WorkPro SCAN 812 DMX User manual

User Manual
SCAN 812 DMX
En isgl h

1
ENGLISH
SCAN 812 DMX. Console for scanners control with protocol of comunication
USITT DMX 12.
Possibility to control until 12 scanners of 16 channels each one.
Transfer and performance time control in order to be able to make flexible the
programmes edition.
Simultaneous edition of several chases beig able to generate a great quality
off effects.
TAP-SYNC button to be able to generate times asincronous according to the
program needs.
Internal microphone.
XLR-3 pins connector
MIDI control.
It memorizes the last state of edition in case of mains cut, returning to the
execution state to return of the same.
PRO
R
Thanks for your reliability on us having acquired a product WORK.
We hope it provides you a long and reliable service.

ENGLISH
2
Program Enable
Programming Scenes
MIDI / REC
BANK
SCANNER BUTTONS 1-12
PROGRAM
SCANNER BUTTONS 1 - 12
Scene Editing
BANK
SCENE BUTTONS 1-8
SCENE BUTTONS 1-8
When the power is turned on, this unit enters Manual mode
automatically.
Press the Program button for three seconds to activate Program
mode, a fast blinking light in the Segment Display next to P OG.
Indicates its selection.
1 . Enter Program mode.
3 . Create a desired scene using the faders. The DMX value is
0 when the fader is fully down(bottom) and 255 when it is fully
up(top).
2 . Press the Scanner button to turn on its fader control, which
is indicated by lit LED.
You may select several scanners at a time by tapping of these
Scanner buttons, so you can assign several fixtures at a time
with this unit.
4 . If necerssary, you may tap the Page Select button to control
the second set of 8 DMX channels.
5 . Once the scene is satisfactory, tap the MIDI/ ec button to
program this scene into memory.
6 . Tap the Bank Up/Down button to select the bank you want to
store your scene into. There are total 30 bank you can select,
you may store up to 8 scenes into each bank.
7 . Tap the Scene button to store your scene, all LEDs and the
Segment Display will flash three times briefly indicating this
operation, then the Segment Display will show the bank and
the scene.
8 . epeat steps 3-7 until all desired scenes have been
programmed into memory. Tap the Scanner button again to
turn off its fader control.
To assing another scanner (fixture), you may tap the
corresponding Scanner button to turn on its fader control, the
you may begin your programming again.
9 . If you wish not continue your programming, press and hold
down the Program button for three seconds to exit Program
mode, the blinking light in the Segment Display goes out
indicating this selection.
1 . Program enable.
Tap the Bank Up/Down button to select the bank that contains
the scene you wish to edit.
2 .
Select the sceneyou want to edit tapping its Scene button.
3 .
4 . Use the Faders to make your desired adjustments.

SCENE
3
Scene Editing
MIDI / REC
Scanner Copy
SCANNER
Scene Copy
SCENE
BANK
BANK MIDI / REC
SCENE
Delete a Scene
SCENE
SCENE
AUTO/DEL
ENGLISH
5 . Once you've made your changes, tap the MIDI/Rec button
6 . Tap the Scene button that corresponds to the scene you're
ed t ng. Th s w ll overwr te the ex ted scene.
Be sure to select the same scene n steps 3 and 6, otherw se
you may acc dentally record over an ex ted scene.
NOTE:
Th s funct on allows you to copy the sett ng of one scanner
to another.
1 . Press and hold down the Scanner button you want to copy.
2 . Wh le hold ng the Scanner button, tap the Scanner button
you want to copy to.
SCANNER
1 . Program enable.
2 . Tap the Bank Up/Down button to select the bank that conta ns
the scene you w sh to copy.
3 . Select the scene you want to copy by tapp ng ts Scene button.
4 . Tap the Bank Up/Down button to select the bank you w sh to
copy the scene to.
5 . Tap the MIDI/Rec button.
6 . Tap the Scene button you w sh copy the scene to.
1 . Tap the des red Scene button to select the scene you
w sh to delete.
2 . Press and hold down the Auto/Del button.
Wh le hold ng down the Auto/Del button, tap the Scene
button that stores the scene you w sh to delete.
When a programmed scene s deleted, all DMX channel
n th s scene s set to 0.

ENGLISH
4
Delete all Scenes
BANK
PROGRAM
Bank Copy
BANK
MIDI / REC
MUSIC/BANK COPY
Programming Chase
MIDI / REC
MUSIC/BANK COPY
CHASE BUTTONS 1-6
BANK
Program a bank of scenes into a Chase
This function will reset all DMX channel to 0 output.
1 . With the power off, press and hold down the Program and
Bank Down uttons at a time.
2 . Apply power again, all scenes should e cleared.
1 . Program ena le.
2 . Tap the Bank Up/Down utton to select the ank you wish
to copy.
3 . Tap the MIDI/Rec utton.
4 . Tap the Bank Up/Doown utton to select the ank you wish
copy to.
5 . Tap the Music/Bank Copy utton, all LEDs and the Segment
Display will flash three times riefly indicating the function
has een completed.
6 . Press the Program utton for three seconds to exit
Programming mode.
You must program scenes efore you can program chases, this
function allows you to store up to 240 scenes into one chase.
1 . Program ena le.
2 . Tap the Chase utton to select the chase to program. Each
time you can select a chase only.
3 . Select a desired scene from the ank that has stored
scenes.(descri ed in Programming Scenes).
4 . Tap the MIDI/Rec utton.
5 . Repeat steps 3-4 until you've reached your desired effect.
You may record up to 240 scenes into a chase.
1 . Program ena le.
MIDI / Rec Copy
2 . Select the chase using Chase uttons 1-6.
3 . Use Bank Up/Down utton to select the ank that contains
the scenes you wish to copy.
4 . Tap the Music/Bank Copy utton.
5 . Tap the MIDI/Rec Copy utton, all LEDs and the Segment
Display utton causing a highlight next to STEP, the first digit
in the Segment Display shows the chase and the next three
digits show its step.

ENGLISH
5
Add a Step
BANK
MIDI / REC
Delete a Step
TAP SYNC/DISPLAY
TAP SYNC/DISPLAY
AUTO/DEL
BANK
Delete a Chase
CHASE Button 1-6
CHASE
AUTO/DEL
1 . Program enable.
2 . Select the chase you wish to add a step to.
3 . Tap the Tap Sync/Display button causing a highlight next to
STEP the firt digit in the Segment Display shows the chase
and the next three digits shows its step.
4 . Tap the Bank Up/Down button to scroll to the step you wish
to add a step after.
5 . Tap the MIDI/Rec button the Segment Display will read the step one higher than before.
For example if you want to insert a step between step 3 and step 4 and you scroll to step
3 when you tap the MIDI/Rec button the Segment Display will read step 4.
Hints : You may tap the Tap Sync/Display button to change the display mode between and the bank.
6 . Tap the Tap Sync/Display button again the Segment Display shows the current chase scene and bank.
Create a desired scene and record it as a new step or select a programmed scene you wish to add into this chase.
7 . Tap the MIDI/Rec button again all LEDs and the Segment Display will flash three times briefly indicating the new step has
been inserted into this chase.
1 . Program enable.
2 . Select the chase that contains the step you wish to delete.
3 . Tap the Tap Sync/Display button causing the Segment Display
shows the steps.
4 . Tap the Bank Up/Down button to scroll to the step you wish
to delete.
5 . Tap the Auto/Del button to delete the step all LEDs and the
Segment Display will flash three times briefly indicating that
the step has been deleted.
1 . Select the chase you wish to delete.
Press and hold down the Auto/Del button.
Tap the Chase button while holding down the Auto/Del
button all LEDs and the Segment Display will flash three
times briefly indicating this chase has been deleted.
2 .

ENGLISH
Delete all Chases
BANK
BANK
AUTO/DEL
Running Scenes
Manual Mode
SCENE
AUTO/DEL
SPEED FADE TIME
Auto Mode
AUTO/DEL
Music Mode
BANK
MUSIC BANK COPY
1 . With the power off, press and hold down the Auto/Del and Bank Down buttons same time.
2 . Apply the power again.
1 . When the power is turned on, this unit enters Manual mode automati ally.
2 . Make sure Auto trigger and Musi trigger indi ators in the Segment Display are both off.
3 . Use the bank Up/Down button to sele t the bank that ontains the s enes you wish to run.
4 . Tap the S ene button to sele t the s ene to run.
This fun tion allows you to run a bank of programmed s enes in a sequential loop.
1 . Tap the Auto/Del button to a tivate Auto mode.
A highlight nex t AUTO TI¡RIGGER will indi ate Auto mode.
2 . Use the Bank Up/Down button to sele t a bank of s enes to run
3 . After sele ting the bank of s enes you wish to run, you an use the Speed slider(or Tap
Syn /Display button) and Fade Time slider to adjust the s enes to your desired effe t.
Hints:
The Tap Syn button is used to set the speed by tapping the button
several times, the last two taps will define the speed with a
maximum of 10 minutes. Tap Syn will override any previous
setting of the Speed slider unless the slider is moved again.
4 . Tap the Auto/Del button again to exit Auto mode.
1 . Tap the Musi /Bank Copy button to a tivate Musi mode.
A highlight next to MUSIC TRIGGER indi ates Musi Mode.
2 . Use the Bank Up/Down button to sele t the bank that holds
the s enes you wish to run. The s enes you've sele ted will
hase in a sequential order a ording to the musi rhythms
dete ted by the built-in mi rophone
3 . Tap the Musi /Bank Copy button again to exit Musi mode.
6

Running Chases
Manual Mode
Auto Mode
AUTO/DEL
CHASE BUTTONS 1-6
SPEED FADE TIME
Music Mode
CHASE BUTTONS 1-6
MUSIC/BANK COPY
MIDI Operation
MIDI/REC
BANK
ENGLISH
You must program scenes before you can run chases.
BANK
1 . When the power is turned on, this unit enter Manual mode automatically.
2 . Select your desired chase by tapping one of the six Chase buttons. A second tap of this button
will deacti ate this function.
3 . Use the Speed slider (or Tap Sync button) and Fade Time slider to adjust the current scenes
to your desired effects.
4 . Use the Bank Up/Down button to scroll through the chase to run all banks of scenes.
1 . Tap the Auto/Del button to acti ate Auto mode. A highlight nex to
AUTO TRIGGER will indicate Auto mode.
2 . Select yor desired chase by tapping one of the six Chase buttons.
A second tap of this button will desacti ate this function.
3 . Use the Speed slider (or Tap Sync) and Fade Time slider to adjust
the chase to your desired effects.
You may select se eral chases at a time, the chases will run in
sequence that you select the chases.
1 . Tap the Music/Bank Copy button to acti ate Music mode. A
highlight in the Segment Display next to MUSIC TRIGGER will
indicate Music mode.
2 . Select your desired chase by tapping one of the six Chase
buttons, the chase will be triggered by the music rhythms.
You may select se eral chases at a time.
MIDI Channel Setting
1 . Press and hold down the MIDI/Rec button for three seconds,
the last two digits of the Segment Display will flash to indicate
MIDI channel setting is ready.
2 . Use the Bank Up/Down button to select the DMX channel 01-
16 to assign to MIDI channel.
3 . Press and hold down the MIDI/Rec button for three seconds
to store your setting and to deacti ate MIDI setting.
If you wish to gi e up your setting, tap any other button (except
Bank Up/Down buttons) to exit MIDI mode.
7

ENGLISH
Implementation
This unit receives Note On signals, which enables to run 15 bank (01-15) of scenes and 6 chases of scenes In addition, blackout function can
be activated by MIDI signal
BANK NOTE Nº FUNCTION
Bank 1 00 to 07 Turn on or off Scenes 1-8 of Bank 1
Bank 2 08 to 15
Bank 3 16 to 23
Bank 4 24 to 31
Bank 5 32 to 39
Bank 6 40 to 47
Bank 7 48 to 55
Bank 8 56 to 63
Bank 9 64 to 71
Bank 10 72 to 79
Bank 11 80 to 87
Bank 12 88 to 95
Bank 13 96 to 103
Bank 14 104 to 111
Bank 15 112 to 119
Turn on or off Chase 1Chase 1
Chase 2
Chase 3
Chase 4
Chase 5
Chase 6
120
121
122
123
124
125
126 BLACKOUT
8
Turn on or off Scenes 1-8 of Bank 2
Turn on or off Scenes 1-8 of Bank 3
Turn on or off Scenes 1-8 of Bank 4
Turn on or off Scenes 1-8 of Bank 5
Turn on or off Scenes 1-8 of Bank 6
Turn on or off Scenes 1-8 of Bank 7
Turn on or off Scenes 1-8 of Bank 8
Turn on or off Scenes 1-8 of Bank 9
Turn on or off Scenes 1-8 of Bank 10
Turn on or off Scenes 1-8 of Bank 11
Turn on or off Scenes 1-8 of Bank 12
Turn on or off Scenes 1-8 of Bank 13
Turn on or off Scenes 1-8 of Bank 14
Turn on or off Scenes 1-8 of Bank 15
Turn on or off Chase 2
Turn on or off Chase 3
Turn on or off Chase 4
Turn on or off Chase 5
Turn on or off Chase 6
Technical Specifications
Power Input
DMX Output
MIDI Signal
Audio Input
Weight
DC 9 - 12 V 500 mA min
3 pin female XLR
5 pin standard interface
By built-in microphone
2,5 Kg
Finally, we want to remember you that:
- Keep the set far from the humidity and avoid that any kind of liquids fo into it. f this occurs
being the mixer switches on, switch it off immediately from the mains.
- Place the mixer away from excessive heat and from direct sunlight.
- Avoid to accumulate dust, above all in the connectors and in the cooling grilles.
- Prevent that metallics objects enter into the mixer.
- f the mixer or the protecting fuses burn out, replace by ones with the same value. Under
no cirumstance, try repair a fuse.
- f you set up the mixer in a rack, be sure that it disposes of an air renovation grille.

USN CONNECTION ABLE
FROM 2006 VERSION

2Scene Buttons
Segment Display
Bank Buttons(Up/Down)
Chase Buttons(1-6)
Program Button
IDI/Rec Button
Auto/Del Button
Press the scene buttons to load or stored your scenes. There are maximum of
240 programable scenes.
Press the Up/Down buttons to select a ban 30 ban s.
Used to select your programmed chase consisting a maximum of 240 scenes.
Shows the currnt activity or programming state.
Used to activate Program mode.
Used to control MIDI operation or to record programs.
Used to activate Music mode or to create scenes and chase programs.
usic/Bank Copy
Blackout Button
Tap Sync/Display
Fade Time Slider
Speed Slider
Page Select Button
Faders
IDI IN
USB Light Connector Allows a USB DJ work light to be plugged into it.
D X Out
DC Input
Used to activate Auto mode or to delete scenes and chases.
Used to disable channel output.
Used to create a standard beat or to change the values display between % and 255.
Used to adjust the Fade Time. Fade Time is the amount of time it ta es for a fixture
(scaner) to move from one position to another, for the dimmer to fade in or fade out.
Used to adjust the speed at which the scenes will chase.
Used to select faders for the fixture between Page A (1-8) and Page B (9-16)
This faders are used to control intensity of channel 1-8 or channel 9-16 depending
upon the selected page.
TRASERA REAR
Receives MIDI data.
This connector sends your DMX value to the DMX fixture or DMX pac .
DC +9-12 V. 5 00 mA min.
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
10

Equipson, S.A.
www.equipson.es
[email protected]
