Wren MPS12D16-12 User manual

LCD
MODE
DISPLAY COLORS
COLOR SATURATION
VIEW ANGLE
RESOLUTION
BRIGHTNESS
CONTRAST RATIO
RESPONSE TIME
IMAGE SENSOR
EFFECTIVE PIXELS
SCANNING SYSTEM
SCANNING FREQUENCY
RESOLUTION
SHUTTER SPEED
S/N RATIO
SYNC. SYSTEM
MIN. ILLUMINATION
WHITE BALANCE
VIDEO OUTPUT
LENS
POWER SUPPLY
POWER CONSUMPTION
WEIGHT
DIMENSIONS
WREN PUBLIC VIEW MONITOR SERIES
TE C HNI CAL S PEC I F I CATI O N S
19” TFT LCD
Premium MVA
16.7M (8 bit)
72 (EBU=100%)
178/178
300 nit
1300:1
8 ms
Sony 1/3” Super HAD
811 (H) x 508 (V)
2:1 Interface
15.734 KHz (H), 59.94 Hz (V)
540 TVL
1/60 - 1/100,000 sec.
50dB (AGC off)
Internal
0.3 Lux/ F1.2 (Color)
0.1 Lux/ F1.2 (B/W)
ATW/ AWC/ Manual
VBS 1.0 Vp-p (75Ω load)
6 mm Fixed Lens
DC24V
50 Watts (DC24V)
11.2 lbs
14.75” (H) x 15.87” (W) x 1.56” (D)
20” PUBLIC VIEW MONITOR20” PUBLIC VIEW MONITOR20” PUBLIC VIEW MONITOR19” PUBL IC VIEW MONITOR
20” TFT LCD
Premium MVA
16.7M (8 bit)
72 (EBU = 100%)
176/176
640 x 480
550 nit
800:1
12 ms
Sony 1/3” Super HAD
811 (H) x 508 (V)
2:1 Interface
15.734 KHz (H), 59.94 Hz (V)
540 TVL
1/60 - 1/100,000 sec.
50 dB (AGC off)
Internal
0.3 Lux/ F1.2 (Color)
0.1 Lux/ F1.2 (B/W)
ATW/ AWC/ Manual
VBS 1.0 Vp-p (75Ω load)
2.9mm~10mm / F1.2
Aspherical Lens
DC24V
100 Watts (DC24V)
17 lbs
16.75” (H) x 17.5” (W) x 3” (D)
20” Outdoor
Premium MVA
16.7M (8 bit)
72 (EBU = 100%)
176/176
640 x 480
550 nit
800:1
12 ms
Sony 1/3” Super HAD
811 (H) x 508 (V)
2:1 Interface
15.734 KHz (H), 59.94 Hz (V)
540 TVL
1/60 - 1/100,000 sec.
50 dB (AGC off)
Internal
0.3 Lux/ F1.2 (Color)
0.1 Lux/ F1.2 (B/W)
ATW/ AWC/ Manual
VBS 1.0 Vp-p (75Ω load)
2.9mm~10mm / F1.2
Aspherical Lens
110 VAC
140 W (w heater on); 50W (w heater off)
24 lbs
16.25” (H) x 17.375” (W) x 4.5” (D)
PROPERTY OF WREN rev_b v2 04.22.08PAGE 1 OF 2
124 W R E N PA R K WAY • J E F F E R S O N C I T Y, M O 6 510 9 • TO L L F R E E ( 8 0 0 ) 8 81-2 24 9 • FA X ( 87 7 ) 8 9 3 -2 317
www.wrensolutions.com
U N I T
20” PVM with PIR
Premium MVA
16.7M (8 bit)
72 (EBU = 100%)
176/176
640 x 480
550 nit
800:1
12 ms
Sony 1/3” Super HAD
811 (H) x 508 (V)
2:1 Interface
15.734 KHz (H), 59.94 Hz (V)
540 TVL
1/60 - 1/100,000 sec.
50 dB (AGC off)
Internal
0.3 Lux/ F1.2 (Color)
0.1 Lux/ F1.2 (B/W)
ATW/ AWC/ Manual
VBS 1.0 Vp-p (75Ω load)
2.9mm~10mm / F1.2
Aspherical Lens
DC24V & AC110V
100 Watts (DC24V)
17 lbs
16.75” (H) x 17.5” (W) x 3.0” (D)
C A M E R A L C D

LCD
MODE
DISPLAY COLORS
COLOR SATURATION
VIEW ANGLE
RESOLUTION
BRIGHTNESS
CONTRAST RATIO
RESPONSE TIME
IMAGE SENSOR
EFFECTIVE PIXELS
SCANNING SYSTEM
SCANNING FREQUENCY
RESOLUTION
SHUTTER SPEED
S/N RATIO
SYNC. SYSTEM
MIN. ILLUMINATION
WHITE BALANCE
VIDEO OUTPUT
LENS
POWER SUPPLY
POWER CONSUMPTION
WEIGHT
DIMENSIONS
WREN PUBLIC VIEW MONITOR SERIES
TE C H N I CAL S PEC I F I CATIO N S
8” TFT LCD
Premium MVA
16.7M (8 bit)
72 (EBU=100%)
130/120
640 x 480
350 nit
250:1
15 ms
Sony 1/3” Super HAD
811 (H) x 508 (V)
2:1 Interface
15.734 KHz (H), 59.94 Hz (V)
540 TVL
1/60 - 1/100,000 sec.
50dB (AGC off)
Internal
0.3 Lux/ F1.2 (Color)
0.1 Lux/ F1.2 (B/W)
ATW/ AWC/ Manual
VBS 1.0 Vp-p (75Ω load)
6 mm Fixed Lens
DC12V
500mA (DC12V)
2.7 lbs
5.69” (H) x 9.44” (W) x 1.56” (D)
32” PUBLIC V IE W MONIT OR26” PUBLIC V IE W MONIT OR8” PUBLIC VIE W MONITOR
26” TFT LCD
Premium MVA
16.7M (8 bit)
72 (EBU = 100%)
170/170
1366 x 768
500 nit
1200:1
12 ms
Sony 1/3” Super HAD
811 (H) x 508 (V)
2:1 Interface
15.734 KHz (H), 59.94 Hz (V)
540 TVL
1/60 - 1/100,000 sec.
50 dB (AGC off)
Internal
0.3 Lux/ F1.2 (Color)
0.1 Lux/ F1.2 (B/W)
ATW/ AWC/ Manual
VBS 1.0 Vp-p (75Ω load)
2.9mm~10mm / F1.2
Aspherical Lens
DC24V
120 Watts (DC24V)
23 lbs
17.2” (H) x 25” (W) x 3” (D)
PROPERTY OF WREN rev_b v2 04.22.08PAGE 2 OF 2
124 W R E N PA R K WAY • J E F F E R S O N C I T Y, M O 6 510 9 • TO L L F R E E ( 8 0 0 ) 8 81-2 24 9 • FA X ( 87 7 ) 8 9 3 -2 317
www.wrensolutions.com
Wren®, the Wren design logo, Wren IP Solutions, No Tools Required, Solution Set Series and The Power to See Your Business are trademarks of Wren. The trademarks that are followed by ® are registered trademarks in the U.S. All other trademarks and/or
registered trademarks mentioned herein are properties of their respective owners and are used for reference purposes only. The use of these trademarks does not indicate any affiliation with or sponsorship of or by Wren. ©2008 Wren. All rights reserved.
U N I T
32” TFT LCD
Premium MVA
16.7M (8 bit)
72 (EBU = 100%)
178/178
1366 x 768
500 nit
1500:1
6.5 ms
Sony 1/3” Super HAD
811 (H) x 508 (V)
2:1 Interface
15.734 KHz (H), 59.94 Hz (V)
540 TVL
1/60 - 1/100,000 sec.
50 dB (AGC off)
Internal
0.3 Lux/ F1.2 (Color)
0.1 Lux/ F1.2 (B/W)
ATW/ AWC/ Manual
VBS 1.0 Vp-p (75Ω load)
2.9mm~10mm / F1.2
Aspherical Lens
DC24V & AC110V
160 Watts (DC24V)
37 lbs
30.1875” (H) x 21.875” (W) x 3.375” (D)
C A M E R A L C D
