XAiOX iTrackU SiRF III User manual

User’s Manual XAiOX iTrackU SiRF III Bluetooth GPS Receiver -1-
User Manual
Bluetooth GPS Receiver
XAiOX iTrackU SiRF III
with Route-Recorder and Voice-Announcement
Copyright©2007 XAiOX Technologies, USA
All rights reserved

User’s Manual XAiOX iTrackU SiRF III Bluetooth GPS Receiver -2-
Table of contents
1. Introduction ……………………………………………………………………………………………………………………… 3
1.1 Read Me First ……………………………………………………………………………………………………………… 3
1.2 Overview ……………………………………………………………………………………………………………………… 3
1.3 Features ……………………………………………………………………………………………………………………… 4
2. Hardware Description ………………………………………………………………………………………………………… 5
3. Box Contents ……………………………………………………………………………………………………………………… 7
4. Volume and LED control …………………………………………………………………………………………………… 8
5. Auto Power ON/OFF …………………………………………………………………………………………………………… 9
6. Power OFF XAiOX iTrackU ………………………………………………………………………………………………… 9
7. General Important Notes ………………………………………………………………………………………………… 10
8. Software-Installation – Pocket PC CE ……………………………………………………………………………… 11
9. Working Modes ………………………………………………………………………………………………………………… 17
Modus A: GPS + Bluetooth + Route-Recorder ………………………………………………………………… 17
Modus B: GPS + Route-Recorder (Bluetooth OFF) …………………………………………………………… 17
Modus C: G-Maus + Route-Recorder (Bluetooth OFF) ……………………………………………………… 18
10. Use the Route-Recorder ………………………………………………………………………………………………… 19
11. Technical Specifications ………………………………………………………………………………………………… 22

User’s Manual XAiOX iTrackU SiRF III Bluetooth GPS Receiver -3-
1. Introduction
1.1 Read Me First
•The battery must be charged for at least 8 hours for ‘INITIAL’ use. The LED2 (GREEN) will
turn off after 3 hours’ charging, please keep on charging for 5 more hours. Thereafter, for
each time charging the battery, please fully charge for 3 hours.
•We strongly recommend to remove the battery if the device will not be used for over 2
weeks.
•For fast data tracking purpose it is recommended to stay still before the position is fixed.
(first FIX then GO!!)
1.2 Overview
The iTrackU Bluetooth GPS receiver, a total solution of GPS Bluetooth wireless technology, is high
quality design dedicated to the user who is usually carrying a portable device such as PDAs/smart
phones all the time.
The iTrackU allows 17 hours of continuous use with a single battery charge. The iTrackU uses GPS
technology to record up to 250.000 Waypoints. This allows you to watch your route in Google
Earth or similar programs.
The iTrackU does not only transmit satellite information to the PDA or smart phone via Bluetooth
but also become a G-Mouse GPS receiver through a data cable to deliver satellite information to
the device without Bluetooth interface.

User’s Manual XAiOX iTrackU SiRF III Bluetooth GPS Receiver -4-
1.3 Features
•20-Channel-Tracking
•Cold-/Warm-/Hot-Start: 42/38/1 seconds
•Reacquisition-Time: 0,1 second
•Supported Standard NMEA-0183
•Compatible with Bluetooth-Devices with Serial Port Profile (SPP)
•Small, slim and lightweight device that fits well in your hand
•Voice-Announcement for GPS-, Bluetooth- und Battery-Status
•Auto-on-/off-function: The device switches into sleep-mode if the GPS-coordinates do
not change for 15 Minutes. It re-engages approx. 3 seconds after the device
recognised a vibration
•Loudspeaker
•Three LEDs on the upper side of the device display Bluetooth- and GPS-reception. A
on/off switch is located on the upper side, too.
•Portable Navigation (PDA, Pocket PC etc.)
•With fully recharged Battery (1100mA Lithium-Ion-Battery) up to 17 hours and
approx. 2000 hours standby
•High sensitive -159 dBm build in GPS-Receiver, active antenna and Bluetooth-
Receiver

User’s Manual XAiOX iTrackU SiRF III Bluetooth GPS Receiver -5-
2. Hardware Description
Status-Scheme
LED Colour Status
RED OFF GPS not yet fixedLED1
SAT RED FLASHING GPS fixed. Will transfer data, when BT connection is on.
GREEN ON Unit is switched on (flashing 1 x per second)
GREEN ON Unit is in charging process (flashing 2 x per second)
LED2
Akku
GREEN OFF Unit is fully charged
BLUE ON Flashing very quickly (in pairing mode)LED3
BT BLUE ON Bluetooth connected (flashing 1 x per second)
Low battery: Notified by voice “battery low”
when battery low.
Battery empty: Notified by “beep” sound and
device switches off.
The iTrackU will automatically turn on if
powered by AC adaptor.

User’s Manual XAiOX iTrackU SiRF III Bluetooth GPS Receiver -6-
GPS Bluetooth operates on OS with Bluetooth function that supports SPP
In order to avoid any unexpected problem,
DO NOT attempt to change the default baudrate

User’s Manual XAiOX iTrackU SiRF III Bluetooth GPS Receiver -7-
3. Box Contents
•XAiOX iTrackU Bluetooth GPS-Receiver
•AC Adapter (220V/110V)
•Car Charger
(Input 12V, Output 5V)
•1100mA Lithium-Ion rechargeable battery
•User’s manual (CD-ROM)
•Gel Pad Holder
Gel Pad Holder
Car charger AC Adapter 1100mA Li-Ion-Battery

User’s Manual XAiOX iTrackU SiRF III Bluetooth GPS Receiver -8-
4. Volume and LED control
1. Volume up
Volume up: press shortly the “volume up” button (notified by “beep” sound)
2. Volume down
Volume down: press shortly the “volume down” button (notified by “beep” sound)
3. LED-lightning on/off
LED on/off: press simultaneous the “volume up” and the “volume down” button for 3
seconds (notified by “beep” sound)

User’s Manual XAiOX iTrackU SiRF III Bluetooth GPS Receiver -9-
5. Auto Power ON/OFF
The iTrackU equipped with vibration sensor for power management (auto power on or sleep mode)
a. Auto power on/off function is available under all working modes except G-mouse mode
b. Goes to sleep mode if vehicle stays still for 15 minutes
c. Auto power on in 3 sec. when detecting vibration (back to previous working mode)
6. Power OFF the XAiOX iTrackU
Press power button for 1 second to switch off the iTrackU.
We strongly recommend to close the E-map before turning off the XAiOX iTrackU,
in order to avoid any possible PDA /Smart phone freeze

User’s Manual XAiOX iTrackU SiRF III Bluetooth GPS Receiver -10-
7. General Import Notes
Car Charger
At the tip of the car charger you find a removable cover (screw able). Behind this cover there is a
changeable 1.5A-fuse. If you detect any malfunction please check this fuse first and replace it if
necessary.
Installing your GPS Receiver to a PDA, Pocket-PC, Smart-Phone, etc.
The following instruction how to install the GPS receiver to your device is based on iPaq HP. It is
possible that the images shown differ to the screen of your device. Unfortunately we cannot show
samples of all different devices because there are too many on the market.
Please refer to the user’s manual of your device if you need further help.

User’s Manual XAiOX iTrackU SiRF III Bluetooth GPS Receiver -11-
8. Connecting to your Bluetooth PDA
1. Turn on the iTrackU
Press power button for 1 second, the LED2 (Power Status LED) and LED3 (Bluetooth Status) start
blinking.
2. Activate Bluetooth function of your PDA / smart phone
Before you are trying to activating the Bluetooth function of your PDA / smart phone, please make
sure the device is equipped with Bluetooth function, and the driver software has been installed.
3. Activate Bluetooth Manager & Established New Connections Illustrations by using HP
2100 PDA shown as follows:
•First, find the device with which you wish to be connected
•Open “Bluetooth Manager” on your PDA
•Press “New”
•Press “Connect”

User’s Manual XAiOX iTrackU SiRF III Bluetooth GPS Receiver -12-
Beispiel: iPAQ Bluetooth mit Pocket PC Software
<1> Turn Bluetooth ON
Select ‚Bluetooth Manager’
<2> Click ‚Connect!’

User’s Manual XAiOX iTrackU SiRF III Bluetooth GPS Receiver -13-
<3> Select ‚Explore a Bluetooth device’
Then click ‘Next’.
<4> Select <No device selected>,
then click ‚Next’.

User’s Manual XAiOX iTrackU SiRF III Bluetooth GPS Receiver -14-
<5> Click ‚BT-GPS’ .
If you are asked to enter a
password, type ‚0000’.
<6> Select ‚SPP slave’,
then click ‚Next’.

User’s Manual XAiOX iTrackU SiRF III Bluetooth GPS Receiver -15-
<7> Click ‚Finish’.
BT-GPS connection is now
established successfully.
<8> Tap the Bluetooth icon again and
select ‘Bluetooth setting’.

User’s Manual XAiOX iTrackU SiRF III Bluetooth GPS Receiver -16-
<9> Settings for TomTom Navigation
Software. You can use any free
Serial COM Port (outgoing)

User’s Manual XAiOX iTrackU SiRF III Bluetooth GPS Receiver -17-
9. Working Modes
Mode A: GPS + Bluetooth + Route-Recorder
1. Power on iTrackU by pressing power button for 1 second
2. “Bluetooth On” by voice announcement
3. Bluetooth status LED (LED3: BLUE) blinking quickly
4. Connect the iTrackU to your Bluetooth PDA (please refer to 8: connecting to
your Bluetooth PDA)
5. GPS status LED (LED1: RED) blinking when GPS is fixed (by voice announcement)
Mode B: GPS + Route Recorder (Bluetooth Off)
1. Power on iTrackU by pressing power button for 1 second.
2. Switch Bluetooth off by pressing power button for 1 second
3. “Bluetooth Off” by voice announcement
4. Bluetooth status LED (LED3: BLUE) off
5. GPS status LED (LED1: RED) blinking when GPS get fixed (by voice announcement)
Remark:
Bluetooth Function
Bluetooth can be turned on anytime by pressing power button for 1 second, user will hear
“Bluetooth On” by voice announcement
Route-Recorder
Route-Recorder can be working without Bluetooth, please see previous page for operational
setting

User’s Manual XAiOX iTrackU SiRF III Bluetooth GPS Receiver -18-
Mode C: G-Mouse + Route-Recorder (Bluetooth Off)
The iTrackU can be used as a G-mouse by simply connecting to laptop PC via USB cable
1. Connecting iTrackU to laptop PC via USB cable, (USB to mini USB cable) please make sure
that the Bluetooth is off
2. Please install USB driver (in document CD) to your laptop PC
3. COM port set-up: start – control panel – system – hardware – device manager – ports
(COM&LPT)
4. GPS status can be read by running GPS software (i.e. Visual GPS)
5. Speed camera detector can be working under G-mouse mode, please see previous page for
operational setting

User’s Manual XAiOX iTrackU SiRF III Bluetooth GPS Receiver -19-
10. Use the Route-Recorder
Install driver
1. Insert supplied cd
2. Open folder “iTrackU-Software”
3. Open folder “iTrackU-USB-driver”
4. Open folder “InstallShield”
5. Run “setup.exe”
6. Connect the device and your operating system will install
the driver automatically
Adjust the iTrackU
1. Insert supplied cd
2. Open folder “iTrackU-Software”
3. Open folder “Set Data Log Utility”
4. Run “Set_Log_Data.exe”
5. Select the Com-Port, with which the iTrackU
is connected (please refer to page 21)
6. Please choose the log interval
a. By Time (0 – 3600 sec.)
b. By Distance (between 100 und 3000 meters)
7. Choose “Update Setting Value” to save the settings
8. Choose “Erase All Log Data” to delete all logged data
9. Now the iTrackU automatically logs your route

User’s Manual XAiOX iTrackU SiRF III Bluetooth GPS Receiver -20-
Remark:
– You can set the vibration auto function on/off or choose the
sensitivity of the sensor.
– You can set the tag-function on/off (this function allows you
to save your current position by holding the “volume up” button)
Dump logged Data
1. Insert supplied cd
2. Open folder “iTrackU-Software”
3. Copy folder “Dump Log Data Utility” on your hard-disk
4. Run “Dump_Log_Data.exe”
5. Select the Com-Port, with which the iTrackU is connected
(please refer to page 21)
6. Please choose the data range for the output file
a. All Log Data (displays all logged data)
b. Search Log Data by Date (displays the data of a defined period)
c. Search Log Data by Tag (displays the data with a defined tag)
7. Please choose the output file format
a. Build Output File (creates *.CSV for Exel)
b. Output for Google Earth (creates *.KML for Google Earth)
c. Output for Trackmaker (creates *.TXT for Trackmaker)
d. Build Output Raw Data File (creates RawData.dat, which includes the RMC-lines of
the NMEA0183 protocol)
