Operation Manual
Parts Washer
61328
Illustration similar, may vary depending on model
Read and follow the operating instructions and safety information before using for the first time.
Technical changes reserved!
Due to further developments, illustrations, functioning steps and technical data can differ insignificantly.
Updating the documentation
If you have suggestions for improvement or have found any irregularities, please contact us.

© by WilTec Wildanger Technik GmbH Seite 2
http://www.WilTec.de
http://www.aoyue.eu März 2020 Version 2
http://www.teichtip.de
The information contained in this document is subject to change without prior notice. No part of this
document may be copied or duplicated in another form without the prior written consent of WilTec Wil-
danger Technik GmbH. The WilTec Wildanger Technik GmbH assumes no liability for any errors in this
user manual or the connection diagram.
Although WilTec Wildanger Technik GmbH has made every effort to make sure that this user manual is
complete, accurate and updated, errors cannot always be avoided. In the event of problems with this
user manual please complete and send this form back to us.
FAX-notification ([phone]),
from: ________________________________________
Name: ________________
Firm:_____________________
Tel/Fax:__________________
I would like to report the following mistakes:
___________________________________________________________________
Customer Service WilTec Wildanger Technik GmbH
e-mail: [e-mail]
Tel: [phone]
Introduction
Thank you for purchasing this quality product. To minimize the risk of injury we urge that our clients
take some basic safety precautions when using this device. Please read the operation instruc-
tions carefully and make sure you have understood its content.
Keep these operation instructions safe.

© by WilTec Wildanger Technik GmbH Seite 3
http://www.WilTec.de
http://www.aoyue.eu März 2020 Version 2
http://www.teichtip.de
ASSEMBLY INSTRUCTIONS
1.Remove machine from carron and inspect for any visual damage.
2.Remove parts inside the machine.
3.Lay clan and hard cardboard on the floor and lay machine on its lid.
(Make sure you hold cover closed when laying machine on its lid.)
4.Mount four legs on brackets with M6X12 philips head screws and M6
Keps nuts. NOTE: DO NOT TIGHTEN.
5.Place lower shelf between legs with flat surface up and attach to legs with
M6X12 philips head screws and M6 keps nuts.
6.With legs press tight against lower shelf, tighten all screws to lower shelf.
7.Tighten all the screws installed in step 4.
8.Stand machine up ,be careful to hold lid closed.
9.Put work shelf and basket into the machine.
10.Mount pump assembly into slot on the side of the machine then place
filter screen in position.
11.Plug machine into standard 115Volt 60Hz(240Volt 50Hz) grounded outlet
and fill with proper amount of fluid.
12.Turn switch on. Fluid should now be flowing from the flexible spigot.
SPECIFICATIONS
Recirculating Parts Washer
Overall Dimensions
30-3/4”X21-1/4”X35-3/4”
Tank Dimensions
29-7/8”X20-4/3”X10-8/10”
Max Solvent Capacity
20.Gallons
Max Pump Output Through Flexible Pipe
2.7-3.3L/min
Electrical Requirements
115V/60Hz0.5A(240V/50Hz/0.5A)
Gross Weight
26kg
CLEANING SOLUTIONS
Approved cleaning solutions:
Water/household detergents (PH6~8)
WARNING
The pump of your Parts Washer may be damaged if you use solvents other
than those listed above such as methyl ethyl ketone (MEK),Perchloroethylene
or trichloroethylene.
TROUBLE SHOOTING
The only trouble you should ever experience with your Parts Washer is
reduced volume flow or no flow of cleaning liquid from the flex hose nozzle.
The probable cause is foreign matter in the flex hose.
CORRECTIVE PROCEDURE
1.Check if indicator light on switch box is lit.
2.Using an insulated handle screw driver to lightly touch tip of housing of motor.
A light oscillation magneticpull indicates power is reaching the motor.
3.Disconnet power plug, remove flex hose from pump flow-out line.
4.Remove front of pump housing. Clean any foreign matter lodged around impeller.
5.Reassemble in reverse order.

© by WilTec Wildanger Technik GmbH Seite 4
http://www.WilTec.de
http://www.aoyue.eu März 2020 Version 2
http://www.teichtip.de
Explosionszeichnung

© by WilTec Wildanger Technik GmbH Seite 5
http://www.WilTec.de
http://www.aoyue.eu März 2020 Version 2
http://www.teichtip.de
Teil
Beschreibung
Menge
1
Cover
1
2
Work bakeet
1
3
Spring pan
4
4
Pin
4
5
Safety plate
1
6
Work shelf
1
7
Body
1
8
Spring washer
24
9
Nut
24
10
O-Ring
1
11
Plug
1
12
Shelf
1
13
Leg
4

© by WilTec Wildanger Technik GmbH Seite 6
http://www.WilTec.de
http://www.aoyue.eu März 2020 Version 2
http://www.teichtip.de
14
Pan screw
24
15
Nut
5
16
Spring washer
5
17
Screw
5
18
Strain relief
2
19
Cable and plug
1
20
Pump housing
1
21
Screen
1
22
Switch
1
23
Switch box
1
24
Flexible pipe
1
25
Elbox seat
1
26
Pump body
1
27
Pump back cover
1
28
Filter cover
1
29
Pump housing cover
1
30
Elbow
1
31
Plastic washer
1
32
Spigot
1
33
Location of knob
1
34
Filter
1
35
Shin washer
1
36
Impeller
1
37
Sealtinr
2
38
Sealring
1
39
Impeller holder
1

© by WilTec Wildanger Technik GmbH Seite 7
http://www.WilTec.de
http://www.aoyue.eu März 2020 Version 2
http://www.teichtip.de
Disposal regulations
EU guidelines regarding the disposal of scrap electric appliances (WEEE, 2012/19/EU) were imple-
mented in the law related to electrical and electronic equipment and appliances.
All WilTec electric devices that fall under the WEEE regulations are labelled with the crossed-out
wheeled waste bin logo. This logo indicates that this electric equipment must not be disposed with the
domestic waste.
The company WilTec Technik GmbH has been registered in the German registry EAR under the WEEE-
registration number DE45283704.
Disposal of used electrical and electronic appliances
(intended for use in the countries of the European Un-
ion and other European countries with a separate col-
lection system for these appliances).
The logo on the article or on its packaging points out
that this article must not be treated as normal house-
hold waste, but must instead be disposed to a recycling
collection point for electronic and electrical waste
equipment. By contributing to the correct disposal of
this article you protect the environment and the health
of your fellow men. Environment and health are threat-
ened by inappropriate disposal.
Materials’ recycling helps reduce the consumption of raw materials.
Additional information on recycling this article can be provided by your local community, municipal waste
disposal facilities or the store where you purchased the article.
Address:
WilTec Wildanger Technik GmbH
Königsbenden 12 / 28
D-52249 Eschweiler
Important notice:
The reprint or reproduction, even of excerpts, and any commercial use, even in part of this instructions
manual require the written permission of WilTec Wildanger Technik GmbH.
