Willoughby WODF-1WM Series User manual

Installation &
Operation Manual
Rev. 6/2015
Willoughby Industries, Inc.
5105 West 78th Street
Indianapolis, IN 46268
Toll Free: [phone]
Local: [phone]
Fax: [phone]
www.willoughby-ind.com MADE IN THE U.S.A.
Table of Contents
Pre-Installation Information.....................................3
Physical / Rough-in Dimensions.............................4
Required Installation Supplies................................6
Parts List and Exploded-view Drawings.................7
Hardware Identification ..........................................9
Installation Instructions.............................................
Step 1: Fixture Installation...............................10
Step 2A: Adjusting Drinking Spout Flow..........11
Step 2B: Battery Operated Infrared Sensor
Startup...............................................11
Care and Maintenance.........................................12
Troubleshooting........................................................
Fixture Plumbing...............................................13
Infrared Sensor.................................................14
Drawings...................................................................
Pushbutton Details ...........................................15
Warranty...............................................................16
WODF-1WM Series
CWBF-1WM Series
Outdoor Drinking Fountain
Outdoor Bottle Filler
Wall Mounted units
WODF-1WM
CWBF-1WM

Installation & Operation Manual
Wall Mounted- Outdoor Drinking Fountain / Bottle Filler
WODF-1WM Series / CWBF-1WM Series
Willoughby Industries, Inc. TOLL FREE [phone] ●LOCAL [phone] ●FAX [phone]
Page 2Rev. 6/2015 www.willoughby-ind.com
(Page intentionally left blank)

Installation & Operation Manual
Wall Mounted- Outdoor Drinking Fountain / Bottle Filler
WODF-1WM Series / CWBF-1WM Series
Willoughby Industries, Inc. TOLL FREE [phone] ●LOCAL [phone] ●FAX [phone]
Page 3Rev. 6/2015 www.willoughby-ind.com
Pre-Installation Information
When installing the Willoughby Industries' WODF-1WM Series drinking fountain system or
CWBF-1WM Series bottle filler system:
Before Step 1 of the installation instructions, ensure that rough-ins are in the correct location.
The valve assembly, including the spray head, MUST NOT BE connected until after all lines have
been flushed to remove the small particles of debris that are inherent with new construction projects
and all chemicals that are used in flushing are purged from the system.
Chemicals used in flushing plumbing systems can attack the internal components of the valve and
spray head and severely damage them, so any flushing of the system must be followed by a full
flushing with pure water to clear any harsh chemicals remaining in the system. Debris in the system if
allowed to enter the valve assembly and spray head can cause poor performance or outright failure.
Again DO NOT attempt to connect the valve assembly and spray head until after all flushing is
complete and pure water is the only media that will be passing through the system. Damage to the
valve assembly or spray head caused by harsh chemicals or debris will not be covered by the
manufacturer's warranty.
Any fittings provided by the installer should be made of plastic to electrically isolate the unit from the
building or connected plumbing system.
The grounding of electric equipment such as telephones, computers, etc, to water lines is a common
procedure. This grounding can cause electrical feedback into a water fountain or similar fixture,
causing electrolysis, which results in a metallic taste or an increase in the metal content of the water.
This can easily be avoided by using the proper materials as indicated.
Installation notice!
Check Rough-In location PRIOR to installation
Flush lines thoroughly PRIOR to hook-up
Installation notice!
Check Rough-In location PRIOR to installation
Flush lines thoroughly PRIOR to hook-up

Installation & Operation Manual
Wall Mounted- Outdoor Drinking Fountain / Bottle Filler
WODF-1WM Series / CWBF-1WM Series
Willoughby Industries, Inc. TOLL FREE [phone] ●LOCAL [phone] ●FAX [phone]
Page 4Rev. 6/2015 www.willoughby-ind.com
Physical / Rough-in Dimensions- WODF-1WM

Installation & Operation Manual
Wall Mounted- Outdoor Drinking Fountain / Bottle Filler
WODF-1WM Series / CWBF-1WM Series
Willoughby Industries, Inc. TOLL FREE [phone] ●LOCAL [phone] ●FAX [phone]
Page 5Rev. 6/2015 www.willoughby-ind.com
Physical / Rough-in Dimensions- CWBF-1WM

Installation & Operation Manual
Wall Mounted- Outdoor Drinking Fountain / Bottle Filler
WODF-1WM Series / CWBF-1WM Series
Willoughby Industries, Inc. TOLL FREE [phone] ●LOCAL [phone] ●FAX [phone]
Page 6Rev. 6/2015 www.willoughby-ind.com
Required Installation Supplies
• Proper mounting hardware
• Proper plastic fittings as indicated
• Hardware for waste oulet connections
• Gasket for waste outlet connection
• Shims (for installation if necessary)
• Supply piping
• Silicone caulk
• Plumbers putty
 WARNING: Willoughby Industries does not assume any
responsibility for personal injury or damage to equipment
due to an improperly installed WODF-1WM Series drinking
fountain system or CWBF-1WM Series bottle filler system:

Installation & Operation Manual
Wall Mounted- Outdoor Drinking Fountain / Bottle Filler
WODF-1WM Series / CWBF-1WM Series
Willoughby Industries, Inc. TOLL FREE [phone] ●LOCAL [phone] ●FAX [phone]
Page 7Rev. 6/2015 www.willoughby-ind.com
Parts List and Exploded-view Drawing-
WODF-1
ITEM # PART # DESCRIPTION QTY.
1 600601HE DECK MOUNTED DRINKING FOUNTAIN BUBBLER 1 2 600116 O-RING, #023, BUNA N-70 1 3 600612N HEXNUT, 3/4"-14 NPSM 1 4 320469 NIPPLE, 3/8" NPT X 2.5" LONG 1 5 320091 COUPLING, 3/8" FPT STAINLESS STEEL 1 6 320437 ADAPTER, 3/8" NPTF MALE X 1/4" TUBE PUSH-TO-CONNECT 1 7 4509SSN 1/4"-20 x 2" FH SECURITY SCREW 1 8 380284 DRAIN, 1-1/2" 1 9 S200033 ADA BOWL - 1-3/4" DEPTH 1
10 380274 GASKET FOR 1-1/2" DRAINS 1 11 380273 DRAIN WASHER, 1-5/8" 1 12 600043 NUT, 1 5/8"-12 THD FOR 1-1/2" DRAIN 1 13 800144 1/4-20 X 1/2" PHILLIPS TRUSS HEAD SCREW 3 14 S200034 RECEPTOR SUPPORT ASSEMBLY w/DRAIN ELBOW 1 15 320288-14 NYLABRAID REINFORCED VINYL TUBING, 1-1/4" X 14" LONG 1 16 S200194 ARM ASSEMBLY - WALL MOUNTED WODF 1 17 980632 STRAINER, IN-LINE, 1/4 TO 3/8 PRESS LOCK 1 18 600471 TUBING, 1/4" OD X 0.17" ID X (20" LONG) 1 19 600315 PUSHBUTTON VALVE ASSEMBLY, ADJUSTABLE 1 20 600471 TUBING, 1/4" OD X 0.17" ID X 18" LONG 1 21 S200197 OUTER BOTTOM COVER - WALL MOUNTED WODF 1 22 4500NSS 1/4-20 X 1/2" BUTTON HEAD SECURITY SCREW 5 23 MK4PC-14 MOUNTING KIT, 4PC 1/2-13 X 14" ALL-THREAD 1
**NOTE: ITEM# 23 NOT SHOWN
FRACTIONS:
TRB
1:8 2 OF 2TRB
NOTED ON PAGE 2 A4/7/14
4/7/14
STANDARD
S200193
P143013A
TOLERANCES
NOTED
2 PLCS:
OUTDOOR DRINKING FOUNTAIN - WALL MOUNTED
SHEET:REV.:
ORIG.:REVISION:
SCALE: REF.:
MAT'L: TITLE / DESC.:
A
WODF-1WM
3 PLCS:
PART #:
Willoughby Industries Inc.
ANGLE:
Indianapolis, Indiana
EXCEPT AS
0.03 0.015 1/32" 1
SIZE:
8
2 1
15
17 22
21
18
19 20
16
14 13
12
6
11
5
10
4 3
9
7
WILLOUGHBY

Installation & Operation Manual
Wall Mounted- Outdoor Drinking Fountain / Bottle Filler
WODF-1WM Series / CWBF-1WM Series
Willoughby Industries, Inc. TOLL FREE [phone] ●LOCAL [phone] ●FAX [phone]
Page 8Rev. 6/2015 www.willoughby-ind.com
Parts List and Exploded-view Drawing-
WODF-2-PET
26"
3-7/8" 5"
18-5/8"
8-5/8"
ITEM # PART # DESCRIPTION QTY.
1 S200129 BODY CAP, 8.625" 1 2 4500NSS 1/4-20 X 1/2" BUTTON HEAD SECURITY SCREW 7 3 320575 ELBOW, 3/8" NPTF MALE X 1/4" TUBE PUSH-TO-CONNECT 1 4 600471-24A TUBING, 1/4" OD X 0.17" ID X 24" LONG 1 5 600612N HEXNUT, 3/4"-14 NPSM 1 6 S200239 WELD ASSEMBLY, WALL MOUNTED BOTTLE FILLER 1 7 380063 HEMISPHERIC BOTTLE FILLER BUBBLER 1 8 S200035 PLACARD FOR CWBF SERIES 1 9 S200142 DRAIN SCREEN FOR CWBF-1 1
10 600315 VALVE ASSEMBLY, ADJUSTABLE 1 11 S200135 DRAIN BOX ASS'Y FOR CWBF-1 1 12 320283 PVC THREADED ADAPTER, 1 1/4" 1 13 320279-3 PVC PIPE, 1 1/4" SCHED 40 X 3" LONG 2 14 320285 ELBOW, 1-1/4", FEMALE, PVC 1 15 320281 ELBOW, 22.5 , 1-1/4" FEMALE UNTHREADED SOCKET ENDS 1 16 320279-8 PVC PIPE, 1 1/4" SCHED 40 X 18" LONG 1 17 600471-24C TUBING, 1/4" OD X 0.17" ID X 18" LONG 1 18 980632 STRAINER, IN-LINE, 1/4 TO 3/8 PRESS LOCK 1 19 320573 REDUCER, 3/8" STEM X 1/4" TUBE 1 20 980440 CHARCOAL FILTER, 3/8" TUBING CONNECTIONS 1 21 S200243 BOTTOM COVER, WALL MOUNTED, CWBF-1WM 1
2 PLCS:
1
Indianapolis, Indiana TRB
TRB 12/1/14
12/1/14
A1 OF 2
P2408-0016
1:12
NOTED
A
SIZE:
BOTTLE FILLER, WALL MOUNTED, SINGLE STATION, ADA
SHEET:REV.:
ORIG.:REVISION:
SCALE: REF.: NOTED
3 PLCS:
PART #:
MAT'L:
FRACTIONS:
TOLERANCES
EXCEPT AS
CWBF-1WM
TITLE / DESC.:
ANGLE:
0.03 0.015 1/32"
Willoughby Industries, Inc.
STANDARD
16 20 19
2
1
6
5
4
3
7
8 9
10
18
17
11 12 13 14
13 15 21
10"
6"
6"
WILLOUGHBY

Installation & Operation Manual
Wall Mounted- Outdoor Drinking Fountain / Bottle Filler
WODF-1WM Series / CWBF-1WM Series
Willoughby Industries, Inc. TOLL FREE [phone] ●LOCAL [phone] ●FAX [phone]
Page 9Rev. 6/2015 www.willoughby-ind.com
Hardware Identification
WODF Series / CWBF Series Hardware
1/4-20 x 1/2"
SECURITY SCREW
4500NSS
T27
1/4" PINNED TORX BIT
800115
1/4"-20 x 2"
FLAT HEAD SECURITY SCREW
4509SSN
1/4"-20 x 1/2"
PHILLIPS SCREW
800144
1/4-20 x 1"
SECURITY SCREW
800114
3/4" NPT
BRASS LOCKNUT
600612N
1/4"-20 x 2-1/2"
CARRIAGE BOLT
600635N
1/4"-20 HEX NUT
600613N

Installation & Operation Manual
Wall Mounted- Outdoor Drinking Fountain / Bottle Filler
WODF-1WM Series / CWBF-1WM Series
Willoughby Industries, Inc. TOLL FREE [phone] ●LOCAL [phone] ●FAX [phone]
Page 10Rev. 6/2015 www.willoughby-ind.com
Installation Instructions
Step 1: Fixture Installation
Note: The WODF outdoor drinking fountain / CWBF outdoor bottle filler is to be mounted
on a flat, suitably level surface (wall, concrete or otherwise) with an adequate
support structure.
Note: Refer to the Physical / Rough-In Dimensions for locating fixture mounting
points and plumbing connections.
1.) Install service shut-off valve in water supply line (valve not furnished).
2.) Locate and complete the rough-in mounting holes and plumbnig access hole as specified.
3.) Install the drinking fountain or bottle filler using the supplied hardware kit. Cut the included all-
thread rods to lengths adequate for proper fixture installation through the wall and thread the
rods into the tappings on the rear of the fixture.
4.) Once the rods have been attached, mount the fixture by inserting the rods through the mounting
holes in the wall. Tighten the included washers and nuts to the all-thread through the chase side
(inside) of the wall just enough to hold the fixture in position.
5.) Make sure that the positioned fixture is level, both front to back and side to side, to ensure
proper draining. Adjust as necessary, then fully tighten the nuts to secure the fixture.
6.) As noted previously, flush the water supply line with clean drinking water before making final
connections to the drinking fountain.
7.) Connect water supply line to inline strainer inside the drinking fountain or bottle filler using 3/8"
plastic tubing (extra tubing not furnished). Push tube straight into fitting on filter about 3/4" until it
reaches a positive stop. Water supply connection must comply with local codes.
8.) Connect the drain line to drainage system. Drain is to be 1-1/2" IPS minimum to a porous gravel
flll or main sewer line located below frost line. Installer to provide waste trap downstream of drain
connection. Drain and waste trap must comply with local codes.
9.) Turn on water supply and check both the water supply lines and drain lines for leaks.*
*If you have a Push Button model fountain or bottle filler, go to Step 2A
If you have a Battery Operated Infrared Sensor model bottle filler, go to Step 2B

Installation & Operation Manual
Wall Mounted- Outdoor Drinking Fountain / Bottle Filler
WODF-1WM Series / CWBF-1WM Series
Willoughby Industries, Inc. TOLL FREE [phone] ●LOCAL [phone] ●FAX [phone]
Page 11Rev. 6/2015 www.willoughby-ind.com
Installation Instructions (cont.)
Step 2A: Adjusting Drinking Fountain Flow (Push Button)
(WODF-1 shown)
1.) Insert a standard flat-head screwdriver into
adjustment opening on face of pushbutton,
as shown.
2.) Rotate screwdriver to adjust until
desired flow is achieved:
Rotate clockwise to increase flow.
Rotate counterclockwise to decrease flow.
Step 2B: Battery Operated Infrared Sensor Startup
1.) Remove the bottle filler body cap on the top of the fixture.
2.) Open the top of the battery box and insert 4X batteries. Replace the battery box, and
check that all sensor, battery box, and valve connections are secure.
3.) Replace the body cap once the IR sensor has completed the start-up mode.

Installation & Operation Manual
Wall Mounted- Outdoor Drinking Fountain / Bottle Filler
WODF-1WM Series / CWBF-1WM Series
Willoughby Industries, Inc. TOLL FREE [phone] ●LOCAL [phone] ●FAX [phone]
Page 12Rev. 6/2015 www.willoughby-ind.com
Care and Maintenance
Stainless Steel Care
Stainless Steels are basically alloys of iron and chromium and are corrosion resistant. Stainless
steel has a bright surface that is easy to clean and is free from oxides. Therefore, cleaning of
stainless steel is relatively simple and easy if done on a regular basis.
)UHTXHQF\RIFOHDQLQJVKRXOGGHSHQGRQWKHUDWHDWZKLFKWKH¿[WXUHEHFRPHVGLUW\5HPHPEHU
that fresh (soft) deposits of all kinds are relatively easy to remove, while removing older (hard)
GHSRVLWVDUHPXFKPRUHGLI¿FXOW(VWDEOLVKDFOHDQLQJ6&+('8/(
5RXWLQH FOHDQLQJ VKRXOG LQYROYH RUGLQDU\ VRDS RU GHWHUJHQW DQG ZDWHU DSSOLHG ZLWK D VSRQJH
brush or cloth. Baking soda, borax or any of several non-abrasive commercial cleansing agents
FDQKHOSKDVWHQWKHFOHDQLQJDFWLRQ$IWHUVFUXEELQJULQVH7+2528*+/<DQGZLSHGU\
'2127XVHFRPPRQVWHHOZRROVFRXULQJSDGVVFUDSHUVZLUHEUXVKHV¿OHVRURWKHUVWHHOWRROVWR
clean stainless steel. Such items will scratch the surface or leave small particles of iron imbedded
in the surface, which will eventually rust and stain the surface - even appearing as if the stainless
itself was rusting.
&HUWDLQFKHPLFDOFRPSRXQGVLIXVHGRQVWDLQOHVVVWHHOFDQJLYHWKHDSSHDUDQFHRIUXVWDQGLI
allowed to stand for long periods of time, can pit the surface of even stainless. Products containing
hydrochloric acid, muriatic acid or potassium hydrochloride can ruin the surface.
Unit Care
Willoughby Industries’WODF Outdoor Drinking Fountains are not freeze resistant without the FRV
Freeze Resistant Valve option. The unit should be disconnected or shut off from the water supply
and drained during the colder months. For more information, refer to the rough-in detail.
In order to ensure adequate flow and cleanliness of water, the inlLne strainer in the supply line
should be cleaned or replaced regularly. New inline strainers can be ordered using Willoughby Part
No. 980632.
Unit Care
Willoughby Industries’CWBF Outdoor Bottle Fillers are not freeze resistant without the FRV Freeze
Resistant Valve option. The unit should be disconnected or shut off rom the water supply and
drained during the colder months. For more information, refer to the rough-in detail.
7KHFKDUFRDOZDWHUILOWHUVKRXOGEHUHSODFHGHYHU\PRQWKVGHSHQGLQJRQZDWHUTXDOLW\1HZ
FKDUFRDOILOWHUVFDQEHRUGHUHGXVLQJ:LOORXJKE\3DUW1R

Installation & Operation Manual
Wall Mounted- Outdoor Drinking Fountain / Bottle Filler
WODF-1WM Series / CWBF-1WM Series
Willoughby Industries, Inc. TOLL FREE [phone] ●LOCAL [phone] ●FAX [phone]
Page 13Rev. 6/2015 www.willoughby-ind.com
Troubleshooting- Fixture Plumbing
I. Insufficient Flow
A. Ensure the service shut-off valve is fully open (provided by installer).
B. Ensure water supply is within the normal operating range of 40-60 psi.
1. If pressure is too low, flow can be drastically reduced.
2. If pressure is too high, the strainer and/or valve may have been damaged.
3. The unit is rated for a maximum range of 30-105 psi.
C. Inspect the unit's valve for damage, and replace if necessary.
D. Inspect the inline strainer for damage and/or clogging, and clean or replace as necessary.
E. Check all fittings and tubing for damage and leaks. Replace components as necessary.
II. Unit has problems draining
A. Remove and clean the drain screen.
B. Remove any debris from the drain.
C. Remove any debris from the PVC pipe and fittings.
D. Check and clear the waste trap (provided by installer).

Installation & Operation Manual
Wall Mounted- Outdoor Drinking Fountain / Bottle Filler
WODF-1WM Series / CWBF-1WM Series
Willoughby Industries, Inc. TOLL FREE [phone] ●LOCAL [phone] ●FAX [phone]
Page 14Rev. 6/2015 www.willoughby-ind.com
Troubleshooting - Infrared Sensor
I. %RWWOHILOOHU does not function (red light does not appear when user steps in front of sensor)
A. Nopowertosensor.Makecertainthatpowerison.CheckEDWWHU\ SRZHUOHYHOVFRQWDFWVand
connections.5HSDLURUUHSODFHDVQHFHVVDU\
B. :LOORXJKE\ IRSensor not operating. Replace :LOORXJKE\ IR Sensor3DUW
II. %RWWOHILOOHU does not function (red light appears when user steps in front of sensor and
solenoiddoes not click)
A. Debris in solenoid; disassemble, clean, and flush.
B. Solenoid not wired correctly; check solenoid connections.
C. Solenoid problem; replace solenoid.
III. No water when activated (valve clicks)
A. Make certain that water is turned on.
B. Valve clogged. Clean or replace filter.
IV. Very low flow or slow dribble
A. Check supply stop(s); open if closed.
B. Debris in filter; remove, clean, and reinstall.
C. Debris in aerator or spray head; remove, clean and reinstall.
D. Disassemble solenoid; clean and flush.
V. Continues to run (with power on and red light flashing)
A. Non-permanent target in range after user leaves. Remove non-permanent target. If this
target is a new permanent target (i.e., a new wall or partition), UHPRYH EDWWHULHV for
fifteen (15) seconds. Turn power back on and let the sensor complete start-up mode.
B. Sensor failure; replace sensor.
VI. Continues to run (even with power disconnected)
A. Solenoid valve installed backwards.
B. Debris in solenoid, won’t close properly; remove operator and clean. Reassemble in the
same manner.

Installation & Operation Manual
Wall Mounted- Outdoor Drinking Fountain / Bottle Filler
WODF-1WM Series / CWBF-1WM Series
Willoughby Industries, Inc. TOLL FREE [phone] ●LOCAL [phone] ●FAX [phone]
Page 15Rev. 6/2015 www.willoughby-ind.com
2 PLCS:
1
PART #:
Indianapolis, Indiana
TRB TRB 12-18-13
12-18-13
A1 OF 1
600315
NOTED
1:1
PUSHBUTTON VALVE ASSEMBLY, ADJUSTABLE
SHEET:REV.:
ORIG.:REVISION:
SCALE: REF.:
NOTED
3 PLCS: AMAT'L:
FRACTIONS:
TOLERANCES
EXCEPT AS
SIZE:
TITLE / DESC.:
ANGLE:
0.03 0.015 1/32"
Willoughby Industries, Inc.
STANDARD
ITEM # PART # DESCRIPTION QTY.
1 380110 PUSH PIN, ADJUSTABLE PUSHBUTTON VALVE 1 2 380111 SLEEVE, ADJUSTABLE PUSHBUTTON VALVE 1 3 800157 6-32 x 1/4" SH CAP SCREW 1 4 380062 SLEEVE, ADAPTER TO ELKAY PLASTIC SELF-CLOSING VALVE 1 5 600286 NUT, CARTRIDGE MOUNTING 1 6 600285 SELF-CLOSING CARTRIDGE, 1 GPM-LK 1
3
2
6
5
4
1
WILLOUGHBY
DRAWING: Pushbutton Detail

Installation & Operation Manual
Wall Mounted- Outdoor Drinking Fountain / Bottle Filler
WODF-1WM Series / CWBF-1WM Series
Willoughby Industries, Inc. TOLL FREE [phone] ●LOCAL [phone] ●FAX [phone]
Page 16Rev. 6/2015 www.willoughby-ind.com
Warranty
Willoughby Industries, Inc. warrants to commercial and institutional purchasers only that each unit
will be free from defects in workmanship and materials under normal use and service upon the
following terms and conditions for a period of one (1) year from date of shipment.
This warranty does not cover installation or any other labor charges and does not apply to any
components damaged by accident, abuse, improper installation or improper maintenance. This
warranty does not cover any installation that did not comply with national, state and local building,
plumbing or electrical codes. The warranty is limited to replacing or repairing at manufacturer’s
option, transportation charges prepaid by the purchaser, any component or part which upon our
inspection shall be deemed as defective within the limitations of this warranty. The replacement or
repair of defective units as stated in this warranty shall constitute the sole remedy of the purchaser
and the sole liability of Willoughby Industries, Inc. Willoughby Industries, Inc. shall not otherwise be
liable under any indirect damages caused by defects in the repair or replacement thereof.
This warranty only extends to commercial and industrial purchasers and does not extend to any
others, including consumer customers of commercial institutional purchasers. This warranty is in
lieu of all other warranties, expressed or implied, including implied warranty of merchantability or
¿WQHVVIRUDSDUWLFXODUSXUSRVHRURWKHUZLVH
