Whirlpool SF317PEY User manual

A Note To You 2
Important Safety
Instructions 3
PartsAnd Features 6
Using Your Range 7
giai For Your 16
IfYou Need
$$-?~ 25
Warranty 28
1-800-253-1301
Cell us with questions or comments.
CONTINUOUS AND STANDARD-CLEANING GAS RANGES
TO THE INSTALLER: PLEASE LEAVE THIS
INSTRUCTION BOOK WITH THE UNIT.
TO THE CONSUMER: PLEASE READ AND
KEEPTHIS BOOK FOR FUTURE REFERENCE.
MODELS SF337PEY
SF317PEY
SF317PCY
ta-52

A Note To You
Thank you for buying a Whirlpool appliance.
You have purchased a quality, worldclass home appliance. Years of engineering experience have gone
into its manufacturing. To ensure that you will enjoy many years of trouble-free operation, we have
developed this Use and Care Guide. lt is full of valuable information on how to operate and maintain
your appliance properly and safely. Please read it carefully. Also, please complete and mail the Owner-
ship Registration Card provided with your appliance. This will help us notify you about any new informa-
tion on your appliance.
Your safety is important to us.
This guide contains safety symbols and statements. Please pay special attention to these symbols and
follow any instructions given. Here is a brief explanation of the use of each symbol.
This symbol will help alert you to such dangers as
personal injury, burns, fire and electrical shock. This symbol will help you avoid actions which
could cause product damage (scratches, dents,
etc.) and damage to your personal property.
l ALL RANGES CAN TIP.
l INJURY TO PERSONS
COULD RESULT.
l INSTALL ANTI-TIP
DEVICES PACKED
WITH RANGE.
l SEE INSTALLATION
INSTRUCTIONS.
For more information, see the “The anti-tip bracket”
on page 15.
Our Consumer Assistance Center number, l-800-253-1301,
is toll-free, 24 hours a day.
If you ever have a question concerning your appliance’s operation, or if you need service, first see “If
You Need Assistance Or Service” on page 25. If you need further help, feel free to call our Consumer
Assistance Center. When calling, you will need to know your appliance’s complete model number and
serial number. You can find this information on the model and serial number plate (see diagram on
page 6). For your convenience, we have included a handy place below for you to record these numbers,
the purchase date from the sales slip and your dealer’s name and telephone number. Keep this book
and the sales slip together in a safe place for future reference.
Model Number
Serial Number
Purchase Date
Deder Name
Dealer Phone

Important Safety Instructions
Gas ranges have been thoroughly tested for safe and efficient operation. However, as with any
appliance, there are specific installation and safety precautions which must be followed to ensure safe
and satisfactory operation.
To reduce the risk of fire, electrical shock, injury to persons, or
damage when using the range, follow basic precautions, including
WARNING: If the information in this manual is not followed exactly,
a fire or explosion may result causing property damage, personal
injury or death.
Do not store or use gasoline or other flammable vapors and liquids
in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
l Do not try to light any appliance.
l Do not touch any electrical switch; do not use any phone
in your building.
l Immediately call your gas supplier from a neighbor’s phone.
Follow the gas supplier’s instructions.
l If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer,
service agency or the gas supplier.
General
l Install or locate the range only in accordance adjusted burners with a blue, rather than a
with the provided Installation Instructions. yellow, flame will minimize incomplete
The range must be installed by a qualified combustion. Venting with a hood or an open
installer. The range must be properly window will further minimize exposure.
connected to the proper gas supply and
checked for leaks. The range must also be
l Do not store things children might want
properly connected to electrical supply and above the range. Children could be burned or
grounded. injured while climbing on it.
l Gas fuels and their use in appliances can
l Do not leave children alone or unattended in
cause minor exposures to benzene, formal- area where the range is in use. They should
dehyde, carbon monoxide and soot, primarily never be allowed to sit or stand on any part of
from incomplete combustion. Significant the range. They could be burned or injured.
exposure to these substances can cause
l Do not operate the range if it is damaged or
cancer or reproductive harm. Properly not working properly.
continued on next page
3

l Do not use the range for warming or heating
the room. Persons could be burned or
injured, or a fire could start.
l Do not attempt to light the oven burner during
a power failure. Personal injury could result.
Reset oven controls to the off position in the
event of a power failure.
l Use the range only for its intended use as
described in this manual.
l DO NOT TOUCH SURFACE BURNERS,
AREAS NEAR SURFACE BURNERS OR
INTERIOR SURFACES OF OVEN.
Areas near surface burners and interior
surfaces of an oven become hot enough to
cause burns. During and after use, do not
touch, or let clothing or other flammable
materials contact surface burners, areas near
surface burners or interior surfaces of oven
until they have had sufficient time to cool.
Other surfaces of the range may become hot
enough to cause burns: such as, the oven
vent opening, the surface near the vent
opening, the cooktop, the oven door and
window.
l Do not wear loose or hanging garments when
using the range. They could ignite if they
touch a hot surface burner and you could be
burned.
. Use only dry potholders. Moist or damp
potholders on surface burners may result in
burns from steam. Do not let potholder touch
surface burners. Do not use a towel or bulky
cloth for a potholder. It could catch on fire.
l Keep range vents unobstructed.
l Do not heat unopened containers. They
could explode. The hot contents could cause
burns and container particles could cause
injury.
l Do not store flammable materials on or near
the range. The fumes can create an explo-
sion andlor fire hazard.
l Do not use the oven for storage.
l Never use a match or other flame to look for
a gas leak. Explosion and injury could result.
l Know where your main gas shutoff valve is
located.
When using the cooktop
l Make sure the utensils you use are large
enough to contain food and avoid boilovers
and spillovers. Heavy splattering or spillovers
left on a range can ignite and bum you. Pan
size is especially important in deep fat frying.
l Check to be sure glass cooking utensils are
safe for use on the range. Only certain types
of glass, glass-ceramic, ceramic, earthen-
ware or other glazed utensils are suitable for
cooktops without breakfng due to the sudden
change in temperature.
l Never leave surface burners unattended at
high heat settings. A boilover could result and
cause smoking and greasy spillovers that
may ignite.
l Turn pan handles inward, but not over other
surface burners. This will help reduce the
chance of bums, igniting of flammable
materials, and spills due to bumping of the
pan.
l Do not use decorative covers or trivets over
the surface burners.
When using the oven
l Always position the oven rack(s) in desired
location while oven is cool.
l Use care when opening oven door. Let hot air
or steam escape before removing or replac-
ing food.
4

Grease
l Grease is flammable. Do not allow grease to
collect around cooktop or in vents. Wipe
spillovers immediately.
l Do not use water on grease fires. Never pick
up a flaming pan. Smother flaming pan by
covering with a well-f&ted lid, cookie sheet or
flat tray. Flaming grease outside of pan can
be extinguished with baking soda or, if
available, a multipurpose dry chemical or
foam-type extinguisher.
Care and cleaning
l Do not use oven cleaners in continuous-
cleaning oven model. No commercial oven
cleaner or oven liner protective coating of
any kind should be used in or around any
part of the oven.
l Do not clean door heat seal. It is essential for
a good seal. Care should be taken not to rub,
damage or move the seal. Clean only parts
recommended in this Use and Care Guide.
l Do not repair or replace any part of the range
unless specifically recommended in this
manual. All other servicing should be
referred to a qualified technician.
l Any addiiions, changes or conversions
required in order for this appliance to
satisfactorily meet the application needs
must be made by a Whirlpool Distributor or
Qualified Agency.
l Disconnect the electrical supply and the gas
supply at the shutoff valve near the range
before servicing the range.
- SAVE THESE INSTRUCTIONS -

Parts And Features
This section contains captioned illustrations of your range. Use them to become familiar with the
location and appearance of all parts and features.
Mmual oven
light switch
\
Antctip bracket
(on wall behind backguuud)
I
Broiler drawer -
Clock/Minute
and grates
Model md aerial
Control panel
Left front L8ft rm
control. knob control knob Right rear
conk01 knob Right front control knob
I
surfue
burner
markers
-- I
bmpotalure
control
6

Using Your Range
In This Section PWP Paw
Using the l urfaca burners ................................. 7
Pooitioning r8cb and pana ............................... 9
For best air circulation ..................................... 10
Setting the clock ............................................... 11
U0lng the Minute Timer .................................... 11
Bakinglroding ................................................ 12
Adudlng the oven bmperature control ........13
Broiling .............................................................. 13
Energy saving tips ............................................ 14
The oven vent ................................................... 14
The anti-tip bracket .......................................... 15
To obtain the best cooking results possible, you must operate your range properly. This section gives
you important information for efficient and safe use of your range.
Using the surface burners
Your range is equipped with electric ignitors.
Electric igniters automatically light the burners
each time they are used.
Push In control knobr and turn them to the
LITE position. The clicking sound is the ignltor
sparking. Visually check that burner has Ht.
To stop the clicking sound after the burner
lights, turn the control knob to the desired
setting. The control knob has stops for HI, MED
and LOW. However, you can set the control knob
anywhere between HI and OFF.
Surface burner markers
The solid dot in the surface burner marker shows
which surface burner is turned on by that knob.
Burner heat settings
Use correct burner heat settings (see next page).
If the heat setting is too high, it can:
l Char bacon and cause curling.
l Make eggs tough and crisp at the edges.
l Toughen liver, fish and seafood.
l Scorch delicate sauces and custards.
l Cause a boilover.

Until you get used to the settings, use the
followlng as a guide. For best results, start
cooking at the high setting: then turn the control
knob down to continue cooking.
SElTING RECOMMENDED USE
LlTE l To light the burner. After the
burner lights, turn control back
to a desired setting to stop the
clicking of the ignitor.
HI l To start foods cooking.
l To bring liquids to a boil.
MED l To hold a rapid boil.
l To fry chicken or pancakes.
l For gravy, pudding and icing.
l To cook large amounts of
vegetables.
LOW l To keep food warm until ready
to serve.
NOTE: Do not cook with the control in the LITE
position.
In case of a prolonged power
failure
Surface burners can be manually lighted. Hold a
lit match near a burner and turn the control knob
to the LITE position. After the burner lights,
turn the control knob to the desired setting.
Burn, Fire, Explosion and
Product Damage Hazard
l Burner flame should not extend beyond the
edge of the cooking utensil. The flame can
burn you and cause poor cooking results.
l Be sure all control knobs are turned to OFF
when you are not cooking. Someone could
be burned or a fire could start if a burner is
accidentally left ON.
l If the flame should go out while cooking, or
if there is a strong gas odor, turn the
burners OFF. Wait five minutes for the gas
odor to disappear before relighting burner.
lf gas odor is still present, see safety note
on page 3. Failure to follow these precau-
tions could result in explosion or fire.
l Do not leave an empty utensil, or one which
has boiled dry, on a hot surface burner. The
utensil can overheat and may damage the
utensil or cooking product.
Cookware tips
There is no one brand of cooking utensil that is
best for all people. Knowing something about pan
materials and construction will help you select the
correct cooking utensils for your needs.
l NOTE: For best resukr and greater fuel
efficiency, use only flat-bottomed utensils that
make good contact with the surface burners.
Utensils with rounded, warped, ridged (porce-
lain enamel-ware) or dented bottoms could
cause severe overheating, which damages the
utensil andlor surface burner.
Woks, canners and teakettles with flat
bottoms suitable for use on your cooktop are
now available in most stores that sell
housewares.
l The pan should have straight sides and a tight-
fifing lid.
l Choose medium to heavy gauge (thickness)
pans that are fairly lightweight.
l The pan material (metal or glass) affects how
fast heat transfers from the surface burner
through the pan material and how evenly heat
spreads over the pan bottom. Choose pans that
provide the best cooking results.
l Handles should be made of a sturdy, heat-
resistant material and be securely attached to
the pan.
l Pans should be easy to clean. Check to be
sure there are no crevices, rough edges or
areas where food migM collect.
l Be sure pans do not tip, whether they are full
or empty.
l Uee utensils only as they were intended to be
used. Follow pan instructions. This is very
important for glass cookware because some
should be used only in the oven. Other pans
are marked as flameware and may be used on
the surface burners.
6

Home canning information
The large diameter of most water-bath or
pressure canners combined with high heat
settings for long periods of time can cause
damage to the cooktop.
To protect your range:
l For beet results, UM a canner which can be
centered over the surface burner.
l Do not place canner on two surface burners at
the same time. Too much heat will build up and
will damage the cooktop.
l Start with hot water. This reduces the time the
control is set on high. Reduce heat setting to
lowest position needed to keep water boiling.
Positioning racks and pans
For baking/roasting with one reck, place the
rack so the top of the food will be centered in the
oven.
Rack placement for specific foods:
FOOD RACK POSlTlON [
Frozen pies, large roasts,
turkeys
Angel and bundt cakes,
most quick breads, yeast
breads, casseroles, meats
Cookies, biscuits, muffins, 2nd or 3rd rack
cakes, nonfrozen pies
1st or 2nd rack
guide from bottom I
2nd rack guide
from bottom
When baking on two racks, arrange racks on
first and third rack guides from bottom.
6th oven rack position
(roasting rack)
When roasting food too large to be placed in
oven with rack in lowest position, place rack on
bottom of oven.
For proper roesting, follow these guidelines:
l The rack must be level.
l Use adequate amount of liquid (meat juices or
water) so food does not get overdone.
l Do not tty to pull rack out over door. Rack will
be at the same level as door when door is
opened.
Personal Injury Hem-d
l Always position oven rack(s) in desired
location before turning oven on. Be sure
the rack(s) is level.
l If rack(s) must be moved while oven is
hot, use potholders or oven mitts to
protect hands.
l Do not place items on the open oven door.
l Be careful when installing and removing
large food items from sixth rack position.
Food will be close to hot surfaces,
including oven bottom and sides.
Failure to follow the above precautions
may result in personal injury.
6th oveniack position

For best air circulation
Hot air must circulate around the pans in the oven
for even heat to reach all parts of the oven. This
results in better baking.
l Place the pans so that one is not directly over
the other.
l For beat results, allow 1I/Z-2inches (4-5 cm)
ofspacearoundeachpanandbetweenpans
and oven walls. There must be a minimum
space of 1 inch (2.5 cm).
l Use only one cookie sheet in the oven at one
time.
Use the following as a guide to determine where
to place the pans.
One pan
Place in the center of the oven rack.
Two pans
Place in opposite corners of the oven rack
Three or four pans
Place in opposite comers on each oven rack.
Stagger pans so no pan is directly over another.
10

Setting the clock
Push in and turn the Minute Timer Knob to set
the clock.
Push in Minute Timer Knob and turn
clockwise until clock shows the correct time
of day.
Let the Minute Timer Knob pop out. Turn
clockwise until Minute Timer hand points to
OFF. The clock setting will change if you
push in the knob when turning.
Using the Minute Timer
The Minute Timer does not start or stop the oven.
It works like a kitchen timer. Set it in minutes up
to an hour. You will hear a buzzer when the set
time is up.
NOTE: Do not push in the knob when setting
the Minute Trrnsr or when stopping the buzzer.
Pushing in and turning the Minute Timer Knob
changes the clock setting.
1. Without pushing it in, turn the Minute Timer
Knob counterclockwise until the timer hand
passes the setting you want.
2. Without pushing it in, turn the knob back to
the setting you want.
When the time is up, a buzzer will sound.
To stop the buzzer, turn the Minute Timer
hand to OFF.
11

Baking/roasting
1. Positiin the rack(s) properly before turning
on the oven. To change rack position, lift
rack at front and pull out. For further informa-
tion, see “Positioning racks and pans” on
page 9.
2. Push in and turn the Oven Temperature
Control to the baking/roasting temperature you
want. The oven burner will automatically light
. in 50-60 seconds.
3. When baking, preheat the oven for 10 min-
utes. Put food in the oven.
NOTE: Do not preheat when roasting or
cooking items such as casseroles.
Do not place food directly on the oven
bottom.
4. During baking/roasting, the oven burner will
turn on and off to maintain the temperature
setting.
5. When baking/roasting is done, turn the
Oven Temperature Control to OFF.
12

Adjusting the oven temperature control
Oven temperature controls will gradually shift
after years of use. So, even though your new
oven is properly adjusted to provide accurate
temperatures, it may cook faster or slower than
your old oven.
If, after using the oven for a period of time, you
are not satisfied with the temperature settings,
you can adjust them by following these steps:
1. Push in and turn the Oven Temperature
Control Knob to the off position. Pull knob
straight off and flip it over.
2. Loosen the locking screws inside the control
knob. Note the position of the notches.
3. To lower the temperature, hold knob handle
firmly and mOve the tooth a notch clockwise.
Each notch equals about 10°F (5°C).
4. To raise the temperature, hold knob handle
firmly and move the tooth a notch counter-
clockwise. Each notch equals about 1O’F
(5°C).
Locking
8omwS
Tighten the locking screws and replace the
control knob.
Broiling
The broiler drawer is located below the oven
door. Always broil with the oven door closed.
1. Pull the broiler drawer open and tilt the door
panel down.
2. Place broiler pan grid so grease can drain
down ribbing and through slots into lower part
of the broiler pan. See picture.
3. Before the broiler is turned on, place food
on broiler pan and position the broiler pan at
one of the three levels. Refer to a reliable
cookbook for broiling chart.
Drain Rib
Side view
Front
13

4. Push In and turn the Oven Temperature
Control to BROIL. The broiler will automati-
cally light in 50-60 seconds.
5. When broiling is done, turn the Oven
Temperature Control to OFF.
NOTE: Do not preheat the broiler before using.
Completely close the broiler drawer during
broiling.
Energy saving tips
Although the energy used for cooking is usually
a very small percentage of the total energy used
in the home, cooking energy can be used effi-
ciently. Here are some tips to help you save
energy when using your cooking product.
l Use pans with flat bottoms, straight sides and
tight-fitting lids.
l Cook with a minimum of liquid or fat to help
shorten cooking time.
l Preheat pans only when recommended and for
the shortest time possible.
l Start food on higher heat settings, then set
surface burner control on low or off to finish
cooking. Use retained heat for cooking when
possible.
l Use the more efficient surface burners instead
of the oven when possible.
l Turn on the surface burner only after placing
filled pan on the burner grate.
l “Oven peeking” may cause heat loss, longer
cooking times and unsatisfactory baking
results. Rely on your timer to keep track of the
cooking time.
l Bake cakes, pies or cookies when oven is
warm. Best time is after a meal has been
cooked in it.
l Preheat the oven no longer than necessary.
l Plan your meals for the most efficient use of
the range. When using the oven to cook one
food, try to cook the rest of the meal in it also.
l Do not preheat when broiling, roasting or
cooking items such as casseroles.
The oven vent
Hot air and moisture escape from the oven
through a vent located in lower part of backguard.
The vent is needed for air circulation. Do not
block the vent. Poor baking/roasting will result.
NOTE: Never store plastics, paper or other items
that could melt or bum near the oven vent, or any
of the surface burners.
Burn Hazard
When the oven is ON, pans and pan handles
left near the oven vent can become hot
enough to burn the user and to melt plastics.
Use potholders to move pans.
14

The anti-tip bracket
The range will not tip during normal use. How-
ever, tipping can occur if you apply too much
force or weight to the open door without the
anti-tip bracket properly secured.
To verify the anti-tip bracket is engaged:
l Look to see if the anti-tip bracket is attached
with screws to the wall behind the backguard.
l Make sure the cable tether on the back of the
range is secured by the two hooks on the
bracket.
l See Installation Instructions for further details.
15

Caring For Your Range
I
In This Section
Plrgs
Pllgb
I
Surface burner grates ...................................... 16 The continuou8-cleAng oven ....................... .20
Surface burner8 and cooktop .......................... 17 Cleaning chvt ................................................... 22
Removing the oven door ................................. 16 The oven light ................................................... 24
Removing the oven bottom ............................. 19
Your range is designed for ease of care. You can
do most cleaning with items found around your
home. Cleaning your range whenever spills or
soiling occurs will help to keep it looking and
operating like new. Burn, Electrical Shock, Fire and
Explosion Hazard
l Make sure all controls are OFF and the
1 range is cool before cleaning.
l For continuous-cleaning ovens, do not use
oven cleaners, bleach or rust removers.
l Do not obstruct the flow of combustion and
ventilation air.
Failure to follow these guidelines could result
in burns, electrical shock, fire or explosion.
Surface burner grates
1. Make sure all surface burners are off and the
surrounding parts are cool.
2. Lift off the surface burner grates.
3. Wash the grates with warm, soapy water or in
a dishwasher. Use a nonabrasive, plastic
scrubbing pad for cooked-on foods. Rinse and
dry well.
4. Replace burner grates.
16

Surface burners and cooktop
The range and burner box areas are specially
designed to make cleaning easier. Because the
four burners are sealed, cleanups are easy and
convenient.
To clean the cooktop, wipe with a damp
sponge and dry.
Product Damage Hazard
Do not remove the cooktop.
Doing so could result in product damage.
Cleaning the contoured well
areas
The contoured well is a recessed area located
around each burner. If spills occur in the con-
toured well section, blot up spill with a paper
towel. Wipe with a clean, damp sponge and dry.
When cleaning the cooktop area or around
the burner base, use care to prevent damage to
the ignitor. If a cleaning utensil should catch the
ignitor, it could damage or break the ignitor. If the
ignitor is damaged or broken, the surface burner
will not light. When cleaning the cooktop, leave
the burner cap in place to protect the ignitor from
possible damage.
Cleaning the burners
The burner caps should be routinely removed and
cleaned. Always clean the burner caps after a
spillover. Keeping the burner caps clean will
prevent improper ignition and an uneven flame.
To clean, pull the burner cap straight up from
the burner base. Remove the burner pan.
(Burner pan must be replaced over burner base
before replacing burner cap. Do not operate
burners without burner pan in place.) Clean
burner cap and burner pan with warm, soapy
water and a sponge. You can also clean with a
nonabrasive scrubbing pad or cleanser. Do not
clean burner cap or burner pan in a dishwasher
or self-cleaning oven.
For proper flow of gas and ignition of the
burner, DO NOT ALLOW SPILLS, FOOD,
CLEANING AGENTS OR ANY OTHER MATE-
RIAL TO ENTER THE GAS TUBE OPENING. If
the opening or the orifice, located inside the
opening, becomes soiled or clogged, use a cotton
swab or a paper towel to clean the area.
tgnitor /
area
17

Gas must flow freely through the small hole in the
brass orifice for the burner to light properly. This
area must be free of any soil and be kept
protected from boilovers or spillovers. ALWAYS
keep the burner caps in place whenever a
surface burner is in use.
After cleaning the gao tube opening, replace
the burner cap and burner pan.
Occasionally check the burner flames for
proper size and shape as shown. A good flame is
blue in color. If flames lii off ports, are yellow, or
are noisy when turned off. you may need to clean
the burners. If port8 are clogged, clean with a
straight pin. Do not enlarge or distort port. Do not
use a wooden toothpick. lf adjustment is
needed, call a qualified technician for service.
To replace burner cap, make sure cap is
u”uu
I
Typical surface burner flame
properly aligned and leveled. Find the recessed
locating tabs on the burner cap (see illustration)
and place cap over the white ignitor in the burner
base.
Turn the burner on to determine if it will light. If
the burner does not light after cleaning,
contact an authorized WhirlpooP service
technician. Do not service the sealed burner
yoursetf.
Removing the oven door
Removing the oven door will help make it easier
to clean the oven.
Burn and Electrical Shock Hazard
Make sure all controls are OFF and the oven is
cool before removing oven door. Failure to do
so can resutt in burns or electrical shock.
To remove:
1. Open the door as far as it will go.
2. Remove the screws on each side of the oven
door.
3. Close the door about % of the way.
4. Lift the door up and off the hinges.
16
4
---A __/’ .
..i
/
/
&
/ .::: screw
..-:::;
........
........
........
........ 0 o
........
.........
.........
........
........
........
........
.p;&..
:.Y. +‘h
7

To replace:
1. Be sure the hinge arms are in the open
position. Be careful if pulling the hinges open
by hand. Hinges may snap back against the
oven frame and could pinch fingers.
2. Hold the door at the sides near the top. Insert
hinge arms into slots at the bottom of the door.
Insert arms evenly, as far as they will go.
3. If the door is not in line with the oven
frame, remove it and repeat the above steps.
4. Replace the screws on the oven door.
arm
Removing the oven bottom
The panel in the oven bottom can be removed for
cleaning.
To remove:
1. Remove oven racks.
2. Remove the two hold-down screws at the rear
of the oven. If screws are too tight to
remove by hand, use a screwdriver.
3. Place fingers in slots in bottom panel and lift
rear of panel up and back until lip at the front
of panel is clear of front frame of oven cavity.
4. Lii bottom up and out.
To replace:
1. Place oven bottom panel in oven with the
back raised about 6 inches or until you can
insert the hold-down lip at front of panel under
the front frame of oven cavity.
2. Push back of oven bottom panel down fully
into place on metal flanges on rear wall and
insert the hold-down screws.
19

The continuous-cleaning oven
(model SF337PEY)
Standard-cleaning oven walls are coated with
smooth porcelain. Your continuous-cleaning oven
walls are coated with a special, rougher porce-
lain. A fat spatter beads up on the smooth
surface, but spreads out on the rougher surface.
The bead of fat on the smooth surface chars and
turns black The spread-out fat on the rough
surface gradually bums away at medium to
high baking temperatures so the oven can
return to a presentably clean condition.
Fat spatter boa&
up. Turn. black Standard
porcelain
Fat l pattar spreada Continuous-
out. Burns away. cleaning porcelain
Cleaning tips
l The oven window, racks, oven bottom and
inside surface of door are not coated. Clean
them by hand.
l If you do more broiling than baking, hand-
cleaning may be needed.
20
