Wido WD010221100 User manual

Impact drill WD010221100
1100W

WD010221100
Thank you for purchasing a WIDO product. We are confident that you will appreciate the
quality of the product and you will be entirely satisfied with your purchase. Please read
carefully the usersafety and operating instruction on how to operate this product correctly
within safety norms and regulations.
2

WD010221100
3
1243
5
6
7 8 9

WD010221100
4
1
2
RL
t
32
4
7
5 6
1

1100W IMPACT DRILL ENG
COMPONENT LIST
1) Chuck
2) Depth gauge
3) Two speed control
4) Drill/impact action selector switch
5) Lock on button
6) Switchtrigger
7) Variable speed control
8) Forward/reverse rotation selector switch
9) Auxiliary handle
NORMAL ACCESSORIES
1) Auxiliary handle: 1pc
1pc
1pc
2) Depth gauge:
3) Chuck key:
4) Spare carbon brush: 1set
We recommend that you purchase your accessories from the same store that sold you the tool.
Use good quality accessories marked with a well-known brand name. Choose the type according to
the work you intend to undertake. Refer to the accessory packaging for further details. Store
personnel can assist you and offer advice.
5

1100W IMPACT DRILL ENG
GENERAL POWER TOOL SAFETY WARNINGS
Warning: Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust.Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause
you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use
any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets
will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges
and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use.
Use of acord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or
medication. A moment of inattention while operating power tools may result in serious personal
injury.
b) Use personal protective equipment. Always wear eye protection. Protective equipment
such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting
to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with
your finger on the switch or energising power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times.This enables better control
of the power tool in unexpected situations.
6

1100W IMPACT DRILL ENG
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and
gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving
parts.
g) If devices are provided for the connection of dust extraction and collection facilities,
ensure these are connected and properly used. Use of dust collection can reduce dust-related
hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off.Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the power tool
before making any adjustments, changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar
with the power tool or these instructions to operate the power tool. Power tools are dangerous
in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of
parts and any other condition that may affect the power tool’s operation. If damaged, have
the power tool repaired before use.Many accidents are caused by poorly maintained power
tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of the power
toolfor operations different fromthose intended could result in a hazardous situation.
5) Service
a) Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
ADDITIONAL SAFETY INSTRUCTIONS FOR YOUR POWER TOOL
1) Wear ear protectors with power tool. Exposure to noise can cause hearing loss.
2) Use auxiliary handles supplied with the power tool. Loss of controlcan cause personal injury.
3) Wear safety goggles or eye protection when using this power tool. Use a dust mask or
respirator for applications which generate dust.
4) Hold power tool by insulated gripping surfaces when performing an operation where the cutting
accessory may contact hidden wiring or its own cord. Cutting accessory contacting a ‘live’ wire will
make exposed metal parts of the power tool ‘live’ and could give the operator an electric shock.
5) Always check walls and ceilings to avoid hidden power cables and pipes. Contact with electric
lines can lead to fire and electric shock. Damaging a gas line can lead to explosion. Penetrating a
water line causes property damage. A metal detector can be obtained from any good DIY store for
this purpose.
6) Use clamps or other practical way to secure and support the workpiece to a stable platform, if
possible. Holding the work by hand or against your body is unstable and may lead to loss of control.
7

1100W IMPACT DRILL ENG
7) Do not use damaged or worn drill bits.
8) Make sure drill bit are tightened securely in chuck.
9) Do not start the drill with the chuck key in chuck.
10) Be sure no one is below when using the tool in high locations.
11)After long working periods, external metal parts and accessories could be hot.
12) Before you lay down the power tool, make sure that all moving parts have come to a stop.
13) When an extension cord is required you must ensure it has the correct ampere rating for your
power tool and that it is in a safe electrical condition.
14) Fully unwind extension cordsto avoid potential overheating.
DOUBLE INSULATION
The power tool is double insulated. This means that all the external metal parts are electrically
insulated from the main power supply. This is done by placing insulation barriers between the
electrical and mechanical components making it unnecessary for the power toolto be earthed.
IMPORTANT NOTE
Be sure the supply is the same as the voltage given on the rating plate. The power tool is fitted with
atwo-core cable and plug.
Remove the main plug from socket before carrying out any adjustment or servicing.
SYMBOLE
To reduce the risk of injury, user must read instruction manual
Double insulation
Warning
Wear ear protection
Wear eye protection
Wear dust mask
Waste electrical products should not be disposed of with household waste. Please recycle
where facilities exist. Check with your Local Authority or retailer for recycling advice
TECHNICAL DATA
Model WD010221100
Voltage 110-120V AC 220-240V AC
Frequency 50-60Hz 50-60Hz
Power input 1100W 1100W
No load speed 0-1200/0-3000/min 0-1200/0-3000/min
Impact rate 0-17600/0-48000/min 0-17600/0-48000/min
Max. drilling
capacity
Concrete 5/8″Φ16mm
Steel1/2″Φ13mm
Wood1-9/16″Φ40mm
Chuck capacity 1/8″- 5/8″Φ3-16mm
Protection class
Machine weight 3.7Kg 3.7Kg
8
//

1100W IMPACT DRILL ENG
OPERATING INSTRUCTIONS
NOTE: Before using the power tool, read the instruction manual carefully.
1. Intended use
The machine is intended for impact drilling in brick, concrete and stone as well as for drilling in
wood, metal and plastic. Machines with electronic control and right/left rotation are also suitable for
screwdriving and thread-cutting.
2. Before using your power tool
1) Be careful of hidden electrical lines or gas and water pipes. Check the working area, e.g., with a
metal detector.
2) Ensure that the power switch is in the off position. If the plug is connected to a power receptacle
while the power switch is in the on position, this power tool will start operating immediately, inviting
serious accident.
3. Adjusting the auxiliary handle
To adjusting the auxiliary handle, loosen the locking screw for handle collar in anticlockwise
direction. Rotate the handle around the handle collar until the handle is in the desiredposition.
Tighten the locking screw in clockwise direction to secure the handle (See Fig 1).
Note: For your personal safety we recommend using the auxiliary handle at all times.
4. Inserting the tool into chuck
Remove chuck key from key storage tab at base of power toolhandle, place key into chuck, turning
the key in anticlockwise direction to loosen chuck, inset tool and firmly tighten chuck by turning key
in clockwise direction (See Fig 2). Remove key and replace in storage tab at base of power tool
handle.
Warning: Before installing tool, remove mains plug from mains supply.
5. Installing the depth gauge
The depth gauge can be used to set a constantdepth to drill. To use the depth gauge, loosen the
locking screw for depth gauge by rotating the auxiliary handle in anticlockwise direction. Insert the
depth gauge through hole in handle. Slide the depth gauge to required depth and tighten fully (See
Fig 3).
6. Operating the on/off switch
1) To start the power tool, simply depress the switch trigger. The power tool speed is increased by
increasing pressure on the switch trigger. Release the switchtrigger to stop your power tool.
2) If you wish to use the power tool continuously, depress switch trigger then lockon button, release
switch trigger first and lock on button second (See Fig 4). Your switch is now locked on for
continuous use. To turn off yourpower tool just depress and release the switch trigger. The switch
will return to "off"position automatically.
7. Variable speed control
Adjust the variable speed control to increase or decrease the speed according to the material and
9

1100W IMPACT DRILL ENG
accessory to be used. Turn the variable speed control in clockwise direction to increase speed and
in anticlockwise direction to decrease speed (See Fig 5). High speed gives higher torque and low
speed will provide low torque.
Warning: Do not operate for long periods at low speed because excess heat will be
producedinternally.
8. Forward/reverse rotation selector switch
This power tool has a forward and reverse selector switch to change the direction of rotation. For
drilling and screw driving use forward rotation marked “R” (selector switch is moved to the left of
power tool). Only use reverse rotation marked “ L” (selector switch is moved to the right of power
tool) to remove screws or release a jammed drill bit (See Fig 5).
Note: Never move the forward andreverse rotation selector switch whilst the power tool in
operation or the on/off switch is locked as this will damage your power tool.
9. Drill/impact action selector switch
10. Two speed control
Choose position “1” for high torqueand low speed range for large diameter drill bits and
screwdriving.Choose position “2” for low torque and high speed range for small diameter drill bits
(See Fig 7). If the gearsdo not engage easily, rotate the chuck by hand to align the gears. Never
change the gears when the tool is rotating, wait until it hasstopped.
WORKING HINTS FOR YOUR POWER TOOL
1 Drilling masonry and concrete
Select the drill/impact action selector switch to the “hammer symbol” position. Tungsten carbide drill
bits should always be usedfor drilling masonry, concrete etc with a high speed.
2 Drilling steel
Select the drill/impact action selector switch to the “drill symbol” position. HSS drill bits should
always be used for drilling steel with a lower speed.
3Pilot holes
When drilling a large hole in tough material (i.e. steel), we recommend drilling a small pilot hole first
before using a large drill bit.
4 Drilling tiles
Select the drill/impact action selector switch to the “drill symbol” position to drill the tile. When tile
has been penetrated, switch over to “hammer symbol” position.
5 Cool the motor
If your power tool becomes too hot, set the speed to maximum and run no load for 2-3 minutes to
coolthe motor.
MAINTENANCE
Warning: Remove the plug from the socket before carrying out any adjustment,
servicing or maintenance.
10
For drilling masonry and concrete, push the drill and impact action selector switch to sign “ ”. For
drilling in wood, metal, plastic and use as a screwdriver, push the drill and impact action selector
switch to sign “ ” (See Fig 6).

1100W IMPACT DRILL ENG
1. Keep the power toolventilation slots clean and free from obstructions. If available, blow
compressed air into the vents to clear any internal dust (safety goggles must be worn when
undertaking this process).
2. Never use water or chemical cleaners to clean your power tool. Wipe clean with a dry cloth.
3. Your power toolrequires no additional lubrication.
4. Always store your power tool in a dry place.
5. If you see some sparks flashing in the ventilation slots, this is normal and will not damage your
power tool.
6. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
TROUBLESHOOTING
1. If yourpower tool will not operate, check the power at the mains plug, or check the carbon
brushes.
2. If the drill doesn’t work properly, check the drill bit for sharpness, replace drill bit if worn. Check
that the drill is set to forward rotation for normal use.
3. If a fault can’t be rectified, return the power toolto an authorized dealer for repair.
ENVIRONMENT PROTECTION
Waste electrical products should not be disposed of with household waste. Please recycle
where facilities exist. Check with your Local Authority or retailer for recycling advice.
11

1100W IMPACT DRILL ENG
EXPLOSIVE VIEW
12

1100W IMPACT DRILL ENG
PART LIST
NO DESCRIPTION Q’TY NO DESCRIPTION Q’TY
1 Depth gauge 1 31 Clutch 1
2 Auxiliary handle 1 32 Slide gear 1
3 Left head screw 1 33 Spacer 1
4 Chuck 1 34 Spring 1
5 Circlip 1 35 Bearing 1
6 Washer 2 36 Seal ring 1
7 Seal ring 1 37 Impact action selector 1
8 Output spindle 1 38 Spring 1
9 Steel ball 2 39 Steel ball 1
10 Bearing 1 40 Shift plate of impact action 1
11 Rotating impact ratchet 1 41 Mid support 1
12 Fixed impact ratchet 1 42 Bearing 1
13 Screw 4 43 Rotor 1
14 Spring 2 44 Bearing 1
15 Two speed control 1 45 Bearing sleeve 1
16 Steel ball 2 46 Stator 1
17 Circlip 1 47 Right housing 1
18 Gear case 1 48 Screw 7
19 Shifting fork 1 49 Nameplate 1
20 Slide pin 1 50 Switch 1
21 Pin 2 51 Chuck key 1
22 Washer 1 52 Screw 2
23 Circlip 1 53 Cable clamp 1
24 Gear 1 54 Cable and plug 1
25 Woodruff key 1 55 Cable protector 1
26 Intermediate gear 1 56 Brush holder 2
27 Needle bearing 1 57 Screw 4
28 Needle bearing 1 58 Carbon brush 2
29 Slide gear 1 59 Left housing 1
30 Locating pin 2 60 Label 1
13

WD010221100
14

15
WD010221100

www.widopt.com
MADE IN CHINA
Copyright @ WIDO Machinery Co., Ltd. All rights reserved.
