WideFly WF43 User manual

WF43 POS PDA Quick Start Guide
WF43 w/ MSR
WF43 w/ Barcode Scanner

WF43 POS PDA Quick Start Guide
Copyri ht
Copyright 2011 Widefly Limited. All rights reserved.
Product specifications and features are for reference
only and are subject to change ithout prior notice.
Declaration
This document is published by Widefly Limited
ithout any arranty.
Improvements and changes to this document
necessitated by typographical errors, inaccuracies of
current information, or improvements to programs
and/or equipment, may be made by Widefly Limited
any time and ithout notice. Such changes ill,
ho ever, be incorporated into ne editions of this
Guide.
FCC Statement
This device complies ith Part 15 of the FCC Rules.
Operation is subject to the follo ing t o conditions:
1．This device may not cause harmful interference, and
2．This device must accept any interference received,
including interference that may cause undesired
operation.
Changes or modifications not expressly approved by the
party responsible for the compliance could void the users’
authority to operate the equipment.
This equipment has been tested and found to comply
ith the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to

WF43 POS PDA Quick Start Guide
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance ith the
instructions, may cause harmful interference to radio
communications. Ho ever, there is no guarantee that
interference ill not occur in a particular installation.
If this equipment does cause harmful interference to
radio or television reception, hich can be determined by
turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the
follo ing measures:
- Reorient or relocate the receiving antenna.
- Increase the separation bet een the equipment and
receiver.
- Connect the equipment into an outlet on a circuit
different from that to hich the receiver is connected.
- Consult the dealer or an experienced radio/TV
technician for help.
SAR Statement
This equipment complies ith FCC radiation exposure
limits set forth for an uncontrolled environment. End user
must follo the specific operating instructions for
satisfying RF exposure compliance. This transmitter must
not be co-located or operating in conjunction ith any
other antenna or transmitter.
The mobile device is designed to meet the requirements
for exposure to radio aves established by the Federal
Communications Commission (USA). These

WF43 POS PDA Quick Start Guide
requirements set a SAR limit of 1.6 W/kg averaged over
one gram of tissue. The highest SAR value reported
under this standard during product certification for use
hen properly orn on the body is 1.15 W/kg.
IC Statement
This device complies ith Industry Canada
license-exempt RSS standard(s). Operation is subject to
the follo ing t o conditions: (1) this device may not
cause interference, and (2) this device must accept any
interference, including interference that may cause
undesired operation of the device.
This Class【B】 digital apparatus complies ith Canadian
ICES-003.
Cet appareil s’accorde avec Industrie Canada
licence-exempte RSS standard.
(1) cet appareil ne peut pas causer l’intervention, et (2)
cet appareil doit accepter de l’intervention, y compris
l’intervention qui peut causer l’opération non désirée de.
Cet appareil numérique de la classe B est conforme à la
norme
NMB-003 du Canada.
Cet appareil a été certifié conforme à la réglementation
gouvernementale en matière d’exposition aux ondes
radio. Lors d’une communication par le réseau sans fil, ce
mobile émet par le biais des radiofréquence de faibles
niveaux d’énergie radio. Le Taux d’absorption spécifique,
TAS, est la quantité d’énergie RF absorbée par le corps

WF43 POS PDA Quick Start Guide
lors de l’utilisation du appareil. Il est exprimé en
atts/kilogramme (W/kg). De nombreux gouvernements
ont adopté des consignes de sécurité internationales
complètes développées par des organes scientifiques,
tels que l’ICNIRP (International Commission on
Non-Ionizing Radiation Protection) et l’IEEE (Institute of
Electrical and Electronics Engineers Inc.). Ces études
scientifiques ont été soumises à des
évaluations périodiques et approfondies. Ces consignes
définissent les niveaux d’exposition aux ondes radios
tolérés pour l’ensemble de la population. Les tests SAR
ont été menés d’après des méthodes standard avec une
transmission fonctionnant au niveau de puissance certifié
le plus élevé sur toutes les bandes de fréquence
employées. Ces données SAR concernent les résidents de
tous les pays qui ont adopté la limite de SAR
recommandée par l’ICNIRP on Non-Ionizing Radiation
Protection), notamment l’Union européenne, le Japon, le
Brésil et la Nouvelle- Zélande. La limite préconisée par
l’ICNIRP est de 2.0 W/kg sur une moyenne de 10 g de
matière.

WF43 POS PDA Quick Start Guide
Important safety information
Please read this carefully before using WF43 POS PDA.
Al ays treat the product ith care and keep it in a
clean and dust-free place.
Do not expose the unit to moisture or humidity.
Do not expose the unit to extreme high or lo
temperatures.
Do not attempt to disassemble the unit
Use only the po er adaptors, charging cradle and
batteries approved by Widefly Limited. The use of
any other type may invalidate any approval and
arranty.
The socket outlet for the po er adaptor shall be
installed near the equipment and shall be easily
accessible.
No reverse polarity charging ith other po er
adaptors/chargers, they may have inverse polarity.
Never use the po er adaptor/chargers if the plug is
damaged.
Never touch the charger/po er adaptor if your
hands/feet are et.
Do not expose the charger/po er adaptor to ater, it
may cause electrical fires.
Do not repair the charger/po er adaptor by yourself
for your safety.
To reduce the risk of fire and burns, do not
disassemble, crush or puncture the battery.
Dispose of used batteries according to the
instructions.
Do not dispose of the battery in fire or ater.
Do not let the metal contacts on the battery touch

WF43 POS PDA Quick Start Guide
other metal object. It could lead to short-circuit and
damage the battery.
Only approved batteries, chargers/po er adaptors
that are designed for the model can be used ith the
unit.
Risk of explosion if battery is replaced by an incorrect
type.
Do not exchange ith rong model battery. It may
cause explosion. Please dispose battery follo ing
instruction.

WF43 POS PDA Quick Start Guide
Table of Contents
1. Overview................................................... 1
1.1. WF43 Overview ................................... 1
1.2. Insertin and Removin Battery .......... 4
1.3. Char in Battery ................................. 5
1.4. LED Li ht Status .................................. 7
1.5. System Info ......................................... 8
1.6. Product Info & Label ............................ 9
2. Gettin Started ........................................10
2.1. Turn ON/OFF ......................................10
2.2. System Sleep Mode & Wakeup ............11
2.3. Wi-Fi Basic Settin s ............................12
2.1. Bluetooth Basic Settin s .....................14

WF43 POS PDA Quick Start Guide
P.1
1. Overview
1.1. WF43 Overview
Main / Programmable LED
Ambient Light Sensor
Protective Flip Cover
Touch Panel & LCD
Front
Without
Flip Cover

WF43 POS PDA Quick Start Guide
P.2
*For example: MSR (Magstripe Card Reader), Laser Barcode
Scanner, RFID Reader. The USB host is NOT designed for
data communication bet een PC.
*USB Host for External
Detachable Devices
Hand Strap Hole
Speaker
Battery Cover
Hand Strap Hole
Battery Cover Latch
Stylus
Strap Hole
Rear

WF43 POS PDA Quick Start Guide
P.3
USB Host for External
Detachable Devices
Po er Key
Shortcut Key (Left)
Shortcut Key (Right)
MicroSD Card Slot
Stylus
Strap Hole
Strap Hole
USB (for Charging
& ActiveSync)
Headset Jack
Reset Key
Microphone
Bottom
Top
Left
Ri
ht

WF43 POS PDA Quick Start Guide
P.4
1.2. Insertin and Removin Battery
Inserting Battery
Align the battery metal contacts ith the contacts
inside the battery compartment.
Press the battery do n ards until it fits the battery
compartment. Push the battery until it is locked
automatically
Removing Battery
Turn off the PDA by press-and-holding the po er key
for 2 seconds. Press “OK” on the “Po er off” dialog
box. (Please refer to 2.1 Turn ON/OFF)
Open the battery cover. Push the battery lock to the
left and hold it.
Gently lift the battery by pulling the strap attached to
the battery top position.
Battery Lock

WF43 POS PDA Quick Start Guide
P.5
1.3. Char in Battery
The battery can be charged by the follo ing:
Plug in the USB po er adaptor to PDA’s bottom USB
socket.
WF43 Charging Cradle
Note: the USB terminal as loaded ith 5V (DC),
100mA during normal condition.
USB Socket
Charge the battery
standalone
Plug in the PDA on
the cradle

WF43 POS PDA Quick Start Guide
P.6
WF43 USB Po er Adaptor:
Manufacturer: Shenzhen Wanhaitong Electronic tech
LTD
Model: WHT0052000CN
Input: 100-240V(AC) 50/60Hz
Ouput: 5V (DC) 2A
Note: The socket outlet shall be installed near the
equipment and shall be easily accessible

WF43 POS PDA Quick Start Guide
P.7
1.4. LED Li ht Status
The main LED has different status:
Amber flash – charging in process
Green – battery fully charged
Red flash – battery lo
Red – battery very lo
Blue flash quickly – Wi-Fi searching
Blue flash slo ly – Wi-Fi connected
Blue flash like breathing – Wi-Fi in sleep mode
Off –Wi-Fi disconnected or the unit is off

WF43 POS PDA Quick Start Guide
P.8
1.5. System Info
Start > Settings > System Info, page “S/N” &
“Version” retrieve important info, for example, PDA
S/N, ROM version
Note: S/N and ROM version info could also be seen
hen PDA is booting up.

WF43 POS PDA Quick Start Guide
P.9
1.6. Product Info & Label
To see the product info label as ell as certification
info, open the battery cover.
Manufacturer: Widefly Ltd.
Product Name: POS PDA
Model No.: WF43
Input: 5V (DC), 500mA
Rating: 3.7V 2670mAh

WF43 POS PDA Quick Start Guide
P.10
2. Gettin Started
2.1. Turn ON/OFF
Turn ON
Press and hold the po er key for 1 second.
When green LED is sho n, the unit is ready to boot
up to the Windo s Mobile operating system.
When red LED is seen, battery level is very lo and is
insufficient to boot up the unit. A arning screen
ill be displayed belo . To restore to the minimum
required po er, charge the unit for 10 to 15 minutes.

WF43 POS PDA Quick Start Guide
P.11
Turn OFF
Press and hold the po er key for 2 second.
Press “OK” on the “Po er off” dialog box.
2.2. System Sleep Mode & Wakeup
System Sleep Mode (Po er Saving)
To enter Sleep Mode hen the screen is ON
Press po er key or
Put the unit upside do n for 5 seconds and enable
auto screen off. (Please refer to 3.3 G-Sensor)
Note: “Sleep Mode” is a unique po er saving feature
innovated by Widefly. This mode enables exceptionally
lo po er consumption like po er off status hile the
Wi-Fi connection could still be kept. This mode
empo ers “Al ays-on Wi-Fi” even the system is in deep
sleep status.
System Wakeup
To akeup the system from “sleep mode”, simply press
po er key.
