Digi-Wave™Dock Setup Guide
SYSTEM EXAMPLES

Digi-Wave Dock Application Guide
2
Table of Contents
Purpose of this Guide 3
Base Station Transmitter 3
Base Station Receiver 4
Teleconferencing 5
Range Extender 6
Interpretation with Wireless Presenter 7
Interpretation and a Relay 8
Floor and Interpretation with 2-way Q&A -or- 2-Group Negotiation 9
4 Simultaneous Talkers (one-way) 10
4-way COM System (two-way) 11

Digi-Wave Dock Application Guide
3
Purpose of this Guide
The DigiWave Dock provides a way to connect the DigiWave wireless product to a hardwired system. Audio can be taken from a hard-
wired system and transmitted to listeners in the audience, or, transmitted audio can be received and sent into a hard wired system. The
dock uses DLT 100’s and/or DLR 60’s to send and/or receive audio. In addition to this, the dock also charges DLT 100’s and DLR 60’s.
This guide is designed to present various ways the Digi-Wave Dock can be utilized. The dock is a versatile piece of equipment, and the
following examples are by no means exhaustive. These examples are provided as a starting point for more creative or complex uses.
Base Station Transmitter
The Digi-Wave Dock can be used as a method of transmitting audio from a sound system to the audience listening with transceivers or
receivers.
How it works:
An audio program, speakers voice, etc. is sent from a sound system or other equipment to the dock input. The dock delivers the audio to
the docked transceiver which broadcasts the audio out to receivers (or transceivers) in the audience.
The docked transceiver should be set to 2-way Chairman Master; this way when listeners enter the room, their receivers (or transceivers)
will synch to the docked unit and begin receiving audio. The dock bay switch for the docked transceiver should be set to the “Auto”
position; this keeps the transmitting unit powered up, the battery charged, and the TALK button on so it keeps transmitting as long as the
dock is powered up.
Digi-Wave Dock
(rear)
A497
Docked
DLT 100 2.0
Transceiver
Analog
Line Output
(XLR or RCA)
Analog Line Input
(XLR or RCA)
An audio program, speakers voice, etc. is sent from a sound system or other equipment to the dock input. The dock delivers the audio to the docked
transceiver which broadcasts the audio out to receivers (or transceivers) in the audience.
Sound System,
Analog Mixer, etc.
DLT 100 2.0
Transceiver in Slave Mode
or
DLR 60 2.0 Receiver
1-way Presenter Mode
or
2-way Chairman Master
Dock Bay Switch
set to “Auto”
Speaker/
Presenter
Listeners hear the
audio or speaker’s
voice from the
sound system.

Digi-Wave Dock Application Guide
4
Base Station Receiver
The Digi-Wave Dock can be used to receive audio from a Digi-wave transceiver, and send this audio into a sound system. Utilized in this
way, a human speaker can be recorded, heard by the audience using receivers, or heard by the audience through loudspeakers.
How it works:
A speaker/presenter’s voice is transmitted from a DLT 100 2.0 to a docked DLR 60 2.0 receiver (or DLT 100 2.0 transceiver). The dock
sends the audio through it’s outputs into a sound system or other equipment.
The Presenter’s DLT 100 should be set to 2-way mode, Master Chairman; this way when the presenter enters the room, the docked
receiver (or transceiver) will sync with the presenter’s DLT and begin receiving the audio. Using a docked receiver is recommended for
simplicity, but if using a docked DLT, it should be set to 2-way Slave mode. The dock bay switch for the docked unit should be set to the
“Auto” position; this keeps the receiving unit powered up, battery charged, searching for a transmitter if there isn’t one, and receiving when
synced with a transmitter.
Digi-Wave Dock (rear)
A496
Docked
DLT 100 2.0 Transceiver in
2-way Slave mode
or
DLR 60 2.0 Receiver
Analog Line Input
(XLR or RCA)
Sound System,
Analog Mixer, or
Recording Equipment
Analog Line Output
(XLR or RCA)
A speaker’s voice is transmitted from a DLT 100 2.0 to a docked DLR 60 2.0 receiver (or DLT 100 2.0
transceiver). The dock sends the audio through it’s outputs into a sound system or other equipment.
DLT 100 2.0 Transceiver
in 2-way Master Chairman
mode.
Speaker/
Presenter
Dock Bay Switch
set to “Auto”
3.5mm
HEADPHONE

Digi-Wave Dock Application Guide
5
Teleconferencing
The dock provides full duplex audio capability when a DLT 100 Transceiver is docked. Utilized in this way, two-way communication can be
established between two conference rooms, with audio sent/received over the internet. People on both sides can speak/listen with DLT
100 transceivers (shown), or just listen with DLR 60 receivers (not shown). A program such as Skype or other teleconference software can
be used to make the conference call over the internet. The 2-way audio from each dock is connected to the computer in that conference
room.
How it works:
In Conference Room 1, a speaker’s voice is transmitted from a DLT 100 2.0 to a docked DLT 100 2.0. The dock sends the audio through
it’s outputs into a computer. The computer sends the audio through the internet where it is received by a computer in Conference Room 2.
The computer in Conference Room 2 sends its audio to a dock that has a docked DLT 100 2.0 transceiver. A listener with a DLT or DLR in
Conference Room 2 hears the audio from Conference Room 1.
In the same manner, audio is sent from Conference Room 2 to Conference Room 1, completing the 2-way communication circuit. Typically
this type of system is coupled with a video screen in each conference room, so the people in both locations can see and hear each other
(not shown).
A499
DLT 100 2.0
Transceiver
in 2-way Slave
Mode
Docked
DLT 100 2.0
Transceiver in
2-way Master
Chairman
mode
Line Output
(RCA)
In Conference Room 1, a speaker’s voice is transmitted from a DLT 100 2.0 to a docked DLT 100
2.0. The dock sends the audio through it’s outputs into a computer. The computer sends the
audio through the internet where it is received by a computer in Conference Room 2. The
computer in Conference Room 2 sends its audio to a dock that has a docked DLT 100 2.0
transceiver. A listener with a DLT or DLR in Conference Room 2 hears the audio from Conference
Room 1.
In the same manner, audio is sent from Conference Room 2 to Conference Room 1, completing
the 2-way communication circuit. Typically this type of system is coupled with a video screen in
each conference room, so the people in both locations can see and hear each other (not shown).
Line Input
(RCA)
Line Input (RCA)
Digi-Wave Dock
(rear)
Line Output
(3.5mm
stereo)
Line Input
(3.5mm stereo)
Line Output (3.5mm stereo)
Conf Rm 1 Audio
Conf Rm 2 Audio
Docked
DLT 100 2.0
Transceiver in
2-way Master
Chairman
mode
DLT 100 2.0
Transceiver
in 2-way Slave
Mode
Dock-
Bay-
Switch
set to
“Auto”
Dock-
Bay-
Switch
set to
“Auto”
Line
Output
(RCA)
Main
Speaker/Presenter
Conf. Rm. 1
Desktop
Computer
INTERNET
Desktop
Computer
Digi-Wave Dock
(rear)
Main
Speaker/Presenter
Conf. Rm 2
CONFERENCE ROOM 1 CONFERENCE ROOM 2
Line Input
(3.5mm stereo)
Additional people
in the room
can join the
conference
with additional
transceivers in
2-way Slave mode
Additional people
in the room
can join the
conference
with additional
transceivers in
2-way Slave mode

Digi-Wave Dock Application Guide
6
Range Extender
The Digi-Wave Dock can be used to extend the range of an existing Digi-wave System, reaching a larger audience or even audiences in
additional rooms or areas.
How it works:
In Room 1, a speaker’s voice is transmitted from a portable DLT 100 2.0 to a docked DLT 100 2.0. The dock sends the received audio
through an XLR cable to a second dock in Room 2. Room 2 has a docked DLT 100 2.0 transceiver that broadcasts the audio to a listener
with a DLT 100 2.0. The length of the range extension is limited by the type of XLR cable used, but can be as much as 500 feet or even
much more.
In the same manner, audio can be sent from Room 2 to Room 1, if 2-way communication is desired (shown).
A500
DLT 100 2.0
Transceiver in
2-way Slave
mode
Docked
DLT 100 2.0
Transceiver in
2-way Master
Chaiman
mode
ANALOG
LINE
OUTPUT
(XLR)
Digi-Wave Dock
(rear)
Docked
DLT 100 2.0
Transceiver in
2-way Master
Chaiman
mode
DLT 100 2.0
Transceiver in
2-way Slave
mode
AREA / ROOM 1
Speaker or Listener
Digi-Wave Dock
(rear)
AREA / ROOM 2
Speaker or Listener
Area/Room 1 Area/Room 2
Distance = 500 feet or more

Digi-Wave Dock Application Guide
7
Interpretation with Wireless Presenter
The Digi-Wave Dock can be used to easily connect an IC-2 Interpreter’s console and provide a wireless transceiver for the main presenter
(oor). The audience hears the interpreted language (from the IC-2 console) on Ch 1.
How it works:
The main presenter/speaker’s voice (i.e. English) is transmitted from a portable DLT 100 2.0 in 1-way mode on Ch. 0, to a docked DLT 100
2.0 in Interpreter Mode on Ch. 1. The dock sends the speakers voice through an XLR cable to the Floor input on the IC-2. The interpreter
hears the speaker’s voice and interprets into Spanish. Spanish comes back from the IC-2 to the Dock on an XLR cable. The docked DLT
100 2.0 broadcasts the interpreter’s voice to the audience listening with DLR 60 2.0 Receivers on Channels 1-14 (depending on how many
interpreted languages are needed). Additional languages require daisy-chaining additional IC-2’s and additional Dock Bays, one for each
interpreted language - just the rst interpreted language/IC-2/dock is shown here. Note that this “Floor-In” method need only be connected
on the rst IC-2 when daisy-chaining a system, as the oor will be carried on the bus to each IC-2 in the chain.
A503
DLT 100 2.0
in
1-way
Presenter
mode
Docked
DLT 100 2.0
in 1-way
Interpreter Mode
Analog
Line Input
(XLR)
Digi-Wave Dock (rear)
DLR 60 2.0
Receiver
Analog
Line Output
(XLR)
Analog
Line Input
(XLR)
Analog
Line Output
(XLR)
IC-2 (rear)
Main Presenter
speaking in English
on Ch. 0
Audience hears Spanish on Ch. 1
Main Presenter (English)
Interpreter’s Voice (Spanish)

Digi-Wave Dock Application Guide
8
Interpretation with a Relay
The Digi-Wave Dock can be used to connect IC-2 Interpreter’s consoles for interpretation with a relay.
In this example there is an English-speaking presenter followed by a French-speaking presenter. Members of the audience are on the
channel they need for the language they need to hear. When the English speaker changes to the French speaker, the audience doesn’t
need to change channels. However, the relay translator begins translating French to English when the French speaker starts talking, and
the interpreter who is translating English to Spanish now switches to listen to the relay’s voice.
How it works:
The First Presenter’s voice (English) comes in from a hard-wired microphone, to the IC-2 on the Floor input. The oor’s voice (English) is
sent to the rst Dock and transmitted on Ch. 2 (for the audience), and also travels down the IC-2 bus to the second IC-2 (for the Interpreter
translating English to French). The Spanish-English Interpreter listens to the Floor and translates English to Spanish, with Spanish
coming out on Ch. 1 of the rst IC-2, sent to the rst Dock where it is broadcast to the audience on Ch. 1. Meanwhile the French-English
Interpreter is listening to English (on the bus) from the rst IC-2 and translating English into French. French is sent to the second dock
where is is broadcast on Ch. 3, to the audience.
When the Second Presenter starts speaking in French, the Relay Interpreter switches to translating French back to English. English travels
from the second IC-2 back on the bus to the rst IC-2, and the Spanish-English Interpreter now listens to the Relay channel, and continues
to interpret English to Spanish. The Floor’s voice is now passed through the second IC-2, then transmitted on Ch. 3 using feedtrough, so
the audience still hears French on Ch. 3. English is sent from the second IC-2 to the rst IC-2 though the bus, then fed though to the rst
dock where is it broadcasted on Ch. 2 for the English members of the audience.
Docked
DLT 100 2.0
Transceiver
Spanish
Ch. 1
A504
Analog
Line Input
(XLR)
The main presenter/speaker’s voice comes in from a hard-wired microphone into the IC-2. The interpreter’s voice comes from the IC-2 to the Dock on an XLR cable
plugged into the input of the second bay. A docked DLT 100 2.0 broadcasts the interpreter’s voice on Ch. 1, and another docked DLT 100 2.0 broadcasts the
Relay’s Voice on Ch. 2, to the audience listening with DLT 100 2.0 Transceivers or DLR 60 2.0 Receivers.
Digi-Wave
Dock
Docked
DLT 100 2.0
Transceiver DLR 60 2.0
Receiver
Analog
Line Input
(XLR)
English
Relay
Ch. 2
IC-2
(rear)
Spanish
Ch. 1
IC-2
(rear)
Digi-Wave
Dock
First Presenter-English
Audience listening to
Spanish on Ch. 1,
or English on Ch. 2,
or French on Ch. 3
English
English
Ch. 2
French
Second Presenter-French
Interpreter, English to Spanish
Relay Interpreter, French to English
French
English
Docked
DLT 100 2.0
Transceiver
French
Ch. 3
Analog
Line Input
(XLR)
Spanish
Analog
Line Input
(XLR)
French
Ch. 3

Digi-Wave Dock Application Guide
9
Floor and Interpretation with 2-way Q&A -or- Two-Group Negotiation
The Digi-Wave Dock can be used to easily connect an IC-2 Interpreter’s console for the oor and interpreter - where the audience can ask
questions and hear the answers in their language. In this example the audience can ask questions and hear the answers in their language
in either English on Group 1 or Japanese, from the Interpreter, on Group 2.
This solution can also be used for two groups that need a back-and-forth dialogue in two languages.
How it works:
By using the Ch. 2 Out and Relay-In on the IC-2, the Interpreter hears Group 1 (English) while speaking to Group 2 (Japanese). If a
question is asked in Japenese, the interpreter switches to hear the question in Japanese and interprets Japanese back to English. English
travels back from the IC-2 in the opposite direction. Audience members tune in to whichever language they want, and they can ask and
hear questions in their language (English or Japanese). When anyone in either group asks a question, it is interpreted and both groups hear
the answer.
A505
Docked
DLT 100 2.0
Transceiver
(Group 1)
Analog
Line Input
(XLR)
Digi-Wave
Dock (rear)
DLT 100 2.0
Transceivers
Analog
Line Input
(XLR)
Analog
Line Input
(XLR)
Docked
DLT 100 2.0
Transceiver
(Group 2)
DLT 100 2.0
Transceivers
Audience talks/listens
to Group 1 English or
Group 2 Japenese
Interpreter listening to
Japanese (translating to English)
Group 1, English
Japanese
(Group 2)
English
(Group 1)
Interpreter translating
English to Japanese
or Japanese to English
(Group 2)
Interpreter listening to English translating to Japanese
Interpreter listening to Japanese, translating to English

Digi-Wave Dock Application Guide
10
4 Simultaneous Talkers (one-way)
The Digi-Wave Dock can be used to add more speakers to an existing DigiWave wireless system. This is accomplished by using the dock
to add-in live microphones to an existing 2-way system. This is one-way communication from the speakers to the audience.
In this example let’s say you have a panel of 4 people, like in a city council meeting. The audience needs to hear all 4 council members.
Since all council members are sitting at the same table, they can hear each other speak, and do not require 2-way communication with
each other. The system example here allows the audience to hear all 4 council members.
How it works:
This example takes advantage of the dock’s ability to mix input signals. By combining inputs at the rst dock, Daryl and Valerie’s voices
(Group 2) are combined with Janet and Bob’s voices (Group 3) are then transmitted out on Group 1 for the audience.
A510
(Group 1)
Taking advantage of the dock’s ability to mix input signals, this configuration alllows 4 people to talk at the same time. By daisy-chaining inputs from one dock to the next, a
speaker’s voice is mixed in, one at a time, to the end of the chain. The return connection from the last bay’s output back to the first bay’s input completes the chain, allowing
everyone to hear, and speak to, each other.
Digi-Wave
Dock (rear)
DLT 100 2.0
Transceivers
DLT 100 2.0
Transceiver
DLR 60 2.0
Receiver
Daryl
DLT 2
Valerie
DLT 3
Janet
DLT 4
DLT 60 2.0
Receiver
Audience
Group 1
Standard RCA cable
Standard XLR cable
DLR 60 2.0
Receiver(s)
(Group 1) (Group 2) (Group 2) (Group 3)
(Group 2) (Group 3)
Group 3
DLT 4 & 5
Janet & Bob
Bob
DLT 5
(Group 3)
Group 2
DLT 2 & 3
Daryl & Valerie
Daryl, Valerie
Janet, Bob
