HY609WIFI-WE/WW User Manual
Many thanks for your selection of our products and services, and also for your trust
and support to us.
HY Series Thermostats used for underfloor Electric Heating System, Water Floor Heating
System, Wall-Hung Boiler Heating System.
Functions
WW: Watwer Heater 3A
WE: Underfloor Heating 16A
WW-LD: Wall-Hung Boiler Heating and Water Heating
Products Features
Standard total Size is 86*86*11 mm,
Used for Manifold, European box

Color:White, Black and others
Installation: Wall mounted make it
more simple
Including built-in sensor and external
sensor
Accuracy:±0.5℃
Children lock to prevent misoperation
by children
Data memory when power is off.
Weekly Programming: 5+2, 6+1,7
days and also Support DIY
programming.
Holiday mode make you enjoy more
comfortable
The temperature of external sensor can
be checked
Temporary Manuel Mode: On the
programmable mode, the thermostat
will run to the next time period
according to the temporarily set
temperature, and then return to the
programming mode.
Products Specifications
Power Supply：90-240VAC
50/60Hz
Sensor：NTC(10K)1%
Contact capacity：3A(WW)；
Search for "Smart RM" or “Smart
Life” Download the Wifi App with
the following icon
Turn on Power ，Open Thermostat, long press
“ ” and “ ” Activate WIFI
distribution network icon

16A(WE)
Range of temperature display:
Range of Temperature Limited：
1~70°C
Set Point Temperature：5~35℃
Accuracy：±0.5℃
External Sensor：Optional（NTC）
Size：86*86*11mm（Exposed
wall）
Diplay
Programmer
Manual mode
Temporary manual mode
Holiday mode
On heating
Child lock
Open window
Temperature
Temperature Setting
External NTC sensor
Description of icon
Turn ON/OFF:Short press to turn on/
turn off
1 Short press to switch automatic mode
and manual mode
2 Turn on thermostat, long press for 3-5
seconds to enter into programmable setting
3. Turn off thermostat, long press for 3-5
seconds to enter into advanced A setting
1.Increase Key
2.long press to check temperature of external
sensor（Only used for senior NTC N3）
On the programmer Mode or ，enter
to temporary manual mode

Confirm key:：short press it to set time
Turn on，Long press 3-5s enter holiday
mode
On OFF，press or will change
to ON，Short press ，choose days
and temperature，after finished,
press enter holiday mode
Turn off Thermostat，Long press3-5s enter
set interface
Decrease key
Long press to lock /unlock
Programmable
5+2(Factory default) 6+1, 7days(Same)6 times period setting for user choose. under power on state,
Long press for 3-5 seconds enter into programming mode setting, Thent, short press
to choose: hour,minute, time period, and press or to adjust data, finished setting,
about 10 seconds will automatic save and exist
Wake up
Outdoor
Back Home
Outdoor
Back Home
Sleep
6：00
20℃
8：00
15℃
11：30
15℃
13：30
15℃
17：00
15℃
22：00
15℃
1、Advanced options A
Under turn off start，long press 3-5for 3-5 seconds to access advanced A setting.，Short
press to switch next option，Press or to adjust data。After finished, .Remain about
10 seconds after finish setting will quit setting.
NO
Setting Optional
Data Setting Function
Factory Default
A1
Measure Temperature
Calibration
-9~+9℃
-1
A2
Temperature control
0.5~2.5℃
1℃

return difference setting
A3
Children lock setting
0:half lock 1：full lock
0
A4
Power with memory
function
0:Power with memory function
1:Shutdown power after power off
2:Shutdown power after power on
0
A5
Backlight sleep brightness
0: 0% of brightness
1: 50% of brightness
2: 100% of brightness
2
A6
Weekly programming
selection
0：5+2
1：6+1
2：7
0
A7
Setting temperature lowest limit
1~10℃
5
A8
Setting temperature highest Limit
20~70℃
35
A9
Protection of low temperature
1.1~10℃，
2.Exceed 10℃，press screen
display【--】, Low temperature
protection was canceled.
5
AA
Protection of high temperature
1.20~70℃
2.Exceed 20℃，press“ ”Screen
Display【--】，High temperature
protection was canceled
45
AB
Return different for high temperature
protection
1~9℃
2
AC
Running temperature of
open window function
1.10~20℃
2.Exceed 10℃ ，
Press“ ”Screen display【--】，
Open window function was canceled
--
AD
Running time of open window
function
10~20 Min
10

AE
Reset
Screen display Ao,Long press
until whole display
Advanced options B
Under turn off state, long press for 3-5 seconds to access advanced B setting, short
press to switch next option, Press or to adjust data, after finished, Remain
about 10 seconds after finish setting will quit setting.
NO
Setting Options
Data Setting Function
Factory
Default
BN
Choose Sensor
N1: only inner sensor
N2: only external sensor
N3: both sensor
N1
BC
Descaling function
0：Close 1：Open
0
Bo
System
Can not change
Remark of High Temperature Protection:
limit valve of external sensor is 45℃ for factory default (A6),value of external
sensor control return difference (A3) is 2. when temperature rise to 45℃,then relay stop working and
will remind high temperature production alarm. If temperature decline to 43℃relay continue to work
and heating alarm will be relieved. (it can be operated ,only when indoor temperature is lower than
setting temperature )
please choose correct working way of built-in and external sensor, if choose wrongly or sensor fault
(breakdown), “E1” or “E2” will be displayed on the screen. Thermostat will stop heating until the fault
is eliminated

Wiring And Installation
1. Read these instructions carefully. Failure to comply with these regulations may
damage the product or cause dangerous situations.
2. Confirm the maximum load given in the manual and the product to ensure that the
product is suitable for your application.
3. The installer must be a trained and experienced maintenance technician.
4. After the installation is complete, follow the instructions in these instructions.
CAUTION
Electrical shock or equipment Damage Hazard. or short equipment circuitry.
Disconnect power supply before installation
Wiring
WE:Electric Heating WW:Water Heating WW-LD ：Wall- Hung Boiler
Heating
NTC ：Optional（WE/WW）

注：This wiring diagram just for reference, please refer to the actual wiring diagram of
the products specific wiring.
Installation
