WooW! Freedom WF1030-01 User manual
WF1030-01 | Wi-Fi 1080p Action Camera
Check The Package
User Manual
WooW! Freedom
Wi-Fi 1080p Action Camera
WF1030-01
WF1030-01 | Wi-Fi 1080p Action Camera
Table of Contents
1
Check The package…………………………………… 2
Know the camera ………………………………….… 4
Wi-Fi Mode …………………………………………….. 9
Shooting Video & Photo ………………………… 12
Viewing Recorded Videos and Photos …….. 16
Other Information …………………………………… 20
WF1030-01 | Wi-Fi 1080p Action Camera
Check The Package
WooW! Action camera
Waterproof case
Handlebar mount
Vented helmet strap mount
USB charging cable
Thanks for purchasing WooW! Action camera! You are about to capture
your stunning moments
2
WF1030-01 | Wi-Fi 1080p Action Camera
Check The Package
Charge The Camera
•Make sure battery is in the camera
•Turn OFF the camera
•Charge the camera by plugging USB cable to camera and PC or any
phone charger with USB port
•When charging, the LED will light up in Blue
1
2
1. Push up the battery cover lever
2. Slide the battery cover to right
* Make sure camera is turned off before
opening battery cover
LED in Blue when Charging
3
WF1030-01 | Wi-Fi 1080p Action Camera
Know The Camera
Shutter
Microphone
LCD Display
Power / Mode Select
Press & hold to turn on/off
Click to select mode
Battery Cover Lever
Wi-Fi On/OFF
LED
Indicator
Wide Angle
Lens
Infrared signal
receiver
Front Right View
4
WF1030-01 | Wi-Fi 1080p Action Camera
Know The Camera
Shutter
Microphone
LCD Display
Wide Angle Lens
SD Memory Card Slot
(Up to 32GB)
2.5mm Microphone Jack
Mini HDMI Output
Micro USB port
(Charging & Connect to PC)
Front Left View
5
WF1030-01 | Wi-Fi 1080p Action Camera
Know The Camera
LCD Display 1. Camera Mode
2. Video Recording Mode
3. Wi-Fi On
4. SD Memory Card Inserted
5. Resolution Icon
6. Mute Icon
7. Timer and Counter *
8. Battery Level Icon
7
8
*In camera mode, it displays the remained number of photos could be taken
In video recording mode, it displays the remained recording time (H:MM). During
recoding, it displays the recorded time of the video clip
6
WF1030-01 | Wi-Fi 1080p Action Camera
Know The Camera
Selecting Camera/Video Recording Mode
•Press the hold (~3 seconds) to turn on/off the camera
•Click the button to select between the modes and resolutions
HI
LO
LO
HILO
HI
Video Recording Mode, Full HD 1080p at 30fps
Video Recording Mode, HD 720p at 30fps
Video Recording Mode, HD 720p at 60fps
Camera Mode, 5M pixels
Camera Mode, 8M pixels
7
FPS means frame per second
WF1030-01 | Wi-Fi 1080p Action Camera
Know The Camera
Shooting Photo And Video
•In Video Recording Mode, click to start or stop recording
•In Camera Mode, click to take photo
•Press and hold to mute the buzzer. Icon will be shown on LCD
Wi-Fi Mode allows the camera to connect with user’s iPhone / iPad
/ Android devices
•Click the button to activate camera Wi-Fi Mode
•Icon will be shown on LCD
•See Wi-Fi section of the user manual for setup details
Wi-Fi Mode
8
WF1030-01 | Wi-Fi 1080p Action Camera
Wi-Fi Mode
Functions In Wi-Fi Mode
While connected with Wi-Fi devices*, user can perform below functions
•Live feed viewfinder
•Shoot video and photo
•Advanced camera setup (continuous shooting, time-lapse mode, white
balance, format memory card)
•View and download videos & photos from camera
* Supported Wi-Fi Devices:
•iPhones
•iPads
•Android Phones
•Android Tablets
9
WF1030-01 | Wi-Fi 1080p Action Camera
Wi-Fi Mode
•Click the Wi-Fi button to activate camera Wi-Fi Mode
•The Button will flash when waiting to connect, and stay on when
connected with devices
•icon will be shown on LCD
Connect Camera Via Wi-Fi
•On your device, Search SYMAGIX on App Store (Apple devices)
or Google Play (Android devices)
•Install SYMAGIX
•On device Wi-Fi Network setting, choose “WOOW-F1030” SSID
•Enter password 1234567890 and connect
•After connected, open SYMAGIC app
10
WF1030-01 | Wi-Fi 1080p Action Camera
Wi-Fi Mode
SYMAGIX App Setting Menu
Battery Level Resolution White Balance
Setting
Playback Mode
Shutter Photo / Video Mode
Remained Recording Time
Live
viewfinder
11
WF1030-01 | Wi-Fi 1080p Action Camera
Shooting Video & Photo
Insert SD Memory Card
•Turn off the camera before inserting memory card
•Use Micro-SD or Micro-SDHC card (at least Class 4)
•For best results Class 10 memory card is recommended
12
WF1030-01 | Wi-Fi 1080p Action Camera
Shooting Video & Photo
Mount The Camera Onto Gear
•It is recommended to always put camera into waterproof case
before mounting to included helmet strap or handlebar mount
•For better sound recording quality and slow speed non-water sport
activities, you may mount the camera directly through the ¼”
tripod hole
•You can check our website for more mounting gears
www.woowcam.com
The camera is waterproof ONLY when securely
enclosed in waterproof case
13
WF1030-01 | Wi-Fi 1080p Action Camera
Shooting Video & Photo
Selecting Camera/Video Recording Mode
•Press the hold (~3 seconds) to turn on/off the camera
•Click the button to select between the modes and resolutions
HI
LO
LO
HILO
HI
Video Recording Mode, Full HD 1080p at 30fps
Video Recording Mode, HD 720p at 30fps
Video Recording Mode, HD 720p at 60fps
Camera Mode, 5M pixels
Camera Mode, 8M pixels
14
FPS means frame per second
WF1030-01 | Wi-Fi 1080p Action Camera
Shooting Video & Photo
Shooting Video & Photo
•Click the shutter button to take photo or start/stop recording video
•The LED at front will flash in red
Shooting Video & Photo In Wi-Fi Mode
•Click Wi-Fi button on camera
•Open SYMAGIX apps on your Wi-Fi Device
(refer to Wi-Fi Section for setup details)
•Use your Wi-Fi Device as viewfinder, change setting or start/stop
recording
•You could turn off the Wi-Fi Mode anytime during recording
When Wi-Fi Mode is ON, you can ONLY start recording with Wi-Fi device.
However, you can stop recording by clicking shutter button on camera
15
WF1030-01 | Wi-Fi 1080p Action Camera
Viewing Recorded Videos & Photos
Viewing in Wi-Fi Mode
•Click the Wi-Fi button on camera
•Open SYMAGIX apps on your Wi-Fi Device
(refer to Wi-Fi Section for setup details)
•Click icon on the lower left corner to download and view
recorded videos and photos
16
WF1030-01 | Wi-Fi 1080p Action Camera
Viewing Recorded Videos & Photos
Viewing In PC
•Turn ON the camera and connect to PC via the included USB cable
•When PC detect the camera. Camera display will show “PCU”
(stand for PC USB)
•There will be 2USB drives shown in PC. First drive stores the
recorded videos and photos. Second drive stores camera
system info
(including SSID_PW.CFG which containing AP ID and password)
•While in “PCU” mode, You could change to “PCC” mode (PC
Camera) by click the Shutter button
Wide Angle PC Webcam
17
WF1030-01 | Wi-Fi 1080p Action Camera
Viewing Recorded Videos & Photos
Viewing On HDTV
•Before connecting to HDTV, stop recording and turn off Wi-Fi Mode
•Connect camera and HDTV with a Mini-HDMI/HDMI cable (not included)
•After connected, it enters TV Playback Mode
File number/Total filesPlayback Mode Icon
Video file icon
•Click ON/OFF button to switch between videos and photos
•Click Wi-Fi button to select the file
•Click Shutter button to play/stop the file
18
WF1030-01 | Wi-Fi 1080p Action Camera
Viewing Recorded Videos & Photos
Deleting Files In TV Playback Mode
•While in TV Playback Mode, Press and hold Shutter button to enter
delete/format menu
•Click ON/OFF button to switch between options
•Click Wi-Fi button to select between delete and format
•Click Shutter button confirm and exit
19/31
Delete this file?
No
Yes
Enter Format
wifi Select
19/31
Format
No
Yes
Enter Delete
wifi Select
19
