Carbon Monoxide Alarm (Type B)
User Manual
Model: XC01/XC05P/XC01P-R
(EN/DE/FR/NL)
Parellaan 2H, 2132 WS Hoofddorp, the Netherlands
Phone Number:+31(0)85-0043.903 F.1.05.XC0501

Contents
English 01-27
Deutsch 28-56
Français 57-85
Nederlands 86-118

Thisusermanualcontainsimportantinformationregardingtheinstallationandoperationofyourcarbonmonoxidealarm.
Pleasetakeafewminutestothoroughlyreadthismanualwhichshouldbesavedforfuturereference.Ifyouareinstallingthe
carbonmonoxidealarmforusebyothers,youmustleavethismanual—oracopyofit—withtheenduser.
English
Thisdeviceisabattery-poweredstandaloneCO(carbonmonoxide)alarmwithanadvancedelectrochemicalsensorfor
domesticuse.Pleasenotethatthisdevicedoesnotdetectsmoke,heat,flamesoranyhazardousgasotherthancarbon
monoxideeventhoughcarbonmonoxidecanbegeneratedbyfire.Forthisreasonyoumustinstallsmokealarmstoprovide
earlywarningoffireandtoprotectyouandyourfamilyfromfireanditsrelatedhazards.
WARNING
• THE INSTALLATION OF THE APPARATUS SHOULD NOT BE USED AS A SUBSTITUTE FOR PROPER INSTALLATION, USE AND
MAINTENANCE OF FUEL-BURNING APPLIANCES INCLUDING APPROPRIATE VENTILATION AND EXHAUST SYSTEMS.
• THIS APPARATUS IS TO BE INSTALLED BY A COMPETENT PERSON.
• IT IS NOT TESTED FOR USE IN A CARAVAN ORBOAT.
01
Introduction

1 ×COAlarm 2 ×Screws
2 ×AnchorPlugs 1×UserManual
Peak Concentration
Indication
Test/Silence Button
Battery Status
CO Concentration
TheTest/Silencebuttonisusedtotesttheunit'selectronicsandtosilencetheunitduringanalarm.Whentestingthealarm
weekly,pressand holdthetestbuttonandyouwillhearashortbeep,indicatingthatthealarmhasenteredthetestmode.
XC01/XC05P:Youshouldfirstwakeupyouralarmbypressingthetestbutton;oncethealarmhaswokenup,theLCD
display will activate, then press the test button again until you heara short beep,indicating that the alarm hasenteredthe
testmode.Pleaserefertothe“Alarm Testing” sectionforfurtherinformation.Thealarmgoesbacktothestandbymodeafter
testing.Tosavepower,the alarm isdesignedtoautomatically turnofftheLCD displayifthere hasbeen nooperation for 5
minutes.
XC01P-R: Short pressthetest button andyou will hearashort beep, indicating thatthe alarm hasentered thetest mode.
NOTE: Afteratesthasbegun,thealarm willsound andtheLEDindicatorwillflash red. Thisdoesnotindicatethat COis
present.Ifyoupressthetestbuttonduringanalarmstate,theunitwillenterthesilencemode.
CO Alarm Levels
ThiscarbonmonoxidealarmisprogrammedtosoundanalarmatthefollowingCOconcentrationswithinthetimeperiods
listed:
02 03
Package Contents
Product Features

30ppmover120minutes,
50ppm for 60–90minutes,
100ppm for 10–40 minutes,
and 300 ppm for 0–3 minutes.
WhenCOisdetectedandthealarmsounds,theCOconcentrationwillbedisplayedontheLCDandabluebacklightwillbelit.
TheLEDindicatorwillflashredandthealarmwillissue4shortbeeps,repeatingthecycleevery6seconds.
CO Concentration and Symptoms
The table below shows the effects of different levels of CO poisoning on the body:
WARNING
THIS DEVICE IS DESIGNED TO PROTECT INDIVIDUALS FROM ACUTE EFFECTS OF CARBON MONOXIDE EXPOSURE. IT MAY
NOT FULLY SAFEGUARD INDIVIDUALS WITH SPECIFIC MEDICAL CONDITIONS. IF IN DOUBT, CONSULT A MEDICAL
PRACTITIONER.
Low-Battery Warning
Ifthebatteryvoltageislow,theunitwillchirp once andtheLED indicatorwillflashyellowevery60secondstoindicatethe
needfor battery replacement.
Ifyoupressthetestbuttonwhenthereisalowbattery,thelow batterysignalwilltemporarilyceasefor10hours;ifyoupress
thetestbuttonagain,theunitwillenter thetestmodeandthenthestandby mode.
End-of-Life Indication and Hush Control
100
Slight headache, nausea,fatigue(flu-likesymptoms).
Oncethemaximumlifetime(10years)isreached,thealarmwilldeliver3beepsandtheLEDindicatorwillflashyellow3times
200
Dizziness andheadachewithin 2–3hours. every 60 seconds. This end-of-life signal can be temporarily silenced for 22 hours by pressing the test button.
400
800
Nausea, frontal headache, drowsiness,confusion andrapid heartrate.
Riskto life afterover3hoursofexposure.
Severe headaches, convulsions, vital organ failures. Death possible within 2–3 hours.
Theend-of-lifesilencefeaturecanonlybeusedforatotalof30days.After30days,theend-of-lifesignalcannotbesilenced.
Duringthisend-of-lifehushperiod,youralarmcontinuesmonitoringCOandprovidesprotectionasusual.
Tohelpidentifythedatetoreplacethealarm,writedownthedateoffirstoperationonthededicatedlabelonthesideofthe
alarm.
04 05
Parts perMillion(PPM) Effects onAdults

06
07
Ideally,acarbonmonoxidealarmshouldbeinstalledineveryroomcontainingafuel-burningappliance,andoneinevery
bedroom.
However,ifthenumberofcarbonmonoxidealarms availableislimited,thefollowingguidelinesshouldbeconsideredwhen
choosing the bestplaces toinstall analarm(s):
• Ifthereisanapplianceinabedroom,aCOmonitorshouldbeinstalled.
• Installanalarminroomscontainingafluelessoropen-fluedappliance.
• Installan alarmwhereresidentsspend mostoftheirtime.
• Inastudioapartment,aCOalarmshouldbeplacedasfarawayfromthecookingappliancesaspossible,butclosetowhere
the personsleeps.
• Ifthe applianceisplacedinaroom notnormallyused (suchasa boilerroom),the COalarm should beplacedjustoutside of
thisroom so thatthe alarm canbeheardmoreeasily.
1. Installing a CO alarm in a room with a fuel-burning appliance (see Figure 1):
• Ifitismountedonawall,itshouldbeinstalledataheightgreaterthantheheightofanydoororwindow,butshouldstill
beat least 150 mm (5.9inches)below the ceiling.
• TheCOalarmshouldhaveahorizontaldistancebetween1m(3.3feet)and3m(10feet)fromanypotentialCOsource.
• Ifthereisapartitionintheroom,theCOalarmshouldbeinstalledonthesamesideofthepartitionasthepotentialCOsource.
300 mm (11.8 in) CO ALARM
150 mm (5.9 in)
DEAD AIR SPACE
DON’T INSTALL HERE
Figure 1: Installation in a room with a fuel-burning appliance
Where to Install
1–3 m
(3.3–10 ft)

08
09
2. Installing the CO alarm in a bedroom or room without a fuel-burning appliance (see Figure 2):
• MounttheCO alarmrelativelyclosetothebreathingzoneoftheoccupant.
• InstallthealarmsuchthattheLEDindicatorisviewablewhentheoccupantisnearthealarm.
NOTE: Due tothe product’s unique design and unfixed installation, itisnotrecommended toinstalliton a ceiling, asit is
prone to fallingoff andcausinginjuries topeople.
Figure 2: Installation in a bedroom or room without a fuel-burning appliance (installed at head level)
Important Note
Improperlocationcanaffectthesensitiveelectroniccomponentsinthisalarm.Toavoidcausingdamagetotheunit,toprovide
optimumperformanceandtopreventunnecessarynuisancealarms,donotlocateCOalarmsinthefollowingareas:
1. Ingaragesor in anyextremelydusty,dirty orgreasyareas.
2. Wherethereisthepossibilityofsmokeorfumesundernormaloperatingcircumstances.
3. Inpoorlyventilatedkitchens,garagesandfurnacerooms.KeeptheCOalarmsatleast1.5m(5feet)frompotentialsmokeor
fumesources(e.g.stoves,furnaces,waterheaters,spaceheaters)ifpossible.
4. Inareaswherea1.5m(5-foot)distancefromapotentialsmokeorfumesourceisnotpossible.Inmodular,mobileorsmaller
houses,itisrecommendedtheCOalarmbeplacedasfarfromanypotentialsmokeorfumesources.
5. Within1.5 m(5 feet)ofanycooking appliance.
Locations to Avoid
CO ALARM
HEADLEVEL

10
11
6. Inextremelyhumidareas.Thisalarmshouldbeatleast3m(10feet)fromabathorshower,sauna,humidifier,vaporizer,
dishwasher,laundryroom,utilityroomorothersourcesofhighhumidity.
7. Inareas where the temperatureis colder than 4°C (40°F) or hotter than38°C (100°F). For example, non-air-conditioned crawl
spaces,unfinishedattics,uninsulatedorpoorlyinsulatedceilings,porchesandgarages.
8. Wheretheairisturbulent,suchasnearceilingfans,heatvents,airconditionervents,freshairreturnvents,oropenwindows.
ExcessiveairflowmaypreventanyCOfromreachingthesensors.
9. In directsunlight.
To Activate the Device
Thisdeviceis equipped withabattery insulatingfilmtoensure itwillnotbepowered onduringtransportation beforeit has
XC01/XC05P
Insulating Film
XC01P-R
Insulating Film
been shipped from the factory. When installing this product, you will needtopulloutthefilm before powering onand
activating thedevice.
Beforeuse,pulloutthebattery insulatingfilmfromthebatterycompartmenttopoweronthe device.Afterthedeviceisturned
on, the buzzer will beep once, the LCD backlight will light up, and the LED indicator will flash through 8 cycles
(yellow/green/red).The device willthen enterstandby mode.
Installation Method

12
13
2.9 in/74 mm
Follow the process below to open the battery compartment cover:
Holdthealarm withboth handsandputyourthumbs onboth ends of the batterycompartmentcover. Then, pushthe cover
upwards with someforce toremove it.
WARNING
CONSTANT EXPOSURE TO HIGH OR LOW TEMPERATURES AND HIGH HUMIDITY MAY REDUCE BATTERY LIFE.
Wall Mounting
1. Chooseasuitableinstallationlocation byreferringto the“Where toInstall” section.
2. Removetheindicationstickerfromthepackagingandrefertotheholelocationsonthesticker.Drawtwoscrewholes
accordingtothesizeandlayout of themounting holesonthebackoftheproduct.Drillthescrewholes 30mm(1.18inches)
deepusingaØ6.0 mm(1/4-inch) drillbit.Notethatthedistancebetweenthecenterofthetwoholesis74mm(2.9inches).
Mounting Slots

14
15
3. Inserttheanchorplugintothescrewholeandhammeritinuntiltheheadoftheanchorplugisflushwiththewall.
4. Usethetwoprovided screws or3.5×25mmcountersunkscrewstoscrewintothetwoanchorplugs.Besuretoleavea5
mm(1/5-inch)gapbetweentheheadoftheanchorplugsandthescrews,whichwillallowforeasydevicemounting.
5. Mountandlockthedeviceontothewallbyaligningthetwomountingslotsonthebackofthedevicewiththescrewson
thewall.
6. Testthedeviceby pushingthetestbuttonto makesurethatthedeviceisfunctioningproperly.
Installation on a Table
The base of the detector has two feet built into the design that allow it to stand freely on a flat surface.
NOTE: When placing on a shelf, please adhere to the recommended placement as described in “Where to Install.”

16
17
Peak CO Concentration Memory and Reset
Besuretotest your COalarms whenyouturnthem onforthefirsttime.Inaddition tothe weeklytest youshould perform,itis
alsorecommendedtotestthealarmafterreturningfromalongtriporvacation.
Type XC01/XC05P XC01P-R
Action
Pushthetestbuttononcetowakeupthealarm,
andpressthetestbutton againwhentheLCDison.
Push the test button.
Device
Response
The device beeps 4 times twice, and theLED will flash red. The LCD will display “---,” “PAS,” the peak
COconcentrationrecordedsincethepreviousreset,andfinally“0.” Thisindicatesthatthedeviceis
functioning properly.
NOTE: The test function accurately tests the alarm’s CO sensing circuit without the need of testing CO.
ThepeakCOconcentrationfeatureishelpfulinidentifyingiftherehavebeenanydangerousCOreadingssinceapeakCO
concentration reset.
Eachtimeyoupushthetestbutton,theLCDdisplaysthepeakCOconcentrationrecordedsincethepreviousreset.Thepeak
COconcentrationwillbedisplayedfor5seconds,andthenthedevicewillenterstandbymode.Intheexample,300ppmwas
themaximumCOconcentrationrecorded sincetheunitwaslastreset.
PeakCOConcentrationReset: Duringthe5secondswhentheLCDdisplaysthepeakCOconcentration,pressandhold
thetestbuttonfor3seconds,thedevicewillbeep,theLED willflashgreen,andthepeakCOconcentrationwillberesetwith
LCD displaying“0.”
NOTE:Ifthecarbonmonoxideconcentrationislowerthan30ppm,itwillnotberecordedinthepeakCOconcentration.
Pressthetestbuttonduringanalarmtohavetheunitentersilencemode.IftheCOdensitystillexceedsthealarmthreshold
after6minutes,theunitwillenter anotheralarmstate. Otherwise,theunitwillexitthe silencemodeafter9minutes and
resumenormaloperation.IftheCOconcentrationisabove300ppm,thesilencefunctioncannotbeenabled.
LCD Display
Silence Mode
Alarm Testing

18
19
Mode
LCD Display
LED Indicator
Audible Alarm
Remarks
Powering On
Runs through 8 cycles
(yellow/green/red) in sequence.
1 quick beep.
Make sure battery insulating
film is removed and the
device is turned on.
Standby Mode
(XC01/XC05P)
None.
Flashes green once every
60 seconds.
None.
None.
Standby Mode
(XC01P-R)
Flashes green once every
60 seconds.
None.
None.
Alarm Mode
ACOconcentrationranging
from30to999ppmhasbeen
present for a certain time
period.Thebluebacklightislit,
andtheLEDindicatorflashes
red4timesevery6seconds.
4 beeps repeating
every 6 seconds.
Dangerous COconcentration
isdetected,andhasreached
thealarmstatus.Pleaserefer
to "What to Do When the
AlarmSounds".
While detecting CO, the LCD will display different indicators to inform you of the alarm status, as shown below:
A CO concentration level
ranging from 30 to 999 ppm
has been detected, but for
less than the allotted
detection period. The LED
indicator flashes green once
every 60 seconds.
None.
Dangerous CO concentration is
detected, but has not reached
the alarm status. Potential
dangerous CO conditions exist.
Pleasesearchfor theCOsource
first.Opennearbywindowsand
doors, and immediately move
to freshair.
Flashes green once every
second for 5 seconds.
None.
Alarm cancellation: when the
CO concentration level drops
below the alarm threshold,
the alarm signal will stop.
Test Mode
2 sets of 4 red flashes.
2setsof4quick
beeps.
Peak CO level recorded since
the previous reset.

20
21
Technical Specifications
Silence Mode
Flashes red 4 times
every 6 seconds.
None.
CO silence mode: After 9
minutes, the unit will exit
silence mode.
Flashes yellow once
None.
Silence mode during low
every 60 seconds.
battery:after10hours,theunit
will exit silence mode.
Flashes yellow 3 times
None.
Silencemodeduringtheendof
every 60 seconds.
cycle: after 22 hours, the unit
will exit silence mode.
Flashes green 3 times.
None.
Exiting silence mode.
Low Battery
Display alternates between
"Lb" and current CO level.
The LED indicator flashes
yellow once every 60
seconds.
1 quick beep
every 60
seconds.
XC01/XC05P:Theunitmustbe
replacedimmediately.
XC01P-R:Thebatterymustbe
replacedimmediately.
Fault
Flashes yellow 2 times
every 60 seconds.
2 beeps every 60
seconds.
Pleasecleanyouralarmandseeifitis
working normally. If "Err" continues to
display, the unit has malfunctioned
andmustbereplacedimmediately.
End of Life
Flashes yellow 3 times
every 60 seconds.
3 quick beeps
every 60 seconds.
Replace the unit immediately.
Power Supply
XC01/XC05P: 10-year sealed lithium battery
XC01P-R: CR123A or CR2/3A (replaceable battery)
Product Lifespan
10 years
Sensor Type
Electrochemical

22
23
Maintenance
appliancetechniciantoinvestigatesourcesofCOfromfuel-burningequipmentandappliances,andinspectforproper
operationof this equipment.
4.Ifproblemsareidentifiedduringthisinspection,havetheequipmentservicedimmediately.Noteanycombustionequipment
thathasnotbeeninspectedbythetechnician andconsultthe manufacturer’s instructions, orcontactthemanufacturers
directlyformoreinformationaboutCOsafetyandthisequipment.Makesurethatmotorvehiclesarenot,andhavenotbeen,
operatingin an attachedgarage or adjacenttotheresidence.
1. Call emergency services assoon as possible.
2. Immediately move outside and make sure that everyone inside the house has evacuated the area or has access to fresh air.
Donot re-enter the house until ithas beenaired out andyour alarm remains under normal condition.Ifitisnotpossibleto
moveoutside,stayclosetoanopendoor/windowuntilemergencyservicerespondersarrive.
3. Afterfollowing steps1–2 above,if youralarmreactivates withina24hourperiod,repeatsteps1–2andcallaqualified
To keep your alarm in good working order, you should adhere to the following steps.
1. Testthe alarm once a weekbypressing the test/silence button.
2. Vacuumthealarm coveroncea monthtoremoveanyaccumulated dust.
3. Neverusedetergentsorsolventstocleanthealarm.Chemicalscanpermanentlydamageortemporarilycontaminatethe
sensor.
4. Avoidsprayingairfresheners,hairspray,paintor other aerosolsnearthealarm.
5. Donotpainttheunit.Paintmayclogtheopeningstothesensingchamberandpreventtheunitfromoperatingproperly.
What to Do When the Alarm Sounds
Safety Standard
EN 50291-1:2018
Operating Temperature
4–38°C (40–100°F)
Operating Relative Humidity
10%–85% RH (non-condensing)
Alarm Loudness
≥ 85 dB at 3 m (10 ft) @ 3.2 ± 0.3 kHz pulsing alarm
Storage and Transport Conditions
-20–60°C (-4–140°F), 5%–95% RH (non-condensing)
Silence Duration
About 9 minutes

24
25
Battery Replacement (for XC01P-R)
Limitations of CO Alarms
WARNING
DO NOT TAMPER WITH THE APPARATUS, AS THERE IS A RISK OF ELECTRIC SHOCK OR MALFUNCTION.
RemovetheoldbatteryandreplacewithaCR123AorCR2/3Abattery(aHuideruiCR123AorPairdeerCR2/3Abatteryis
recommended)whentheLCDdisplaysthe“Lb” messageandtheLEDindicatorflashesyellowonceevery60secondswiththe
buzzer chirping.
Afterchangingthebattery,thebuzzerwillbeeponce,theLCDbacklightwilllightup,andthe LEDindicatorwillflashthrough
8cycles(yellow/green/red).Reinstallyouralarmandtestitbypressingthetest/silencebutton.
NOTE: Rechargeable batteries are not recommended for use with this device.
1. COalarmsmay notwake upallindividuals.IfchildrenorothersdonotreadilyawakentothesoundoftheCOalarm,orifthere
areinfantsorfamilymemberswithmobilitylimitations,makesurethatsomeone assiststhemintheeventofanemergency.
2. ThisCOalarm will notsensecarbonmonoxidethatdoesnotreachthesensor. ThisCOalarmwillonlydetect COthat
reachesthesensor.COmaybepresentinotherareas.DoorsorotherobstructionsmayaffecttherateatwhichCOreaches
theCOalarm.Forthisreason,ifbedroomdoorsareusuallyclosedatnight,itisrecommendedthatyouinstallaCOalarmin
each bedroom and inthehallway betweenthem.
3. COalarmsmaynotsenseCOonanotherlevelofthehouse.Forexample,aCOalarmonthesecondlevel,nearthe
bedrooms,maynotsenseCOinthebasement.Forthisreason,oneCOalarmmaynotgiveanadequatewarning.Complete
coverageisrecommendedbyplacingCO alarmsoneachlevelof thehouse.
4. COalarmsmay notbeheard.Thealarm buzzernoiselevelisover85dBatadistanceof3m(10feet).However,iftheCO
alarmisinstalledoutsidethebedroom, itmaynotawakenasoundsleeperoronewhohasrecentlyuseddrugs orhasbeen
drinkingalcohol.Thisisespeciallytrueifthedoorisclosedoronlypartiallyopen.Evenpersonswhoareawakemaynothear
thealarmhornifthesoundisblockedbydistanceorcloseddoors.Noisefromtraffic,stereos,radios,televisions,air
conditioners,orotherappliancesmayevenpreventalertpersonsfromhearingthealarmhorn.ThisCOalarmisnotintended
for people whoare hearingimpaired.
5. COalarmsare notasubstituteforasmokealarm.Althoughfireisasourceofcarbon monoxide,thisCOalarmdoesnot
sense smoke or fire. This CO alarm senses CO thatmay beescaping unnoticed from malfunctioning furnaces, appliances, or
otherpossiblesourcesofincompletecombustion.Theinstallationofasmokealarmisrequiredforanearlywarningoffire.
6. COalarmsarenotasubstituteforlifeinsurance.ThoughtheseCOalarmswarnagainstincreasingCOlevels,wedonot
warrantorimplyinanywaythattheywillprotectlivesfrom COpoisoning.Homeownersandrenters muststillinsuretheir
lives.

26
27
Environmental Protection
Importer
7. COalarmshavealimitedlife.AlthoughtheCOalarmandallofitspartshavepassedmanystringenttestsandaredesigned
tobeasreliable aspossible,anyofthesepartscouldfailatanytime.Therefore,youarestronglyrecommendedtotestyour
CO alarmweekly.
8. COalarmsarenotfoolproof.Likeallotherelectronicdevices,COalarmshavelimitations.TheycanonlydetectCOthat
reachestheirsensors.TheymaynotgiveearlywarningofrisingCOlevelsiftheCOiscomingfrom aremotepartofthe
house,or is atsome distancefromtheCO alarm.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with
Local Authority or retailer for recycling advice.
X-Sense Innovations Co., Ltd.
Address: B4-503, Kexing Science Park, 15 Keyuan Road, Shenzhen, 518057, CHINA
X- Sense Europe B.V.
Parellaan 2H, 2132 WS Hoofddorp, the Netherlands
Thank you for purchasing our product. X-Sense Pro provides a 5-year worry-free guarantee from the date of purchase. If you
haveanyquestions,pleasefeelfreetocontactthe dealersordistributorsinyourregion.Theywillgetbacktoyouwithin1-3
working days.
Dankvoorhetaanschaffenvanonsveiligheidsproduct.X-SenseProgeeft5jaargarantieopditproduct, ingaandeopdedag vanaankoop.Alsjenogvragenhebt,neemdancontactopmet dedealer ofdistributeurinderegio.Ze
nemendanbinnen1 tot3 dagen contact met je op.
Warranty
Manufacturer and Service Information
