Wolck WK-3801W User manual

GPON 1GE+WiFi
Chapter1: Overview
1.1 Product Description
GPON 1GE+WiFi ONU meet telecom operators FTTO (office), FTTD(Desk),FTTH(Home)
broadband speed, SOHO broadband access, video surveillance and other requirements and
design an GPON Gigabit Ethernet products. It is based on mature and stable, cost-effective
GPON technology, high reliability, easy management, configuration flexibility and good quality
of service (QoS) guarantees to meet the technical performance of the module GPON
Equipment from China Telecom.
Figure 1 1GE+WiFi
1.2 Application Chart
Figure 2 Application Chart

GPON 1GE+WiFi
1.3 Technical Parameters
Technical item
1GE+WiFi
PON interface
1GPON connector, SC single-mode/single-fiber, uplink 1.25Gbps,
downlink 2.5Gbps
Wavelength
Tx1310nm,Rx 1490nm
Optical interface
SC connector
LAN interface
1x 10/100/1000Mbps auto adaptive Ethernet interfaces.10/100M
Full/Half, 1000M Full Duplex, RJ45 connector
Wireless
Compliant with IEEE802.11b/g/n, 300Mbps, 2T2R 1 internal antenna, 1
external antenna
LED
5, For Status of POWER、LOS、PON、LAN、WiFi
Operating
condition
Temperature: -5℃～55℃
Humidity: 10%～90%（non-condensing）
Storing
condition
Temperature :-30℃～60℃
Humidity :10%～90%（non-condensing）
Power supply
DC 12V/0.5A
Power
consumption
≤6W
Dimension
120mm×78mm×30mm（L×W×H）
Net weight
0.13Kg
Table 1 Technical Parameters
1.4Equipment List
Table 2 Equipment List
1.5Certification Card
Contents
Quantity
ONU
1 pcs
Power adapter
1 pcs
User manual
1 pcs
P01.030160

GPON 1GE+WiFi
Chapter2: Installation
2.1 Installation Requirements
To avoid equipment damage caused by improper use and personal injury, please observe the
following precautions:
Do not place the device near water or in damp places, in order to prevent water or
moisture from entering the device.
Do not place the device in an unstable place, avoid falling damage to equipment.
Make sure that the supply voltage of the device matches the required voltage value.
Do not open the equipment chassis without permission.
Unplug before cleaning the power plug; prohibit the use of liquid cleaning.
Installation Environment Requirements
ONU equipment must be installed in the interior, and to ensure the following conditions:
Confirmation at the ONU installation at sufficient space to facilitate cooling machine.
ONU suitable operating temperature of -5℃~ 55 ℃,humidity 10% to 90%.
Electromagnetic Environment
ONU equipment in use can be affected by external electromagnetic interferences, such as
radiation and conduction through the impact on the device, this should note the following:
Device workplace should avoid radio transmitters, radar stations, and high-frequency
interference from power equipment.
Users cable typically require alignment indoors if outdoor lightning traces measures
should.
Equipment Installation
ONU product is a fixed configuration cassette equipment, site equipment installation is
relatively simple. Simply install the device on a specified place, connecting the upstream fiber
subscriber line connections, connect the power cable. Actual operation is as follows:
1. Installed on the desktop
Place the machine on a clean bench, this installation is relatively simple, you can observe the
following operation:
Ensure the smooth workbench.
Around the device enough space for heat dissipation.
Do not place objects on the device.
2. Mounted on the wall
Observation ONU equipment chassis two cruciform recess, in accordance with the
position of the groove, installed two screws in the wall.
The original selected two mounting screws gently snap into recesses aligned.
Slowly let go, so that the device under the support of the screw hanging on the wall.
2.2 Panel Lights
LED
Mark
Status
Description
Power
POWER
On
The device is powered up.

GPON 1GE+WiFi
Off
The device is powered down.
Optical signal
loss
LOS
Blink
Device does not receive optical signals.
Off
Device has received optical signal.
Registration
REG
On
The device is registered to the PON
system.
Off
Device is not registered to the PON
system.
Blink
Device registration is incorrect.
Interface
LINK/ACT
On
Port is connected properly (LINK).
Off
Port connection exception or not
connected.
Blink
Port is sending or/and receiving data
(ACT).
WiFi
WiFi
On
WiFi running
Off
WiFi not working
Table 3 Panel Lights
2.3 Lan Port Connection Definition
Table 4 FE/GE Connection Definition
Chapter3:Web Management
GPON ONU provides simple Web management functions, including Device Information ,
modify WAN connection, LAN management IP address, Loid and Password, Configuration
File backup and restore, Firmware upgrade etc...
Grade
No.
Function
direction
FE
GE
FE
GE
1
RX+( receive data +)
BI_D0+( Bi-directional Data+)
input
Input/output
2
RX-(receive data -)
BI_D0- (Bi-directional Data-)
input
Input/output
3
TX+ (send data +)
BI_D1+( Bi-directional Data+)
output
Input/output
4
NC(null)
BI_D2+( Bi-directional Data+)
-
Input/output
5
NC(null)
BI_D2- (Bi-directional Data-)
-
Input/output
6
TX- (send data -)
BI_D1-( Bi-directional Data-)
output
Input/output
7
NC(null)
BI_D3+( Bi-directional Data+)
-
Input/output
8
NC(null)
BI_D3- (Bi-directional Data-)
-
Input/output

GPON 1GE+WiFi
NOTE:
About more ONU detail configurations should be configured via ONU web.
3.1 Default configuration
The following is the default device configuration information.
Local (LAN access) Username: admin , Password: admin
LAN port management IP address: 192.168.1.1/24
3.2 Basic Configuration
Figure 3 Web login
Figure 4 Device Information
Web login default username: admin, password: admin
Status Menu displays the current device base informations. Including Hardware Version、
Software Version、Device Model、Device ID.
Note:
All the device information may be changed, the received device shall prevail.

GPON 1GE+WiFi
Figure 5 Modify Loid and Password
Figure 6 Restore Default
LOID Menu displays the current device Loid and Password informations.
Loid: 0-24 bytes.
Password: fixed 10 bytes.
Note:
All the changes take effect in the equipment after the restart.

GPON 1GE+WiFi
Figure 7 Upgrade
Figure 8 Backup/ Restore Configuration
Restore Default: The operation to restore the device to its factory configuration.
Upgrade Menu displays the current equipment upgrades related information.
Download: The operation to backup configuration from the device.
Upload:The operation to restore configuration from a configuration file.

GPON 1GE+WiFi
Chapter4: Troubleshooting
1. After power all the lights are lit？
Reasons:
1) Power connection errors;
2) Power is not normal.
Solution:
1) Check that the power cable is connected;
2) The rear panel of the power supply is turned on.
2. GE / FE led does not light?
Reasons:
1) Network cable is damaged or loose connection;
2) Cable type error;
3) Long lines outside the allowable range.
Solution:
1) Replace the network cable, and pay attention to the standard Ethernet cable must be
parallel or crossing lines.
3. After working for some time to stop working?
Reasons:
1) Power supply is not working properly;
2) The equipment from overheating.
Solution:
1) Check if there is contact with abnormal voltage is too high or too low;
2) Check the ambient conditions, vents are normal ventilation.
4. LOS led flashes?
Reasons:
1) Fiber failure;
2) Central office equipment failure.
Solution:
1) Inspect fiber is connected properly, is connected to the correct connector, optical power is
normal;
2) Contact your operator.
5. PON led flashes?

GPON 1GE+WiFi
Reasons:
1) Fiber optic connector is loose;
2) Central office equipment failure;
3) Fiber optic connectors are dust.
Solution:
1) Inspect fiber is connected properly;
2) Cotton ball with alcohol swabbing fiber optic connectors;
3) Contact your operator.
