Wow iQ 150 User manual

User manual
iQ 150 –Generation 21
Scieneo.amplio 2
2153-ENG / V-1.1-29/04/13

1
All Rights Reserved.
The information in this document is subject to change without prior notice
in order to improve reliability, design and function and does not represent
a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special,
incidental, or consequential damages arising out of the use or inability to
use the product or documentation, even if advised of the possibility of such
damages.
This document contains proprietary information protected by copyright. All
rights are reserved. No part of this manual may be reproduced by any
mechanical, electronic, or other means in any form without prior written
permission of the manufacturer.
Limitation of Liability
While reasonable efforts have been made to ensure the accuracy of this
manual, the manufacturer and distributor assume no liability resulting from
errors or omissions in this manual, or from the use of the information
contained herein.
Copyright 2012

2
Content
1For Your Safety................................................................................................. 3
1.1 Caring for Your iQ150 ..................................................................................... 4
1.2 Regulatory Information ..................................................................................... 5
1.3 Information on the Power Cord ......................................................................... 6
1.4 Battery Pack Safety ........................................................................................... 6
1.5 Lithium Battery Warning / Bridge Battery Warning............................................... 7
1.6 Heat Related Safety Notice ................................................................................ 7
1.7 Headset and Earphone Volume Level Notice....................................................... 8
1.8 Cleaning the Keyboard ..................................................................................... 8
1.9 Travel Notice.................................................................................................... 8
2Touring the WOW! 150 ..................................................................................... 9
2.1 Front ............................................................................................................... 9
2.2 Left view ........................................................................................................ 10
2.3 Right view ...................................................................................................... 11
2.4 Back.............................................................................................................. 12
2.5 Base.............................................................................................................. 13
3Getting Started ............................................................................................... 14
3.1 Installing the Battery ....................................................................................... 14
3.2 R emoving the Battery Pack .............................................................................. 15
3.3 Operating on Battery Power ............................................................................ 15
3.4 Battery Low-Power Warning............................................................................. 15
3.5 Connecting the AC Adapter............................................................................. 16
3.6 Charging the Battery and Charging Time ......................................................... 16
3.7 Opening the LCD Panel .................................................................................. 17
3.8 Turning On Your Computer ............................................................................ 18
3.9 Switching the Power Off .................................................................................. 18
3.10 Conserving the Battery Power ..................................................................... 19
3.11 LED Status Indicators ................................................................................. 20
4Using the WOW! 150...................................................................................... 21
4.1 Using the Keyboard ........................................................................................ 21
4.2 Using the Touch Pad....................................................................................... 22
4.3 Using the Touch Screen .................................................................................. 23
4.4 Quick Controller ............................................................................................ 24
4.5 Rotating the Display Panel............................................................................... 25
4.6 Using the Display Panel as a Writing Pad ......................................................... 27
4.7 Using the Built-in Rotating Camera .................................................................. 28
4.8 Sharing the Same Audio Source....................................................................... 29
5Network Communication ................................................................................. 30
5.1 Establishing a Wireless Connection .................................................................. 30
5.2 Pairing with a Bluetooth Device........................................................................ 30
5.3 Establishing a Bluetooth Pairing....................................................................... 30
6Troubleshooting.............................................................................................. 31
6.1 System recovery.............................................................................................. 31
7Specifications ................................................................................................. 34
8FAQ.............................................................................................................. 35
8.1 Serialnumber ................................................................................................. 35
8.2 Activation code for Windows ........................................................................... 35
9Contacts........................................................................................................ 36

3
1For Your Safety
Before using the IQ150, make sure that you understand the following
precautions:
Do not drop, crush, or step on the iQ150.
Do not place objects or apply heavy pressure on the iQ150.
Do not place on uneven or unstable work surfaces.
Do not block the openings provided for ventilation, as overheating
may occur.
Do not use or store the iQ150 in extreme weather conditions.
Do not expose to sudden changes in temperature or humidity: keep
the iQ150 away from heating and A/C vents.
Do not expose to magnetic fields.
Do not expose to direct sunlight.
Do not place near fire or other sources of heat.
Do not expose to rain or moisture.
Do not leave the iQ150 turned on or plugged in when enclosed in
a non-ventilated container, such as a backpack, as overheating
may occur

4
1.1 Caring for Your iQ150
To avoid electrical shock or damage to the unit…
Disconnect power from the computer by unplugging the power cord
from the AC outlet (not by unplugging the power cord from the
computer).
Be sure not to clean the computer when it is plugged into a wall
socket.
When cleaning the unit, clean only with a damp soft cloth. Do not
pour liquid onto the unit.
Do not clean while the computer is “on” or plugged into a wall
socket.
Caution students to avoid using this device under wet conditions
and also to protect the unit when carrying under this condition.
Be sure the touch pad does not come into contact with dirt, liquids,
or grease.
Power connection must be removed before installing signal cables,
whenever it is functionally and legally allowed.
Power cords must be reconnected only after all signal
interconnections have been completed.

5
1.2 Regulatory Information
Product: scieneo.amplio 2 (iQ150)
Model No.: EC10IS2
Applicant: Elitegroup Computer Systems Co., LTD
European Notice
Products with the CE Marking comply with both the EMC Directive
(2004/108/EC) and the Low Voltage Directive (2006/95/EC) and R&TTE
Directive (1999/5/EC) issued by the Commission of the European
Community.
Compliance with these directives implies conformity to the following
European Norms:
EN55022: 2006, CLASS B
EN61000-3-2: 2006, CLASS D
EN61000-3-3: 1995+A1: 2001+A2: 2005
EN55024: 1998+A1: 2001+A2: 2003
IEC61000-4-2: 2001 ED. 1.2
IEC61000-4-3: 2006 ED. 3.0
IEC61000-4-4: 2004 ED. 2.0
IEC61000-4-5: 2005 ED. 2.0
IEC61000-4-6: 2006 ED. 2.2
IEC61000-4-8: 2001 ED. 1.1
IEC61000-4-11: 2004 ED. 2.0
EN 300 328-2, EN 300 328-1, EN 301 489-1, EN 301 489-17 (ETSI 300
328, ETSI 301 489) Electro-magnetic Compatibility and Radio Spectrum
Matter.
EN60950 (IEC60950) I.T.E. Product Safety

6
1.3 Information on the Power Cord
To reduce the risk of electric shock or damage to the equipment:
Plug the power cord into an AC outlet that is easily accessible at all
times.
Disconnect power from the computer by unplugging the power cord
from the AC outlet (not by unplugging the power cord from the
computer).
If provided with a 3-pin attachment plug on the power cord, plug
the cord into a grounded (earthed) 3-pin outlet. Do not disable the
power cord grounding pin, for example, by attaching a 2-pin
adapter. The grounding pin is an important safety feature.
Only the AC adapter provided with the computer should be used
with the computer
1.4 Battery Pack Safety
Keep the battery away from children.
The battery pack is intended to use only with this iQ150.
To reduce potential safety issues, only the battery provided with the
computer, a replacement battery provided by the supplier, or a
compatible battery purchased as an accessory from the supplier
should be used with the computer.
To reduce the risk of fire or burns, do not disassemble, crush, or
puncture a battery; short the external contacts on a battery; or
dispose of a battery in fire or water.
Do not expose a battery to temperatures above 60ºC (140ºF).
Handle a damaged or leaking battery with extreme care. If you
come in contact with the electrolyte, wash the exposed area with
soap and water. If it contacts the eye, flush the eye with water for 15
minutes and seek medical attention.
Do not charge the battery pack if the ambient temperature exceeds
45°C (113°F).
Do not expose the battery pack to low storage temperatures (below
0°C, 32°F).
To obtain a replacement battery, contact your local dealer.

7
When discarding a battery pack, contact your local waste disposal
provider regarding local restrictions on the disposal or recycling of
batteries.
Use only supplied AC Adapter for charging .
CAUTION!
Danger of explosion if battery is incorrectly replaced. Only qualified
service technicians should replace and discard the battery pack.
Replace only with same or equivalent type recommended by the
manufacturer. Discard used batteries according to the manufacturer’s
instructions or local laws.
1.5 Lithium Battery Warning / Bridge Battery Warning
This iQ150 contains a lithium battery to power the clock and calendar
circuitry.
1.6 Heat Related Safety Notice
The iQ150 and the AC adapter comply with the user-accessible surface
temperature limits defined by the International Standard for Safety of
Information Technology Equipment (IEC 60950).
To reduce the possibility of heat-related injuries or of overheating the
computer:
Do not place the computer directly on your lap or obstruct the
computer air vents.
Use the computer only on a hard, flat surface. Do not allow another
hard surface, such as an adjoining optional printer, or a soft
surface, such as pillows or rugs or clothing, to block airflow.
Do not allow the AC adapter to contact the skin or a soft surface,
such as pillows or rugs or clothing, during operation.

8
1.7 Headset and Earphone Volume Level Notice
Listening to music at high volume levels and for extended durations
can damage one's hearing. To reduce the risk of hearing damage,
lower the volume to a safe, comfortable level and reduce the
amount of time listening at high levels.
For your own safety, before using headsets or earphones, always
reset the volume. Some headphones are louder than other
headphones, even if the volume control setting is the same.
Changing the default audio or equalizer settings might lead to
higher volume and should only be done with caution.
1.8 Cleaning the Keyboard
To reduce the risk of electric shock or damage to internal components:
Do not use a vacuum cleaner attachment to clean the keyboard. A
vacuum cleaner can deposit household debris on the keyboard
surface.
Clean the keyboard regularly to prevent keys from sticking and to
remove dust, lint, and particles that can become trapped beneath
the keys. A can of compressed air with a straw extension can be
used to blow air around and under the keys to loosen and remove
debris.
1.9 Travel Notice
WARNING
To reduce the risk of electric shock, fire, or damage to the equipment,
do not attempt to power the computer with a voltage converter kit sold
for appliances.

9
2Touring the WOW! 150
2.1 Front
1.
Built-in rotating camera
Use the Built-in rotating camera for video conferencing.
2.
Microphone
The microphone is used when you are having an
audio/video conference with the other party.
3.
LCD display
Contents of the current system operation are displayed
here.
4.
Camera button
When the camera software is running, press this button to
view the software in full-screen mode. When the camera
software is not running, press this button to start the
software and capture images/videos.
5.
Home button
Press once to bring back the desktop screen. Press this
button twice to launch the quick controller display panel
when the computer is turned to tablet mode.
7.
LED status indicators
The operation status of your iQ150 is displayed here. See
“LED Status Indicators”.
8.
Keyboard
Use the keyboard to enter data.
1
2
3
4
5
7
8
9
10
11
12

10
9.
Touch pad
Use the touch pad and two buttons as a mouse. See
“Using The Touch Pad”.
10.
Touchpad Buttons
Works like the two buttons on an ordinary mouse.
11.
Scrolling switch
Use the scrolling switch when the system is in tablet mode.
Scroll from left to right: for scrolling up function
Scroll from right to left: for scrolling down function.
12.
Power button
Press this button to turn your iQ150 on and off. See
“Switching the Power On”.
2.2 Left view
1.
External monitor port
Use this port to connect to an external monitor.
2.
HDMI Port
Compact audio/video interface for transmitting
uncompressed digital data.
3.
USB 2.0 port
Use this port to connect Universal Serial Bus devices. The
iQ150 supports v.2.0 of the USB standard.
4.
Ventilation Opening
The ventilation opening allows the computer to cool off and
prevent overheating. Do not block this opening when the
computer is turned on.
5.
2 in 1 Card Reader
Supports SDHC / MMC memory card.
1
2
2
2
3
3
4
4
5
5

11
2.3 Right view
1.
Stylus pen slot
The Stylus pen for the touch screen is stored here.
2.
Headphone jacks
Use the headphone jacks to connect external headphone
sets.
3.
Microphone jack
Use the microphone jack to connect an external microphone.
4.
USB 2.0 port
Use this port to connect Universal Serial Bus devices. The
iQ150 supports v.2.0 of the USB standard.
5.
Ethernet / LAN
(RJ-45)
Use this port to connect a standard RJ-45 plug of a router or
ADSL modem.
6.
Power adapter port
Connect your AC adapter to this port to power up your
iQ150 and charge the battery pack.
1
3
2
4
5
6

12
2.4 Back
1.
Handle
Use the handle to carry the iQ150.
2.
LCD Display Rotating
Bar
This bar is used to rotate the LCD display.
3.
Scrolling switch
Use the scroll bar when the system is in tablet mode.
Scroll from left to right: for scrolling up function
Scroll from right to left: for scrolling down function
1
2
3

13
2.5 Base
1.
Battery bay
The battery pack is stored here.
2.
Battery lock switch
Use the battery lock switch to lock the battery pack in
the battery bay.
3.
Stereo speakers
The stereo speakers allow for audio output.
1
2
3

14
3Getting Started
Congratulations on your purchase of the iQ150.
Your iQ150 features a built-in rotating camera, two headphone ports for
sharing music, a rotating LCD display panel, and touch screen functions. In
this section, you will be introduced to the basic operations of your iQ150.
3.1 Installing the Battery
WARNING!
Before installing or removing the battery, make sure the iQ150 is
turned off.
1. Align the tabs on the battery pack with the slots in the battery bay, and
insert the battery pack into the battery bay.
2. Slide and hold the battery lock switch to the right, in the unlocked
position.
3. Slide the battery pack down gently but firmly until it locks into place.
4. Slide the battery lock switch left into the locked position.

15
3.2 R emoving the Battery Pack
1. Slide and hold the battery lock switch to the right, in the unlocked
position.
2. Lift and remove the battery.
NOTE
You must charge the battery pack for at least six hours before using it
for the first time.
3.3 Operating on Battery Power
Your computer comes with a rechargeable battery pack that lets you
operate the computer without an external power source. When the battery
pack is fully charged, you can operate the computer under the following
conditions:
The battery pack initially has a full charge.
No peripheral devices are installed.
NOTE!
You must charge the battery pack for at least six hours before using it
for the first time. In the Standby Suspend mode, a fully charged battery
loses its power in roughly 1/2 day or less. When not being used, the
battery’s power will deplete in one to two months. The battery pack in
this system is replaceable by the end user.
3.4 Battery Low-Power Warning
Low Battery Warning
Low battery condition occurs when battery power is reduced to 10
percent.
Very Low Battery Warning
Very Low battery condition occurs at 5 percent power remaining.
The red battery status LED indicator blinks and the system beeps 3x in
1.2sec (each beeping last 200ms and 200ms off interval before the next
beep). When the WOW! 150 warns you of its low battery condition, you
will have about three to five minutes to save your current work.
WARNING!
Do not expose battery packs to temperatures below 0 degree Celsius
(32 degree F) or above 60 degree C (140 degree F). This may
adversely affect the battery pack.

16
3.5 Connecting the AC Adapter
A universal AC adapter is provided to supply your computer with power
and also charge the computer’s battery pack. The adapter’s AC input
voltage can range anywhere from 100 to 240 volts, covering the standard
voltages available in almost every country.
To connect the computer to an external power source:
WARNING
Do not use inferior extension cords as this may result in damage to
your WOW! 150. WOW! 150 comes with its own AC adapter. Do not
use a different adapter to power the computer and other electrical
devices.
WARNING!
Never turn off or reset your iQ150 while the hard disk is in use; doing
so can result in loss or destruction of your data. Always wait at least 5
seconds after turning off your WOW! 150 before turning it back on;
turning the power on and off in rapid succession can damage the
WOW! 150 electrical circuitry.
Whenever possible, keep the AC adapter plugged into the WOW! 150 and
an electrical outlet to recharge the battery.
3.6 Charging the Battery and Charging Time
To charge the battery, plug the AC adapter into the WOW! 150 and an
electrical outlet.
Charging time for 6 cells (5200mAh) battery pack; the battery will be 70
percent charged in about 150 mins and fully charged in about 260mins .
NOTE
If system runs at heavy loads or in a high temperature environment,
the battery may not be fully charged. You need to continue to charge it
with the AC adapter plugged in until the charging LED turns blue.
NOTE!
System will not charge battery when temperature exceeds 45°C.

17
3.7 Opening the LCD Panel
To open the LCD panel:
1. Steady the base of the iQ150 with one hand.
2. Hold a corner of the LCD panel with the other hand.
3. Gently raise the LCD panel to the upright position.
WARNING!
Never slam the LCD panel shut, as this may damage the Display.
NOTE !
Do not grip the Built-in rotating camera when trying to open or close
the LCD panel.
LCD Care
LCD screens are delicate devices that need careful handling. Please pay
attention to the following precautions:
When you are not using the computer, keep the LCD screen closed
to protect it from dust.
If you need to clean your LCD screen, use a soft tissue to gently
wipe the LCD surface.
Do not put your fingers or sharp objects directly on the surface and
never spray cleaner directly onto the display.
Do not press on, or store any objects on the cover when it is closed.
Doing so may cause the LCD to break.

18
3.8 Turning On Your Computer
Once you have connected your AC adapter or charged the battery pack,
you can power on your iQ150.
When you power on your iQ150, the Power-On Self Test (POST) runs
automatically to check the internal hardware and configuration. After the
POST is completed, your iQ150 loads the installed operating system.
If hardware configuration has been changed or the POST fails, a warning
message may appear on the screen. This message will inform you of any
errors or invalid settings, and prompt you to run the BIOS Setup Utility to
correct the problem.
3.9 Switching the Power Off
1. Make sure all applications are turned off.
2. Press the ON/OFF button for Stand-by.
3. To completely switch off the WOW! 150, shut down him down from the
Windows start menu.
WARNING
Never turn the iQ150 off during the POST, or an unrecoverable error
may occur.
Never turn the iQ150 off while the hard disk is in use, or system data
may be lost or corrupted.
