WRAP INTRENSIC User manual

PRODUCT
MANUAL
wrap.com

Contact: 800-583-2652, option 4 | [email protected] | wrap.com/intrensic
©2023 WRAP TECHNOLOGIES, INC. | ALL RIGHTS RESERVED
WRAP INTRENSIC X2 BODY WORN CAMERA

CONTENTS
Camera Introduction
Features and Specifications
Camera Buttons/Functions Legend
Charging and Status LEDs
Guide to Upload from Your MDT
To Change to Record Reminder Feature
FCC Warning
1
2
4
5
6
8
9-10
WRAP INTRENSIC X2 BODY WORN CAMERA

PAGE 1
CAMERA INTRODUCTION
Wrap Intrensic
X2 Camera
Wrap Intrensic | Evidence on Cloud™
Technical Support
[email protected]
800-583-2652, option 4
To log onto Evidence on Cloud™:
app.intrensic.com
Optional Mounts
Magnetic Camera-Mounting Stud
MOLLE Mount Fixed Outer Carrier
Stud
Your kit contains:
1
1
1
Alligator Clip Mount
Camera Dock
(Charging/Transferring)
1110-120V AC to USB Wall Charger
1Camera Introduction Booklet
WRAP INTRENSIC X2 BODY WORN CAMERA
1Camera 1USB Cable (1 m or 39 in)

PAGE 2
FEATURES
• Battery life - up to 14 hours
• Front video record button
• Captures photos while video continues uninterrupted
• Digital Audio Recorder
• GPS
• One button activates “Discreet Mode”
• IP67
• Notifications & Alerts: Recording Reminder, Low Battery, Low Storage
• Secured: Evidence & Settings
SPECIFICATIONS
Video resolution
Low light
Camera resolution
FOV
Battery life
Image stabilization
Charging dock
Charge time
Battery capacity
Storage
Video file format
Storage type
Pre/Post Event Recording
Up to 1440
Auto/manual
40MP
140°
Up to 14 hours
Yes
Yes + data
250 minutes
3200mAh
64GB
.MP4
Internal
Yes
Yes
Yes
Yes
Yes
Yes
Yes
IP67
Yes
Yes
5.75
3.3" x 2.2" x 1"
1 year & optional
extended
Yes
One-touch recording
Record reminder
GPS
Bluetooth
Photos while recording
Password protection
Waterproof rating
USB
LCD screen
Weight (ounces)
Dimensions
Warranty
Multiple mounts
Light sensor
R. IR light
Microphone
Lens
Video Recording Button 1
FRONT
USB port
Discreet button
SIDE 1
BACK
Mounting slot
Speaker
LCD screen
Menu controls
Menu button Up arrow
Down arrow
Playback button
Photo Button 1 Video Recording Button 2
Charging LED
TOP
Status LED
Photo button 2
Low light button
Digital audio button
Power button
SIDE 2
(Photo: zoom-out)
(Photo: zoom-in)
WRAP INTRENSIC X2 BODY WORN CAMERA

PAGE 3
Photograph—Snapshot Capture
Screenshot
Audio Recording
Power On/Standby
When the camera is powered OFF, press, and hold the power button
for 3 seconds to turn the camera ON.
• The camera will vibrate once
• The status LED will turn solid green
• The LCD screen will remain off
• If using the Pre-Event Recording Mode feature,
the Status LED will be solid red.
Power Off
When the camera is powered ON, press, and hold the power button
for 3 seconds to turn the camera OFF.
• The camera will beep once
• The camera will quickly vibrate three times
• The Wrap Intrensic logo will display on the LCD screen
• The status LED will turn off
When the camera is powered on/standby mode but is not currently
recording, press the photo button 1 or 2 to take a photograph. This will
be a higher resolution photograph (note zoom-in and zoom-out features
available.)
When the camera is recording a video, press photo button 1 or 2 to take
a snapshot from the recording video. This photo will be smaller in size
than a regular photo.
Note: Taking a screenshot does not disrupt your video recording. It copies
one frame from your video as a photo and saves it separate from the
video recording. The photo will be much smaller and a reduced quality.
When the camera is powered on/standby mode but is not currently recording:
• Start = Single-Press the audio recording button to start recording audio
Status LED will flash green while recording audio
• Stop = Double-Press the audio recording button again to stop recording
If you press either of the Video recording buttons during a digital audio recording,
the audio recording will save to a file and begin a new video recording.
When the camera is powered on/standby mode but is not currently
recording:
• Start = Single-Press the video recording button to start recording
video
• Stop = Double-Press (default) the video recording button again to
stop the recording.
* There is an optional single-tap stop programmable in the camera
manager
If you press the Digital audio recording button during a video
recording, the video recording will save to a file and begin a new
digital audio recording.
Camera Power ON/OFF
Video Recording
WRAP INTRENSIC X2 BODY WORN CAMERA

BUTTON/
FUNCTION
LEGEND
PAGE 4
BUTTON BUTTON ICON OPERATION FUNCTION
Power button Press once Turn the LCD ON/OFF
Hold for 3 seconds Turn the camera ON/OFF
Video recording
buttons
(front and top)
Press once Start recording when the camera is powered ON
Press and hold for 3 Seconds Start recording when the camera is powered OFF
Press twice Stop recording a video (default)
Digital audio
recording button
Press once Start recording (camera on)
Press twice Stop recording (default)
Photo recording
button Press once Take a photo
Low light button Press once Turn low light ON/OFF
Hold for 3 seconds Turn flashlight ON/OFF
PTT button
(Same as photo recording button) Press once Take a photo
SOS button
(Discreet mode) Press and hold While recording video or audio, press and hold
the SOS button to mute the audio recording
Menu button Press once Menu and/or confirm selection
Up-arrow button Press once Scroll up/left
Hold for 3 seconds Zoom out
Down-arrow button Press once Scroll down/right
Hold for 3 seconds Zoom in
Playback button Press once Go back/exit
Hold for 3 seconds Playback last recorded file
Reset Press and hold for 10 seconds
Reset the camera by holding both the top video recording
button and the power button at the same time.
Reset the camera: No settings or evidence will be lost

PAGE 5
Charging and Status LEDs Guide to Upload to TOC
(Multi-Camera “Kiosk Mode”)
LCD Display
Charging LED
Blue : Charging
OFF : Charged
Solid Green: Camera is On
Solid Red: Pre-Event Buffering
Flashing Green: Audio Recording
Flashing Red: Video Recording
Status LED
Fully charge the X2 camera using the included USB cable and charging dock
for 3–4 hours.
* The charging indicator on the top of the camera will turn solid blue LED
when charging. When the device is fully charged, the blue LED will turn off.
Power the Wrap Intrensic X2 Camera
OFF and place in docking dtation. If
the camera is assigned and the PIN
requirement is “OFF” the camera will
automatically begin to offload.
If the camera is not assigned, you will
see this screen and must identify
yourself prior to uploading if the PIN
requirement is OFF after selecting
yourself from the list, the camera will
begin to offload.
If the PIN requirement is ON for
your agency, you will see this screen
and must code your PIN# for the
camera to begin offloading.
When it’s completed, the message will
display for 30 seconds after the offload
to indicate the offload is complete, and
you may remove your camera.
Note: After the offload and upload to
the cloud you may go to the link
below to identify and categorize your
videos. A new screen “Evidence
Labeling” is now available to assist you
in labeling your evidence. ** Ask about our CAD/RMS integration.
It saves time and adds consistency.
Press the Power button
once to wake the LCD when
the camera is powered on
or press any of the menu
buttons below the LCD.
Visit app.intrensic.com
WRAP INTRENSIC X2 BODY WORN CAMERA
1080P30
YYYY/MM/DD—HH:MM:SS xx.xxG/xx.xxG
Recording resolution
Elapsed time of
recorded event
Recording remaining time
(# hrs. remaining memory)
Bluetooth is ON
Camera time and date Space Remaining of Total
Formatted Space
Agency and your ID# XX:XX:XX
GPS
Remaining
battery
Recording indicator
000:00:00

PAGE 6
WRAP INTRENSIC X2 BODY WORN CAMERA
Guide to Upload from Your MDT
(Single-Dock Mobile or Desktop)
From your MDT or desktop make sure the Wrap Intrensic
uploader is installed per the previous instructions and
connected to the single docking station with the USB
cable provided.
Power-off the camera, then dock the Wrap Intrensic
X2 camera in your single dock supplied (connected to
MDT or desktop)
When prompted, log in with your username and password
(this tells the system where to park your files)
Preview, edit, and add identifiers to your evidence, then hit
“Send to Cloud”. The video will be copied from the camera
to the computer where they will process and upload to
the cloud.
Once prompted, “Video Transferred, Safe to Remove your
Camera”, unplug your camera and place back in service.
2
1
3
4
5

PAGE 7
Log in screen to the Wrap Intrensic
Evidence on CloudTM website
Visit app.intrensic.com
(Admin.) Agency settings menu
(Admin.) Global settings and categories
(Admin.) Global user settings
(Admin.) Agency org chart
The NEW evidence labeling
Evidence menu
Case menu
Share menu
Reports menu
Wrap Intrensic
camera uploader
Evidence on CloudTM navigation menu
* Change your password
** Before using the Wrap Intrensic
System, change your password from
the Wrap Intrensic default password

PAGE 8
(User Selectable)
Single press the first button on the back to wake up the device. Single press
again to “Enter Password.” The password is [SIX] 0’s, or just hit the main
“ENTER” button (the first button below the screen) six times.
After entering the
password, press button
3 to highlight the gear,
and button 1 to select.
Press button 3 to
scroll down to “record
reminder” and select
using 1. Scroll through
the options and select
with button 1
Add Your Wrap Intrensic
Uploader (New Install)
To Change to Record
Reminder Feature
Log in to the Wrap Intrensic Evidence on CloudTM
2
Open your browser and go to app.intrensic.com
1
Select the last item in the menu: “Wrap Intrensic Uploader”
3
Click the icon to download then click set-up in toolbar
Follow instructions to complete set-up
4
5
Enter
button Up
arrow Down arrow
Escape/
back
WRAP INTRENSIC X2 BODY WORN CAMERA

PAGE 9
WRAP INTRENSIC X2BODYWORN CAMERA
FCC Warning
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.
Specific Absorption Rate (SAR) information:
This X2 meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent
scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to
assure the safety of all persons regardless of age or health.
FCC RF Exposure Information and Statement

PAGE 10
WRAP INTRENSIC X2BODYWORN CAMERA
FCC Warning
– This radio is designed for and classified as “General population/uncontrolled Use”, the guidelines are based on standards that were developed by independent
scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the
safety of all persons regardless of age or health.The exposure standard for wireless radio employs a unit of measurement known as the Specific Absorption Rate,
or SAR, the SAR limit set 1.6W/kg.
– Body-worn operation; this device was tested for typical body-worn operations with the back of the handset kept 0mm for body worn. To maintain compliance
with RF exposure requirements, use accessories that maintain a 0mm for body worn. The use of belt clips, holsters and similar accessories should not contain
metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with RF exposure requirements, and should
be avoided.
– The highest reported SAR value for worn on the body is 0.626 W/kg

©2023 WRAP TECHNOLOGIES, INC. | ALL RIGHTS RESERVED
