WLD-TEC powerjet User manual

economical
convenient
safe
EN
Instruction manual
powerjet

3
2
1
4
1 - Gas controller
2 - Flame orifice
3 - Burner tube
4 - Trigger
5 - Locking device for continous operation
6 - Threaded adapter for
gas cartridges Camping Gaz CG1750
7 - Sealing
8 - Cartridge CG1750
(not included)
7
5
6
8

Read these instructions carefully to familiarize yourself with the product. Please retain
these operating instruction for future reference.
Application: Mobile laboratory burner for heating and flame sterilizing
SAFETY PRECAUTIONS:
•On unpacking the unit, check for possible transportation damages. Do not operate the
unit if damages are visible.
• Pay attention to your relevant rules for using liquid gas.
•Do not check for leaks with a naked flame. Use soapy water only.
•If there has been a leakage you have to be extra careful and evacuate the gas by
ventilation.
• Note that LP Gas is heavier than air. Therefore it can easily accumulate in
trenches or below ground level.
•Unattended operation of the unit is not permissible.
• Use the appliance on safe distance from walls and other
combustible material.
•Do not operate the unit near flammable liquids or hazardous materials.
•Always work in a well-ventilated area.
• Disconnect the unit before leaving it unattended.
• Before connecting a gas cartridge, ensure that the sealing (7) is in place and in
goodcondition.
• Never use a unit with damaged or worn seal (7) and never use a leaking, damaged
or malfunctioning unit.
• Always change or fit the gas cartridge/cylinder in a safe place, away from any
source of ignition such as naked flames, pilot lights, electric fires and away from
other people.
•Allow sufficient time for flame orifice (2) and burner tube (3) to cool down prior to
cleaning, desinfecting, servicing or transport. Ensure that the unit and the gas supply
is turned off.
•Note that the burner orifice (2) and burner tube (3) remains hot after the flame has been
extinguished. Do not touch. Can cause burns.
• After use or for any longer period of time without attandance, ensure that the gas
controller (1) is shut completely. (Turn the gas controller (1) in clockwise direction to
the stop position). Disconnect the gas cartridge from the powerjet.
The range: powerjet Art.No.: 6.005.000
for gas cartridges CG1750 from Campin gaz
Instruction manual
2-year warranty

1. Setup Procedure:
The powerjet can only be used with propan/butane gas cartridges CG1750 from Camping
Gaz. An adaptation to other types of gas is not possible.
1.1 Gas cartridge connection:
Shut off the gas controller (1) completely (Turn the gas controller (1) in clockwise
direction to the stop position).
Connect the powerjet with the threaded adapter (6) to the gas cartridge (8).
Keep the gas cartridge (8) upright when fitting it to the threaded adapter (6).Place the threaded
adapter (6) adequately on top of the gas cartridge valve. Gently screw the gas cartridge into
the threaded adapter (6). Be careful not to fit the gas cartridge cross threaded.
NOTE! Screw hand tight only. Do not over tighten or you will damage the threaded adapter
of the powerjet or the gas cartridge valve.
Pay attention that the gas connection is gas-tighted.
Temperature range when using cartridges is +10°C to +35°C. (50°F to 95°F)
2.1 Operating Procedure:
Note that the burner orifice (2) and the burner tube (3) remains hot after the flame has
been extinguished. Do not touch. Can cause burns.
Point the burner away from body and flammable objects.
The unit is ignited by gradual pressure on the trigger (4). Maintain pressure throughout the
flame-off procedure. Disconnect the unit before leaving it unattended.
The flame can be varied in size by turning the gas controller (1).
The flame is extinguished upon release of the trigger (4).
The trigger (4) is equipped with a locking device (5). The locking device is pushed side
wards when trigger (4) is pressed. To release locking device press trigger.
2.2 End of operation procedure:
After use or for any longer period of time without attandance, ensure that the gas controller
(1) is shut completely. (Turn the gas controller (1) in clockwise direction to the stop position).
Disconnect the gas cartridge from the powerjet.
3. Exchanging the gas cartridge CG1750/Camping Gaz:
Ensure that the flame is extinguished, the burner has cooled down and no other flame is
nearby. Shut off the gas controller (1) completely (Turn the gas controller (1) in
clockwise direction to the stop position).
Screw the empty gas cartridge (8) out of the powerjet.
After, press again the trigger (4), to be sure that no gas is left in the powerjet.
Attention: The burner can ignite a flame shortly.
Check the sealing (7). Replace the sealing if damaged or worn
(Sealing for powerjet, Art.-No. 6.005.010)
Connect the new gas cartridge to the threaded adapter (6) of the powerjet. Keep the gas
cartridge (8) upright when fitting it to the threaded adapter (6).

Place the threaded adapter adequately on top of the gas cartridge valve. Gently screw the
gas cartridge into the theaded adapter. Be careful not to fit the gas cartridge cross
threaded.
NOTE! Screw hand tight only. Do not over tighten or you will damage the threaded
adapter of the powerjet or the gas cartridge valve.
4. Routine service and maintenance
Ensure that the sealing (7) is in place and in good condition. Inspect every time you use
the powerjet. Replace the sealing if damaged or worn.
(Sealing for powerjet, Art.-No. 6.005.010)
5. Cleaning / assembly and disassemly of the burner tube:
Shut off the gas controller (1) completely (Turn the gas controller (1) in clockwise direction
to the stop position). Allow sufficient time for burner orifice (2) and burner tube (3) to cool down.
Check the unit is disconnected. The burner can be cleaned with customary commercial
disinfectants.
Disassembly of the burner tube (3) :
The powerjet is equipped with a bayonet quick fitting connection.
Turn the burner tube (3) 90° counterclockwise out of the locking device.
Pull the burner tube out of the powerjet.
Assembly of the burner tube (3):
Push the burner tube into the powerjet and turn 90° clockwise into the locking device.
7. Warranty:
The powerjet is covered under our two-year manufacturer warranty against any manufacture
defects in material. The WLD-TEC warranty guarantees powerjet under normal usage
conditions and does not cover any damages as a direct result of user misuse. The warranty
is void upon any unauthorized servicing, disassembly or modifications.

Technical Data
Type: powerjet
Gas supply and Gas types: liquid gas
consumption Gas cartridge CG1750: Camping Gaz
Connected load: 0,12 kg / h liquid gas
Temperatures Flame temperature: 1350 °C on liquid gas
Temperature threshold 1,54 kW liquid gas
level:
Mechanical Measurements: W = 150 mm
H = 180 mm
Weight: 300 g
