Xtreme Power 81066 Original instruction manual

26CC 2-CYCLE GAS HEDGE TRIMMER
SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY,
OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT’S
SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH
AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER).
OWNER’S MANUAL AND SAFETY INSTRUCTIONS
ITEM: 81066
FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: [phone] MON-FRI 9AM TO 3PM PST

GENERAL SAFETY WARNINGS
Read all safety warnings and instructions. Failure to follow the warnings and instructions may
result in electric shock, re and/or serious injury. Save all warnings and instructions for future
reference.
SAFETY
The warnings, precautions, and instructions discussed in this instruction manual cannot cover all possible
conditions and situations that may occur. It must be understood by the operator that common sense and
caution are factors which cannot be built into this product, but must be supplied by the operator.
1
Keep work area clean and well lit. Cluttered or dark areas invite accidents.
IMPORTANT SAFETY INFORMATION
DO NOT operate power tools in explosive atmospheres, such as in the presence of ammable liquids,
gases or dust. Power tools create sparks which may ignite the dust or fumes.
To reduce the risk of electric shock, this tool has a polarized plug (one blade is wider than the other).
This plug will t into the polarized wall outlet only one way. If the plug does not t fully into the wall outlet,
reverse the plug. If the plug still does not t, contact a qualied electrician to install the proper wall outlet.
DO NOT change the plug in any way.
Avoid body contact with grounded surfaces such as pipes, radiators, ranges, and refrigerators. There is
an increased risk of electric shock if your body is grounded.
Avoid running the engine indoors. The exhaust gasses contain harmful carbon.
When using your trimmer for the rst time, before beginning actual work, you should practice in a wide,
bright area.
Limit the amount of time of using the trimmer continuously to somewhere around 30-40 minutes per
session and take 10-20 minutes of rest between work sessions.
Be sure to wear proper clothing and safety gear when operating the trimmer. Safety gear includes a hel-
met, protective goggles, thick work gloves, non-slip work boots and ear protection. NEVER wear loose
tting clothes. Make sure long hair is tied back.
It is believed that a condition called Raynaud’s Phenomenon, which affects the ngers of certain
individuals, may be brought about by exposure to vibration and cold. Exposure to vibration and cold
may cause tingling and burning sensations, followed by loss of color and numbness in the ngers. The
following precautions are strongly recommended, because the minimum exposure, which might trigger
the ailment, is unknown. Keep your body warm, especially the head, neck, feet, ankles, hands, and wrists.
Maintain good blood circulation by performing vigorous arm exercises during frequent work breaks, and
also by not smoking. Limit the hours of operation. Try to ll each day with jobs where operating the unit
or other hand-held power equipment is not required. If you experience discomfort, redness, and swelling
of the ngers followed by whitening and loss of feeling, consult your physician before further exposing
yourself to cold and vibration.
Maintain footing and balance at all times. DO NOT stand on slippery, uneven or unstable surfaces. DO
NOT work in odd positions or on ladders. DO NOT over reach.
Use only XtremePowerUS approved attachments. Serious injury may result from the use of a non-
approved attachment combination. XtremePowerUS will not be responsible for the failure of cutting
devices, attachments or accessories which have not been tested and approved by XtremePowerUS.
Read and comply with all safety instructions listed in this manual and safety manual.

2
SAVE THESE WARNINGS
IMPORTANT SAFETY INFORMATION
Check unit for loose/missing nuts, bolts, and screws. Tighten and/or replace as needed. Check that the
cutting attachment is rmly attached and in safe operating condition. Dull, loose or damaged blades
should not be used.
Moving parts can amputate ngers or cause severe injuries. Keep hands, clothing and loose objects away
from all openings.
DO NOT start or operate unit unless all guards and protective covers are properly assembled to unit.
NEVER reach into any opening while the engine is running. Moving parts may not be visible through
openings.
Check fuel system for leaks due to fuel tank damage, especially if the unit is dropped. If damage or leaks
are found, DO NOT use unit, otherwise serious personal injury or property damage may occur.
NEVER store cans of fuel or rell the tank in any place where there is a boiler, stove, re, sparks or
anything that can ignite the fuel.
When relling the tank, always turn off the engine rst and make sure there are no sparks or open ames
present.
If any fuel spillage occurs during refuelling , use a dry rag to wipe up any spills before turning the engine
back on.
After refuelling, screw the fuel cap back tightly onto the fuel tank and then carry the hedge trimmer to a
spot three meters or more away from where it was refuelled before turning on the engine.
This trimmer is equipped with a centrifugal clutch. The blade doesn’t rotate in a state of idling.
Grip the handles rmly with both hands when the engine is running. Always be sure to maintain steady,
even posture while working.
NEVER touch the spark plug and wire while the engine is in operation.
While operating and stopping the machine, NEVER touch the mufer, spark plug and other metal parts.

3
PRODUCT INFORMATION / PARTS LIST
SPECIFICATIONS
NOTE: Specications are subject to change without notice.

PRODUCT INFORMATION / PARTS LIST OPERATION
WARNING: Using pure gasoline will damage the engine. When relling, make sure the fuel is the correct
MIXING FUEL
2. Pour in the rest of gasoline and agitate it again for at least a minute. Some oils may be more difcult to
agitate than others depending on their ingredients. Failure to fully agitate the oil can result in piston seizing.
1. Press the primer pump until the fuel goes back into the fuel tank.
4
WARNING: Fuel will corrode if it is under the inuence of UV or high temperatures for extended periods.
Mixed fuel should be used within 30 days.
WARNING: Using fuel with water will corrode the engine and carburetor. NEVER allow water to enter the fuel
tank.
IMPORTANT: Measure out the quantities of gasoline and oil to be mixed is 40:1.
1. Put the gasoline in a clean container. Pour in all the oil and agitate it well.
IMPORTANT: Make sure to select bare ground for fuelling. Make sure the fuel tank is fastened securely. Wipe
up all spills before starting the engine.
IMPORTANT: Before starting the engine, move at least 3 meters away from the fuelling site. Make sure
to inspect the entire unit for loose ttings and fuel leakage. Make sure the cutting attachment is properly
installed and securely fastened.
When starting the engine, place it on the ground in a at, clear area and hold it rmly in place so as to ensure
that the cutting part doesn’t contact any obstacles.
The cutting attachment will begin to rotate as soon as the engine is started by putting the throttle to the
START position.
After starting the engine, check to make sure the cutting attachment stops rotating when the throttle is moved
fully back to its original position. If not, stop the engine and check the throttle cable and the adjusting bolt of
the carburetor. Remove the blade cover before starting.
2. Move the choke lever to the closed position.
3. Put the machine on a rm, at ground surface. At rst, slowly then pull the throttle quickly.
4. After starting the engine, return the throttle spanner.
5. Allow the engine to run for 1-2 minutes to let it warm up. When the engine is hard to start due to excess
fuel, remove the spark plug and dry it, then restart it.
STOPPING THE ENGINE
STARTING THE ENGINE
1. Release the throttle lever to allow the engine to idle for 1-2 minutes.
2. Put the stop lever in the STOP position.
3. Put the machine on a rm, at ground surface. At rst, slowly then pull the throttle quickly.
USING THE HANDLE
1. Free the handle by pulling the locking lever.
2. Turn the handle until the locking lever clicks into place.
3. When the handle is locked in its new position, now you can begin work.
WARNING: DO NOT use for trimming when the handle is pulled.

TROUBLESHOOTING and MAINTENANCE
5

MAINTENANCE and STORAGE
Air Cleaner:Every 25 hours, please remove the cleaner’s outside cover. Then clean the inside dust. When
the element is dirty, clean it in warm water and dry it before installing.
A clogged cleaner will reduce engine performance. If there is no cleaner or it is damaged or deformed,
NEVER start the machine, otherwise the engine will damage quickly.
Fuel Filter: Every 25 hours, take the lter from the fuel tank for dust cleaning. If it is dirty, replace it. The
clogged lter will reduce the engine speed and the speed is not stable. After removing the lter, use a clip to
hold the suction pipe to prevent ber or dust.
Spark Plug:The spark plug is easily clogged by carbon deposits. Every 25
hours of operation, remove the spark plug and clean the electrodes with a steel
brush. The suitable clearance of the spark plug is 0.6~0.7mm.
Gear Case: Every 20 working hours, use the grease pump to add grease to the hear case from the inlet.
Blade: Every 1-2 hours add grease to the blade.
Mending the Blade:
1. Start the engine, allow the blade to run at low speed, stagger the up and down
blade for 2mm and stop the engine.
2. After xing the unit, sharpen the cutting edges with a at or a grinder.
3. Start it again, stagger the blade for 2mm, then stop it.
4. Sharpen the side blade and sharpen the top of the blade.
Mufer:
Every 50 hours, remove the mufer, clear the inner carbon deposit with a screwdriver. At the same time clean
the carbon from the exhaust port.
IMPORTANT: Aged fuel is one of the major causes of engine starting failure. DO NOT over-tighten the tank
lid. This can damage the sealing ring.
1. While cleaning the machine, inspect every part for damage or loose parts. If found, repair it before using
the trimmer again.
STORAGE
2. Empty the fuel tank completely. Run the engine until it stops from the lack of fuel.
3. Remove the spark plug and put 2-stroke oil in the engine. Pull the starting ropes 2-3 times, replace the plug
and stop it at the contraction point.
4. Apply anti-rust oil to the metal parts such as the throttle wire. Put the cover back on the blade and keep it
indoors. Avoid putting the trimmer in damn atmospheres.
6

7
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT
HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS
QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR
DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE
UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER
ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL
PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION
OF REPLACEMENT PARTS THERETO.
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only and are not available individually
as replacement parts.
PLEASE READ THE FOLLOWING CAREFULLY
OF NOTE
PRODUCT MADE IN CHINA
