Whirlpool W10860701C User manual

W10860701C
W10862387C-SP
Top-Loading Washer
Use and Care Guide
Table of Contents
WASHER SAFETY...................................................................... 2
WHAT’S NEW UNDER THE LID? .............................................. 3
CONTROL PANEL AND FEATURES ......................................... 4
CYCLE GUIDE............................................................................ 5
USING YOUR WASHER............................................................. 7
WASHER MAINTENANCE......................................................... 9
TROUBLESHOOTING.............................................................. 11
WARRANTY.............................................................................. 16
ASSISTANCE OR SERVICE..................................BACK COVER
Table des matières
SÉCURITÉ DE LA LAVEUSE ................................................... 17
QUOI DE NEUF SOUS LE COUVERCLE? .............................. 18
TABLEAU DE COMMANDE
ET CARACTÉRISTIQUES ........................................................ 19
GUIDE DE PROGRAMMES ..................................................... 20
UTILISATION DE LA LAVEUSE ............................................... 22
ENTRETIEN DE LA LAVEUSE ................................................. 25
DÉPANNAGE ............................................................................ 27
GARANTIE................................................................................ 34
ASSISTANCE OU SERVICE............... COUVERTURE ARRIÈRE
Laveuse à chargement par
le dessus guide d’utilisation
et d’entretien
Para una versión de estas instrucciones en español, visite www.whirlpool.com

2
You can be killed or seriously injured if you don't immediately
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”
These words mean:
follow instructions.
instructions.
DANGER
WARNING
Washer Safety

3
What’s New Under the Lid?
Sounds
At different stages of the wash cycle, you may
hear sounds and pauses that are different from those
of your previous washer. For example, you may hear a
clicking and hum at the beginning of the spin phase as
the lid lock goes through a self-test. There will be different
kinds of humming and whirring sounds as the agitator
tests for load balance or moves the load. Sometimes,
you may hear nothing at all as the washer allows time for
clothes to soak.
Lid Lock
To allow for higher spin speeds, the lid will lock and the
Lid Locked light will turn on. When this light is lit, the lid is
locked and cannot be opened. When this light is blinking,
the washer is paused. When this light is off, the lid can be
opened. After a cycle is started, the washer will ll to the
appropriate water level. When the washer is done lling,
it will start to agitate. If you need to open the lid to add a
garment after this point, the lid will remain unlocked during
the entire agitation portion of the wash phase. The cycle
will automatically pause when the lid is opened, and the
cycle will resume once the lid is closed. The lid will lock
before the spin phase begins. If you need to pause or
stop after this point, you must press the Start/Stop button
and wait for the lid to unlock. The lid will only unlock after
washer movement has stopped. Depending on when in
the cycle you try to pause, it may take several seconds to
several minutes for the lid to unlock. Press the Start/Stop
button to resume the cycle.
Water Level Options
Set the Water Level knob to the Auto Sensing setting and
the washer will ll to a level that ensures the load engages
the agitator. From this point, the electronic control will
sense the load and determine if additional water is needed.
Set the Water Level knob to the Deep Water Wash setting
and the washer will ll to the maximum water level.
Sensing
This washer will perform a series of spins to check for load
balance. During this time, a series of clicks and a whirring
noise signal that sensing technology is determining if there
is an off-balance load.
IMPORTANT:
■After the washer basket lls to the selected water level, the lid must be closed before the wash cycle can start. If lling stops with
the lid open, close lid and press the Start/Stop button if cycle does not automatically resume.
■Fabric Softener option must be set to "Yes" to ensure fabric softener dispenses at the correct time and is evenly distributed.
Use only High Efciency detergents. The package will be
marked “HE” or “High Efciency.” Using non-HE detergent
will likely result in longer cycle times and reduced rinsing
performance. It may also result in component malfunction
and, over time, buildup of mold or mildew. HE detergents
should be low-sudsing and quick-dispersing to produce
the right amount of suds for the best performance. They
should hold soil in suspension so it is not redeposited
onto clean clothes. Not all detergents labeled as High
Efciency are identical in formulation and their ability to
reduce suds. For example, natural, organic, or homemade
HE detergents may generate a high level of suds. Always
follow the detergent manufacturer’s instructions to
determine the amount of detergent to use.
Choosing the Right Detergent
Use only High Efciency (HE) detergent.
Select cycles default to a spray rinse. During these cycles,
you will hear water enter the washer as the tub spins,
allowing the rinse water to penetrate clothes. Check
the “Cycle Guide” for details.
Spray Rinse

4
1
6
Control Panel and Features
WASH TEMPERATURE
Wash Temperature senses and maintains uniform water
temperatures by regulating incoming hot and cold water.
Select a wash temperature based on the type of fabric
and soils being washed. For best results, and following
the garment label instructions, use the warmest wash
water safe for your fabric.
■On some models and cycles, warm and hot water may
be cooler than your previous washer.
■Even in a cold- and cool-water wash, some warm water
may be added to the washer to maintain a minimum
temperature.
All rinses are cold.
FABRIC SOFTENER
This option must be set to “Yes” if you are using fabric
softener in the fabric softener dispenser. This ensures that
fabric softener is added at the correct time in the rinse for
even distribution.
WATER LEVEL
Set the Water Level knob to the Auto Sensing setting and
the washer will ll to a level that ensures the load engages
the agitator. From this point, the electronic control will sense
the load and determine if additional water is needed.
Set the Water Level knob to the Deep Water Wash setting
and the washer will ll to the maximum water level.
NOTE: Expect longer cycle times due to extended ll times
when using the Deep Water Wash option.
WASH CYCLE KNOB
Use the wash cycle knob to select cycles on your washer.
See “Cycle Guide” for detailed descriptions of cycles.
1
2
3
4
START/STOP BUTTON
Press to start the selected cycle; press again to pause the
cycle and unlock the lid.
NOTE: If the washer is spinning, it may take several minutes
to unlock the lid. Press and hold for 3 seconds to cancel
a cycle.
CYCLE STATUS LIGHTS
The Cycle Status Lights show the progress of a cycle.
At each stage of the process, you may notice sounds or
pauses that are different from your previous washer.
SENSING/FILL
When the Start/Stop button is pressed and the Water
Level knob is set to Auto Sensing, the washer will ll
and begin sensing to determine load size and balance.
Once sensing is complete, the washer will ll to the
appropriate level for the detected load size and then
begin the wash phase of the cycle.
NOTE: Sensing and wash phases will be paused by
opening the unlocked lid. Close the lid to resume the
cycle. If the lid is left open for more than 10 minutes,
the washer will cancel the cycle and pump out the water.
The lid will lock after the wash phase to begin the initial
spinout and remain locked for the remainder of the cycle.
5
6
Not all features and options are available on all models.
Appearance may vary.
4
3
2
5

5
CYCLE COMPLETE
Once the cycle is complete, this light will come on.
For best results, remove the load promptly.
LID LOCKED
The Lock feature allows for higher spin
speeds. When lit, the lid is locked and
cannot be opened without pausing the
cycle. When the light is off, the lid can
be opened.
To open the lid after it has been locked,
press the Start/Stop button. The lid will
unlock once the washer movement has
stopped. This may take several minutes
if the load was spinning at high speed.
Press the Start/Stop button while
the lid is closed to resume the cycle.
WASH
The washer will ll to the correct water level based
on the load size and the Water Level selection. Certain
cycles may agitate during the ll process to boost
cleaning. You will hear the agitator rotate followed
by a pause lasting several seconds. When the wash
cycle begins, you will hear the agitator increase speed.
The motor sounds may change at different stages in
the wash cycle while the machine performs different
wash actions.
RINSE
Certain cycles use a spray rinse, which adds water to
the tub while the basket spins. When Fabric Softener
“Yes” is selected, you will hear sounds similar to the
wash cycle as the washer rinses and moves the load.
You may hear the motor turning on briey (short hum)
to move the basket while lling.
FINAL SPIN
The washer spins the load at increasing speeds for
proper water removal based on the selected cycle
and spin speed.
Cycle Guide
For best fabric care, choose the cycle that best ts the load being washed. Recommended settings for best performance are shown
in Bold. Not all cycles and options are available on all models.
Items to wash: Cycle: Temperature:* Spin
Speed: Cycle Details:
Heavily soiled no-
iron fabrics, cottons,
permanent press,
linens, synthetics
Heavy Hot
Warm
Cool
Cold
Tap Cold
Low Use this cycle to wash heavily soiled loads of no-iron
fabrics such as sport shirts, blouses, casual business
clothes, permanent press, and blends.
No-iron fabrics,
cottons, permanent
press, linens,
synthetics
Regular Hot
Warm
Cool
Cold
Tap Cold
Low Use this cycle to wash loads of no-iron fabrics such
as sport shirts, blouses, casual business clothes,
permanent press, and blends.
Lightly soiled
no-iron fabrics,
cottons, permanent
press, linens,
synthetics
Light Hot
Warm
Cool
Cold
Tap Cold
Low Use this cycle to quickly clean a small number of lightly
soiled no-iron fabrics such as sport shirts, blouses,
casual business clothes, permanent press, and blends.
Large items such
as sheets, sleeping
bags, small
comforters, jackets,
small, washable
rugs. Sturdy fabrics,
colorfast items,
towels, jeans
Super
Heavy Hot
Warm
Cool
Cold
Tap Cold
High Provides maximum wash time and action for tough
stains and soils. Use this cycle for heavily soiled or
sturdy items, as well as large items such as jackets
and small comforters.
Cottons, linens,
and mixed-garment
loads
Regular Hot
Warm
Cool
Cold
Tap Cold
High Use this cycle for normally soiled cottons and
mixed-fabric loads.
Bright or darkly
colored cottons,
linens, casual and
mixed loads
Light Hot
Warm
Cool
Cold
Tap Cold
High Use this cycle to quickly wash a small number of lightly
soiled cottons and mixed fabric loads.
CASUALNORMAL
*All rinses are cold.
