Wolfe Ridge 4226 DI Series User manual

Professional Log Splitter
Firewood Conveyor
Owner’s Manual
PRO28
PRO22C - PRO28C - PRO35C
28HO - 35HO
28SHO - 35SHO - 35SHOBW
28HDI - 35HDI
4226XDI
FC16 - FC24 - FC32 - FC40

- 2 -
T  C
Page(s)
California Proposition 65 Information 5
Copyright & Version information 6
Important Safety Information 7-19
Hazard Signal Denitions 7
Intended Use 7
Personal Protective Equipment 8
For Rental Companies 8
Safety Decals 9-11
General Safety 12
Work Area Safety 12-13
Safe Operation of the Log Splitter 13-14
Safe Preparation of the Log 14
Hydraulic Safety 14
Repair and Maintenance Safety 14
Fire Prevention 15-16
Fuel Safety 15
Battery Safety 17-18
Towing Safety 19
Operating Instructions
Hydraulic Oil/Filter Recommendations 20
Engine Oil Recommendations 21
Engine Fuel Recommendations 21

- 3 -
T  C
Page(s)
Operating Instructions
Starting Instructions 21
Long Term Storage 21
Using 4-way & 6-way Optional Splitting Wedges 21
On Site Set Up 22
Operation - Wheeled & Industrial Log Splitters 23-24
Operation - Skid Steer Log Splitters 25
Operation - Firewood Conveyor 26
Getting Service - Contact Information Rear Cover
Warranty and Service Information 27
Models
28PRO - 28 Pro Log Splitter
Controls and Features Identication 28
Specications 29
PRO28C - PRO28C - PRO35C - Compact Commercial Log Splitter
Controls and Features Identication 30
Specications 31
28SHO - 35SHO - 35SHOBW - Super High Output Commercial Log Splitter
Controls and Features Identication 32
Specications 33

- 4 -
T  C
Page(s)
Models
28HDI - 35HDI - Heavy Duty Industrial Log Splitter
Controls and Features Identication 34
Specications 35
4226XDI - Extreme Duty Industrial Log Splitter
Controls and Features Identication 38
Specications 39
FC16 - FC24 - FC32 - Firewood Conveyor
Controls and Features Identication 40
Specications 41
Maintenance and Troubleshooting
Hydraulic & Engine Oil & Filters 42
Push Block Slides Replacement 42
Hydraulic System - Warnings & Main Pressure Adjustment 43
Splitter Hydraulic Detent Adjustment 44
Splitter Hydraulic Auto Cycle Valve 45
Serial Number Locations 46
Serial Number Records 47
Notes, Maintenance Performed Records 47

- 5 -
C P  W
PETROLEUM PRODUCTS
WARNING: Crude oil, gasoline, diesel fuel and other petroleum products can expose
you to chemicals including toluene and benzene, which are known to the State of
California to cause cancer and birth defects or other reproductive harm. ese ex-
posures can occur in and around oil elds, reneries, chemical plants, transport and
storage operations such as pipelines, marine terminals, tank trucks and other facilities
and equipment.
For more information go to: www.P65Warnings.ca.gov/petroleum.
GASOLINE ENGINE EXHAUST
WARNING: Breathing gas/diesel engine exhaust exposes you to chemicals known to
the State of California to cause cancer and birth defects or other reproductive harm.
• Always start and operate the engine in a well-ventilated area.
• If in an enclosed area, vent the exhaust to the outside.
• Do not modify or tamper with the exhaust system.
• Do not idle the engine except as necessary.
For more information:
https://www.p65warnings.ca.gov/fact-sheets/gasoline-engine-exhaust
WOOD DUST
WARNING: Drilling, sawing, sanding or machining wood products can expose you
to wood dust, a substance known to the State of California to cause cancer. Avoid
inhaling wood dust or use a dust mask or other safeguards for personal protection.
For more information:
https://www.p65warnings.ca.gov/fact-sheets/wood-dust
DIESEL ENGINE EXHAUST
WARNING: Breathing diesel engine exhaust exposes you to chemicals known to the
State of California to cause cancer and birth defects or other reproductive harm.
• Always start and operate the engine in a well-ventilated area.
• If in an enclosed area, vent the exhaust to the outside.
• Do not modify or tamper with the exhaust system.
• Do not idle the engine except as necessary.
For more information:
https://www.p65warnings.ca.gov/products/diesel

C ©
P   U S  A,   . N      
       
W R MFG E C WI USA 
A ,           ,
    .
V . --
- 6 -

- 7 -
I S I
WARNING: Read and thoroughly understand all instructions in
this manual and on safety decals before operating this log splitter.
Failure to do so may cause serious injury or death. Do not allow
anyone to operate this log splitter who has not read and understood
this manual. As with all power equipment, this log splitter can be
dangerous if used improperly. Do not operate this log splitter if you
have any questions concerning safe operation. To get answers to any
questions, call our technical support department at 715-598-7790.
H S W D
is is the SAFETY ALERT SYMBOL. It is used to alert you to
potential personal injury hazards. Obey all safety messages that
follow this symbol to avoid possible injury or death.
DANGER (red) indicates a hazardous situation which, if not
avoided, will result in serious injury or death.
WARNING (orange) indicates a hazardous situation which, if
not avoided, could result in serious injury or death.
CAUTION (yellow) indicates a hazardous situation which, if not
avoided, could result in minor or moderate injury.
IMPORTANT (blue) is used to address practices not related to
personal injury.
Intended Use
NEVER use this log splitter for any other use than splitting wood.
It is designed for this use only. Any other use can cause serious
injury or death.

- 8 -
P P E
BEFORE operating this log splitter, make sure that you wear safety gear such as goggles or safety
glasses, steel toed shoes and tight tting gloves (without loose cus or draw strings). Always wear a
protective hearing device when operating this log splitter.
NEVER wear loose clothing or jewelry that can be caught by moving parts of this log splitter. Keep
clothing and hair away from all moving parts when operating this log splitter.
A: A R C
 P O   
E  
I S I
All persons to whom you rent/loan the log splitter must have access to and read and understand this
manual. Keep this owner’s manual with the log splitter at all times and advise all persons who will
operate the machine to read and understand it. You must provide instruction on how to safely oper-
ate the splitter and remain available to answer any questions a renter/borrower might have.

- 9 -
Make sure that all safety warning decals are in good condition and readable. Always replace missing
or defaced decals. Contact Wolfe Ridge MFG at: 715-598-7790 for replacement decals.
S D
DANGER PINCH POINT
Located at the on the top of the hydraulic cylinder of every log splitter.
I S I

- 10 -
DANGER
Located next to the gasoline/diesel engine of every log splitter.
S D (Continued)
DANGER PINCH POINT
Located at the operators station of every log splitter.
I S I

- 11 -
Caution
Located on each end of the rewood conveyor near drive and idler pulleys.
S D (Continued)
I S I

G S
Failure to follow these instructions may result in serious injury or death.
A LWAYS read the operator’s manual before operation. It is located in the plastic canister on the
machine.
ALWAYS keep all bystanders and pets a minimum of 10 feet away from your work area when operat-
ing this log splitter. Only the operator is to be near the log splitter during use.
ALWAYS operate the log splitter with a clear mind, free of the inuence of alcohol, drugs or medica-
tion.
ALWAYS wear close tted clothing, free from lanyards, strings or jewelry which could be an entrap-
ment hazard.
NEVER allow children to operate this log splitter. NEVER allow adults lacking proper instructions
and understanding to operate this log splitter.
NEVER actuate the control until all people are clear of the work area.
NEVER allow a person who is tired or otherwise not alert to operate the log splitter.
I S I
W A S
NEVER operate the log splitter on slippery, wet, muddy or icy ground.
ONLY operate your log splitter on level ground. Operating on a slope could cause the log splitter to
roll over or logs to fall o.
NEVER operate your log splitter in an enclosed area. Exhaust fumes contain carbon monoxide which
can be deadly when inhaled.
NEVER attempt to move your log splitter over hilly or uneven terrain without a tow vehicle or ade-
quate help.
NEVER operate log splitter with missing or broken jack stands.
- 12 -

I S I
W A S
ALWAYS use jack stands and block the wheels to prevent movement of the log splitter while in oper-
ation.
A LWAYS operate your log splitter on level ground. (Operating on a slope couyld cause the log split-
ter to roll over or logs to fall o.)
A LWAYS keep the work area clean. Remove split wood around your log splitter immediately so that
you don’t trip over it.
ONLY operate your log splitter in daylight or under good articial light.
- 13 -
S O   L S
KNOW how to stop the log splitter and disengage the controls before operating it.
FAILURE to operate the log splitter from the operators position can result in serious injury or
death.
NEVER place hands or feet between the log and splitting wedge during forward or reverse stroke.
Serious injury or death could result.
NEVER straddle or step over the log splitter during operation.
NEVER try to cross split a log. Always split with the grain.
NEVER attempt to load the log splitter when the wedge is in motion.
NEVER place hands or feet between the log and splitting wedge during forward or reverse stroke as
this could result in serious injury or death.
NEVER move the log splitter while the engine is running.
A LWAYS use your hand to operate the control lever on the valve. NEVER use your foot, a rope or
any extension device.

- 14 -
I S I
S O   L S
A LWAYS shut o the engine even if you are leaving the log splitter for a short period of time.
A LWAYS avoid contact with the muer and other hot areas of the engine during operation or aer
running to prevent burns.
CAUTIONS FOR GAS OR DIESEL ENGINE OPERATION
Operate your engine/machine only in well ventilated areas.
Failure to follow this will result in serious injury or death.
S P  T L
Both ends of the log should be cut as square as possible to help prevent the log from riding out of
the splitter during operation.
A LWAYS split wood along the grain NEVER split across the grain.
H S
e hydraulic system of your log splitter requires careful inspection along with the mechanical parts.
Be sure to replace frayed, kinked, cracked or otherwise damaged hydraulic hoses or hydraulic compo-
nents.
NEVER check for leaks of hydraulic uid with your hand. Fluid escaping from a small hole can be
almost invisible. Escaping uid under pressure can have sucient force to penetrate skin causing
SERIOUS INJURY or even DEATH. Leaks can be safely detected by passing a piece of cardboard over
the suspected leak and looking for discoloration.
NEVER remove the cap from the hydraulic tank or reservoir while the log splitter is running. e
tank could contain hot oil under pressure which could result in serious injury.
NEVER adjust the hydraulic valve. e pressure relief valve on your log splitter is preset at the facto-
ry. Only a qualied service technician should perform this adjustment.
A LWAYS seek professional medical attention immediately if injured by escaping hydraulic uid.
Serious infection or reaction can develop if proper medical treatment is not administered immediately.
A LWAYS be sure to relieve all pressure by shutting o the engine and moving the valve control han-
dle back and forth should it become necessary to loosen or remove any hydraulic tting.

- 15 -
I S I
R  M S
NEVER operate your log splitter when it is in poor mechanical condition or in need of repair.
NEVER alter your log splitter in any manner. Such alterations may cause your log splitter to be un-
safe and will void the warranty.
NEVER tamper with the engine to run it at excessive speeds. e maximum engine speed is preset
by the manufacturer and is within safety limits. See Honda engine manual.
ALWAYS perform all recommended maintenance procedures BEFORE using your log splitter.
ALWAYS replace all damaged or worn parts IMMEDIATELY.
A LWAYS check the level of hydraulic oil and engine oil BEFORE operation.
PERIODICALLY check that all nuts, bolts, screws, hydraulic ttings and hose clamps are tight.
F P - F S
NEVER operate your log splitter near a ame or spark. Hydraulic oil and gasoline are ammable and
can explode.
NEVER ll the gas tank while the engine is hot or running. Allow the engine to cool before refueling.
NEVER smoke while operating or refueling your log splitter. Gas fumes can easily explode.
A LWAYS replace the gas cap securely.
A LWAYS drain the fuel tank prior to storage to avoid the potential re hazard.
ONLY refuel your log splitter in a clear area with no gas fumes or spilled gas.
If gasoline has spilled, move the log splitter away from the area of the spill and avoid creating any
source of ignition until the spilled gas has evaporated.
NEVER store gasoline in the house or near a heating appliance.

F P
I S I
ALWAYS store gasoline in an approved - OSHA Standard 29 Code of Federal Regulations (CFR)
1926.152(a)(1) - tightly sealed container. Store the container in a cool, dry place.
A LWAYS turn the fuel shut o valve on the engine to the “OFF” position before towing the log
splitter. Failure to do so may result in ooding the engine.
IMPORTANT NOTE – (spark arrester):
As a precautionary measure against possible ying sparks, always take a Class B re extinguisher with
you when operating this log splitter in dry areas. is log splitter is equipped with an internal com-
bustion engine and should not be used on or near any unimproved forest-covered, brush-covered
or grass-covered land unless the engine’s exhaust system is equipped with a spark arrester meeting
applicable local or state laws (if any). If a spark arrester is used, it should be maintained in efective
working order by the operator. In the state of California, a spark arrester is required by law. Other
states have similar laws. Federal laws apply on federal lands. A spark arrester muer is optional and
available as an accessory at your nearest engine dealer. Always check the legal requirements in your
area.
S C  D  G E
- 16 -
OPERATE your engine/machine ONLY IN WELL VENTILATED areas. Failure to follow
this will result in serious injury or death.
NEVER operate an engine with a fuel or oil leak, which can
result in re. Failure to follow this will result in serious injury or death.

- 17 -
U C W W W B
I S I
EYE CONTACT Sulfuric Acid and Lead: Flush eyes immediately with large amounts of
water for at least 15 minutes while liing lids. Seek immediate medical
attention
if eyes have been exposed directly to acid.
SKIN CONTACT Sulfuric Acid: Flush aected area(s) with large amounts of water using
deluge
emergency shower, if available, shower for at least 15 minutes. Remove
contaminated clothing, including shoes. If symptoms persist, seek medical
attention. Wash contaminated clothing before reuse. Discard contaminated
shoes.
Lead: Wash immediately with soap and water.
INGESTION Sulfuric Acid: Administer large amounts of water. Do NOT induce vomit-
ing
or aspiration into the lungs may occur and can cause permanent injury or
death; consult physician.
INHALATION Sulfuric Acid: Remove to fresh air immediately. If not breathing, give arti-
cial
respiration. If breathing is dicult, give oxygen. Consult a physician.
Lead: Remove from exposure, gargle, wash nose and lips; consult physician.
A LWAYS Keep sparks, ames, burning cigarettes, or other ignition sources away from batteries at
all times. Failure to follow this will cause serious injury or death.
A LWAYS wear safety goggles and a face shield when working ear batteries. Failure to follow this will
cause serious injury.
BATTERY POSTS, terminals and related accessories contain lead and lead compounds. Wash
hands aer handling. Failure to follow this may result serious injury.
ALWAYS Charge the battery in a well ventilated area. Failure to follow this may result serious injury
or death.
EMERGENCY TREATMENT FOR CONTACT WITH BATTERY COMPONENTS
(LEAD/SULFURIC ACID)

I S I
U C W W W B
ALWAYS Disconnect the negative battery terminal cable before performing any service to the 12-
Volt electrical system. Failure to follow this may result in injury and/or electrical system damage.
DO NOT attempt to charge a frozen battery. Failure to follow this may result serious injury or
death.
DO NOT overcharge the battery. Overcharging may reduce the overall service life of the battery.
BE SURE the battery is fully charged before transporting the wood splitter. If the battery is not fully
charged, excessive vibration could reduce the overall service life of the battery.
- 18 -

T S
I S I
- 19 -
NEVER attempt to move your log splitter over hilly or uneven terrain without a tow vehicle or ade-
quate help.
NEVER allow anyone to sit or ride on your log splitter.
NEVER exceed 45 mph when towing your log splitter models with a solid axle (no springs) (28
PRO, PRO22C, PRO28C, PRO35C) and the Firewood Conveyor. Models with spring mounted axles
can be safely towed at posted highway speeds (28HO, 35HO, 28SHO, 35SHO). Adjust towing speed
for terrain and conditions. Be extra cautious when towing over rough terrain especially railroad
crossings.
A LWAYS check all local and state regulations regarding towing, licensing, and lights before towing
your log splitter.
ALWAYS check before towing to make sure that the log splitter is correctly and securely attached to
the towing vehicle and that the safety chains are secured to the hitch or bumper of the vehicle with
enough slack to allow turning. Always Class I, 2” ball with this log splitter.
A LWAYS be careful when backing up with your log splitter in tow. It could jackknife.
A LWAYS disconnect your log splitter from the towing vehicle before operating it.
A LWAYS turn the fuel shut o valve on the engine to the “OFF” position before towing the log
splitter. Failure to do so may result in ooding the engine and damaging engine oil.
MAKE SURE tires are fully inated and in good condition if you will be towing the
splitter. See tire sidewall for recommended tire pressure.
NEVER use the log splitter or rewood conveyor as a trailer to haul equipment, tools or wood.
All loose item should be removed before towing the equipment.

O I
WARNING: Read and thoroughly understand all instructions and safety infor-
mation before operating this log splitter. Failure to do so may cause serious injury or
death. Do not allow anyone to operate this log splitter who has not read this manual.
As with all power equipment, a log splitter can be dangerous if assembled or used im-
properly. Do not operate this log splitter if you have doubts or questions concerning
safe operation.
Call our customer service department at 715-598-7790 to address these concerns.
CAUTION: DO NOT START OR RUN THE ENGINE BEFORE ADDING/
CHECKING OIL IN THE HYDRAULIC RESERVOIR AND OIL IN
THE ENGINE.
Wolfe Ridge equipment is shipped/delivered with engine oil/hydraulic oil installed and are ready to
run. Please conrm hydraulic oil and engine oil are at correct levels before startup. Hydraulic oil level
should be visible in the sight tube installed on the side of the hydraulic tank.
HYDRAULIC OIL/FILTER RECOMMENDATIONS
e hydraulic reservoir must be lled with hydraulic oil before operation. AW-32 /
ISO 32 hydraulic oil is recommended for temperature ranges from 0 to 160 degrees F.
Use only clean oil and take care to prevent dirt from entering the hydraulic reservoir.
Capacities:
28 Pro - 14 gal. (gallons) total, 12 gal. to rell tank.
Compact Commercial- 22 gal. total, 18 gal. to rell tank.
High Output- 25 gal. total, 22 gal. to rell tank.
SHO - 26 gal. total, 22 gal. to rell tank.
HDI - 26 gal .total, 22 gal. to rell tank.
Conveyors- 10 gal total, 7 gal. to rell tank.
Hydraulic Oil Filter:
Pro 28 and Conveyors - Cheif 226011
All other machines - Baldwin BT287-10
Change hydraulic lters annually
- 20 -
