
internal injuries. Always buckle your safety belt into the latch nearest you.
• A safety belt that is too loose will not function properly. In a sudden stop you could jerk
too far forward, increasing the possibility of injury. Wear your safety belt snugly.
• A belt that is positioned under your arm is very dangerous. Your body could strike the
inside surfaces of the vehicle in a collision, increasing the possibility of injury. A belt worn
under the arm can cause internal injuries. Wear the belt over your shoulder.
• A shoulder belt placed behind you will not protect you from injury during a collision.
The lap and shoulder belts are to be used together.
WARNING
• It is extremely dangerous to ride in a cargo area of a vehicle. In a collision, people riding in
these areas are more likely to be seriously injured or killed.
• Do not allow people to ride in any area of your vehicle that is not equipped with seats and
seat belts.
• Be sure everyone in your vehicle is in a seat and using a seat belt properly.
SEAT BELTS AND PREGNANT WOMEN
We recommend that pregnant women use seat belts throughout their pregnancy. Keeping
the mother safe is the best way to keep the baby safe. Pregnant women should wear the
lap part of the belt across the thighs and as snug across the hips as possible. Keep the
belt low so that it does not come across the abdomen. That way the strong bones of the
hips will take the force if there is a collision.

16
SEAT BELT EXTENDER
If a seat belt is too short, and even when fully extended is in its lowest position, your dealer
can provide you with a seat belt extender. This extender should be used only if the existing
belt is not long enough. When it is not required, remove the extender and store it.
WARNING
Using a seat belt extender when not needed can increase the risk of injury in a collision. Only use
when the seat belt is not long enough when it is worn low and snug and in the recommended
seating positions. Remove and stow the seat belt extender when not needed.
CHILD RESTRAINT
WARNING
Everyone in your vehicle needs to be buckled up at all times–babies and children, too. Every
state in the United States and all Canadian provinces require that small children ride in proper
restraint systems. This is the law, and you can be prosecuted for ignoring it. There are different
sizes and types of restraints for children from newborn size to the child almost large enough
for an adult safety belt. Always check the child seat owner’s manual to ensure you have the
correct seat for your child. Use the restraint that is correct for your child.
In a collision, an unrestrained child, even a tiny baby, can become a missile inside the vehicle.
The force required to hold an infant could become so great during an accident that you
could not hold the child no matter how strong you are. The child and others could be badly
injured. Any child riding in your vehicle should be in a proper restraint for the child’s size.
INFANTS AND CHILD RESTRAINTS
Safety experts recommend that children ride rearward-facing in the vehicle until
they are at least one year old and weigh at least 20 lbs (9 kg). Two types of child
restraints can be used rearward-facing: infant carriers and “convertible” child seats.
The infant carrier is only used rearward-facing in the vehicle. It is recommended for children
who weigh up to about 20 lbs (9 kg). “Convertible” child seats often have a higher weight
limit in the rearward-facing direction than infant carriers do so they can be used rearward-
facing by children who weigh more than 20 lbs (9 kg) but are less than one year old. Both
types of child restraints are held in the vehicle by the lap/shoulder belt.
This vehicle is not equipped with a “latch” child restraint anchorage system. The lap/shoulder
belt must be used to secure both types of child restraints into the vehicle. Improper installation
can lead to failure of an infant or child restraint. It could become loose in a collision. The child
could be badly injured or killed. Follow the manufacturer’s directions exactly when installing
an infant or child restraint.

17
TIPS FOR GETTING THE MOST OUT OF YOUR CHILD RESTRAINT
• Before buying any restraint system, make sure that it has a label certifying that it meets all
applicable Safety Standards. The manufacturer also recommends that you try a child restraint
in the vehicle seats where you will use it before you buy it.
• The restraint must be appropriate for your child’s weight and height. Check the label on the
restraint for weight and height limits.
• Carefully follow the instructions that come with the restraint. If you install the restraint
improperly, it may not work when you need it.
• All passenger seat belts are equipped with cinching latch plates.
• Seat belts are designed to keep the lap portion tight around the child restraint so that it is
not necessary to use a locking clip. If the seat belt has a cinching latch plate, pulling up on the
shoulder portion of the lap/shoulder belt will tighten the belt (the cinching latch plate will keep
the belt tight; however, any seat belt system will loosen with time so check the belt occasionally
and pull it tight if necessary).
• If the belt still cannot be tightened, or if pulling and pushing on the restraint loosens the belt,
disconnect the latch plate from the buckle, turn the buckle around and insert the latch plate
into the buckle again. If you still cannot make the child restraint secure try a different seating
position.
• Buckle the child into the restraint exactly as the manufacturer’s instructions tell you.
• When your child restraint is not in use, secure it in the vehicle with the seat belt or remove it
from the vehicle. Do not leave it loose in the vehicle. In a sudden stop or collision it could strike
the occupants or seat backs and cause serious personal injury.
NOTE: For additional information refer to seatcheck.org or call 1-866-SEATCHECK.
OTHER CHILDREN AND CHILD RESTRAINTS
Children who weigh more than 20 lbs (9 kg) and who are older than one year can ride
forward-facing in the vehicle. Forward-facing child seats and convertible child seats used in
the forward-facing direction are for children who weigh 20 to 40 lbs (9 to 18 kg), and who
are older than one year. These child seats are also held in the vehicle by the lap/shoulder belt.
The belt-positioning booster seat is for children weighing more than 40 lbs (18 kg), but who
are still too small to t the vehicle’s seat belts properly. If the child cannot sit with knees bent
over the vehicle’s seat cushion while the child’s back is against the seat back, they should use
a belt-positioning booster seat. The child and belt-positioning booster seat are held in the
vehicle by the lap/shoulder belt.
CHILDREN TOO LARGE FOR BOOSTER SEATS
Children who are large enough to wear the shoulder belt comfortably, and whose legs are
long enough to bend over the front of the seat when their back is against the seat back,
should use the lap/shoulder belt.
• Make sure that the child is upright in the seat.
• The lap portion should be low on the hips and as snug as possible.
• Check belt t periodically. A child’s squirming or slouching can move the belt out of
position.
• If the shoulder belt contacts the face or neck, move the child closer to the center of the
vehicle. Never allow a child to put the shoulder belt under an arm or behind their back. Not
all child restraint systems will be installed as we have described here. Again, carefully follow
the instructions that come with the child restraint system.
TRANSPORTING PETS
Pets should be restrained in a pet harness or in a pet carrier that is secured by seat belts.

18
CONVENIENCE ITEMS
a. Power assisted windows
b. Power assisted outside mirrors
c. Remote controlled door locks
d. Remote charging port door release
e. Interior dome light
f. Glove box
g. Adjustable bucket seats
h. Rear window and tailgate
POWER ASSISTED WINDOWS
The windows in your WHEEGO vehicle are
motor operated. Push on the button located on
the inner door handle to roll the window down
and pull it gently to roll the window up.
POWER ASSISTED OUTSIDE MIRRORS
The power controls for the outside mirrors are
located on the driver’s side inner door handle
at the top. Move the selector to choose the left
or right hand mirror and then press one of the
4 directional buttons to change the position of
the mirror.
REMOTE CONTROLLED DOOR LOCKS
There are lock and unlock buttons on the vehicle key that will
electronically lock and unlock the doors. The doors can also be
locked and unlocked manually with the key. If the doors are locked
using the remote control, they should also be unlocked using the
remote control. Otherwise, the hazard warning lights will begin to
ash. The key uses two replaceable CR2016 3v batteries.
NOTE: Should the hazard ashers start to automatically ash after
turning the vehicle ON, remove the key from the switch, press
the lock button on the key, then press the unlock button, put the
key back into the switch and turn the vehicle back ON to restore
normal operation of the vehicle.
REMOTE CHARGING PORT DOOR RELEASE
The charging port door is released when you pull up on the remote
lever located on the oor next to the driver’s door.
INTERIOR DOME LIGHT
The interior dome light will illuminate the passenger compartment of the vehicle when
one of the doors has been opened. To turn it on while the doors are closed, press the
button at the base of the light and to turn it off press the button again. The light should
be turned OFF when exiting the vehicle.

19
GLOVE BOX
The glove box is located to the right of the center console in the dash.
ADJUSTABLE BUCKET SEATS
The driver and passenger seats have a metal bar
located under the front edge of the seat to allow
the seats to be moved toward the front or rear
of the vehicle as needed by the passengers. They
have a lever on the outside rear of the seat base
to adjust the angle of the seat back. The 2 knobs
on the front outside edge of the seat base adjust
the angle of the seat base. The front knob controls
the angle of the front of the seat base and the rear
knob controls the same adjustment on the rear of
the seat base.
REAR WINDOW AND TAILGATE
To unlatch and open the rear window, insert the
key into the tailgate and turn clockwise. Raise
the window using the nger lift. Pull the left and
right red tabs at the top corners of the tailgate
simultaneously to release and open the gate. Close
the tailgate before lowering and latching the rear
window. If the vehicle is equipped with a rear-
mounted spare tire carrier, it must be opened before
attempting to unlatch the rear window.

20
5 UNDERSTANDING THE OPTIONAL FEATURES OF YOUR CAR
CONTENTS
a. Air Conditioning
b. Dual Battery Chargers
c. Exterior Mounted Rear Spare Tire Carrier
AIR CONDITIONING
If your WHEEGO vehicle has the AC option installed,
engaging the AC system while the ventilation system
is running will allow the temperature of the passenger
compartment to be cooled. While the ventilation blower
is running, press on the air volume selector knob to turn
on the Air Conditioner. Press it a second time to turn it
off.
DUAL BATTERY CHARGERS
If your vehicle is equipped with a dual charger
system, you can charge using either a 120 Volt 15A
power source OR a 240 Volt 20A AC power source.
Separate power cords are provided for each voltage
level. Using the 240 Volt cord will usually result in a
decrease of 40% of the time needed to complete a
full recharge.
EXTERIOR MOUNTED REAR SPARE TIRE CARRIER
If your vehicle is equipped with a rear spare tire
carrier, the spare tire can be mounted on the rear
of the vehicle. To open the tire carrier, press the
silver release button located on the left side of the
carrier.
6 VEHICLE OPERATION & MAINTENANCE
VEHICLE OPERATION
a. Operating sequence
b. Range information
c. Charging the vehicle
d. Long term storage
e. Battery pack break-in period
f. Power Conserve modes
g. Maximum operating speed
h. Transporting your vehicle
OPERATING SEQUENCE
The basic sequence of operation is:
Disconnect the power cord from the source and the vehicle, and store it in a safe place.
Enter the vehicle and close both doors.
Have all passengers buckle their seat belts.
