Redgum Electric Logsplitter User manual
RGELS-0122 Rev 0Australia's No.1 Selling Honda-Powered Log Splitters
LOGSPLITTERS
RedGum Electric Logsplitter
� WARNING HAZARD SIGNAL DEFINITIONS safety alert symbol. DANGER WARNING CAUTION
2
3
Important Safety Rules.................................... 4-6
Check Prior to Operation.................................. 7
Operation Instructions..................................... 8-9
Towing the Log Splitter.................................... 10
Log Splitter Components................................. 11
Log Splitter & Motor Specifications.................. 12
Log Splitter Troubleshooting............................ 13
Maintenance, Storage & Essential Checks...... 14
Warranty & Service Information................... 15-17
Notes........................................................... 18-19
Accessories...................................................... 20
The Crush Hazard Zone is between The Splitting Wedge and the End Plate. The Splitting Wedge can cut through skin and break bones. Make sure hands are clear of crush hazard zone when Log Splitter is in operation.Make sure all fittings are tight before starting the Log Splitter.
Relieve system pressure before servicing by turning off the Log
Splitter and moving Control Valve Lever forward and back and
returning to neutral position.
4
5.) Breathing hazard.
Do not operate the logsplitter indoors. even if ventilated. This
product is intended for outdoor use only and may lead to
serious injuries or even death.
5
before using this RedGum Log Splitter.Hydraulic oil levels with a Dip Stick.Turn the engine off before leaving the logsplitter unattended.
6
This diagram shows theOperator Safety ZoneHORIZONTAL OPERATION
WORK ZONEWORK ZONE3 meters3 meters3 meters
7
PREPARING THE LOG SPLITTER FOR USERemove the Lock Pin (14) from the Towing Pin Hole (16) and lower the
Front Support Leg (10). While making sure that the Front Support Leg (10)
is on the floor, connect the Lock Pin (14) to the Operating Pin Hole (15) and secure tightly.Operating Pin HoleFront Support LegTowing Pin HoleLock PinHOW TO OPERATE THE LOG SPLITTEROperation Instructions continued...
8
4.) Start the splitting procedure by pushing and holding the Control ValveLever (2) forward. Plese note the Splitter Wedge (8) only moves forward whenyou are holding the lever forward. When you let go of the Control Valve Lever (2)the Splitter Wedge (8) stops immediately.Proper Operation of the Logsplitter:
Always follow Operational Warnings & Check-list before operating!
1.) Plug in the 240V Cord into a compatible power outlet.
2.) Press the "Green" On/Off button (17) on the side of the logsplitter to switch
on the logsplitter.
3.) Place a log onto the beam against the End Plate (12).
plitter Wedge (8) and the EndPlate (12) Make sure hands are clear of the Crush Hazard Zone. 5.) To return wedge to starting position, simply pull the Control Valve Lever (2) backwards and away from the End Plate (12). Please note the Splitter Wedge (8)Control Valve Lever (2) returns to the neutral position after the Splitter Wedge (8)Correct operating procedures should be followed to ensure that your logsplitter is not
damaged. Incorrect operation can result in bending the Beam (1), Splitting Wedge (8) and/or
End Plate (12). Important: If Beam, Wedge or End Plate are bent due to incorrect operation, it is not the manufacturer's fault and subsequently would not be covered under
Warranty. Ideally, the log should be cut into "rounds" with flat or even surfaces. If they are
cut and the edges are on an angle or have an uneven surface, you must ensure you place
the log onto the Beam (1) as shown in the Second or Third diagrams, as shown below:
9
reasons, the Splitter Wedge (8) stops approx. 3-4cm from the End Plate (12).To avoid the build up of Hydraulic Pressure, please refrain from
holding the Control Valve Lever (2) forward after the Splitter Wedge (8) has reached
the end of it's travel.
6.) Clear the split wood from the Operator Zone.
7.) Repeat these steps as and when required.
Note: If the unit is Overloaded or Overheated, press the RESET Switch on the Electric
Motor (located near the Gear Pump (5)).
Never ride on or transport cargo on the Log Splitter.TOWING THE LOG SPLITTERAlways secure and only after the Log Splitter to the vehicle hitch before towing.Drive the vehicle only after the Log Splitter is securely attached.Turn off the vehicle if leaving the Log Splitter unattended.Choose a leveled surface to operate the Log Splitter.Avoid large holes and ditches when towing the Log Splitter in a vehicle.Do not exceed a speed of 45KM/H when towing the Log Splitter.While towing, raise the Front Support Leg (10) and connect the Hitch Tongue (13)to your vehicle. The Lock Pin (14) should then be removed from the
Operating Pin Hole (15) and inserted in the Towing Pin Hole (16).Front Support LegOperating Pin HoleHitch TongueLock PinTowing Pin Hole
10
12) End Plate13) Hitch Tongue14) Lock Pin
15) Operating Pin Hole
16) Towing Pin Hole
LOG SPLITTER COMPONENTS5.5" Splitting Wedge - Features wedge wings & tapered ends making splitting easier.----10) Front Support Leg - Supports the logsplitter during operation or towing
11
Control Lever
17) On/Off Switch
Cycle Time ............................................................................................................16 s...............................................................................................................105 kg.................................................................................................................. 36.2".................................................................................................................... 36.6"............................................................................................................... 61.34"MOTOR SPECIFICATIONSLOG SPLITTER SPECIFICATIONSMax. Force .......................................................................................................12 TonHydraulic Tank Capacity ................................................................................... 7LMax. Pressure ...................................................................................................... 21"Hydraulic Oil Required ................................................................................... 5.2LElectric Engine ................................................................................................. 240VHydraulic Cylinder .......................................................................... 3.15" x 19.1"Max. Pressure ........................................................................ 25Mpa (3600 psi)Gear Pump ...................................................................................................... 5GPMMax. Towing Speed ..................................................................................... 5MPHWheel Size ..................................................................................................12inchesAmps .......................................................................................................................13.5Volts ......................................................................................................................... 230Poles ............................................................................................................................ 2Hz ............................................................................................................................... 50R.P.M ................................................................................................................... 2800Shield .....................................................................................................................IP54
12
Horsepower .............................................................................................................. 3
LOG SPLITTER TROUBLESHOOTING Problem Cause Solution M-Engine
13
Improper maintenance and storage of the log splitter may void your warranty. WARNINGWARNINGOil Filter This machine is not fitted with an Oil Filter and does not require one.
14
WARRANTY AND SERVICE INFORMATION STATEMENT OF WARRANTY If the product is found to be defective, in RedGum Products' opinion (due to a fault of the manufacturer) within the Warranty Period, RedGum Products will carry out the repair or replacement to the customer Free of Charge, provided: The Warranty Periods 24 months3 months12 Months 3 Months NOTE: -
