William Sound Pocketalker 2.0 PKT 2.0 User manual

English
1
Pocketalker®2.0
Personal Amplifier Model PKT 2.0
USER Manual
MAN 181E

English
2
Contents
Safety Warnings .....................................................................3
Overview ................................................................................5
Included Items........................................................................5
Getting Started.......................................................................6
Recharging NiMH Batteries ..................................................10
Listening during conversations with others ...........................11
Extending the Microphone....................................................12
Using an Optional Neckloop.................................................13
Using the Lanyard ................................................................14
LED Indicators......................................................................16
Hints & Tips..........................................................................17
Pocketalker® 2.0 Specications ............................................18
Limited Warranty ..................................................................19

English
3
Safety Warnings
CAUTION!
The Pocketalker is capable of producing very loud sound levels.
To prevent sound levels greater than 130dB that can potentially
damage hearing with long-term exposure, use only earphones
and headphones supplied by Williams Sound. The Williams
Sound Headphone model HED 026 should not be used with the
Pocketalker as it can produce sound levels greater than 130dB.
CAUTION!
This product is designed to amplify sounds to a high volume level
which could potentially cause hearing damage if used improperly. To
protect your hearing and the hearing of others:
1. Make sure the volume is turned down before putting on the
earphone or headphone. While wearing the earphone or
headphone, adjust the volume to a comfortable level.
2. Set the volume level at the minimum setting that you need to hear.
3. If you experience feedback (a squealing or howling sound), reduce
the volume setting and move the microphone away from the
earphone or headphone.
Do not allow children or other unauthorized persons to have access
to this product.
WARNING!
1. Do not use this apparatus near water.
2. Clean only with a damp cloth. Do not use alcohol or any other type
of cleaner.
3. Do not use near any heat sources such as radiators, heat registers,
stoves, or other apparatus that produce heat.
4. Use only attachments/accessories specied by the manufacturer.
5. Do not use the product with a neckloop in areas where the
neckloop could get pulled or caught in a machine.
SERVICING OR ATTEMPTING TO SERVICE THIS DEVICE WILL VOID THE
WARRANTY.
Refer servicing to qualied personnel. Servicing is required when
the unit has been damaged in any way; if liquid has been spilled into
the unit, it has been exposed to rain or moisture, does not operate
normally, or has been dropped.

English
4
POWER SUPPLY SAFETY WARNINGS:
1. Never charge the unit in enclosed spaces such as handbags,
cases, or other closed storage bags.
2. Unplug this device during lightning storms, or when charging is
complete and the device is unused for long periods of time.
3. Be advised that dierent operating voltages require the use of
dierent types of line cord attachment plugs. Check the line
voltage in your area and use the correct type.
4. Use only the power supply provided by the manufacturer of this
device. Other power supplies may have similar specications, but
may not be equivalent. Use of an unapproved power supply may
leave the device partially or completely inoperable, and will void
the warranty.
5. Protect the power cord from being walked on or pinched,
particularly at plugs, receptacles, and near the power jack on the
unit.
FOR CUSTOMERS IN THE UNITED STATES
This equipment has been tested and found to comply with the limits
for Class A digital device, pursuant to part 15 of the FCC rules.
CAUTION
RISK OF ELECTRICAL SHOCK — DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR SIDES). NO USER-SERVICABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL.
!
AVIS
RIQUE DE CHOC ELECTRIQUE. NE PAS OUVRIR
ATTENTION: POUR RÉDUIRE LE RISQUE DE DÉCHARGE ÉLECTRIQUE, NE
RETIREZ PAS LE COUVERCLE (OU CÔTÉS). IL NE SE TROUVE AL’INTÉRIEUR
AUCUNE PIECE POUVANT ETRE RÉPARÉE PAR L’USAGER. S’A DRESSER A
UN RÉPARATEUR COMPÉTENT.
!
FOR CUSTOMERS IN CANADA
This Class A digital device meets all requirements of the Canadian
Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe A respecte toutes les exigencies
du Règlement sur le matériel brouilleur du Canada.
CAUTION
RISK OF ELECTRICAL SHOCK — DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR SIDES). NO USER-SERVICABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL.
!
AVIS
RIQUE DE CHOC ELECTRIQUE. NE PAS OUVRIR
ATTENTION: POUR RÉDUIRE LE RISQUE DE DÉCHARGE ÉLECTRIQUE, NE
RETIREZ PAS LE COUVERCLE (OU CÔTÉS). IL NE SE TROUVE AL’INTÉRIEUR
AUCUNE PIECE POUVANT ETRE RÉPARÉE PAR L’USAGER. S’A DRESSER A
UN RÉPARATEUR COMPÉTENT.
!

English
5
Overview
The Pocketalker®2.0 is a versatile, high quality assistive
listening device designed to improve communications
in dicult listening situations. The Pocketalker delivers
clear, distinct sound, while its large, manageable
controls provide for easy operation.
Use the Pocketalker to improve listening on a one-to-
one basis, in small group situations, while listening to
your favorite TV or radio programs, or while riding in the
car.
The Pocketalker is not sold, advertised, or intended
for use as a personal hearing aid. Williams Sound
recommends that any individual experiencing hearing
loss be examined by a physician/audiologist to
determine the cause before using an amplication
device like the Pocketalker.
The Pocketalker is oered with rechargeable options.
Call Williams Sound for more information at
1-800-328-6190.
Included Items
(1) PKT 2.0 Personal Amplier
(1) BAT 010-2 Two AAA Batteries
(1) MIC 014-R Plug-Mount Microphone, Omnidirectional
(1) EAR 042 Dual Stereo Isolation Earphones
(1) HED 024 Stereo Headphones
(1) RCS 003 Lanyard
(1) WCA 007 WC 3.5 mm male to 3.5 mm female cable
with mounting clips (12 ft)

English
6
Getting Started
1. Open the battery cover: Using your thumb, apply rm pressure on the
ridges of the cover and slide it down and away from the Pocketalker.
2. Switch the Battery Type Switch to the position for the battery type
that will be used (NiMH or Alkaline).
Battery Installation
+
–
+–
A544
T-Coil Switch
(in “On” position)
T-Coil “On” LED
USB Micro-B
Charging Port
External Microphone
Jack
Battery
Compartment
Lanyard Slot
Clip
Internal Microphone
Clip
Battery
Cover
Battery
Type*
Switch
AAA
Batteries
NiMH* or
Alkaline*
Power On/Off
and
Volume Adjust
Rotary Dial
Power “On”
Green LED
Lanyard Slot
Headphone/
Earphone
Jack
Tone Adjust
Rotary Dial
NiMH
Alkaline
SLIDE
PRESS HERE
WHILE SLIDING
+
–
+–
Balance
Control
(Fully
counter-
clockwise
= Mono)
Left Right
(Mono)
Balance
Adjust
Charging LED
indicator
T-Coil Symbol
Power On
Volume+
Adjust
Volume-
Power Off
Adjust
T-coil
Switch
Tone
Adjust
Dial
*NOTE: If using rechargeable NiMH AAA batteries, the battery switch
MUST be switched to the NiMH position to allow charging!
3. Press 2 AAA batteries into place in the battery compartment,
being careful to observe correct placement of (+) and (–)
terminals.
4. Your Pocketalker system is supplied with the headphone
and earphone for best performance. Williams Sound oers
additional options - visit www.williamssound.com.
WARNING! Do not attempt to charge Alkaline batteries!

English
7
Headphone/Earphone Jack
Pocketalker ®2.0: Left Side View
+
–
+–
A544
T-Coil Switch
(in “On” position)
T-Coil “On” LED
USB Micro-B
Charging Port
External Microphone
Jack
Battery
Compartment
Lanyard Slot
Clip
Internal Microphone
Clip
Battery
Cover
Battery
Type*
Switch
AAA
Batteries
NiMH* or
Alkaline*
Power On/Off
and
Volume Adjust
Rotary Dial
Power “On”
Green LED
Lanyard Slot
Headphone/
Earphone
Jack
Tone Adjust
Rotary Dial
NiMH
Alkaline
SLIDE
PRESS HERE
WHILE SLIDING
+
–
+–
Balance
Control
(Fully
counter-
clockwise
= Mono)
Left Right
(Mono)
Balance
Adjust
Charging LED
indicator
T-Coil Symbol
Power On
Volume+
Adjust
Volume-
Power Off
Adjust
T-coil
Switch
Tone
Adjust
Dial
5. Wear the earphone or headphone so it ts comfortably.
6. Adjust the balance for the type of headphone or earphone
being used. Using a small screwdriver, turn left (or right) to
increase (or decrease) the volume level on the left or right side
of the headphones.
Note: If using a single/mono headphone/earphone or a neckloop, turn
the balance fully left (counter-clockwise) - this will maximize volume
and help to maximize battery life.
Balance Adjustment - Single/Dual Earphones
Pocketalker ®2.0: Battery Compartment
+
–
+–
A544
T-Coil Switch
(in “On” position)
T-Coil “On” LED
USB Micro-B
Charging Port
External Microphone
Jack
Battery
Compartment
Lanyard Slot
Clip
Internal Microphone
Clip
Battery
Cover
Battery
Type*
Switch
AAA
Batteries
NiMH* or
Alkaline*
Power On/Off
and
Volume Adjust
Rotary Dial
Power “On”
Green LED
Lanyard Slot
Headphone/
Earphone
Jack
Tone Adjust
Rotary Dial
NiMH
Alkaline
SLIDE
PRESS HERE
WHILE SLIDING
+
–
+
–
Balance
Control
(Fully
counter-
clockwise
= Mono)
Left Right
(Mono)
Balance
Adjust
Charging LED
indicator
T-Coil Symbol
Power On
Volume+
Adjust
Volume-
Power Off
Adjust
T-coil
Switch
Tone
Adjust
Dial
7. Close the battery compartment cover: align the cover on the
back of the unit and slide it upwards until it snaps into place.
8. Optional: If the external microphone (MIC 014-R) will be used,
plug it into the External Microphone Jack on the top of the unit.

English
8
Microphone Use / Installation
Pocketalker ®2.0: Top View
+
–
+–
A544
T-Coil Switch
(in “On” position)
T-Coil “On” LED
USB Micro-B
Charging Port
External Microphone
Jack
Battery
Compartment
Lanyard Slot
Clip
Internal Microphone
Clip
Battery
Cover
Battery
Type*
Switch
AAA
Batteries
NiMH* or
Alkaline*
Power On/Off
and
Volume Adjust
Rotary Dial
Power “On”
Green LED
Lanyard Slot
Headphone/
Earphone
Jack
Tone Adjust
Rotary Dial
NiMH
Alkaline
SLIDE
PRESS HERE
WHILE SLIDING
+
–
+–
Balance
Control
(Fully
counter-
clockwise
= Mono)
Left Right
(Mono)
Balance
Adjust
Charging LED
indicator
T-Coil Symbol
Power On
Volume+
Adjust
Volume-
Power Off
Adjust
T-coil
Switch
Tone
Adjust
Dial
9. Turn ON the Pocketalker by rolling the “Power On/O Volume
Adjust” rotary dial (located on the front) towards the top. The
power “on” green LED indicator on the front of the unit should
light up. As you rotate the knob further towards the top, the
volume will get louder.
Power On / Volume Adjustment Dial
Pocketalker®2.0: Front View
+
–
+–
A544
T-Coil Switch
(in “On” position)
T-Coil “On” LED
USB Micro-B
Charging Port
External Microphone
Jack
Battery
Compartment
Lanyard Slot
Clip
Internal Microphone
Clip
Battery
Cover
Battery
Type*
Switch
AAA
Batteries
NiMH* or
Alkaline*
Power On/Off
and
Volume Adjust
Rotary Dial
Power “On”
Green LED
Lanyard Slot
Headphone/
Earphone
Jack
Tone Adjust
Rotary Dial
NiMH
Alkaline
SLIDE
PRESS HERE
WHILE SLIDING
+
–
+–
Balance
Control
(Fully
counter-
clockwise
= Mono)
Left Right
(Mono)
Balance
Adjust
Charging LED
indicator
T-Coil Symbol
Power On
Volume+
Adjust
Volume-
Power Off
Adjust
T-coil
Switch
Tone
Adjust
Dial
10.Adjust the volume up or down according to your preferences
by rotating the volume dial towards the top (for more volume) or
towards the bottom (for less volume).
NOTE: The Power “On” Green LED will blink fast when the
battery is low.

English
9
11.Adjust the tone according to your preferences. Turning the tone
control towards the top (+) boosts the treble (high frequency).
Turning the tone control towards the bottom (-) boosts the bass
(low frequency). The white dot on the dial indicates the normal
position (no treble or bass boost).
Tone Adjustment Dial
Pocketalker®2.0: Left Side View
+
–
+–
A544
T-Coil Switch
(in “On” position)
T-Coil “On” LED
USB Micro-B
Charging Port
External Microphone
Jack
Battery
Compartment
Lanyard Slot
Clip
Internal Microphone
Clip
Battery
Cover
Battery
Type*
Switch
AAA
Batteries
NiMH* or
Alkaline*
Power On/Off
and
Volume Adjust
Rotary Dial
Power “On”
Green LED
Lanyard Slot
Headphone/
Earphone
Jack
Tone Adjust
Rotary Dial
NiMH
Alkaline
SLIDE
PRESS HERE
WHILE SLIDING
+
–
+–
Balance
Control
(Fully
counter-
clockwise
= Mono)
Left Right
(Mono)
Balance
Adjust
Charging LED
indicator
T-Coil Symbol
Power On
Volume+
Adjust
Volume-
Power Off
Adjust
T-coil
Switch
Tone
Adjust
Dial
Adjust
Tone
Adj.
Dial
Normal
position
(dot in
center)
More
bass
More
treble
More
treble
More
bass
+
–
+–
A544
T-Coil Switch
(in “On” position)
T-Coil “On” LED
USB Micro-B
Charging Port
External Microphone
Jack
Battery
Compartment
Lanyard Slot
Clip
Internal Microphone
Clip
Battery
Cover
Battery
Type*
Switch
AAA
Batteries
NiMH* or
Alkaline*
Power On/Off
and
Volume Adjust
Rotary Dial
Power “On”
Green LED
Lanyard Slot
Headphone/
Earphone
Jack
Tone Adjust
Rotary Dial
NiMH
Alkaline
SLIDE
PRESS HERE
WHILE SLIDING
+
–
+–
Balance
Control
(Fully
counter-
clockwise
= Mono)
Left Right
(Mono)
Balance
Adjust
Charging LED
indicator
T-Coil Symbol
Power On
Volume+
Adjust
Volume-
Power Off
Adjust
T-coil
Switch
Tone
Adjust
Dial
Adjust
Tone
Adj.
Dial
Normal
position
(dot in
center)
More
bass
More
treble
More
treble
More
bass
Using the built-in T-coil with a Loop System
The Pocketalker can be used with loop systems. When the T-coil
switch on the Pocketalker is enabled, the Pocketalker disables the
microphone input, picks up the loop signal, and sends the audio
through the headphone jack.
To use this feature:
Follow the “Getting Started” instructions and instead of step 8,
ip the T-coil switch to the “T-coil” position (up towards the T-coil
symbol). The T-coil “On” LED indicator above the switch will light
up.

English
10
Internal T-Coil Switch and Indicator LED
Pocketalker: Right Side View
+
–
+–
A544
T-Coil Switch
(in “On” position)
T-Coil “On” LED
USB Micro-B
Charging Port
External Microphone
Jack
Battery
Compartment
Lanyard Slot
Clip
Internal Microphone
Clip
Battery
Cover
Battery
Type*
Switch
AAA
Batteries
NiMH* or
Alkaline*
Power On/Off
and
Volume Adjust
Rotary Dial
Power “On”
Green LED
Lanyard Slot
Headphone/
Earphone
Jack
Tone Adjust
Rotary Dial
NiMH
Alkaline
SLIDE
PRESS HERE
WHILE SLIDING
+
–
+–
Balance
Control
(Fully
counter-
clockwise
= Mono)
Left Right
(Mono)
Balance
Adjust
Charging LED
indicator
T-Coil Symbol
Power On
Volume+
Adjust
Volume-
Power Off
Adjust
T-coil
Switch
Tone
Adjust
Dial
Note: For best performance when using the t-coil feature, the
Pocketalker must be in a vertical orientation. This ensures the best
magnetic coupling to the loop system.
Recharging NiMH Batteries
The Pocketalker can recharge NiMH batteries when used with an
optional BAT KT7 (US) or BAT KT8 (International) charging kit.
1. Verify or change battery switch to the NiMH position.
2. Verify or insert NiMH batteries into battery compartment.
3. Using the included USB A to USB Micro-B cable, plug the
USB Micro-B end into the USB Micro-B charging port on
the Pocketalker. Plug the USB A end into the USB A port
on the power supply included with the charging kit. Plug
the power supply into a wall outlet.
4. The charging indicator will blink slow while charging, and
then will stay on solid when the unit is charged.
WARNING! Do not attempt to charge Alkaline batteries!

English
11
Charging Connections
Pocketalker and BAT KT7 (US) Charging Kit
A557
USB
Micro-B
Charging
Port
LED Power Indicator
USB Micro-B
Plug (small)
USB A Plug (large)
USB A
Port
Power Supply
(plug into wall outlet)
LED Charging Indicator
Listening during conversations with others
The Pocketalker picks up sounds and boosts them according
to the volume you’ve set. For best results, place or hold the
Pocketalker’s microphone as close as possible to the person
who is speaking.
Seated
Many users set the Pocketalker on a table if they’re in a
restaurant or small group situation. Aim the microphone in the
direction of the person speaking.
Standing Or Walking
Many users use the Pocketalker “Clip” and attach it to their
pocket, pants or skirt. The lanyard may also be used (see
section “Using the Lanyard”).
In The Car
For conversations in the car, you can use the External
Microphone (MIC 014-R) with the optional 3.5 mm - 3.5 mm
Microphone Extension Cord (WCA 007 WC) and optional Lapel
Clip (CLP 014) to attach the microphone to the shirt or blouse
of your fellow rider (see “Extending the Microphone”).

English
12
Extending the Microphone
When the Pocketalker’s internal microphone is too far away from
the desired sound to be eective, the optional 12 ft, 3.5 mm - 3.5
mm extension cord kit (WCA 007 WC) can be used to extend an
external microphone to a television or another person.
To extend the Microphone:
1. Plug the external microphone into the female end of the
extension cord. Arrange the cord to reach the loudspeaker of
the TV or other person. Plug the male end of the extension
cord into the microphone jack on the Pocketalker.
Using the 3.5mm Extension Cord
Pocketalker: Front View
A544
External
Microphone
MIC 014-R
3.5mm - 3.5mm
Extension Cord
WCA 007
Microphone Plug/Jack
Headphone
jack
Earphone or
Headphone
Plastic Clip
(PLC 004)
External Microphone
(MIC 014-R)
3.5mm - 3.5mm
Extension Cord
(WCA 007)
TV Speaker
2. For a TV: Attach one of the plastic clips (two PLC 004 clips
are included with the WCA 007 WC kit) to the TV, near the
loudspeaker, as shown in the illustration.
3. For a TV: Press the microphone into the plastic clip.
4. For a TV: Turn on the TV and the Pocketalker. Adjust the volume

English
13
on both as needed.
5. If attaching the microphone to another person, ask them to
begin speaking and adjust the volume as necessary.
Placement of Mic Clip on TV
A544
External
Microphone
MIC 014-R
3.5mm - 3.5mm
Extension Cord
WCA 007
Microphone Plug/Jack
Headphone
jack
Earphone or
Headphone
Plastic Clip
(PLC 004)
External Microphone
(MIC 014-R)
3.5mm - 3.5mm
Extension Cord
(WCA 007)
TV Speaker
Using an Optional Neckloop
Williams Sound’s optional neckloop (NKL 001) can be used with
the Pocketalker in situations where the Pocketalker is needed, and
the user has a hearing aid with a T-coil.
How it works: The Pocketalker picks up the sound with the
internal or external microphone, and sends it into the neckloop.
The neckloop magnetically couples with the T-coil in the listener’s
hearing aid(s). With the hearing aid T-coil switch on, the listener
can hear the sound directly in their hearing aid(s).
To use the neckloop: Place the neckloop around your neck as
shown below. While holding the housing with one hand, pull up on
the cord lock bead with the other hand to tighten for comfort. Plug
the neckloop into the headphone jack on the Pocketalker. Turn on
the T-coil in the hearing aid(s). Turn on the Pocketalker and adjust
the volume to a comfortable listening level.

English
14
Using a Neckloop
Operating the
Pocketalker
worn hanging
around the
neck with
the supplied
Pocketalker
Lanyard
A547
Adjusting
Neckloop
The RCS 003 Lanyard
has a safety breakaway
feature that disconnects
when too much tension
is applied to the lanyard.
Cord Lock “Bead”
Pull up to tighten
Neckloop “Housing”
Hold down while
tightening
Operating the
Pocketalker
at a table using
the PockeTalker
Lanyard as a
wrist strap
Using the Lanyard
The supplied Pocketalker Lanyard (RCS 003) provides a
convenient way of transporting the Pocketalker from place to
place; it protects your investment from accidental dropping,
and provides quick and easy access for operation whenever it
is needed. Wear the lanyard around your neck.
Operating the
Pocketalker
worn hanging
around the
neck with
the supplied
Pocketalker
Lanyard
A547
Adjusting
Neckloop
The RCS 003 Lanyard
has a safety breakaway
feature that disconnects
when too much tension
is applied to the lanyard.
Cord Lock “Bead”
Pull up to tighten
Neckloop “Housing”
Hold down while
tightening
Operating the
Pocketalker
at a table using
the PockeTalker
Lanyard as a
wrist strap

English
15
Installing the Lanyard (RCS 003)
Step 1 Step 2 Step 3
Step 1 Step 2 Step 3
Operating the
Pocketalker
worn hanging
around the
neck with
the supplied
Pocketalker
Lanyard
A547
Adjusting
Neckloop
The RCS 003 Lanyard
has a safety breakaway
feature that disconnects
when too much tension
is applied to the lanyard.
Cord Lock “Bead”
Pull up to tighten
Neckloop “Housing”
Hold down while
tightening
Operating the
Pocketalker
at a table using
the PockeTalker
Lanyard as a
wrist strap

English
16
LED Indicators
Power
LED Charge LED T-Coil LED Condition Indicated
On Off Operating normally; battery level
sufficient
Fast
blinks Off Battery is low
Slow blinks Battery is charging
On (charger
plugged in) Battery charging complete
Off (charger
plugged in) No batteries detected or charger not detected
On T-coil in use; internal and external
mic jack disabled
Off T-coil not in use; internal mic enabled (or external mic if plugged
in)
Off Off Battery too low to operate
Fast blinks
Batteries are too low to charge.
Pocketalker is attempting to
recondition batteries. If fast blinks
persist for more than 2 hours,
batteries are bad; replace with new
batteries. If recondition attempt
is successful, Charge LED will
change to slow blinks, indicating
that normal charging is now
occuring.
LED Indicators Blink Rates
Fast = 4 blinks every 2 seconds
Slow = 1 blink every 2 seconds
Fast
Slow
0.5 Sec
0.4 Sec
Fast
Slow
1 Sec 2 Sec
0.1 Sec
3 Sec

English
17
Hints & Tips
The Pocketalker has been designed to be as easy to use as
possible. However, if you have trouble, check the following:
1. If using an external microphone, make sure the microphone is
plugged into the “External Mic” jack and the T-Coil switch is
set to “O”. Make sure the earphone or headphone is plugged
into the “Headphone” jack . If using the T-Coil on the
Pocketalker, make sure the T-Coil Switch is on and verify that
the T-Coil indicator LED is lit.
2. Make sure the batteries are not depleted and have been
inserted (observing correct polarity ±) into the battery
compartment.
3. If using rechargeable batteries, make sure the batteries
are suciently charged and that the battery switch is set
appropriately.
4. If you experience a howling or squealing sound, this is called
feedback. Depending on the earphone or headphone used, you
can sometimes get feedback when the volume control is turned
higher than 3 or 31⁄2.
To reduce feedback, turn down the volume, or move the
microphone (internal or external) farther away from the
earphone or headphone.
Also, try turning the Tone Control down (counter-clockwise)
to reduce the high frequency.
5. The Pocketalker headphone jack is a stereo jack, designed for
use with stereo earphones or headphones. However, if you use
mono earphones or headphones with the Pocketalker, turn the
balance control (located in the battery compartment) fully to the
left, or “mono” position. While this maximizes volume, this will
also help in maximizing battery life.
6. Observe what the LED indicators on the unit are doing:
Power ON LED (on front)
Charging LED (on right side)
T-Coil LED (on right side)
See the chart under “LED Indicators” to determine unit status
and problem resolution.
7. If the steps above don’t solve the problem, contact your
Williams Sound Dealer for further instructions.

English
18
Pocketalker® 2.0 Specications
Personal amplier Model PKT 2.0
Dimensions: 4.9” L x 2.0” W x 1.0” H. (124mm x 51mm x 25mm) (Not including clip or
microphone assembly)
Weight: 3.1 oz. (88 grams) (with batteries)
Color/material: White ABS/Polycarbonate molded plastic case.
*Battery Type: Two 1.5V (AAA size), Alkaline* or NiMH rechargeable*
(Williams Sound BAT 010-2 Alkaline or BAT 022-2 NiMH recommended)
Battery Life: Up to 105 hours (typical usage) with the BAT 010-2.
Low Battery Indicator: Power “On” Green light on front panel ashes.
**NiMH battery
Charging:
Charging: 16 hours with BAT 022-2. Red LED blinks when charging.
End of Charge: Red LED is on solid. At end of charge, maintenance
charge is provided.
NOTE: Charging requires optional charging kit BAT KT7 or BAT KT8.
Microphone: Internal, omnidirectional MEMS microphone (micro-electro-mechanical
system).
Optional External, omnidirectional, plug-in electret microphone with foam
windscreen and 3.5mm mono plug (MIC 014-R).
T-Coil: Internal with on/o switch and LED indicator.
Tone Control: External rotary control knob allows user to adjust high/low frequency to
optimize hearing.
***Balance Control: Adjusts Left/Right Volume Balance
Power/Volume
Control:
External rotary volume control knob with integrated power ON-OFF switch.
Microphone Jack: 3.5 mm, stereo mini plug.
Tip=Mic signal, Ring=NC, Sleeve=Gnd.
Headphone Jack: 3.5 mm, stereo mini plug.
Tip=Left/Mono, Ring=Right, Sleeve=Gnd.
Optional
Accessories:
Clip: CLP 014; Allows the user to clip MIC 014 to clothing such as a lapel
or shirt pocket.
Lanyard: RCS 003; Allows user to wear unit around the neck, or as a
wrist strap.
3.5mm-3.5mm Extension Cord: WCA 007 WC; extends an external
microphone to 12 ft.
Stereo Earphones / Headphones / Neckloop:
EAR 042 / HED 024, HED 036 / NKL 001-S (stereo) Neckloop
Mono Earphones / Headphones / Neckloop***:
EAR 013, EAR 008, EAR 022, EAR 041 / HED 021, HED 027 / NKL 001
(mono) Neckloop
Charging Kits: BAT KT7 (US), BAT KT8 (International)
Approvals: RoHS, WEEE, FCC, IC
Warranty: 5 years, parts and labor (90 days on accessories)

English
19
Electrical Specications (1 kHz Sine Wave reference) Typical
Power output: 52 mW (max) into 32 ohms (Stereo)
ALC: Automatic Level Control; Limits maximum output level
Distortion: 1% THD (max)
Max gain: 63 dB @ 2.5 kHz (Tone=High)
Frequency response
Tone Control at high
position: 2.7dB boost at 5 kHz, 6.7dB cut at 400 Hz.
Tone Control at mid
position: 0.6dB cut at 5 kHz, 2.9dB cut at 400 Hz.
Tone Control at low
position: 2.0dB cut at 5 kHz, 3.0dB boost at 400 Hz.
*Battery switch must be in correct position for battery type being used.
**Charging requires optinal charging kit BAT KT7 (USA) or BAT KT8 (International).
***When using mono earphones, headphones or neckloop, the balance control on the Pocketalker
must be turned fully counter-clockwise (to the “mono” position) for best volume and battery life.
Note: The Pocketalker is not sold, advertised, or intended for use as a personal hearing aid. Williams
Sound recommends that any individual experiencing hearing loss be examined by a physician/audi-
ologist to determine the cause before using an amplication device such as the Pocketalker.
Acoustic Specications for Headphones recommended for use with the Pocketalker are published
on our website.
Limited Warranty
Williams Sound products are engineered, designed and manufactured under carefully controlled
conditions to provide you with many years of reliable service. Williams Sound warrants the
Pocketalker PKT 2.0 Personal Amplier against defects in materials and workmanship for FIVE
(5) years. During the rst ve years from the purchase date, we will promptly repair or replace the
Pocketalker PKT 2.0 Personal Amplier.
Microphones, earphones, headphones, batteries, cables, carry cases, and all other accessory
products carry a 90-day warranty. Neckloops carry a 1-year warranty.
WILLIAMS SOUND HAS NO CONTROL OVER THE CONDITIONS UNDER WHICH THIS PRODUCT IS USED. WILLIAMS
SOUND, THEREFORE, DISCLAIMS ALL WARRANTIES NOT SET FORTH ABOVE, BOTH EXPRESS AND IMPLIED, WITH
RESPECT TO THE Pocketalker®2.0 AMPLIFIER, INCLUDING BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. WILLIAMS SOUND SHALL NOT BE LIABLE TO ANY
PERSON OR ENTITY FOR ANY MEDICAL EXPENSES OR ANY DIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES
CAUSED BY ANY USE, DEFECT, FAILURE OR MALFUNCTION OF THE PRODUCT, WHETHER A CLAIM FOR SUCH
DAMAGES IS BASED UPON WARRANTY, CONTRACT, TORT OR OTHERWISE. THE SOLE REMEDY FOR ANY
DEFECT, FAILURE OR MALFUNCTION OF THE PRODUCT IS REPLACEMENT OF THE PRODUCT. NO PERSON HAS
ANY AUTHORITY TO BIND WILLIAMS SOUND TO ANY REPRESENTATION OR WARRANTY WITH RESPECT TO THE
Pocketalker®2.0. UNAUTHORIZED REPAIRS OR MODIFICATIONS WILL VOID THE WARRANTY.
The exclusions and limitations set out above are not intended to, and should not be construed so
as to contravene mandatory provisions of applicable law. If any part or term of this Disclaimer of
Warranty is held to be illegal, unenforceable or in conict with applicable law by a court of competent
jurisdiction, the validity of the remaining portions of this Disclaimer of Warranty shall not be aected,
and all rights and obligations shall be construed and enforced as if this Limited Warranty did not
contain the particular part or term held to be invalid.

English
20
©2015 Williams Sound • All Rights Reserved
10300 Valley View Rd • Eden Prairie, MN 55344
800-843-3544 / 952-943-2252 • FAX: [phone]
Website: www.williamssound.com
Email: [email protected]
MAN 181E
