Wheelock MIZ-24S-R User manual

Description:
Wheelock Series MIZ piezoelectric Mini Horns are
compact electronic alarm appliances that are listed
under CAN/ULC-525-99 forAudible SignalAppliances.
The Series MIZ offer field selectable settings for
Temporal (Code 3) or Continuous Horn along with an
attractiveappearanceanddependableperformance.The
Series MIZ offers high sound output along with low
current draw and is ideal for alarm signaling in individual
rooms, apartments, hotels, motels and offices. Color
choices of red or off-white will blend with any décor.
Applications:
• IndividualRooms
• Apartments
• Hotels
• Motels
• Offices
SERIES MIZ
Copyright 2005 Wheelock Inc. All rights reserved.
Features:
• Approvalsinclude: CAN/ULC-S525-99forAudible
SignalAppliances
•Field selectable settings forTemporal (Code3) or
ContinuousHorn.
• Designedto meet orexceed NFPA/ANSI standards.
• Convenientmountingtoanystandardsingle-gangbox.
• Noadditionaltrimplaterequiredforflushmounting
• FastinstallationwithIn/Out screw terminals using
#12 to #18 AWG.
• Highsoundoutput/lowcurrentdraw/low temperature
compensation.
•Availableinred or off-whitecolor.
General Notes:
• MiniHornmodelsareListedforindoorusewithatemperature range of 0º C to49ºC(32ºF to 120º F) and maximum
humidityof 93%RH±2%.
• Rated Input voltage (either filtered DC or unfiltered full-wave-rectified FWR): 16-33 VDC (for 24 VDC MIZ-TC)
• MIZ-TC audible appliances are not designed to be used on coded systems in which the applied voltage is
cycled on and off. Not designed to be used with Sync Modules (SM or DSM).
Specifications and Ordering Information
*Refer to Data Sheet S7000 for Mounting Options.
+-
+
-TO NEXT
APPLIANCE
OR EOLR
+
-
FROM
PRECEDING
APPLIANCE
OR FACP
SERIES MIZ MINI HORN
TEMPORAL (CODE 3) OR
CONTINUOUS TONE
ledoM redrO edoC noitpircseD gnitnuoM *snoitpO
R-S42-ZIM5848deR-snoitpOnroHsuounitnoCrolaropmeT,nroH-iniMtloV
42B
W-S42-ZIM4848etihW-snoitpOnroHsuounitnoCrolaropmeT,nroH-iniMtloV42B
FIRE ALARM SYSTEMS
Wiring Diagrams (for all models)
22
INC.
Helping People Take Action
SM

WE SUPPORT AND ENCOURAGE NICET CERTIFICATION
MADE IN THE USA
3 YEAR WARRANTY
NOTE: All CAUTIONS and WARNINGS are identified by the symbol . All warnings are printed in bold capital letters.
WARNING: PLEASE READ THESE SPECIFICATIONSAND ASSOCIATED INSTALLATION INSTRUCTIONS CAREFULLY
BEFORE USING, SPECIFYING OR APPLYING THIS PRODUCT. FAILURE TO COMPLY WITH ANY OF THESE INSTRUCTIONS,
CAUTIONS OR WARNINGS COULD RESULT IN IMPROPER APPLICATION,INSTALLATION AND/OR OPERATION OF THESE
PRODUCTS IN AN EMERGENCY SITUATION, WHICH COULD RESULT IN PROPERTY DAMAGE, AND SERIOUS INJURY OR
DEATH TO YOU AND/OR OTHERS.
WARNING:CONTACTWHEELOCKFORTHECURRENT“INSTALLATION INSTRUCTIONS” (P83963)AND “GENERAL
INFORMATION” SHEET (P82380) ON THESE PRODUCTS. THESE DOCUMENTS UNDERGO PERIODIC CHANGES. IT IS
IMPORTANT THAT YOU HAVE CURRENT INFORMATION ON THESE PRODUCTS. THESE MATERIALS CONTAIN IMPORTANT
INFORMATION THAT SHOULD BE READ PRIOR TO SPECIFYING OR INSTALLING THESE PRODUCTS, INCLUDING:
• TOTAL CURRENT REQUIRED BY ALL APPLIANCES CONNECTED TO SYSTEM SECONDARY POWER SOURCES.
• FUSE RATINGS ON NOTIFICATION APPLIANCE CIRCUITS TO HANDLE PEAK CURRENTS FROM ALLAPPLIANCES ON THOSE
CIRCUITS.
• THE VOLTAGE APPLIED TO THESE PRODUCTS MUST BE WITHIN THEIR RATED VOLTAGE RANGE.
• FAILURE TO COMPLY WITH THE INSTALLATION INSTRUCTIONS OR GENERAL INFORMATION SHEETS COULD RESULT IN
IMPROPER INSTALLATION,APPLICATION, AND/OR OPERATION OF THESE PRODUCTS INAN EMERGENCY SITUATION, WHICH
COULD RESULT IN PROPERTY DAMAGE AND SERIOUS INJURY OR DEATH TO YOU AND/OR OTHERS.
• CONDUCTOR SIZE (AWG), LENGTH AND AMPACITY SHOULD BE TAKEN INTO CONSIDERATION PRIOR TO DESIGNAND
INSTALLATION OF THESE PRODUCTS, PARTICULARLY IN RETROFIT INSTALLATIONS.
Wheelock products must be used within their published specifications and must be PROPERLY specified, applied, installed, operated,
maintained and operationally tested in accordance with their installation instructions at the time of installation and at least twice a year or
more often and in accordance with local, state and federal codes, regulations and laws. Specification, application, installation, operation,
maintenance and testing must be performed by qualified personnel for proper operation in accordance with all of the latest National Fire
ProtectionAssociation(NFPA), Underwriters’Laboratories (UL), National ElectricalCode (NEC), Occupational Safetyand Health
Administration(OSHA), local, state,county, province,district, federal and other applicable building and firestandards,guidelines,
regulations,laws and codes including, butnot limitedto, all appendicesand amendmentsand the requirements of thelocal authorityhaving
jurisdiction(AHJ).
Architects and Engineers Specifications
273 BRANCHPORT AVENUE • LONG BRANCH, NJ 07740 • TEL: [phone] • FAX: [phone]
Distributed By:
NOTE: Due to continuous development of our products, specifications and offerings are subject to change without notice in
accordance with Wheelock Inc. standard terms and conditions.
The notification appliance shall be a Wheelock Series MIZ audible appliance or approved equal. The MIZ Notification Appliance shall
be electronic and shall have field selectable settings for Temporal (Code 3) or Continuous horn. The sound pressure measurement
on Temporal (Code 3) setting shall be 87 dBA minimum at 24VDC. The sound pressure measurement on Continuous Horn setting
shall be 87 dBA minimum at 24 VDC. Operating voltage shall be 24 VDC using filtered power or unfiltered power supply (full-wave-
rectified). All models shall have provision for standard reverse polarity type supervision and IN/OUT wiring using terminals that
accept #12 to #18 AWG wiring. The appliances shall be mounted indoors and mount on standard electrical backboxes requiring no
additional trimplates or adapters.
S1700C 05/05
NATIONAL SALES OFFICE
800-631-2148
Canada 800-397-5777
E-Mail: [email protected]
http://www.wheelockinc.com
segnaRdnasledoMdetsiLCLU:1elbaT
ledoM detalugeR CLU egatloV
detaR egarevA tnerruC
rePABdciohcenA tf01@99-525S-
CLU/NAC
suounitnoC3edoC
CDSMRABdABd
S42-ZIM
0.02420.720.4848
0.42520.830.7878
0.13620.340.0998
