XDP Recreation 74520SF User manual

MODEL 74520SF
“SWINGIN' FREE+” Swing Set
Assembled dimensions are 168"*91"*74".
Allow 6 - 12 ft of clearance around the perimeter of the swing set area when fully assembled.
OWNER'S MANUAL, ASSEMBLY INSTRUCTIONS, CARE, MAINTENANCE AND USER'S GUIDE
Important Instructions & Warnings!
Please read this entire instruction and assembly manual completely before proceeding. You must follow all
safety instructions while using this equipment. The surface area where this swing set is set up must be level andfreeof
all debris. This set is designed to be anchored into the ground and is not to be set up on any hard surfaces such as
concrete, hardened soil or asphalt. Proper surfacing under and surrounding the set adds to the safety level such as
sand or mulch. Read all cautionary statements on the following pages before using this equipment and save this
instruction manual. DO NOT ALLOW CHILDREN TO PLAY ON THIS GYM SET UNSUPERVISED! CONSTANT
ADULT SUPERVISION IS REQUIRED. Do not use when raining or during any inclement weather (i.e. rain, sleet, snow,
ice, high winds, thunderstorms or lightening). DO NOT ALLOW CHILDREN TO JUMP ON OR CLIMB UP ON THIS
SET'S TOP BAR.
For warranty details and registration see the back page of this manual.
FOLLOW ALL ASSEMBLY INSTRUCTIONS AS WRITTEN IN THIS MANUAL
Please retain sales receipt for warranty purposes. DO NOT RETURN THE SET TO
THE STORE. If replacement parts or customer service is needed please contact XDP Recreation by email at
[email protected] or by calling 1-866-884-0535 between 8:00am and 5:00pm (Eastern Standard Time), Monday - Friday. This
gym is designed to be used safely by up to seven (7) children, ages 3 years to 8 years, with weight capacity of 100 lbs per child or total
combined weight limit of 700 lbs for all seven (7) children (318kg). This play gym is designed for backyard use only and is NOT intended
for playgrounds, schools, day care facilities, nurseries or other public places. Follow all assembly instructions carefully and as directed in
this manual. This gym conforms to all safety requirements by ASTM for Home Playground equipment when properly assembled using the
instructions enclosed. Adult assembly is required. Contains small parts. For proper stability and safety this gym set should be installed
with ground anchors.
Anchor Kits can be ordered directly from XDP RECREATION at https://www.xdprecreation.com or by calling
1.866.884.0535 or thru your retailer of choice.

DO NOT RETURN TO RETAILER WHERE YOU PURCHASED AT.
CONTACT XDP FOR PARTS AND SUPPORTAT 1.866.884.0535 or [email protected] 1
IMPORTANT INSTRUCTIONS AND WARNINGS
WARNING
READ ALL INSTRUCTIONS BEFORE ASSEMBLING OR USING THIS EQUIPMENT.
AGE & WEIGHT LIMIT
This product is designed to be used by up to seven (7) children between the ages of 3 to 8. Maximum
user weight is 100 pounds (45 kg) each with a combined maximum weight of 700 pounds (318 kg).
The play set is designed for children over three (3) years of age up to (8) years of age. Use by smaller
children can result in entrapment.
On-site adult supervision is required at all times for children of all ages.
Do not allow use by children with any physical condition that may affect his/her ability to use this equipment
safely.
BEFORE YOU BEGIN
Carefully read all instructions in this manual before assembling and using this product.
The unit must be assembled by adults. Heavy duty working gloves must be worn to avoid injuries during
assembly.
Children must not use the equipment until it is properly assembled and anchored.
Adult supervision is required during the use of this equipment at all times.
Unpack all parts. Take a complete inventory of all parts and hardware using the parts and hardware lists in
the following pages. If any parts are missing, do not return to the store. Please call customer service toll-free
number listed on the cover page for assistance. Store the product back in the original box and do not begin
to install until all parts are obtained.
LOCATION OF PLAY SET
The equipment must be placed more than six (6) feet (1.8 meters) from any structures or obstructions,
including but not limited to buildings, fence, garage, trees, laundry lines, electrical wires. Children can be
seriously injured running or swinging into obstacles.
The play set must be installed on level ground. Uneven ground must be leveled prior to installation.
Installation on sloping or uneven ground will put stress on the joints, causing the unit to become loose and
unstable which may result in serious injuries.
Remove any tripping hazards from the safe play area, such as roots, tree stumps, rocks, landscaping,
sprinkler heads, railroad ties, plumbing and electrical connections.
Windy conditions: it is possible for the product to be blown about by a high wind. If you anticipate
high winds, the frame should be secured to the ground with the use of an Anchor kit. If you anticipate
severe winds, the product should be moved to a sheltered location or completely disassembled.
Anchor kits can be ordered directly from XDP RECREATION at https//:www.xdprecreation.com or by
calling 1-866-884-0535.
Warning the owner to instruct children not to use the
equipment in a manner other than intended. Never add extra length to chain or rope. The chains
or ropes provided are the maximum length designed for the swinging element(s).

DO NOT RETURN TO RETAILER WHERE YOU PURCHASED AT.
CONTACT XDP FOR PARTS AND SUPPORTAT 1.866.884.0535 or [email protected] 2
DO NOT install your play set over hard surface, e.g. asphalt, concrete, packed earth, tile or brick floor.
A fall onto a hard surface can result in serious injury or death to the user. The following is a list of
recommended ground covers from the Consumer Product Safety Commission:
SUGGESTED MATERIAL UNCOMPRESSED DEPTH
Double Shredded Bark Mulch 9”
Uniform Wood Chips 12”
Fine Gravel 12”
Fine Sand 12”
The Consumer Product Safety Commission’s Outdoor Home Playground Safety Handbook recommends to
install and maintain the playground equipment over at least 9 inches of wood chips, mulch or shredded
rubber (for equipment up to 8 feet high) or sand or pea gravel (for equipment no more than 5 feet high) as
shock absorbing material. Dirt and grass, which are the most prevalent surfaces under home playground
equipment, do not adequately protect children from serious head injuries. Install protective surfacing at least
six feet in all directions from play equipment. For swings, the surface should extend, in back and front, twice
the height of the suspending bar. You should consult a local contractor about ways to secure the product in
your location. Do not install your play set over hard surface, e.g. asphalt, concrete, packed earth, tile or brick
floor. Please refer to the CONSUMER PRODUCT SAFETY COMMISSION’S OUTDOOR HOME
PLAYGROUND SAFETY HANDBOOK for detailed guidelines to prevent injuries from falls and other hazards
on public and home playgrounds.
WARNINGS ON ANCHORING
This product must be anchored into the ground to prevent movement and to make the swing set more stable
during use.
Some consumers want an anchoring system that allows the product to be moved to different locations. Other
consumers want to keep their swing set in a permanent location.
It is highly recommended that you seek the opinion from a local licensed contractor on the best way to secure the
swing set in your location. The best way to anchor a product is to create a concrete footing and use that as a base
for an anchor. Whatever method you prefer for your location, an anchoring system for this product should be used
at all times.
WEATHER CONDITIONS
DO NOT use this equipment if the swing seat, slide or any parts are wet. Use the play set only when the
parts are clean and dry. If the equipment is wet, the user could slip and suffer injuries.
Please be aware of weather conditions when using the equipment. If it is too windy, users could lose
control and suffer injuries. The playground equipment must be properly anchored, stored away or
restricted from use during inclement weather such as heavy winds or severe weather storms. You
should consult a local contractor about ways to anchor the product in your location.
WARNINGS / ALERTS
Observing the 'Warnings' and 'Safety' statements, reduces the likelihood of serious or fatal
injury to user - Child/Adult.
The OWNER of the equipment needs to Warn the Children/Users NOT to use the equipment in a
manner than otherwise intended - See MANUAL.
Never add 'extra length' to the Chain or Rope. The Chain and Rope, that are provided, are the
'maximum' length designed for the swinging elements.
Observing the following statements and warnings reduces the likelihood of serious or fatal
injury.

DO NOT RETURN TO RETAILER WHERE YOU PURCHASED AT.
CONTACT XDP FOR PARTS AND SUPPORTAT 1.866.884.0535 or [email protected] 3
PLAY SUPERVISION
DO NOT allow more than one child to play on the individual swing or slide component at any one time.
DO NOT allow children to stand on the slide, swing seats, trapeze, seesaw, rocky rider, disc swing or glide
ride. The glide ride and seesaw are made for only two users at a time. The disc swing & rocky rider are
made for one or two users at a time.
DO NOT allow children to walk too close to moving parts. ALWAYS keep a safe distance to avoid being
struck by other children while playing on swings, slides, disc swing and glide ride etc.
DO NOT swing empty seats as this may cause injuries.
ALWAYS guide children to sit in the center of swinging parts, with their full weight placed in the seat center
and holding on to the swing chains.
DO NOT allow children to jump off the equipment while it is in motion. ALWAYS come to a full stop before
dismounting.
ALWAYS dress children appropriately for proper play, e.g. wear well-fitted rubber sole shoes, and remove
loose or sharp items such as jewelry, hair accessories, scarves which may become entangled in the
equipment or cause injuries.
ALWAYS make sure children remove their bike or other sports helmets before playing on the playground.
DO NOT allow children to slide down the slide head first.
DO NOT allow children to climb onto swing or jump to/from different play areas of the equipment.
ALWAYS return safely to the ground before approaching another play area.
DO NOT allow children to climb on structural parts (e.g. legs, top bar). These are structural components
and are not designed for play.
ALWAYS check the slide or other parts exposed to the body for extreme heat from the sun before allowing
children to use the equipment.
ALWAYS prevent access and secure from any unauthorized use when there is no adult supervision.
DO NOT allow pets or other animals near the equipment to prevent damage or injuries.
Adequate overhead clearance is essential. A minimum of 24 ft (7.3 meters) from ground level is
recommended. Provide clearance for wires, tree limbs and other possible hazards.
Use the swing set in a well-lit area. Artificial illumination may be required for shady areas.
DO NOT allow children to twist the swing chains or loop them over the
top support bar as this may reduce the strength of the chain. Twisting
may break the chain and causing danger to children.

DO NOT RETURN TO RETAILER WHERE YOU PURCHASED AT.
CONTACT XDP FOR PARTS AND SUPPORTAT 1.866.884.0535 or [email protected] 4
INSPECTION PRIOR TO EACH USE OR DAILY INSPECTION
DO NOT use the equipment if any bolts or nuts are missing or loose. ALWAYS check to ensure the
equipment and all parts are well secured and stable before each use.
ALWAYS clear the play area of any rocks, sharp objects, or any materials that could be potentially
hazardous to users.
DO NOT attach items to the equipment that are not specifically designed for use with the equipment,
including, but not limited to, jump ropes, clothesline, pet leashes, cables and chains as they may cause
choke hazards.
The steel and plastic parts used in your product are subject to normal wear. Gradual deterioration of the
material will occur, the speed of which will depend on the level of exposure to UV rays, airborne pollution,
outdoor weather conditions such as rain and wind and the amount of use. You must inspect the equipment
prior to every use. This includes, but is not limited to inspecting the set for cracks, excess wear, missing
parts, loose connections and for overall integrity. When the set shows any signs of weakness, you must
stop using the play set immediately, properly store the set or restrict access by users until the condition is
resolved.
Verify that the chains are secured at both ends and tightened, so that there is no loose chain hanging
that can result in choking hazard.
When conducting inspections, it is recommended that you use the Suggested General Maintenance
Checklist and Routine Inspection and Maintenance Issues checklists provided by the US Consumer Product
Safety Commission, a copy of which is contained in this user manual.
CARE & MAINTENANCE INSTRUCTIONS
Inspect all nuts and bolts twice monthly during the usage season for tightness and tighten as required. It is
particularly important that this procedure is followed at the beginning of each season.
Oil all metallic moving parts monthly during the usage period.
Sand rusted areas on metal tubing and repaint using a nonlead-based paint meeting the requirements of
Title 16 CFR Part 1303.
Check swing seats and chains monthly during usage season for deterioration. Replacements should be
made in accordance with the manufacturer’s instructions.
Check all coverings for bolts and sharp edges twice monthly during usage season to be certain that they are
in place and replace when necessary. It is especially important to do this at the beginning of each new
season.
Do not use when the temperature drops below 32 degrees F (0 degrees C); remove and store the plastic
swing seats and slide indoors.
READ THROUGH THE ENTIRE ASSEMBLY PAGES
FIRST BEFORE STARTING.

DO NOT RETURN TO RETAILERWHERE YOU PURCHASED AT.
CONTACT XDP FOR PARTS AND SUPPORT AT 1.866.884.0535 or [email protected]
5

DO NOT RETURN TO RETAILER WHERE YOU PURCHASED AT.
CONTACT XDP FOR PARTS AND SUPPORTAT 1.866.884.0535 or [email protected] 6
ANCHORING
(NOTE:ANCHORS ARE NOT INCLUDED-MUST BE PURCHASED SEPARATELY)
There are different ways of anchoring the equipment, depending on the type of ground on which
the equipment is to be installed. Make sure that all anchors are below ground level to prevent
tripping.
You should consult your local contractor to decide the most appropriate way to anchor the
equipment in your location.
The following anchoring options may be considered:
Corkscrew Anchoring (Corkscrew Anchors not included)
If your soil is hard (clay, etc.), the corkscrew method may be suitable.
Be sure that the swing set is located on level ground.
Twist the corkscrew anchor into the ground until only the end with the hook is above the ground
and next to the leg. Insert the hook into the bottom opening of the leg.
Ensure that the hook is secured onto the leg opening.
Concrete Anchoring (Materials not included)
●If the swing set is set up on grounds with sandy soil (soft) condition, it must be anchored
with concrete footing (concrete not included)
●Be sure that the swing set is assembled and placed on level ground
●Dig holes around swing leg tube, as shown in drawing in the next page. As you dig deeper,
enlarge the diameter of the hole to fix the cement
●Place 2 inches of brick or gravel underneath the leg, as shown in drawing in the next page
●Use about 45 lbs. of concrete per leg
●Cover the concrete with dirt and protective surface material
●Allow 6-7 days for the concrete to dry properly
Anchor Kits for Swing Sets are available at https://www.xdprecreation.com or your retailer of
choice.

DO NOT RETURN TO RETAILER WHERE YOU PURCHASED AT.
CONTACT XDP FOR PARTS AND SUPPORTAT 1.866.884.0535 or [email protected] 7
Note: The maximum fall height for this product is 4 feet. The minimum ground
clearance between the bottom of the suspended plays and the playing or
ground surface must be 8 inches.
You must maintain a minimum of 8 inches of ground clearance.
WARNING
Please properly anchor the swing set to minimize the risk of injury or
death.
If the swing set is used without proper anchoring, it may be
dangerous and may tilt over.
FRAME LEG CONCRETE
BRICK OR GRAVEL BED
2”
12-5/8”
5”
8”

DO NOT RETURN TO RETAILER WHERE YOU PURCHASED AT.
CONTACT XDP FOR PARTS AND SUPPORTAT 1.866.884.0535 or [email protected] 8
CARE AND MAINTENANCE CHECKLIST
AT THE BEGINNING OF EACH PLAY SEASON:
Tighten all hardware.
Lubricate all metallic moving parts.
Check all protective coverings on bolts, pipes, edges, and corners. Replace if they are loose,
cracked, or missing.
Check all moving parts including swing seats and chains for wear, rust or other deterioration.
Replace as needed.
Check metal parts for rust. If found, sand and repaint using a non-lead paint meeting the
requirements of 16 CFR 1303.
Reinstall any plastic parts, such as swing seats or any other items that were removed for the cold
season.
Rake and check depth of loose fill protective surfacing materials to prevent compaction and to
maintain appropriate depth. Replace as needed.
TWICE A MONTH DURING PLAY SEASON:
Tighten all hardware.
Check all protective coverings on bolts, pipes, edges and corners. Replace if they are loose,
cracked or missing.
Rake and check depth of loose fill protective surfacing materials to prevent compaction and to
maintain appropriate depth. Replace as needed.
ONCE A MONTH DURING PLAY SEASON:
Lubricate all metallic moving parts per manufacturer’s instructions.
Check all moving parts including swing seats and chains for wear, rust or other deterioration.
Replace as needed.
Rake and check depth of loose fill protective surfacing materials to prevent compaction and to
maintain appropriate depth. Replace as needed.
AT THE END OF EACH PLAY SEASON:
At the end of each play season or when the temperature drops below 32 degrees F (0 degrees C).
Remove plastic swing seats and other items as specified by the manufacturer and take indoors or
do not use.
Rake and check depth of loose fill protective surfacing materials to prevent compaction and to
maintain appropriate depth. Replace as needed.
As a general rule, maintenance should be performed at any time it is deemed necessary.
DISPOSAL INSTRUCTIONS
Please use care when disassembling the equipment, when it is no longer in operational condition.
Wear heavy duty working gloves to avoid injuries.
Fully disassemble the entire swing and slide sets before disposal. Do not leave partially
disassembled parts in areas accessible by children.
Should you wish to recycle the steel tubing, please take the frame to your local recycling center.
All plastic parts can be recycled, take it to your local recycling center. Do not let children play with
any disassembled parts meant for disposal, such as chains, slide, tubing, bolts, nuts, screws, etc.
All rusted parts, bolts must be properly disposed of in trash bin. Do not reuse.
Owners shall be responsible for maintaining the legibility of the warning labels.

DO NOT RETURN TO RETAILER WHERE YOU PURCHASED AT.
CONTACT XDP FOR PARTS AND SUPPORTAT 1.866.884.0535 or [email protected] 9
TOOLS NEEDED
Please prepare the following tools
prior to assembling this equipment.
Special Socket Wrench Tape Measure
(Not included) (Not included)
Hammer Wrench
(If you intend to install anchor, this is needed) (Included)
Wrench Medium Allen Wrench
(Not Included) (Included)
Flat Head and Philips Head Screwdriver Big Allen Wrench
(Not included) (Included)
Small Allen Wrench Scissors
（
Not Included) (Not included)

DO NOT RETURN TO RETAILER WHERE YOU PURCHASED AT.
CONTACT XDP FOR PARTS AND SUPPORTAT 1.866.884.0535 or [email protected] 10
Part list for main frame assembly
A1 LEFT TOP BAR 1
A2 MIDDLE TOP BAR 1
A3 RIGHT TOP BAR 1
A4 TOP SECTION LEG 4
A5 BOTTOM SECTION LEG WITH FOAM 3
A6 BOTTOM SECTION LEG WITH FOAM 1
A7 CROSS BAR (WITH TWO HOLES) 1
A8 CROSS BAR (WITH FOUR HOLES) 1
Hardware used for main frame assembly
B1 BOLT 5/16" (63MM) 12
B2 BOLT 5/16" (68MM) 4
B3 NYLON NUT 5/16" 16
B4 PLASTIC CAP (WITH ARC WASHER) 16
B5 ARC WASHER 5/16" 12
B6 WASHER 5/16" 4

DO NOT RETURN TO RETAILER WHERE YOU PURCHASED AT.
CONTACT XDP FOR PARTS AND SUPPORTAT 1.866.884.0535 or [email protected] 11
Part list for FireflyTM LED Lighted swing seat assembly
J1-N3 PVC COVERED CHAIN 2
J3-L
ATTACHMENT BOLT
(PRE-ASSEMBLED ON J1-N3)
***BLUE MARKING on screw***
2
J3-N
ONE EYE BOLT WITH ATTACHMENT
BOLT (PRE-ASSEMBLED ON J1-N3)
***The plastic is Ivory Color.***
2
K1-F FIREFLY SEAT 1
Hardware used for FireflyTM LED Lighted swing seat assembly
Part list for Stand R SwingTM assembly
J1A PVC COVERED CHAIN
(PRE-ASSEMBLED) 2
J3A ATTACHMENT BOLT
(PRE-ASSEMBLED ON J1A)2
J3A-N
ONE EYE BOLT WITH ATTACHMENT
BOLT (PRE-ASSEMBLED ON J1A)
***The plastic is Green.***
2
K2 STANDRSWING 1
Hardware used for Stand R SwingTM assembly
J6 NUT 5/16" 4
J7 WASHER 5/16" 2
J8 PLASTIC CAP (WITH ARC WASHER) 2
J9 PLASTIC CAP (WITH FLAT WASHER) 2
J6A NUT 5/16" 4
J7A WASHER 5/16" 2
J8A PLASTIC CAP (WITH ARC WASHER) 2
J9A PLASTIC CAP (WITH FLAT WASHER) 2

DO NOT RETURN TO RETAILER WHERE YOU PURCHASED AT.
CONTACT XDP FOR PARTS AND SUPPORTAT 1.866.884.0535 or [email protected] 12
Part list for SUPER DISCTM Swing assembly
R1-N3 PVC COVERED CHAIN 4
R2A-N3 ATTACHMENT BOLT
(PRE-ASSEMBLED ON R1-N3)2
R2B-N3 ATTACHMENT BOLT
(PRE-ASSEMBLED ON R1-N3)4
R3-N DISC SWING TUBE 4
R3-1 DISC SWING TUBE FOAM
(PRE-ASSEMBLED ON R3-N)4
R4 DISC SWING FABRIC 1
Hardware used for SUPER DISCTM Swing assembly
Part list for slide assembly
X1-N SLIDE SUPPORT (WITH OPENING) 1
X2-N SLIDE SUPPORT 1
X3-N SLIDE LEG TUBE 2
X4-N SLIDE TOP SUPPORT BAR 1
X5-N SLIDE FRONT SUPPORT 1
X6 SLIDE LADDER STEPS 2
Y4-1 SLIDE A 1
Y4-2 SLIDE B 1
F1-N NUT 5/16" 6
F2-N ARC WASHER 4
F3-N PLASTIC CAP (WITH ARC WASHER) 2

DO NOT RETURN TO RETAILER WHERE YOU PURCHASED AT.
CONTACT XDP FOR PARTS AND SUPPORTAT 1.866.884.0535 or [email protected] 13
Hardware used for slide assembly
Y1 PLASTIC CONNECTOR 2
Z1 BOLT 1/4" (38MM) 6
Z2-N BOLT 1/4" (97MM) 2
Z3 SPRING WASHER 4
Z4 CAP NUT 1/4" 10
Z5 CAP BOLT 1/4"x1/2" 4
Z6 SPRING WASHER (SMALL) 29
Z7 BOLT 1/4” (75MM) 2
Z8 BOLT 1/4” (58MM) 4
Z10 BOLT 1/4” (20MM) 5
Part list for seesaw assembly
U16 SEAT 2
U17-1 SEAT SUPPORT 1 1
U17-2 SEAT SUPPORT 2 1
U18 HANDLE BAR 2
U19-1 LEFT HANDLE BAR SUPPORT 2
U19-2 RIGHT HANDLE BAR SUPPORT 2
U20 L-SHAPED TUBE 1

DO NOT RETURN TO RETAILER WHERE YOU PURCHASED AT.
CONTACT XDP FOR PARTS AND SUPPORTAT 1.866.884.0535 or [email protected] 14
Hardware used for seesaw assembly
U1 BOLT 5/16” (82MM) 4
U2 BOLT 5/16” (63MM) 1
U3 BOLT 5/16” (68MM) 2
U4 ARC WASHER Φ8.5*T1.5MM 12
U5 NUT 5/16” 9
U6 CAP NUT 1/4” 4
U7 BOLT 1/4” (37MM) 4
U8 SPRING WASHER 4
U9 SCREW M4 (12MM) 4
U10 PLASTIC CAP (WITH FLAT WASHER) 1
U14 FLAT WASHER 1
U15 PLASTIC CAP (WITH ARC WASHER) 4
U21 SPRING WASHER(SMALL) 4
U22 BOLT 5/16” (51MM) 2

DO NOT RETURN TO RETAILER WHERE YOU PURCHASED AT.
CONTACT XDP FOR PARTS AND SUPPORTAT 1.866.884.0535 or [email protected] 15
ASSEMBLY INSTRUCTIONS
Place the playground equipment on level ground and not less than
6ft (1.8m) from any structure or obstruction such as a fence, garage,
house, overhanging branches, laundry line or electrical wires.
Do not install the playground equipment over concrete, asphalt,
packed earth or any other hard surface; a fall onto a hard surface can
result in serious injury or death to the equipment user.
Adequate overhead clearance is essential. A minimum clearance from
ground level shall be recommended. Provide clearance for wires, tree
limbs and other possible hazards.
Use the swing set in a well-lighted area. Artificial illumination may be
required for shady areas.
Secure the swing set against unauthorized and unsupervised use.
The owner and supervisors of the swing set are responsible to make all
users aware of practices specified in the use instructions.
TIGHTENING NUTS & BOLTS
For ease of installation, do not over-tighten the nuts and bolts when
you are first putting the equipment together. This will allow for
some possible adjustments during installation.
Once you have finished assembling each component of the play set,
make sure to go back over each step and properly tighten all nuts,
bolts and plastic caps. Check the entire unit to ensure all parts are
properly assembled before allowing children to use the playground
equipment.

DO NOT RETURN TO RETAILER WHERE YOU PURCHASED AT.
CONTACT XDP FOR PARTS AND SUPPORTAT 1.866.884.0535 or [email protected] 16
STEP 1 – Assemble the top bar frame of the swing set
Connect A1, A2 and A3 secure with B1, B5, B4 and B3 as shown below.
Note: All round holes should be facing up and concave holes facing down.
NOTE:
1. Do not over-tighten the nuts and bolts at every step.
2. Do not snap in the cover of plastic cap until you have finished the assembly of
each step and went back to tighten all of the nuts and bolts.
A2
A1
A3
B1 B1
B3 B3
B4
B4
B5 B5

DO NOT RETURN TO RETAILER WHERE YOU PURCHASED AT.
CONTACT XDP FOR PARTS AND SUPPORTAT 1.866.884.0535 or [email protected] 17
STEP 2 – Assemble the support legs of swing set
Connect A1 to A4 and secure using B1, B5, B4 and B3 as shown below.
Repeat this step for the right side of the swing (A3 and A4)
NOTE:
1. Do not over-tighten the nuts and bolts at every step.
2. Do not snap in the cover of plastic cap until you have finished the assembly of
each step and went back to tighten all of the nuts and bolts.
A1
A
4
A4
B5 B5
B1
B1
B3
B4
A5
A6

DO NOT RETURN TO RETAILER WHERE YOU PURCHASED AT.
CONTACT XDP FOR PARTS AND SUPPORTAT 1.866.884.0535 or [email protected] 18
STEP 3 – Assemble the support legs of swing set
Connect A4 to A5 & A6 and secure using B1, B5, B4 and B3 as shown below.
Repeat this step for the right side of the swing set (A3 with A4).
NOTE:
1. Do not over-tighten the nuts and bolts at every step.
2. Do not snap in the cover of plastic cap until you have finished the assembly of
each step and went back to tighten all of the nuts and bolts.
B1
B5
B1
B5
B4
B4
B3
B3
A5
A
6
A4
A
4
A1

DO NOT RETURN TO RETAILER WHERE YOU PURCHASED AT.
CONTACT XDP FOR PARTS AND SUPPORTAT 1.866.884.0535 or [email protected] 19
STEP 4 – Attach the crossbar to the support legs
Attach A7 to the outer side of A5 & A6 and secure using B2, B6, B4 and B3.
NOTE:
1. Do not over-tighten the nuts and bolts at every step.
2. Do not snap in the cover of plastic cap until you have finished the assembly of
each step and went back to tighten all of the nuts and bolts.
B6
A7
B6
A1
B2
A5
B2
A4
A4
A6
B3
B3
B4
B4
