Willz WLCMWP09S2B-09 User manual

Microwave Oven
User Manual
WLCMWP09S2B-09
WLCMWP09BKB-09
WLCMWP09WEB-09

CONTENT
IMPORTANT SAFETY INSTRUCTIONG ............................................................................................................. 1
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY .............................. 2
GROUNDING INSTRUCTIONS .......................................................................................................................... 3
INSTALLATION GUIDE ...................................................................................................................................... 4
INSTALLING THE TURNTABLE ......................................................................................................................... 4
PRODUCT DIAGRAM ........................................................................................................................................ 5
CONTROL PANEL ............................................................................................................................................. 5
OPERATION INSTRUCTIONS ......................................................................................................................... 6-9
COOKING UTENSILS GUIDE ........................................................................................................................... 10
COOKING TECHNIQUES .................................................................................................................................11
CLEANING AND CARE ....................................................................................................................................12
SPECIFICATIONS .............................................................................................................................................12
PRODUCT WARRANTY ....................................................................................................................................13
WARRANTY REGISTRATION ............................................................................................................................14
IMPORTANT SAFETY INSTRUCTIONG
WARNING - to reduce the risk of burns, electric shock, fire, injury to persons, or exposure to excessive
microwave energy, basic safety precautions should be followed, including the following:
1. Read all instructions before using the microwave.
2. Read and follow the specific “PRECAUTIONS TO AVOID POSSIBLE EXPOSURE OR EXCESSIVE
MICROWAVE ENERGY” .
3. This microwave must be grounded. Connect only to properly grounded outlets. See page for grounding
instructions.
4. Install or place this microwave only in accordance with installation instructions.
5. Some produce such as whole eggs and sealed containers - for example, closed glass jars - are able
to explode and should not be heated in this oven.
6. This microwave is intended for use only as described in this manual. Do not use corrosive chemicals
or vapors in this microwave.This type of microwave is specifically designed to heat, cook, or dry foods.
It is not designed for laboratory use.
7. As with any appliance, close supervision is necessary when used by children.
8. To reduce the risk of fire in the oven cavity:
Do not overcook food. Carefully attend to the microwave when paper, plastic, or other combustible
materials are placed inside the microwave to facilitate cooking.
Remove wire twist-ties from paper or plastic bags before placing in microwave.
If materials inside the microwave should ignite, keep microwave door closed, turn it off, and disconnect
the power cord or turn off the power fuse at the circuit breaker panel.
Do not use the microwave cavity for storage purposes. Do not leave paper products, cooking utensils,
or food in the cavity when not in use.
1

9. Liquids, such as water, coffee, or tea, may overheat beyond the boiling point without appearing to be
boiling due to surface tension of the liquid. Visible bubbling or boiling when the container is removed
from the microwave is not always present. THIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY
BOILING OVER WHEN A SPOON OR OTHER UTENSIL IS INSERTED INTO THE LIQUID. To reduce the
risk of injury:
Do not overheat the liquid;
Stir the liquid both before and halfway through heating;
Do not use straight-sided containers with narrow necks;
After heating, allow the container to stand in the microwave a short time before removing;
Use extreme care when inserting a spoon or other utensil into the container.
10.Do not heat oil or fat for deep frying in this microwave. It is difficult to control the temperature of oil in
the microwave.
11.Pierce foods with heavy skins, such as potatoes, before cooking.
12.The contents of feeding bottles and baby jars should be stirred or shaken and the temperature should be
checked before serving to avoid burns.
13.Cooking utensils may become hot from heat transferred from the heated food. Pot holders may be needed
to handle these utensils.
14.Do not cover or block any openings on the microwave.
15.Do not store or use this microwave outdoors. Do not use this microwave near water, for example, near a
kitchen sink, in a wet basement, near a swimming pool, or similar location.
16.Do not operate this microwave if it has a damaged cord or plug, if it is not working properly, or if it has
been damaged or dropped.
IMPORTANT SAFETY INSTRUCTIONG(continued)
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
1. Do not attempt to operate this microwave with the door open. Door open operation can result in harmful
exposure to microwave energy. It is important not to defeat or tamper with the door interlocks
2. Do not place any objects between the microwave front face and the door, or allow soil or cleaner residue to
accumulate on sealing surfaces.
3. Do not operate the microwave if damaged. It is particularly important that the microwave door be properly
closed and there is no damage to the door (bent), hinges and latches (broken or loosened), or door seals
and sealing surfaces.
4. The microwave should not be adjusted or repaired by anyone except properly qualified service personnel.
2

GROUNDING INSTRUCTIONS
This microwave must be grounded. In the event of an electrical short circuit, grounding reduces risk of electric
shock by providing an escape wire for the electric current.Consult a qualified electrician or serviceman if the
grounding instructions are not completely understood, or if doubt exists as to whether the appliance is
properly grounded, and either: 1) If it is necessary to use an extension cord, use only a 3-wire extension cord
that has a 3-blade grounding plug and a 3-slot receptacle that will accept the plug on the appliance. The
marked rating of the extension cord shall be equal to or greater than the electrical rating of the appliance, or 2)
Do not use an extension cord. If the power supply cord is too short, have a qualified electrician or serviceman
install an out let near the appliance. For questions regarding the grounding instructions, please contact our
Customer Support Center at 1-800-324-0340.
WARNING: Improper use of the grounding plug can result in risk of electric shock.
ELECTRICAL REQUIREMENTS
The electrical requirements are a 120 volt 60 Hz, AC only, 20 amp
It is recommended that a separate circuit serving only the oven be provided.
The oven is equipped with a 3-prong grounding plug. It must be plugged into a wall outlet properly
installed and grounded.
POWER CORD
A short power supply cord is provided to reduce the risks resulting from becoming entangled in or
tripping over a longer cord.
Longer cord sets or extension cords are available and may be used if care is exercised in their use.
If using a longer cord, the marked electrical rating of the cord set or extension cord should be at least as
great as the electrical marking of the microwave itself and the extension cord must be a grounded-type
3-wire cord. The longer cord should be arranged so it will not drape over the counter or tabletop.
RADIO OR TV INTERFERENCE
Should there be any interference caused by the microwave oven to your radio or TV, check that the
microwave oven is on a different circuit, relocated the radio or TV as far away from the oven as feasible
or check position and signal of receiving antenna.
3

INSTALLATION GUIDE
1. Make sure that all the packing materials are removed from inside the microwave door.
2. Check the microwave for damage, such as misaligned or bent door, damaged door seals and sealing
surface, broken or loose door hinges and latches, and dents inside the cavity or on the door. If there are any
damages, do not operate the microwave and contact Customer Service at 1-800-324-0340.
3. This microwave must be placed on a flat, stable surface to hold its weight and the heaviest food likely to be
cooked inside.
4. Do not place the oven where heat, moisture, or high humidity is generated. Do not place microwave near
combustible materials.
5. For correct operation, the oven must have sufficient airflow. Allow 8” of space above the microwave, 4” at
back and 2”on each side of the unit.
6. The appliance should only be used on a countertop over 3 feet above the floor.
7. This appliance should be serviced only by qualified service personnel, contact nearest authorized service
facility for examination, repair, or adjustment.
8. Do not cover or block any openings on the microwave. Do not remove microwave feet. Do not operate the
oven without glass tray, roller support, and shaft in their proper positions.
9. Make sure that power cord is undamaged and does not run under the microwave or over any hot or sharp
surface.
10.The socket must be readily accessible so the microwave oven can be easily unplugged in an emergency.
INSTALLING THE TURNTABLE
Never place the glass tray upside down.
The glass tray should never be restricted.
Both the glass tray and turntable ring assembly must always be used during cooking.
All food and containers of food should always be placed on the glass tray for cooking.
If the glass tray or turntable ring assembly cracks or breaks, call customer service 1-800-324-0340.
4

PRODUCT DIAGRAM
1. Door Lock System
2. Oven Window
3. Roller Ring
4. Door Release Button
5. Control Panel
6. Wave Guide (Do not remove)
7. Glass Turntable
EXPRESS COOK
BEVERAGE FROZEN
DINNER
PIZZA
REHEAT
POPCORN
POTATO
123
7 8 9
456
CLOCK
0
STOP
CANCEL
TIME
COOK TIMER
WEIGHT
DEFROST
TIME
DEFROST POWER
LEVEL
START
+30 SEC
DISPLAY Cooking time, power, indicators and food weight are
displayed.
AUTO COOK MENUS Instant settings to cook popular foods.
UMBER PADS (0-9) Press to set time or weight.
CLOCK Press to set current time.
TIME COOK Press to set microwave cooking program.
TIMER The TIMER function can be used alone, even in the
process of cooking.
TIME DEFROST Press to set defrost program based on time.
WEIGHT DEFROST Press to set defrost program based on
weight.
POWER Press to set microwave power levels.
STOP/CANCEL Press to reset the oven before setting a cooking
program. Press once temporarily stop cooking, or twice to cancel
cooking altogether.
START/+30 SEC.Press to start a cooking program. It is also
used to set quick start function or to increase cooking time during
cooking.
CONTROL PANEL
5

OPERATION INSTRUCTIONS
●During the setting mode, the system will return to waiting mode if there is not any operation within 30s
●During cooking, if press Stop/Cancel pad once, the program will be paused, then press START/+30 sec.
pad to resume, but if press Stop/Cancel pad again, the program will be canceled.
●After ending cooking, the system will sound beeps to remind user every two minutes until user press
Stop/Cancel pad or open the door.
SETTING THE CLOCK
This is a 12- or 24-hour clock. You can choose it by pressing Clock pad.
For example, suppose you want to set the oven clock time to 8:30.
1. Press Clock pad once to select 12-hour clock, press again to select 24-hour clock.
2. Use the number pads to enter the clock time (touch number pads 8,3,0 in order to enter 8:30).
3. Press Clock or START/+30 Sec. once to confirm.
NOTE : During the cooking program, the current time can be seen by pressing Clock pad.
SETTING THE OVEN TIMER
1. Press Timer pad once.
2. Enter the amount of time you want to count down by touching the number pads.
The maximum time is 99 minutes and 99 seconds.
3. Press START/+30 Sec. pad to start.
NOTE: The timer function can be used in any cooking process. You can check the countdown time by pressing
Timer pad, but if press Stop/Cancel pad when the display shows the time, the function is canceled.
EXPRESS COOKING
In standby mode, press a number (1-6) key once, to start cooking time respectively 1 min., 2 mins., 3 mins.,
4 mins., 5 mins. and 6 mins. The oven will start to cook at full power.
ADD 30 SECONDS
In standby mode, press START/+30 Sec. pad repeatedly to enter cooking time (each for 30 seconds, up to
99 minutes 59 seconds) the oven will start automatically at 100% high power level. During cooking (except
auto cook and defrost) you can add cooking time by pressing START/+30 Sec. pad.
6

OPERATION INSTRUCTIONS(continued)
MICROWAVE COOKING
1. Press Time Cook pad.
2. Press number pad to enter desired cooking time. The maximum number can be entered is 99 minutes and
99 seconds.
3. Press Power pad once and then use the number pads to enter the power level.
4. Press START/+30 Sec. pad.
Use single digit to adjust a cooking power level:
NOTE: During cooking, press Power pad to check the cooking power level for 5 seconds, and you can adjust
the cooking power level by touching number pad within 5 seconds.
SETTING TIME DEFROST
1. Press Time Defrost pad.
2. Enter desired defrosting time by touching correct number pads. The longest time you can set is 99 minutes
and 99 seconds.
3. Press START/+30 Sec. pad.
NOTE: During defrosting, the oven will pause and sound beep to remind user to turn the food over, after that,
press START/+30 Sec. to resume. You can check the power level during defrosting by pressing Power pad.
MULTI-STAGE COOKING
Your oven can be programmed for up to 2 automatic cooking sequences.
Suppose you want to set the following cooking program.
1. In standby mode, press Time Cook pad once and enter the cooking time by number pads.
2. Press Power pad to set the power level. Do not touch START/+30 Sec.
3. Repeat the steps above to input the second cooking program.
4. Press START/+30 Sec. to start.
NOTE: Only microwave functions for multi-cooking stage settings, you can set a maximum of two microwave
cooking programs.
Press number Power (Display)
1,0 100%(P10)
9 90%(P-9)
8 80%(P-8)
7 70%(P-7)
6 60%(P-6)
5 50%(P-5)
Press number Power(Display)
4 40%(P-4)
3 30%(P-3)
2 20%(P-2)
1 10%(P-1)
0 0%(P-0)
7

OPERATION INSTRUCTIONS(continued)
SETTING WEIGHT DEFROST
1. Press Weight Defrost pad.
2. Use the number pads to enter food weight (The weight range is 4oz to 64oz.).
3. Press START/+30 Sec. pad.
NOTE:The maximum weight is 64 ounces. During defrosting program, the system will pause and sound
beeps to remind user to turn food over, and then press START/+30 Sec. to resume the defrosting.
SETTING DOOR LOCK
The child lock prevents unsupervised operation by children.
To set, in standby mode, press and hold Stop/Cancel for 3 seconds. ‘Loc’ is indicated on the display.
To cancel, press and hold Stop/Cancel for 3 seconds. ‘Loc ’ indication disappears.
AUTO COOK MENUS
The auto cook menus setting allow you to cook or reheat food automatically without entering power level
or time.
POTATO
For potatoes (8oz/each):
1. Press Potato once to set 1 portion, or press twice to set 2 portions.
2. Press START/+30 Sec. to start.
POPCORN
For a 3.5 oz. bag of microwave popcorn:
1. Press Popcorn once.
2. Press START/+30 Sec. to start.
PIZZA
Reheating pizza:
1. Press Pizzato switch between 6, 11 or 16oz.
2. Press START/+30 Sec. to start.
BEVERAGE
For Beverage :
1. Press Beverage to switch between 8,12,16oz.
2. Press START/+30 Sec. to start.
8

FROZEN DINNER
For frozen dinners:
1. Press Frozen Dinner to switch between 9,18oz.
2. Press START/+30 Sec. to start.
REHEAT
For a plate of cool food (7-28 oz.):
1. Press Reheat to switch between 7-28oz.
2. Press START/+30 Sec. to start.
Auto Menu Weight / Portion Time
1-PC(8oz) 5:00
2-PC(16oz) 8:00
Popcorn 3.5oz 2:30
6oz 0:50
11oz 1:20
16oz 1:50
8oz 1:30
12oz 2:40
16oz 3:50
Potato
Pizza
Beverage
Auto Menu Weight / Portion Time
9oz 6:00
18oz 10:00
7oz 1:30
11oz 2:00
14oz 2:30
18oz 3:00
21oz 3:30
25oz 4:00
28oz 4:30
Frozen Diner
Reheat
OPERATION INSTRUCTIONS(continued)
9

COOKING UTENSILS GUIDE
This section lists which utensils can be used in this microwave, which have limited use for short periods,
and which should not be used in this microwave.
RECOMMENDED
Microwave browning dish -- Use to brown the exterior of small items such as steaks, chops, or pancakes.
Follow the directions provided with your browning dish.
Microwaveable plastic wrap -- Use to retain steam. Leave a small opening for some steam to escape
and avoid placing it directly on the food.
Paper towels and napkins -- Use for short-term heating and covering; these absorb excess moisture and
prevent splattering. Do not use recycled paper towels which may contain metal and could ignite.
Glass and glass-ceramic bowls and dishes -- Use for heating and cooking.
Paper plates and cups -- Use for short-term heating at low temperatures. Do not use recycled paper which
may contain metal and could ignite.
Wax paper -- Use as a cover to prevent splattering.
Thermometers -- Use only those labeled “Microwave Safe” and follow all directions. Check the food in several
places. Conventional thermometers may be used on microwave food once the food has been removed from
the microwave.
LIMITED USE
Aluminum foil -- Use narrow strips of foil to prevent overcooking exposed areas. Using too much foil can
damage your microwave, so be careful. Keep 1” between aluminum foil and cavity.
Ceramic, porcelain, and stoneware -- Use these if they are labeled “Microwave Safe”. If they are not labeled,
test them to make sure they can be used safely.
Plastic -- Only use if labeled “Microwave Safe”. Other plastics may melt.
NOT RECOMMENDED
Glass jars and bottles -- Regular glass is too thin to be used in a microwave. It can shatter and cause damage
and injury.
Paper bags -- These are a fire hazard, except for popcorn bags that are designed for microwave use.
Styrofoam plates and cups -- These can melt and leave an unhealthy residue on food.
Plastic storage and food containers -- Containers such as margarine tubs can melt in the microwave.
Metal utensils -- These can damage your oven. Remove all metal before cooking.
NOTE:Should you wish to check if a dish is safe for microwaving, place the empty dish in the oven and
microwave on HIGH for 30 seconds. A dish which becomes very hot should not be used.
10

COOKING TECHNIQUES
Your microwave makes cooking easier than conventional cooking, provided you keep these considerations
in mind:
STIRRING
Stir foods such as casseroles and vegetables while cooking to distribute heat evenly.
Food at the outside of the dish absorbs more energy and heats quicker, so stir from the outside
to the center.
The microwave will turn off when you open the door to stir your food.
ARRANGEMENT
Arrange evenly shaped foods, such as chicken pieces or chops, with the thicker, meatier parts towards
the outside of the turntable where they receive more microwave energy.
To prevent overcooking, place delicate areas, such as asparagus tips, towards the center of the turntable.
SHIELDING
Shield food with narrow strips of aluminum foil to prevent overcooking.
Areas that need shielding include poultry wing tips, the ends of poultry legs, and corners of square
baking dishes.
Use only small amounts of aluminum foil, as larger amounts may damage your microwave.
TURNING
Turn foods over midway through cooking to expose all part to microwave energy.
This is especially important when cooking large foods such as roasts.
STANDING
Foods cooked in a microwave build up internal heat and continue to cook for a few minutes after
heating stops.
Let foods stand to complete cooking, especially for foods such as cakes and whole vegetables.
Roasts need this time to complete cooking in the center without overcooking the outer areas.
All liquids such as soup or hot chocolate, should be shaken or stirred when cooking is complete.
When heating baby food, stir well after removing from microwave and test temperature before serving.
ADDING MOISTURE
Microwave energy is attracted to water molecules.
Food that uneven in moisture content should be covered or allowed to stand so that the heat
disperses evenly.
Add a small amount of water to dry food to help it cook.
11

CLEANING AND CARE
1. Turn off the microwave and unplug the power cord from the wall when cleaning.
2. Keep the inside of the microwave clean. When food splatters or spilled liquids adhere to microwave walls,
wipe with a damp cloth. Mild detergents may be used if the microwave gets very dirty. Avoid using spray or
other harsh cleaners. They may stain, streak, or dull the door surface.
3. The outside of the microwave should be cleaned with a damp cloth. To prevent damage to the operating
parts inside the microwave, water should not be allowed to seep into the ventilation openings.
4. Wipe the window on both sides with a damp cloth to remove any spills or splatters.
5. Do not allow the control panel to become wet. Clean with a soft, damp cloth. When cleaning the panel, leave
the microwave door open to prevent it from accidentally turning on.
6. If steam accumulates inside or around the outside of the door, wipe with a soft cloth. This may occur when
the microwave is operated under high humidity. This is normal.
7. It may be necessary to remove the glass tray for cleaning. Wash the tray in warm, soapy water or in a
dishwasher.The roller ring and microwave floor should be cleaned regularly to avoid excessive noise.
Wipe the bottom surface of the microwave with a mild detergent.
8. The roller ring may be washed in mild, soapy water or in a dishwasher. When removing the roller ring,
be sure to replace it in the proper position.
9. Remove odors from your microwave by combining a cup of water with the juice and skin of one lemon in a
microwaveable bowl. Microwave for 5 minutes. Wipe thoroughly and dry with a soft cloth.
10. If the light bulb burns out, please contact customer service to have it replaced.
11. The microwave should be cleaned regularly and any food deposits should be removed. Failure to maintain
the microwave in a clean condition could lead to deterioration of surfaces that could adversely affect the life
of the unit and could possibly result in a hazardous situation.
12. Please do not dispose of this appliance into a regular garbage receptacle. Please check to see where you
can dispose such appliances.
SPECIFICATIONS
Power Consumption 120V, 60Hz, 1400W (microwave)
Output 900W
Operation Frequency 2450MHz
Outside Dimensions (H × W × D) inch.
Oven Cavity Dimensions (H × W × D) inch.
Oven Capacity 0.9 cu. ft.
Net Weight Approx. 24.3 lbs.
10 34
9
16
13
19
93
16
516 78
12
13
12

13
PRODUCT WARRANTY
This warranty applies to products sold by Galanz Americas in the U.S. This warranty is in lieu of
any other warranty and expressly applies to the individual product only.
Galanz product is warranted for one year following purchase for defects in material and
workmanship. Please save your receipt as proof of purchase is required to make a warranty
claim. During this period, we will provide the purchase price of this product, a replacement or the
equivalent, or repair per our discretion.
The warranty cannot be transferred through resale, including the resale through a 3rd party
unauthorized retailer and is only bestowed up on the original consumer purchaser upon purchase
from an authorized retailer.
This warranty does not cover and excludes damage or defects caused by:
Consumer misuse
Abuse
Neglect including the failure to clean and/or provide adequate regular maintenance as outlined
in the user manual
Commercial use
Subjecting the product to any voltage outside the specified range
Loss of parts
The affixing of any attachments not provided with the product
Accident
Use in a manner not intended and outlined in the user manual.
Any subsequent damages caused by the above listed exclusions will not
be covered and any claims determined to meet the above exclusions will
be denied. All liability is limited to the purchase price and does not include any:
Retail offered extended warranties
Tax
Other charges(including postage to send required materials)
Incidental and/or consequential damages associated with the product in question.
Every implied warranty, including any statutory warranty of merchantability or fitness for a particular
purpose is disclaimed except to the extent prohibited by law, in which case such warranty is limited to
the duration of this written warranty. This warranty gives you specific legal rights. You may have other legal
rights that vary depending on where you live. Some states do not allow limitations on implied warranties
or special, incidental, or consequential damaged, so the above limitations may not apply to you.
If you have a claim under this warranty, please call our Customer Service number: 1-800-562-0738.
For faster service, please have the model number, serial number, and receipt ready for the operator to
assist you.














Please mail this warranty card to the address below within
30 days of purchase.Or you can register your product on
line by going to www.galanz.com\us.
Galanz Americas, 55 Challenger Road, Suite 503,
Ridgefield Park, NJ 07660.
PLEASE PRINT CLEARLY.
Name
Address
City State ZIP
Phone Email
Model Number Serial Number
Purchase Location
You must attach a copy of your purchase receipt to
validate your registration.
WARRANTY REGISTRATION
14

Distributed by Guangdong Galanz Microwave Electrical Appliances Manufacturing Co., Ltd.,
Huangpu, Zhongshan, Guangdong, 528429, China
For service, support and warranty information, call 800-562-0738
