Whirlpool UMH50008 User manual

Model/Modèle
W11174206B
MICROWAVEHOOD COMBINATION
Use&CareGuide
For assistance or service, call: In the U.S.A., call 1-800-253-1301 n Canad, all 1-800-807-6777.
or visit our brand website at
In the U.S.A, www.whirlpool.com
In the Canada, www.whirlpool.ca
ENSEMBLE FOUR À MICRO-ONDES/HOTTE
Guided’utilisationetd’entretien
Pour assistance ou service composez le
ou visitez notre site web à
ww.whirlpool.com
www.whirlpool.ca
Table of Contents/Table des matières .........................................2

2
TABLE OF CONTENTS
MICROWAVE HOOD COMBINATION SAFETY ...........................3
Electrical Requirements ...............................................................5
PARTS AND FEATURES................................................................5
Turntable ......................................................................................5
MICROWAVE OVEN CONTROL ...................................................6
Display..........................................................................................6
Start..............................................................................................6
Cancel...........................................................................................6
Time Entry ....................................................................................6
Timer.............................................................................................6
Clock ............................................................................................6
Language/Weight Entry................................................................6
Vent Fan .......................................................................................7
Cooktop Light...............................................................................7
Tones............................................................................................7
MICROWAVE OVEN USE ..............................................................7
Food Characteristics....................................................................7
Cooking Guidelines......................................................................7
Cookware and Dinnerware ..........................................................8
AluminumFoil and Metal .............................................................8
Microwave Cooking Power..........................................................8
Defrost..........................................................................................9
Manual Cooking ...........................................................................9
MICROWAVE OVEN CARE..........................................................10
General Cleaning........................................................................10
Replacing Grease Filter..............................................................11
Replacing Charcoal Filter (for recirculation installation only).....11
Replacing Cooktop Light ...........................................................11
TROUBLESHOOTING ..................................................................12
ASSISTANCE OR SERVICE.........................................................13
Replacement Parts.....................................................................13
WARRANTY ..................................................................................14
TABLE DES MATIÈRES
SÉCURITÉ DE L’ENSEMBLE FOUR À MICRO-ONDES/HOTTE....15
Spécifications électriques .........................................................
PIÈCES ET CARACTÉRISTIQUES ..............................................17
Plateau rotatif .............................................................................
COMMANDE DU FOUR À MICRO-ONDES ..............................18
Affichage.....................................................................................
Mise en marche..........................................................................
Annuler .......................................................................................
Programmation de la durée .......................................................
Minuterie.....................................................................................
Horloge.......................................................................................
Programmation de la langue/des unités de poids.....................
Ventilateur...................................................................................
Éclairage de la table de cuisson ................................................
Signaux sonores.........................................................................
UTILISATION DU FOUR À MICRO-ONDES...............................19
Caractéristiques des aliments....................................................
Guide de cuisson........................................................................
Ustensiles de cuisson et vaisselle..............................................
Papierd’aluminium et métal.......................................................
Puissance de cuisson des micro-ondes....................................
Décongélation ............................................................................
Cuisson manuelle.......................................................................
ENTRETIEN DU FOUR À MICRO-ONDES .................................22
Nettoyage général ......................................................................
Remplacement du filtre à graisse ..............................................
Remplacement du filtre à charbon (pour une installation avec
recyclage uniquement)...............................................................
Remplacement de la lampe de la table de cuisson...................
DÉPANNAGE.................................................................................24
ASSISTANCE OU SERVICE.........................................................25
Pièces de rechange....................................................................
GARANTIE.....................................................................................26

3
MICROWAVE HOOD COMBINATION SAFETY
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
When using electrical appliances basic safety precautions should be followed, including the following:
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
WARNING: To reduce the risk of burns, electric shock,
fire, injury to persons, or exposure to excessive microwave
energy:
■Read all instructions before using the microwave oven.
■Read and follow the specific “PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE
ENERGY” found in this section.
■The microwave oven must be grounded. Connect only to
properly grounded outlet. See “GROUNDING
INSTRUCTIONS” found in this section and in the provided
Installation Instructions.
■Install or locate the microwave oven only in accordance
with the provided Installation Instructions.
■Some products such as whole eggs in the shell and sealed
containers - for example, closed glass jars - are able to
explode and should not be heated in the microwave oven.
■Use the microwave oven only for its intended use as
described in the manual. Do not use corrosive chemicals or
vapors in the microwave oven. This type of oven is
specifically designed to heat, cook, or dry food. It is not
designed for industrial or laboratory use.
■As with any appliance, close supervision is necessary
when used by children.
■Do not operate the microwave oven if it has a damaged
cord or plug, if it is not working properly, or if it has been
damaged or dropped.
■The microwave oven should be serviced only by qualified
service personnel. Call an authorized service company for
examination, repair, or adjustment.
■Do not cover or block any openings on the microwave oven.
■Do not store this microwave oven outdoors. Do not use the
microwave oven near water - for example, near a kitchen
sink, in a wet basement, near a swimming pool, or similar
locations.
■Do not immerse cord or plug in water.
■Keep cord away from heated surfaces.
■Do not let cord hang over edge of table or counter.
■See door surface cleaning instructions in the “Microwave
Oven Care” section.
■To reduce the risk of fire in the oven cavity:
– Do not overcook food. Carefully attend the microwave
oven when paper, plastic, or other combustible materials
are placed inside the oven to facilitate cooking.
– Remove wire twist-ties from paper or plastic bags before
placing bags in oven.
– If materials inside the oven ignite, keep oven door closed,
turn oven off, and disconnect the power cord, or shut off
power at the fuse or circuit breaker panel.
– Do not use the cavity for storage purposes. Do not leave
paper products, cooking utensils, or food in the cavity when
not in use.

4
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
Liquids, such as water, coffee, or tea are able to be
overheated beyond the boiling point without appearing to
be boiling. Visible bubbling or boiling when the container is
removed from the microwave oven is not always present.
THIS COULD RESULT IN VERY HOT LIQUIDS
SUDDENLY BOILING OVER WHEN THE CONTAINER IS
DISTURBED OR A SPOON OR OTHER UTENSIL IS
INSERTED INTO THE LIQUID.
To reduce the risk of injury to persons:
– Do not overheat the liquid.
–Stir the liquid both before and halfway through heating it.
– Do not use straight-sided containers with narrow necks.
– After heating, allow the container to stand in the
microwave oven for a short time before removing the
container.
– Use extreme care when inserting a spoon or other
utensil into the container.
Do not mount over a sink.
Do not store anything directly on top of the microwave oven
when the microwave oven is in operation.
Clean Ventilating Hoods Frequently - Grease should not be
allowed to accumulate on hood or filter.
When flaming foods under the hood, turn the fan on.
Suitable for use above both gas and electric cooking
equipment.
Intended to be used above ranges with maximum width of
24" (61.0 cm).
Use care when cleaning the vent-hood filter. Corrosive
cleaning agents, such as lye-based oven cleaners, may
damage the filter.
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door open
since open-door operation can result in harmful exposure
to microwave energy. It is important not to defeat or
tamper with the safety interlocks.
(b) Do not place any object between the oven front face and
the door or allow soil or cleaner residue to accumulate on
sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly
important that the oven door close properly and that there
is no damage to the:
(1) Door (bent),
(2) Hinges and latches (broken or loosened),
(3) Door seals and sealing surfaces.
(d) The oven should not be adjusted or repaired by anyone
except properly qualified service personnel.
State of California Proposition 65 Warnings:
WARNING: This product contains one or more chemicals known to the State of California to cause cancer.
WARNING: This product contains one or more chemicals known to the State of California to cause birth defects or other
reproductive harm.

5
Electrical Requirements
Observe all governing codes and ordinances.
Required:
A 120 V, 60 Hz, AC only, 15 or 20 A electrical supply with a
fuse or circuit breaker.
Recommended:
A time-delay fuse or time-delay circuit breaker.
A separate circuit serving only this microwave oven.
PARTS AND FEATURES
This manual may cover several different models. The model you
have purchased may have some or all of the features shown here.
The appearance of your particular model may differ slightly from
the illustrations in this manual.
Turntable
The turntable can rotate in either direction to help cook food
more evenly. For best cooking results, do not operate the
microwave oven without having the turntable in place. See
“Assistance or Service” to reorder any of the parts.
To Install:
1. Place the support on the microwave oven cavity bottom.
2. Place the turntable on the support.
Fit the raised, curved lines in the center of the turntable
bottom between the three spokes of the hub. The rollers on
the support should fit inside the turntable bottom ridge.
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
WARNING GROUNDING INSTRUCTIONS
SAVETHESE INSTRUCTIONS
For all cord connected appliances:
The microwave oven must be grounded. In the event of
an electrical short circuit, grounding reduces the risk of
electric shock by providing an escape wire for the electric
current. The microwave oven is equipped with a cord
having a grounding wire with a grounding plug. The plug
must be plugged into an outlet that is properly installed
and grounded.
WARNING: Improper use of the grounding plug can
result in a risk of electric shock. Consult a qualified
electrician or serviceman if the grounding instructions are
not completely understood, or if doubt exists as to whether
the microwave oven is properly grounded.
Do not use an extension cord. If the power supply cord is
too short, have a qualified electrician or serviceman install
an outlet near the microwave oven.
A. Model and serial number plate
B. Control panel
C. Upper component housing
D. Microwave inlet cover
E. Microwave oven light
F. Door lock system
G. Window
H. Visor
I. Cooktop light
J. Grease lter
Parts and Features not shown
Turntable
ABC D E
FGH I J
A. Turntable
B. Support
C. Hub
A
B
C
This device complies with Part 18 of FCC Rules. This device
complies with Industry Canada ICES-001.
