2007 Service Handbook
“WHAT IT MEANS TO RIDE WRIGHT”

Table of Contents
Forms 1
Warranty Claim Form 2
Warranty Period Chart 3
Pre-Delivery Mower Service 4
Parts Order Issues (PFD) 6
Service Bulletins 7
Bulletin # 54 – Hydro Hose Application Chart 8
Bulletin # 55 – Removing Hydro Cooler 10
Bulletin # 56 – Adding Muffler Heat Shield 16
Bulletin # 57 – Flat Rate Guide 21
Bulletin # 58 – Re-routing Z Hydraulic Hose 24
Bulletin # 59 – Mower Deck Lift upgrade 27
Bulletin # 60 – Front Caster Part Number Information 28
Bulletin # 61 – Cutting Deck Baffle System 29
Bulletin # 62 – Deck Height Cog and Latch Kit 30
Bulletin # 63 – 0069 pulley 31
Service and Repair 33
Neutral Adjust RTN 34
Tracking Adjustments Z 35
Checking and Adjusting Deck Alignment and Pitch 36
Deck Alignment and Pitch Z 37
Deck Alignment and Pitch Sentar 38
Deck Alignment and Pitch WSES, WSR 39
Deck Height Adjustments WSS 40
Deck Height Adjustments WS, WV 42
Deck Height Adjustments Velke Gear/Belt Drive 43
Cutting Deck Baffle System 44
Cutting Deck Baffle System w/o Pre-Punched Holes 45
Electrical Troubleshooting 46
Clutch Installation 47
Clutch Evaluation 48
Clutch Troubleshooting 49
Spring compression tool 50
Hydro Pump 51
Hydro Pump Troubleshooting 52
Deck Lift Improvement Kit 53

2007 Service Handbook
Forms
1

Instructions
Model Number: ______________
Serial Number: ______________
Hour Meter Reading:___________
Copies to: White - Wright Mfg. Inc. zYellow - Distributor zPink - Dealer zGold - Owner
\\Server01\company\Marketing\Pagemaker\Product Specific Documents\Stander\Stander Warranty.p65; revised 6/19/01
Warranty
Request
Customer / Owner Information Dealer Information
Dealer's Name:________________________________
Address: _________________________________
City/State/Zip: _________________________________
Contact Name:_________________________________
Phone: ( ) ________________________________
Fax: ( ) ________________________________
Email: ______________________________________
Distributor Name:_______________________________
Owner's Name: _________________________________
Company (if appl.):________________________________
Address: ___________________________________
City/State/Zip: ___________________________________
Contact Name: ___________________________________
Phone: ( ) _________________________________
Fax: ( ) _________________________________
Email: ________________________________________
Owner signature Date Dealer signature Date
This is a: (check one)
Repair part warranty request
Whole goods warranty request
1. Verify that the part is covered by the warranty and that it is a valid claim. (See the
original warranty statement and WMI Warranty Policy and Procedures.)
2. Verify that the mower is registered. Contact your Wright Distributor if you have
questions regarding a mower registration. Only registered mowers are eligible for
warranty.
3. Completely fill out this form, including Owner and Dealer signatures.
Note: Claims are not valid without signatures, model and serial numbers.
4. Give gold copy of this form to customer; dealer keeps pink copy.
5. Submit the remaining copies of this claim to your distributor within 30 days of the
repair.
6. Please contact your distributor if you have any questions regarding this claim.
CLAIM #
What part failed or caused the failure:
PartNumber:____________________Description:___________________________________________________
Describethe failure and correctionperformed:______________________________________________________
_________________________________________________________________________________________________________________________
_________________________________________________________________________________________________________________________
_______________________________________________________________________________________________________
/ /
/ /
$
hrs.
$
$
$
/ /
#
LABORREQUESTED $________________________ X__________ ._________ =$_____________________
LABOR RATE HOURS TENTHS LABORREQUESTED
PARTS USED FOR REPAIR
QTY PARTNUMBER DESCRIPTION
Date Sold:________________________
Date Brought in for Repair:____________
Date of Repair:_____________________
Shaded Area for WMI Only
Date Request Received
Date Request Processed
Registered Labor Rate
Labor Hours Approved
Labor Credit Approved
Parts Credit Approved
Total Credit Approved
Date Credited Distributor
WMICredit Memo Number
2

Warranty Period Changes
4/01/05 Retail
sale and later
3/17/03 Retail
sale and later
3/01/02 Retail
sale and later All previous
General 2 year P&L 1P&L +1 Part 2 year P&L 2 year P&L
Clutch 2 year P&L 1P&L +1 Part 1P&L +1 Part 1P&L +1 Part
Spindle 2 year P&L 1P&L + 2 Part 1P&L +1 Part 1P&L +1 Part
Pump 2 year P&L 2 year P&L 2 year P&L 2 year P&L
Wheel Motor 2 year P&L 2 year P&L 2 P&L +2 Part 2 P&L +2 Part
Deck 2 year P&L 1P&L +2 Part LL - 2 yr P&L LL - 2 yr P&L
Engine Deck 2 year P&L 1P&L +2 Part LL - 2 yr P&L LL - 2 yr P&L
Frame 2 year P&L 1P&L +2 Part LL - 2 yr P&L LL - 2 yr P&L
Upright 2 year P&L 1P&L +2 Part LL - 2 yr P&L LL - 2 yr P&L
Hydraulic Hose 2 year P&L Excluded Excluded Excluded
Battery 90 day 90 day 90 day 90 day
Belt 90 day Excluded Excluded Excluded
* Applicable warranty based solely on original retail purchase of mower
* Refer to applicable warranty document for clarification and exclusions
* Warranty not transferable
* Cracked weldments must be pre-approved
LL = Limited Lifetime
P&L = Parts and Labor
3

PRE-DELIVERY SERVICE OF MOWER BY DEALER
The Wright Mower is shipped completely assembled and has been adjusted and tested at the factory.
However, due to the jostling of the shipping process and the delivery time lapse, the following items
need to be repeated again before starting the mower. After you have uncrated the mower, follow these
procedures in the order indicated:
xRemove spark plug wire from spark plug(s).
xInspect the mower for any damage, unusual conditions or missing parts.
xInspect the mower for all of its decals, especially the warning decals. There should be one blade
warning decal on each side of the deck, the “shield missing” decal under the blade belt cover, and
the dash decal.
x Check to ensure belt guard is in place before operation.
xCheck (and fill if necessary) engine oil level according to the engine manufacturer’s recommendation.
xCheck (and fill if necessary) hydraulic fluid level. Use fully SYNTHETIC oil: Mobil-1 15W-50.
xCheck tire pressures. Adjust to recommended pressure. It should be even on both sides but the
recommended pressures are generally different for the front and rear tires.
xRemove the blade belt cover and check (adjust if necessary) all belt tensions according to
specifications in Owners Manual. DO NOT OVERTIGHTEN.
xRotate the blade pulleys slightly to see if they all turn together. (Note: Clutch Brake will create some
resistance.)
xLubricate all appropriate moving parts
xReinstall the blade belt cover.
xRemove battery (if electric start version) from machine and fully charge (if necessary) in an open,
well-ventilated area according to the recommendations of the battery charger manual. The battery
is 12 volts. After fully charged, install on mower and attach battery cables, positive first (from
starter motor) and negative last (from ground).
xFill fuel tank with regular unleaded gasoline. Open fuel valve located between fuel tank and engine.
xDO NOT START THE ENGINE AT THIS TIME. FOLLOW THE NEXT PROCEDURE BEFORE
STARTING. The hydraulic system MUST be checked for proper operation before allowing wheels
to operate on the ground.
xSet the rear of the machine on jack stands or blocks to raise rear wheels off the ground two or three
inches and check to be sure that the mower will not fall off the supports you devise. The stand(s)
must be able to secure the mower from rolling off or away during the next procedures. Check
under the mower deck for any debris or unusual conditions.
xWith hand controls and speed control in the neutral position, apply the parking brake.
xOpen the manual bypass valve on top of each pump a half-of-a-turn counterclockwise.
xReattach spark plug wires to spark plugs.
xBefore starting the engine, be ready to stop it if the wheels begin to turn with the brake on. (If this
happens, check that the manual bypass valve on top of each motor are open at least a half-of-a-
turn counterclockwise.)
xStart the engine according to the engine manufacturer’s recommendation. Let the engine run at low
RPM for several minutes to get the hydraulic fluid circulating through the pumps, etc. Release the
parking brake. Now gradually close the manual bypass valve on top of each pump one at a time,
and see if the wheels start to move. If the wheels move when the hand controls are in neutral
position, adjust the neutral adjustment allen screw located on each pump until they stop (use the
neutral adjust knob for older mowers). The manual bypass valve on top of each pump should now
be firmly closed. Now try moving the hand control levers, one at a time, to make the wheels move
in forward and backward rotation. Check to see if the wheels move forward and backward
according to position of the levers. If not, service the hand control system. If the wheels stop when
the hand controls are in the neutral position the parking brake should now be applied. Now check
4

if the parking brake locking system (if applicable) prevents the unit from being driven while
engaged. If not, service the parking brake locking system.
xBefore testing the blade clutch/brake operation, make sure the area is clear and there is nothing
vulnerable to possible thrown objects from under the mower. No one should be near the mower
deck or in its line of discharge at this or at any time. The discharge chute deflector should be in
the down position. Move the engine throttle control to its highest RPM speed setting.
xTurn on the blade clutch switch. Run blades for a minute or so. Try engaging and disengaging the
blades a few times about 10 seconds apart. If the blades do not start and stop in a few seconds
each time, service the blade brake system. With the blades on, now try disengaging the OPC
switch to test the Operator Presence Control switch (OPC). The engine should die and the blades
should stop in several seconds. If not, service the OPC system. Try this a couple of times.
xDisengage the blades, shut off the engine and remove the mower from the stand(s).
xDrive the mower around on a level parking lot. It is recommended that the slower setting of the Speed
Adjustment be used. (See further in this manual for information on Speed Adjustment.) Check that
the mower drives in a straight line when both hand controls are at the full speed position. If not,
see further in this manual for information on tracking adjustment.
xAs you drive the mower, listen for any unusual noises and test for irregular operation and adjust or
service as necessary. Next, go over the safety information and operating procedures in this
manual with the customer. Instruct the customer in proper operation and observe the customer
during their initial operation on a level parking lot. Make sure the customer is familiar and
comfortable with the basic operation and use of the mower.
xDealer: Register the mower online. If unable to use the online registration process then follow
the instructions on the Product Registration Form and have the customer fill out his part of
the form. After the Product Registration Form is filled out and signed by the customer and
a representative from your dealership, please mail or fax it immediately (within 30 days
from date of retail purchase) to your Wright Commercial Products Distributor according to
the directions on the Form. Then give the customer his copy of the registration form and
then keep your copy and mail the remaining copies of the form to your Wright
Manufacturing Products Distributor. The limited warranty is not valid unless the mower is
registered and all of the above steps are taken. Remember, the purchaser is both your and
our customer and his satisfaction is very important. Thank you for supporting our
products.
xThe mower is now ready for delivery to your customer.
5

PFD
 Some parts have been revised but still are using same part #.
¾WS Upright Frame – Two styles, same part # 93420038
¾52” Sentar Deck – Need serial # + photo
¾61” Sentar 1 & 2 – Need serial #
¾WS Cockpit/tractor frame – Need serial #
6

2007 Service Handbook
Service Bulletins
7

Hydro Hose Application Chart
INFORMATION ONLY
Subject: The following page is a chart to be used as a
resource for determining the proper high pressure
hydraulic hose and part number for the various
possible current applications
Units
Affected: ALL current
Situation: None – information only
The Fix: None – information only
Claim
Procedure: None – information only
Bulletin # 054
2 Pages
February 9, 2006
8

High Pressure Hose Application Chart
Hydro hose
part #
Hose
cut-
length
Sentar1-S/Npriort
o
19729
Sentar2-S/N19729
andhigher
Sentar 3-S/N26980
andhigher
SentarS
port
LargeStander -48,52,61
SmallSt
ander-36,42
StanderRH
WSSS
tander32,36,42 -
S/N26288andhigher
VelkeMowerQuad
Lever
VelkeMowerP
istolGrip
Hoops
Crimp Fitting
Pump
Crimp Fitting
M otor C omme nts
Obsolete ĺPump With Hoops Use 33410062 / With-Out Hoops Use 3341006333410004 ĺ
33410005 ĺ 33410010 ĺ 33410011 ĺ 33410015 ĺ 33410031 ĺ 33410032 ĺ 33410012 27" Xw
90 FF Straight JIC FF Nipple Incl.
33410014 28-1/4" Xw/o
Straight FF Long 90 JIC 35410041 Fitting Incl
33410037 48" XX Straight FF Short 90 JIC Right Side 33410038 43" XX Straight FF Short 90 JIC Left Side 33410050 20" XX Short 90 FF Straight JIC 28215 & Up 33410051 21" XX
Short 90 FF Straight JIC
FF Nipple/ JIC 90
Incl -Velke Mower
=S/N pre 28215
33410052 21" XStraight FF Short 90 JIC 35410041 Fitting Incl 33410057 34" XStraight FF Long 90 JIC All 33410061 21" XStraight FF 45 JIC All 33410062 23" Xw
90 FF Straight JIC FF Nipple/ JIC 90 Incl
33410063 23" Xw/o
Straight FF Short 90 JIC 35410041 Fitting Incl
33410064 27" Xw
90 FF Straight JIC FF Nipple/ JIC 90 Incl
33410065 27" Xw/o
Straight FF Short 90 JIC 35410041 Fitting Incl
33410066 32" Xw
90 FF Straight JIC FF Nipple Incl.
33410067 32" Xw/o
Straight FF Long 90 JIC 35410041 Fitting Incl
Obsolete ĺ Obsolete ĺ
Pump With Hoops Use 33410051 / With-Out Hoops Use 33410052
Pump With Hoops Use 33410051 / With-Out Hoops Use 33410052
Obsolete ĺ
Pump With Hoops Use 33410066 / With-Out Hoops Use 33410067
FF = Flat-Face fitting w/ o-ring
Obsolete ĺ Obsolete ĺPump With Hoops Use 33410062 / With-Out Hoops Use 33410063 Obsolete ĺPump With Hoops Use 33410064 / With-Out Hoops Use 33410065 Obsolete ĺPump With Hoops Use 33410066 / With-Out Hoops Use 33410067
Pump With Hoops Use 33410066 / With-Out Hoops Use 33410067
9

Bulletin # 055
6 Pages
May 10, 2006
REMOVING HYDRAULIC OIL COOLER ON
SPORT and RH MOWERS
*** PRODUCT RECALL ***
Subject: Removal of hydraulic oil coolers on all Sport and RH mowers
Units
Affected: All Sport and RH mowers with a serial number from 24188
through 30058 that have the hydraulic oil cooler. Mowers
beyond this serial number range have been produced to
updated standards according to new design.
Situation: It has been determined that the hydraulic oil cooler for these
mowers is unnecessary for the hydraulic system and that it
should be removed. All mower registrations must be completed
and entered into the Wright online registration system and
communicated to Wright Manufacturing within 20 days of
receipt of this letter. Failure to do this exposes the Dealer to
the liability of consequential damages should a problem
develop with the mower related to the items in this bulletin.
This product recall requires that all affected mowers have
the hydraulic oil cooler removed as quickly as possible
and no later than 40 days from the date of this bulletin. In
cases where the mower has been retailed, the Dealer
should make very effort to accommodate those mowers
into their schedule at the earliest possible date.
We will be contacting all currently registered mower
owners to inform them of the need for this service but
request that each Distributor/Dealer contact their
customers as well. Additionally, we may not have
registration for all retailed mowers which makes it
impossible for us to contact the consumer. In the event
that engine damage occurs due to the consumer not
having knowledge of this recall due to non-registration, the
10

Bulletin # 055
6 Pages
May 10, 2006
liability for consequential damage will be on the selling
Dealer.
This work is to be done in conjunction with Bulletin #056
The Fix: Using the attached instructions:
1) Remove the hydraulic oil cooler from all affected mowers
2) ONLY IF MOWER RETAILED - Remove the engine shroud
and clean the engine cooling area and fins with compressed
air
For units that have been retailed, contact the end-user to have
these services performed. Units that have been retailed but
not registered must be registered immediately.
*** All affected mowers need to have this update performed.
No affected mower should be retailed without this service being
performed
*** The engine manufacturer recommends cleaning the
dust, dirt and debris from cylinder and cylinder head
cooling fins every 100 hours or more often under dusty
conditions. Grass clogged cylinder heads and cooling fins
can contribute to engine overheating and we strongly
recommend this service item be done frequently. Please
take this opportunity to perform this necessary
maintenance service. The plastic engine shroud must be
removed to perform this service.
Claim
Procedure: 0.6 hour of labor allowed. An additional 0.4 is allowed for
cleaning the engine cooling fins if the unit has been retailed.
Complete the attached “Quick-Claim-Form” and submit within
15 days of the date of repair. Work must be performed at the
same time as Bulletin #056 and should be claimed on the same
claim form.
11

Bulletin # 055
6 Pages
May 10, 2006
B
Hydraulic Oil Cooler Removal and Engine cooling area
cleaning Instructions
Sentar Sport and Rapid Height (RH) Stander mowers only
1. Remove cooler cover by removing truss-head screw (Fig 1, A).
2. Remove truss-head screws attaching front (Fig. 2, A) cooler bracket to engine guard
and 2 nuts attaching rear bracket to engine guard. (Fig. 2, B)
3. Lift cooler from engine, reinstall and tighten acorn nuts
4. Loosen hose clamp (Fig.2, hose 1)
5. Remove knee pad.
CAUTION: There are several cut wire ties behind knee pad that can cut you.
Fi
g
. 1
Fi
g
. 2
A
A
B
1
2
12

Bulletin # 055
6 Pages
May 10, 2006
NOTE: The two photos below (Fig’s 3 & 4) are using the numbers 1 & 2 to indicate
which hose from Fig 3 will correspond with the hose from Fig 4.
6. Cut wire ties holding feed and return line together (see arrow in Fig 4)
7. Crimp hose at hydro tank return (Fig 4 hose 1)
NOTE: Crimping tool would be ideal, if you do not have, use care not to crush
hose.
8. Hose 2 needs to be cut from the return line tee. Use care not to cut yourself and
not to damage the tee.
NOTE: Oil may spill
9. Remove line 1 from cooler (Fig.3) and cut 5” from
end NOTE: Some oil may spill
10. Connect hose to return line tee (Fig 5 hose 1)
11. Check fluid level and fill as needed. Fig 5
12. Check for leaks and re-install knee pad.
13. FOR RETAILED MOWERS ONLY:
Remove engine shroud/fan housing and
thoroughly remove all grass and debris from
engine and fan using compressed air. This
bulletin provides an additional 0.4 hours of labor
for this step to be performed on retailed mowers.
* This is an engine manufacturer recommended service and should be
done regularly according to the engine manufacturer recommendations
1
2
2
Feed
Return
1
Fig 3 Fig 4
Return
Feed
1
13

Bulletin # 055
6 Pages
May 10, 2006
Below is a copy of the letter being sent to each currently registered owner of the
affected mowers. Keep in mind the registration information we have may not be
accurate or current so do not assume this letter will make it to the registered
owner – please also contact them yourself.
___________________________________________________________________________________
PRODUCT RECALL
Models affected within a limited serial number range:
• Sentar Sport
• Stander RH
May 15, 2006
We are pleased you have chosen to own a Wright product and trust your experience has been pleasant
thus far. Wright Commercial Products is committed to continuous improvement. Consistent with that
commitment, we are recalling specific mowers for the following repairs:
• The hydraulic oil cooler located on the top of the engine is unnecessary and should be removed.
The engine cooling fins will be cleaned out at the time of this service.
oMowers with a serial number from 24188 through 30058 and a model number beginning
with either WSES or WSR
• A newly designed muffler heat shield needs to be installed
oMowers with a serial number from 24188 through 33155 and a model number beginning
with either WSES or WSR
Choosing to not have this product recall work performed on your mower within the prescribed
time frame could eventually result in severe overheating damage to your engine and will VOID
THE WARRANTY on your engine making any repairs to or replacement of the engine your
responsibility.
The product recall work must be performed at your local Authorized Wright Dealer and there will be no
charge to you for these services. Please schedule to have this work performed as quickly as possible
and within no more than 20 days from receipt of this letter. If needed, you can find the Dealer of your
choice at www.wrightmfg.com and choose the Dealer locator option.
As always, we’re committed to making your experience with Wright products as productive and
pleasant as possible.
The Wright Commercial Products Team
14

Bulletin # 055
6 Pages
May 10, 2006
Wright Warranty Quick-Claim-Form - Bulletins 055 and 056 only
1 mower per form
Dealer Name: _______________________________ Dealer Location/City: ___________________
Distributor: _____________________________ Date of repair: ___________________________
Mower Serial Number: _______________
Registered: ƑYes ƑNo (if not then attach registration if retailed)
Mower Model: ƑWSES36 ƑWSES48 ƑWSES52 ƑWSR36 ƑWSR48 ƑWSR52
Engine Serial Number (Full): ______________________ (Claim will be rejected without this information)
Choose only 1 of the 4 scenarios below that most accurately represents the
situation with this mower
ƑScenario #1
* Mower not retailed – needs heat shield only
Time allowed for this scenario: .6 hours - Serial range is 24188 - 33155
ƑScenario #2
* Mower retailed – needs heat shield and engine cooling fins cleaned
Time allowed for this scenario: 1.0 hours - Serial range is 24188 - 33155
ƑScenario #3
* Mower not retailed – needs hydraulic oil cooler removed and heat shield
Time allowed for this scenario: 1.2 hours - Serial range is 24188 - 30058
ƑScenario #4
* Mower retailed – needs hydraulic oil cooler removed, engine cooling fins cleaned and heat shield
Time allowed for this scenario: 1.6 hours - Serial range is 24188 - 30058
FOR ALL SCENARIOS – if applicable
Condition of Engine Cooling Fins (if applicable):
ƑNo notable grass/debris collection ƑMostly clean ƑMostly clogged ƑVery Badly Clogged
_______________________________________________________________________________
Make additional copies if needed. Fax or Mail completed forms to your Distributor
15

Bulletin # 056
5 Pages
May 10, 2006
ADDING MUFFLER HEAT SHIELD ON SPORT &
RH MOWERS
*** PRODUCT RECALL ***
Subject: Adding the muffler heat shield on all Sport and RH mowers
NEW PART # 91410026 – includes heat shield and gaskets
Units
Affected: All Sport and RH mowers with a serial number from 24188
through 33155. You may find that some of the serial numbers
in this range have had the update performed prior to your
receiving the mower.
Situation: It has been determined that a muffler heat shield needs to be
added to the affected mowers listed above. This is an
important recall. All mower registrations must be completed
and entered into the Wright online registration system and
communicated to Wright Manufacturing within 20 days of
receipt of this letter. Failure to do this exposes the Dealer to
the liability of consequential damages should a problem
develop with the mower related to the items in this bulletin.
This product recall requires that all affected mowers have
the muffler heat shield installed as quickly as possible, and
no later than 40 days from the date of this bulletin. In
cases where the mower has been retailed, the Dealer
should make very effort to accommodate those mowers
into their schedule at the earliest possible date.
We will be contacting all currently registered mower
owners to inform them of the need for this service but
request that each Distributor/Dealer contact their
customers as well. Additionally, we may not have
registration for all retailed mowers which makes it
impossible for us to contact the consumer. In the event
that engine damage occurs due to the consumer not
16
