CK65
Mobile Computer for use in Hazardous Locations
CK65 NI (CK65-L0N-xxxxx1F)
Quick Start Guide
CK65-HZ-A-EN-QS-01 Rev A
2/20

1
Introduction
This document is only for CK65 models marked as certified for
use in hazardous environments. CK65 models intended for use
in hazardous locations are identifiable by specific labeling on
the back of the device.
Out of the Box
Make sure that your shipping box contains these items:
• CK65 mobile computer
• Rechargeable 3.6 VDC Li-ion battery
•Handstrap
•I/Ocover
• Product documentation
If you ordered accessories for your mobile computer, verify that
they are also included with the order. Be sure to keep the original
packaging in case you need to return the mobile computer for
service.
Before you attempt to use, charge or replace the
battery in the device, carefully read all labels,
markings and product documentation provided in the
box or online at www.honeywellaidc.com.
Avant d’essayer d’utiliser, de charger ou de remplacer
la batterie de l’appareil, lisez attentivement toutes les
étiquettes, marquages et documentation du produit
fournis dans la boîte ou en ligne à
www.honeywellaidc.com.

2
Memory Card Specifications
Honeywell recommends the use of Single Level Cell (SLC)
industrial grade microSD™ or microSDHC™ memory cards with
mobile computers for maximum performance and durability.
Contact a Honeywell sales representative for additional
information on qualified memory card options.
Equipment for Use in Hazardous Locations
Routine operator inspections should occur to check for possible
device damage before using the mobile computer in areas
known to be hazardous.
Caution: Improper battery replacement or incompatible
device usage may result in risk of burns, fire, explosion, or
other hazard. Dispose of batteries according to local
regulations.
Mesee en garde: Le remplacement incorrect de la pile ou
l’usage d’un appareil non compatible peut représenter des
risques de brûlures, d’incendie, d’explosion ou d’autres
dangers. Éliminez les piles lithium-ion usagées
conformément aux réglementations locales.
Warning: Explosion Hazard - Batteries must only be changed
or charged in an area known to be non-hazardous.
Use ONLY Honeywell CK65 battery part number 
318-063-003 (Li-ion, 3.6 VDC).
Risqued’explosion-Les batteries doivent uniquement être
remplacées ou rechargées dans un endroit non dangereux.
Utilisez UNIQUEMENT Honeywell CK65 batterie 
P/N 318-063-003 (Li-ion, 3.6 VDC).
Do not remove the I/O cover in the hazardous area or
attempt to make an I/O connection.
Ne pas retirer le capot E / S dans un environnement
dangereux ni essayer de réaliser une connexion via les E / S
dans un environnement dangereux.

3
Charging accessories and additional spare batteries must
not be carried into the hazardous area.
Les accessoires de charge et les batteries de rechange
supplémentaires ne doivent pas être transportés dans un
environnement dangereux.
Warning: Explosion Hazard - Substitution of any
components may impair suitability.
Avertissement: Risque d’explosion - La substitution de
composants peut nuire à l’aptitude aux emplacements.
Warning: The device must be protected from impacts with
high impact energy, permanent UV light emission and high
electrostatic discharge processes.
Avertissement: Avertissement: L’appareil doit être protégé
contre les chocs énergétique à fort impact, l’émission
permanente de lumière UV, et les processus de décharge
électrostatique élevés.

4
Mobile Computer Features
Microphone
Power Button
Ambient Light
Sensor
Touch Panel
Keyboard
(model dependent)
Notification/Scan/
Battery Status LEDs
Imager (LED / Laser Aperture)
Keypad Status LEDs
Scan Buttons
All Imagers

5
Camera Lens
and Flash
(optional)
Battery Latch
(under hand strap)
Laser Safety 
Label Location
Scan/Aux Button
Hand Strap
I/O Cover
Scan/Aux
Button
CK65 Model with N6803 Imager
MicroSD Card Door
(battery and hand strap removed)
I/O Connector
(I/O cover removed)
All CK65 Units
Speaker
Port Speaker Port

6
Camera Lens
and Flash
(optional)
MicroSD Card Door
(battery and hand strap removed)
I/O Connector
(I/O cover removed)
Battery Latch
(under hand strap)
Laser Safety 
Label Location
Scan/Aux Button
Hand Strap
I/O Cover
Scan/Aux
Button
CK65 Model with EX20 Imager
All CK65 Units
Speaker
Port Speaker Port

7
Install a microSD Card (Optional)
See "Install the Battery" for hand strap release information.
Format the microSD card before initial use.
Always power off the computer before attempting to
install or remove a card.
1 2
4
3

8
Install the Battery
The CK65 mobile computer ships with a Li-ion 3.6 VDC, 
25.2 watt-hour battery manufactured for Honeywell
International Inc.
Before you attempt to use, charge or replace the
battery in the mobile computer, carefully read all the
information under "Equipment for Use in Hazardous
Locations".
Avant d’essayer d’utiliser, de charger ou de remplacer
la batterie de l’ordinateur portable, lisez
attentivement toutes les informations relatives aux
"Equipment for Use in Hazardous Locations".

9
Ensure all components are dry prior to placing the
battery in the computer. Mating wet components may
cause damage not covered by the warranty.
Assurez-vous que tous les composants sont secs
avant de placer la batterie dans l’ordinateur.
L’insertion de composants humides risque de
provoquer des dommages non couverts par la
garantie.
Battery must be latched when using the CK65 in a
hazardous environment.
AVERTISSEMENT: la batterie doit être verrouillée lors
de l’utilisation du CK65 dans un environnement
dangereux.
1
2
3
4

10
Charge the Mobile Computer
The CK65 mobile computer ships with a partially charged
battery. Charge the battery with a CK3 Series charging device
for a minimum of 4 hours. Using the computer while charging
the battery increases the time required to reach a full charge.
CK65 mobile computers are designed for use with CK3 Series
charging accessories.
Before you attempt to use, charge or replace the
battery in the mobile computer, carefully read all the
information under "Equipment for Use in Hazardous
Locations".
Avant d’essayer d’utiliser, de charger ou de remplacer
la batterie de l’ordinateur portable, lisez
attentivement toutes les informations relatives aux
"Equipment for Use in Hazardous Locations".
We recommend the use of Honeywell accessories and
power adapters. Use of any non-Honeywell
accessories or power adapters may cause damage not
covered by the warranty.
Mise en garde: Il est recommandé d'utiliser les
périphériques, les cordons d'alimentation et les
adaptateurs secteur conçus par Honeywell.
L'utilisation de tout périphérique, cordon
d'alimentation ou adaptateur secteur d’une autre
marque est susceptible de provoquer des dommages
non couverts par la garantie.
Ensure all components are dry prior to mating the
computers and batteries with peripheral devices.
Mating wet components may cause damage not
covered by the warranty.
Mise en garde: Assurez-vous que tous les composants
sont secs avant de connecter les terminaux/batteries
à des périphériques. L’insertion de composants
humides risque de provoquer des dommages non
couverts par la garantie.

11
Remove the I/O Cover
Remove the I/O cover before inserting the CK65 into a charging
dock:
Turn Power On/Off
The first time you power on the computer, a Welcome screen
appears. You can either scan a configuration barcode or use the
Wizard to manually set up the computer. Once setup is
complete, the Welcome screen no longer appears on startup
and Provisioning mode is automatically turned off (disabled).
To turn the computer on:
•PressandholdthePower button for approximately 3 seconds,
and then release.
To turn the computer off:
1. Press and hold the Power button until the options menu
appears.
2. Touch Power off.
Warning: The I/O cover must be attached when using
the CK65 in a hazardous environment.
Avertissement : Le couvercle entrée-sortie doit être
fixé lorsque le CK65 est utilisé dans un
environnement incendiaire.

12
Battery Replacement
Hot Swap
You can replace the battery on demand provided the following
conditions are met:
• The computer has been powered on for at least 4 minutes.
AND
• You insert a new battery within 30 seconds.
Swap Battery Mode
Swap Battery mode places the computer in a low power state so
that the battery can be removed for a short time.
To activate Swap Battery mode:
1. Press and hold the Power button until the options menu
appears.
2. Touch Swap Battery and follow the on-screen instructions.
3. Once you replace the battery, press the Power button.
Sleep Mode
Sleep mode automatically turns the touch panel display off and
locks the computer to save battery power when the computer is
inactive for a programmed period of time.
Before you attempt to use, charge or replace the
battery in the mobile computer, carefully read all the
information under "Equipment for Use in Hazardous
Locations".
Avant d’essayer d’utiliser, de charger ou de remplacer
la batterie de l’ordinateur portable, lisez
attentivement toutes les informations relatives aux
"Equipment for Use in Hazardous Locations".

13
1. Press and release the Power button to wake the computer.
2. Drag the toward the top of the display to unlock the
computer.
About the Home Screen
Notification /Status Bar
Search Bar
Home Screen Panel
Favorites Tray
Navigation Buttons

14
Navigation and Function Buttons
For button locations, see "Mobile Computer Features".
About Provisioning Mode
After completing the out-of-box set up process, Provisioning
mode is automatically turned off. Scanning a barcode to install
applications, certificates, configuration files, and licenses on
the computer is restricted unless you enable Provisioning mode
in the Settings app. To learn more, see the user guide.
Button Description
Back Return to the previous screen.
Home Return to the Home screen.
Recent Apps View and switch between
recently used apps.
Scan Press the right, left or front
scan button to trigger the
scanner.

15
Scan a Barcode with the Scan Demo
Note: For optimum performance, avoid reflections by scanning the
barcode at a slight angle.
1. Swipe up from the bottom of the Home screen to access all
apps.
2. Touch Demos > Scan Demo.
3. Point the computer at the barcode.
4. Touch Scan on the touch screen or press and hold any Scan
button. Center the aiming beam over the barcode.
The decode results appear on the screen.
Note: In the Scan Demo app, not all barcode symbologies are enabled by
default. If a barcode does not scan, the correct symbology may not
be enabled. To learn how to modify the default app settings, see
the user guide.

16
Sync Data
To move files between your CK65 and a computer:
1. Connect the CK65 to your computer using a USB charge/
communication accessory.
2. On the CK65, swipe down from the top of the screen to see
the notifications panel.
3. Touch the Android System notification twice to open the
options menu.
4. Select either File Transfer or PTP.
5. Open the file browser on your computer.
6. Browse to the CK65. You can now copy, delete and move
files or folders between the computer and CK65 as you
would with any other storage drive (e.g., cut and paste or
drag and drop).
Note: When Provisioning mode is turned off, some folders are hidden
from view in the file browser.
Restart the Mobile Computer
You may need to restart the mobile computer to correct
conditions where an application stops responding to the system
or the computer seems to be locked up.
1. Press and hold the Power button until the options menu
appears.
2. Select Restart.

17
To restart the computer if the touch panel display is
unresponsive:
•PressandholdthePower button for approximately 8 seconds
until the computer restarts.
Note: To learn about advanced reset options, see the user guide.
Support
To search our knowledge base for a solution or log into the 
Technical Support Portal and report a problem, go to 
www.hsmcontactsupport.com.
Documentation
Product documentation is available at www.honeywellaidc.com.
Limited Warranty
For warranty information, go to www.honeywellaidc.com and
click Resources > Product Warranty.
Patents
For patent information, see www.hsmpats.com.
Trademarks
Google, Android, Google Play and other marks are trademarks of
Google LLC.

18
Disclaimer
Honeywell International Inc. (“HII”) reserves the right to make
changes in specifications and other information contained in
this document without prior notice, and the reader should in all
cases consult HII to determine whether any such changes have
been made. The information in this publication does not
represent a commitment on the part of HII.
HII shall not be liable for technical or editorial errors or
omissions contained herein; nor for incidental or consequential
damages resulting from the furnishing, performance, or use of
this material. HII disclaims all responsibility for the selection
and use of software and/or hardware to achieve intended
results.
This document contains proprietary information that is
protected by copyright. All rights are reserved. No part of this
document may be photocopied, reproduced, or translated into
another language without the prior written consent of HII.
Copyright © 2020 Honeywell International Inc. All rights
reserved.
