Whirlpool Light programmable oven User manual

Service & Installation manual
Light programmable oven with
boiler

- 2 -
Table of Contents
Page
Preface and terms of warranty 3
Rating plate 4
Installation and connection 5
-Installation 6
-Water connection 7
-Drain connection 8
-Electrical connection/survey of supply lines 9
Exhaust 10
Checking before use 11
Annual service check 12-13
Start menu 14
Oven set-up 15-17
-Set-up mode U1 to U9 16
-Set-up mode U10 to U15 17
Test functions 18-23
-Test mode D0 to D6 19
-Test mode D7 to D15 20
-Test mode D16 to D20 22
-Test mode D21 to D28 23
-Test mode D29 to D47 24
User menu 25-29
-User menu B1 to B6 26
-User menu B7 to B12 27
-User menu B13 to B20 28
-User menu B21 to B24 29
Error codes 30
Survey of error codes 31
Appendices 32-34
-Appendix 1: WHIRLPOOL installation checklist 32-33
-Appendix 2: WHIRLPOOL instruction checklist 34
Notes 35-36
GB

- 3 -
Preface and Terms of Warranty
You are now the owner of one of the leading oven products on the market.
All WHIRLPOOL products are currently subjected to intensive product development, which
ensures that the products always contain the latest technology and the most up-to-date and
energy-saving methods of preparation.
Furthermore, the WHIRLPOOL products are entirely up-to-date with the latest developments/
technology in terms of
•ERGONOMICS AND SAFETY
•SIMPLE AND LOGICAL OPERATION
•USER FRIENDLY DESIGN
•RELIABILITY AND SERVICE
To ensure that our customers get an optimum and reliable product, all WHIRLPOOL units are
passed through an extensive test program in which all functions are subjected to a continuous
and extreme load.
For optimum results
Before you start using the oven, we recommend that you study the user’s manual thoroughly
in order to be able to fully utilise the many facilities and to ensure optimum cooking results.
Furthermore, by going through the manual, you will obtain a better understanding of the
advanced technology and feel safer when using the oven in your daily work.
Terms of warranty
Provided that it has been registered on the WHIRLPOOL website, your new WHIRLPOOL oven is
covered by a 48-month factory warranty. The warranty covers the oven cabinet and spare
parts. Furthermore, there is a 10-year warranty on the exterior door glass. The period of
warranty takes effect from the date of production. For further information on the warranty
terms, please visit www.houno.com/warranty.
The warranty does not include....
We especially draw your attention to the fact that the factory warranty does not cover glass
parts such as interior door glass, lamp glass and halogen lamps, nor does it cover sealings.
Furthermore, the factory warranty does not apply in the case of
•defects that are due to the fact that installation has not been carried out in accordance
with the WHIRLPOOL Installation & Service Manual at present in force (electricity, gas,
water/drain, exhaust),
•damage resulting from accidents, including damage caused by water, transport,
misapplication or negligence,
•defects and interruptions of operation that are the result of the oven not being
handled/operated as specified in the user's manual.
WHIRLPOOL cannot be made liable for indirect loss, including loss of profits.
If you utilise all the technological facilities of this oven, you are guaranteed perfect results with
only a minimum of resources.
Enjoy your new WHIRLPOOL oven.
Yours sincerely,
WHIRLPOOL

- 4 -
Rating Plate
When communicating with WHIRLPOOL, we kindly ask you inform us of the serial number of
the oven that is stated on the approval plate. The approval plate is located on the right-hand
corner post of the oven cabinet, as shown below.

- 5 -
Installation and Connection
Unpacking the oven
The oven is best handled while still in its wrapping. Wherever possible, use a lifting trolley.
Introduce the lifting trolley under the lower cross tube of the stand and place a couple of
wooden blocks between the cross tube and the lifting trolley.
To achieve the best possible balance, introduce the lifting trolley from the front of the oven or
from the motor side. Note that the oven can be lifted off the stand.
Remove the original packaging from the oven. Do not remove the foil that covers the surfaces
until the oven has been installed, as once the foil has been removed the surfaces are
vulnerable to sharp objects such as tools.
Remove all packaging material that secures the racks in the oven chamber.
The packaging should be destroyed in accordance with national rules and
regulations governing waste disposal. Information on the composition of the
packaging material can be obtained from the WHIRLPOOL Customer Centre.

- 6 -
Installation and Connection
Installing the oven
To ensure that the oven functions correctly when installed, it should be placed upright and
level (horizontally). This is measured at the front and side edge of the roof, and adjustment is
made by means of the adjusting screws on the stand or on the legs of table models. The
height of the oven can also be adjusted to fit the trolley for rack.
Correct
Wrong
The oven should be placed 5 cm / 2 inch from the rear wall and the distance
between the right side of the oven and the nearest wall or piece of furniture, etc.
should be at least 7 cm / 2.75 inch. This is to ensure the necessary flow of cooling air
to the oven. Strong sources of heat such as hotplates, tilting frying pans, deep fat
fryers, etc. should not be placed near the oven, otherwise the warranty may cease to
apply.
(NSF) On an oven with stand, the distance to the floor must be at least 150
mm / 5.9 inch. Only 2½ threads must be visible on the adjustable feet.
(NSF) On table models, the legs must be adjusted to allow a minimum
clearance of 76 mm / 3 inch to the surface on which the oven stands.

- 7 -
Installation and Connection
Water connection
WHIRLPOOL ovens have one or two water connections.
To facilitate cleaning and service, the oven should be connected with an approved flexible ¾’’
hose and the permanent installations should be fitted with a stop tap.
Before connecting the oven to water, flush the tubes thoroughly.
Hardness of the water: max. 3 dH
Conductivity: min. 75 microsiemens
Water pressure: min. 2.5 bar (36 PSI) dynamic pressure (when CombiWash on),
max. 6 bar (87 PSI)
Water flow: min. 12 l/m
Water temperature: max. 20°C (68°F)
Chloride concentration: max. 100 mg/litre
Sulphate: max. 150 mg/litre
The connection wire to the system should be fitted with a stop valve and a nonreturn valve.
If the feeder is connected to the water distribution system with a flexible hose, this hose
should be VA approved.
If the water temperature exceeds 20°C / 68°F, problems with regard to
ClimaOptima calibration and cooling of the oven may occur.
Ovens with a steam generator must not be connected to a reversed osmosis
plant, as this may cause problems with the reading of the water level in the
steam generator.
The water connection must be carried out by an authorised plumber in
accordance with existing rules and regulations
Clogged up water filters and dirt in the solenoid valves are not covered by the
warranty.
To ensure that the water quality is in conformity with the above requirements,
the installation of a water filter in front of the water connection to the oven is
recommended.
The installation of a particle filter (0.25mm) is also recommended.
In the case of two water connections, the following applies:
1) 1 connection for raw water for the condensation jet (cold water). Located at the back.
2) 1 connection for the steam generator and the jet in the oven chamber. Must meet the
requirements applying to water supplied to household appliances; however, hot water with
a temperature not exceeding 20°C / 68°F can be used. Located at the front.

- 8 -
Installation and Connection
Drain connection
From the factory, the WHIRLPOOL ovens are equipped with a drain system that removes
surplus water from the oven chamber. This water may be condensed water from the products,
or it may occur when the oven chamber is cooled down with cold water, or when the oven
chamber is cleaned.
Connection must be carried out by an authorised plumber, to an open or to a closed
drain.
It is recommended that a water outlet is available/established in the floor of
the room where the oven is located.
The drain must never end directly beneath the oven.
The drain must be of stainless steel or an equally temperature-resistant material, have a
diameter of at least 50 mm / 2 inch and a fall of at least 3° or 5%.

- 9 -
Installation and Connection
Electrical connection/survey of supply lines
The electrical connection must be carried out by an authorised electrician in accordance with
existing rules and regulations.
The wiring diagram is located in the motor compartment.
The terminal for the electrical connection is located behind the right side plate.
An approved plug outlet or a safety cutout must be located close to the oven so that
the oven can be disconnected during installation and repair. The safety cutout must be
able to cut off all poles with a total distance of break of at least 3 mm. Each of the two
units in a stacked arrangement (CombiPlus) must have its own plug outlet or safety cut-
out.
The warranty does not cover incorrect connection.
Supply lines - survey (applies to all electric models )
(All cross sections in mm² )
382,
395 382, 395
AFO ----Æ375,
388 375, 388
376,
377,
378,
389,
390,
391
376,
377,
378,
389,
390,
391 379,
392 379, 392 380, 393 380, 393 383,
396 383, 396 384, 397 384, 397
9 kW Fuse 18 kW Fuse 24 kW Fuse 36 kW Fuse 27 kW Fuse 60 kW Fuse
400V 3N ~ 50/60
Hz 5x2,5 16A 5x4 35A 5x10 50A 5x10 63A 5x10 50A 5x25 100A
400V 3 ~ 50/60
Hz 4x2,5 16A 4x4 35A 4x10 50A 4x10 63A 4x10 50A * *
415V 3N ~ 50/60
Hz 5x2,5 16A 5x4 25A 5x10 50A 5x10 50A 5x10 50A 5x25 100A
440V 3 ~ 50/60
Hz 4x2,5 16A 4x4 25A 4x10 50A 4x10 50A 4x6 35A * *
200V 3 ~ 50/60
Hz 4x4 35A 4x16 63A 4x25 100A 4x35 125A 4x25 80A * *
230V 3 ~ 50/60
Hz 4x4 25A 4x10 50A 4x25 80A 4x35 100A 4x25 80A * *
480V 3 ~ 50/60
Hz 4x2,5 16A 4x4 25A 4x6 35A 4x10 50A 4x6 35A * *
208V 3 ~ 50/60
Hz 4x4 25A 4x10 50A 4x25 80A 4x35 100A 4x25 80A * *
* Not possible
Recommended supply line: H07RN-F
When you connect the oven, you should
•Follow the installation instructions and the information given on the rating plate.
•Comply with local rules and regulations.
•WHIRLPOOL recommends the use of a (Type B) RCD/RCCB. 300 mA

- 10 -
Exhaust
The WHIRLPOOL ovens are equipped with an open/direct exhaust system that removes
surplus humidity from the oven chamber. The exhaust system has an electrically operated
damper.
The exhaust tube can be connected to a ventilating system. In that case, a special
extraction funnel is fitted to avoid suction directly from the oven chamber. This extraction
funnel can be ordered from WHIRLPOOL.
The scope of supply also includes a specially designed extraction hood, see illus. below.
If an extraction hood is installed in the ceiling above the oven, it should project 50 cm over
the front of the oven. The suction effect should be 400 – 800 m3/h.
The ventilation motor can be controlled directly from the oven. This means that the
ventilation starts when a program is started and runs for 10 minutes after the program is
completed.
The installation of the ventilation must comply with local rules and
regulations.

- 11 -
Checking before Use
The oven should be checked before you start using it.
On the outside
•Check that the oven has not been damaged in transit (dents, scratches, etc.)
•Check/adjust the height and check that the oven is placed level (horizontally)
•Check/adjust oven door
•Connections
•Check for correct water connection
•Turn on water supply
•Check for leaks
•Turn off water supply
•Check and clean dirt filter
•Turn on water supply again
•Check hand shower
•Check for correct electrical connection
•Check connection to drip tray
•Check for correct mounting of drip tray
•Check for correct fall of hose from drip tray, and check for leaks
•Check for correct exhaust and drain connection
•Clean oven
•Apply steel oil
•Oven chamber
•Check that filter housing is mounted correctly
•Check interior light
•Clean oven
•Operation panel
•Check and adjust, if necessary, each of the preset values
•Heat up the oven at 250°C for approx. 5 min.
The installation checklist and the instruction checklist (appendices 1 and 2) should
be filled in and returned to WHIRLPOOL 30 days after the installation, at the latest.

- 12 -
Annual Service Check
Customer:
Address:
By: Postal code:
Serial No of the oven: Model:
1. Connection: Functioning correctly YES NO
Water connection – dirt filter (may need tightening)
Electrical connection (may need tightening)
Drain connection (may need tightening)
Positioning of oven
2. Door:
Closing device (may need adjusting)
Catch (may need adjusting)
Sealing (must be tight at 100°C steam or combi steam)
Hinging (may need adjusting)
Interior glass (hinging, fastening)
Calibrate door sensor
3. Inside:
Interior light
Jets (may need cleaning)
Fan (should rotate freely and be tightly fitted)
Heating element (may need tightening)
4. Under oven:
Drain system (check for leaks and blocks)
Condensation jet and drain sensor
Drip tray (clean hose for discharge connection piece)
Drip slide on oven door
5. Motor room:
Connection to heating elements
Load distribution on phases
Wire connection (overloading, bad connection, and tightening)
Exhaust motor
Fan motor (may need tightening)
Frequency transformer (check regulation)
ClimaOptima
Cooling fan
Filter for intake (may need cleaning)
Cooling plate for solid-state relays (clean)
Check for moisture

- 13 -
6. Steam generator: Functioning correctly YES NO
Heating elements (check for leaks)
Load distribution on phases
Level sensor – to be cleaned
Drain pump
May need descaling
7. Functional test:
Components (use test function)
Core temperature probe
Operation modes
CombiWash (clean jet head)
Service engineer: Date and signature
Parts to be replaced at 12-, 24- and 36-month service intervals:
12-month inspection
Follow the annual service
check (see above).
Change:
Door seal
Light bulbs
Gasket for lamp glass
Nozzles
Bearing for nozzle arm
Update software
24-month inspection
Follow the annual service
check (see above).
Change:
Door seal
Light bulbs
Gasket for lamp glass
Nozzles
Main contactor
Spring for handle
Bearing for nozzle arm
Update software
36-month inspection
Follow the annual service
check (see above).
Change:
Door seal
Light bulbs
Gasket for lamp glass
Nozzles
Exhaust for damper motor
Detergent and rinse pump
Nozzle arm assy
Update software

- 14 -
Start Menu
Set temperature (press temperature key, temperature flashes, set temperature with
turn switch, press temperature key again to save).
Set time (press time key, time flashes, set time with turn switch).
Set core temperature (press core temperature key, set temperature with turn switch).
C and K models only.
Set injection time (press injection key, time flashes, set injection time with turn
switch). B model only.
Change oven
temperature with
turn switch
Change time with
turn switch
Core temperature
on C and K models.
Injection time on B
model.
Program key
Step key
HOT AIR selected if
control lamp on
COMBI STEAMING
selected if upper or
middle control lamp
is on. REHEATING is
selected if lower
control lamp is on.
Steaming on C and
K, preheating on B
Exhaust open if
control lamp on
Fan speed can be
set between 20 and
100%. Control lamp
is on when speed
< 100.
Alarm key
Turn switch
Main switch
Start/Stop

- 15 -
Oven set-up
To enter set-up mode, press hot-air key and steaming/preheating key for 2 sec.
To leave set-up mode, turn switch to the left. Change between set-up and test mode by
pressing combi-steam key.
The set-up mode is only intended for service engineers who wish to change the set-up
of the computer control of the oven model in question.
The program display shows a description of the "U" function in question.
Display shows
setting
Not active
Display shows "U"
No.
Display shows
description of "U"
function
Display shows
setting
Press HOT AIR and
STEAMING for 2 sec.
Possible to change to
"d" test mode with
combi steam key
Press STEAMING/
PREHEATING and
HOT AIR for 2 sec.
Not active
Not active
Confirmation of
special settings
Main switch
Not active
Select "U" settings
with turn switch

- 16 -
Set-up Mode U
In the set-up function, it is possible to set the oven controller to match the mechanical set-up
and the choice of software.
If the set-up has been changed in U1, U4 or U15, the oven will be reset.
U1 Oven model
The setting should be set to 1( by pressing the step key ).
You press the temperature key to select a PassThrough model (two doors).
1= one door (standard) 2= two doors
When you have selected the oven model, confirm by pressing the alarm key if the control lamp
flashes.
After that, the controller initializes.
NOTE: ALL settings and programs are reset.
U2 Oven size
You choose the oven size by pressing the step key: 0-7.0= 6, 1= 8, 2= 10, 3= 12, 4= 16, 5=
20, 6= 2 x 10, 7= 2 x 14.
The oven size you have chosen is shown in the field next to the temperature key.
U3 CombiWash
You activate or deactivate CombiClean by pressing the step key.
0=OFF, 1=ON.
U4 Temperature scale
You choose between Celsius and Fahrenheit as scale of temperature by pressing the step key.
0= Celsius 1= Fahrenheit.
You can ”even out” the current temperature by pressing the temperature key.
0=OFF, 1=ON
When you have chosen the temperature scale, confirm by pressing the alarm key if the control
lamp flashes.
After that, the controller initialises.
NOTE: ALL settings and programs are reset.
U5 Not in use
U6 Low-temperature steaming
You activate and deactivate low-temperature steaming by pressing the step key.
0= OFF, steaming only possible at 100°C, 1= ON, steaming only possible between 30°C and
120°C.
U7 Preheating at 300°C
You activate and deactivate preheating by pressing the step key.
0= OFF, 1= ON.
NOTE: Preheating at temperatures above 250°C is only possible for max. 15 minutes.
U8 Setting water level sensor
When you press the temperature key, the water level value starts flashing and can then be set
between 40 and 80 (default 70).
If the conductivity of the water is low, set the water level higher.
U9 Automatic restart
You activate and deactivate automatic restart by pressing the step key.
0= OFF, 1= 10 minutes, 2= 30 minutes, 3= 60 minutes.
This means that if there is a power cut, the program that was interrupted will be reassumed
provided that the power returns within the time set.
U10 Programs
You activate the program mode by pressing the step key.

- 17 -
0= OFF, 1= 10 programs with 3 process steps.
NOTE: It is still possible to activate the cleaning program even though the program
mode is not active.
0= OFF.
U11 Core temperature probe
You activate and deactivate the core temperature probe by pressing the step key.
0= OFF, 1= ON.
U12 Drain cooling
You activate and deactivate drain cooling by pressing the step key.
0= OFF, 1= ON.
U13 Timer start
You activate or deactivate timer start by pressing the step key.
0= OFF, 1= ON.
U14 Demo
You activate or deactivate the demo mode by pressing the step key.
0= OFF, 1= ON.
NOTE: If the demo mode is on (1= ON), the oven will run without heating elements
and steam generator being switched on.
When the oven starts, it will let you know whether the demo mode is on.
U15 Initialising
You reset the controller by pressing the alarm key.

- 18 -
Display shows
setting
Activates each
function briefly
Display indicates
whether the
function is active
Display shows a
description of the
"d" function
Display shows "d"
No.
Display shows
setting
For test mode, press
HOT AIR and COMBI
STEAMING for 2 sec.
For test mode, press
COMBI STEAMING and
HOT AIR for 2 sec.
Possible to change to
"U" setting by pressing
STEAMING/PRE-
HEATING
Not active
Not active
Possible to choose a
"d" function with turn
switch
Main switch
Not active
Test Mode
To enter test mode, press hot-air key and combi-steam key for 2 sec.
To exit test mode, turn switch left. Change between set-up mode and test mode by
pressing steaming/preheating key.
How to operate the selected component: You turn the component on (1) and off (2) by
pressing the step key. Or, you press the alarm key, and the component is active for as
long as you press the key.
The set-up mode is only intended for service engineers who wish to test the various
modes/functions.

- 19 -
Test Mode D0-D6
In the test mode, it is possible to activate all electrical components. This is very useful in
connection with fault detection and the testing and adjusting of replacement parts.
D0 Main contactor(s)
This function activates contactor K1.
You activate or deactivate the function by pressing the step key. The function can, however,
only be activated when the fan is on.
To pulse, press the alarm key.
0= OFF, 1= ON.
Status for the main alarms appear in the display as follows:
Digit 1 fan
Digit 2 oven
Digit 3 generator
Digit 4 Solid State Relay
If ER28 appears, the alarm sensor circuit board or wiring harness is defective.
D1 Oven heat
This function activates contactor K2.
You activate or deactivate the function by pressing the step key.
Humidity pulsing is possible by pressing the alarm key.
0= OFF, 1= ON.
D2 Steam generator heat
This function activates contactor K3.
You activate or deactivate the function by pressing the step key. However, this function can
only be activated when there is water in the steam generator.
To pulse, press the alarm key.
0= OFF, 1= ON.
D3 Fan, right-hand, high/low
This function activates the frequency exchanger.
You can test the speed of the motor by pressing the step key.
0= OFF, 2= ON
By pressing the time key, it is possible to adjust the speed of the motor from 0 to 100%.
The RPM appears in the temperature display.
Note: The main contactor K1 must be active for this function to work, as the
frequency transformer is connected via K1
D4 Fan, left-hand, high/low
This function activates the frequency exchanger.
You can test the speed of the motor by pressing the step key.
0= OFF, 2= ON
By pressing the time key, it is possible to adjust the speed of the motor from 0 to 100%.
The RPM appears in the temperature display.
Note: The main contactor K1 must be active for this function to work, as the
frequency transformer is connected via K1
D6 Solenoid valve
This function activates solenoid valve MV1.
You activate or deactivate the function by pressing the step key
To pulse, press the alarm key.
0= OFF, 1= ON.

- 20 -
Test Mode D7-D15
D7 Filling valve
This function activates solenoid valve MV2.
You activate or deactivate the function by pressing the step key.
To pulse, press the alarm key. 0= OFF, 1= ON.
D8 Drain pump
This function activates motor M2.
You activate or deactivate the function by pressing the step key.
To pulse, press the alarm key. 0= OFF, 1= ON.
D9 Drain cooling
This function activates solenoid valve MV3.
You activate or deactivate the function by pressing the step key.
To pulse, press the alarm key. 0= OFF, 1= ON.
D10 Damper motor
This function activates motor M3.
In the display next to ”Time”, it is possible to read the status of the damper motor switch.
OFF= damper open, ON= damper closed.
You activate or deactivate the function by pressing the step key.
To pulse, press the alarm key. 0= OFF, 1= ON.
D11 Exhaust
This function activates the outlet for controlling the external ventilation, terminals 4 and 5.
In the display next to ”Time”, it is possible to read which outlet is active.
OFOF= both outlets are off, ONOF= outlet 4 is active and outlet 5 is off.
OFON= outlet 4 is off and outlet 5 is active. ONON= both outlets are active.
You activate or deactivate the function by pressing the step key.
0= OFOF, 1= OFON, 2= ONOF, 3= ONON.
D12 Cooling fan
This function activates motors M7 and M7A.
You activate or deactivate the function by pressing the step key.
To pulse, press the alarm key.
0= OFF, 1= ON.
D13 Buzzer
This function activates buzzer H2.
You activate and deactivate this function at high volume by pressing the step key.
It is possible to pulse at low volume by pressing the alarm key.
0= OFF, 1= ON.
D14 Interior light
This function activates interior light H1.
You activate or deactivate the function by pressing the step key.
To pulse, press the alarm key.
0= OFF, 1= ON.
D15 Oven temperature
Here it is possible to read the current oven temperature, P1.
In the field next to ”Temperature”, the current temperature is shown. If ERR appears, the
sensor circuit is defective.
In the field next to ”Time”, an adjustment value between 80 and 120 (default 100) is shown.
To adjust the temperature, press the time key until the digit in the display flashes. Then adjust
upwards or downwards until the correct temperature is shown. Finally, press the time key
again to save the setting.
The temperature can be adjusted by +- 10
