YAKUMO NOTEBOOK Q7M ENTERTAINMENT XD User manual

Yakumo Notebook
Handbuch
Deutsch, English, Français , Italiano, Espan˜ol .

I
Introduction (English)
This Concise User’s Guide introduces the main features
of your computer. The English version of this guide be-
gins on page 1. The expanded User’s Manual is on the
Device Drivers & Utilities + User’s Manual CD-ROM.
Einführung (Deutsch)
Dieses ausführliche Benutzerhandbuch führt Sie in die
Hauptfunktionen des Notebooks ein. Die deutsche Versi-
on des Handbuchs beginnt auf Seite 37. Das erweiterte
Benutzerhandbuch finden Sie auf der CD-ROM für die
Gerätetreiber und Hilfsprogramme (Device Drivers &
Utilities + User's Manual CD-ROM).
Présentation (Français)
Ce Guide Utilisateur Concis présente les fonctionnalités
principales de votre ordinateur. La version française de
ce guide commence à la page 73. Le Manuel de l'Utilisa-
teur étendu se trouve sur le CD-ROM de Pilotes & Utili-
taires + Manuel de l'Utilisateur (Device Drivers &
Utilities + User's Manual CD-ROM).
Introducción (Español)
Esta Guía del usuario concisa le presenta las característi-
cas principales de su ordenador. La versión española de
esta guía comienza en la página 109. El Manual del usua-
rio completo se encuentra en el CD-ROM de Controla-
dores del dispositivo y Utilidades + Manual del usuario
(Device Drivers & Utilities + User's Manual CD-ROM).
Introduzione (Italiano)
La presente Guida rapida per l'utente introduce le carat-
teristiche principali del computer. La versione italiana di
questa guida inizia da pagina 145. Il Manuale utente
completo si trova nel CD contenente driver e utilità +
Manuale utente (Device Drivers & Utilities + User's Ma-
nual CD-ROM).

II
Contents
Notice ................................................................................................1
About this Concise User Guide .........................................................2
Instructions for Care and Operation ..................................................3
Quick Start Guide .............................................................................8
Not Included ......................................................................................9
System Map: Top View with LCD Panel Open ..............................10
System Map: Front View ................................................................13
System Map: Left View ..................................................................14
System Map: Right & Rear Views ..................................................15
System Map: Bottom View .............................................................16
Optional Modules ............................................................................17
Video Features ................................................................................19
Power Management Features ..........................................................22
Driver Installation ...........................................................................23
Troubleshooting ..............................................................................30
Hyper-Threading .............................................................................32
Specifications ..................................................................................33
Inhalt
Hinweis ...........................................................................................37
Über das ausführliche Benutzerhandbuch ......................................38
Hinweise zu Pflege und Betrieb ......................................................39
Schnellstart ......................................................................................44
Systemübersicht: Ansicht von oben mit geöffnetem
LCD-Bildschirm ..............................................................................46
Systemübersicht: Ansicht von vorne ...............................................49
Systemübersicht: Ansicht von links ................................................50
Systemübersicht: Ansicht von rechts und Rückansicht ...................51
Systemübersicht: Ansicht von unten ...............................................52
Optionale Module ............................................................................53
Grafikfunktionen .............................................................................55
Energieverwaltungsfunktionen ........................................................58
Installation der Treiber ....................................................................59
Fehlerbehebung ...............................................................................66
Hyper-Threading .............................................................................68
Technische Daten ............................................................................69
Sommaire
Avertissement ..................................................................................73
A propos de ce Guide Utilisateur Concis ........................................74
Instructions d’Entretien et d’Utilisation ..........................................75
Guide de Démarrage Rapide ...........................................................80
Carte du Système : Vue du Dessus avec l’écran LCD Ouvert ........82
Carte du Système : Vue De Face .....................................................85
Carte du Système : Vue Gauche ......................................................86
Carte du Système : Vues Droite & Arrière .....................................87
Carte du Système : Vue d’en Dessous ............................................88
Modules Optionnels ........................................................................89
Caractéristiques Vidéo ....................................................................91

III
Caractéristiques de Gestion de l’Alimentation ...............................94
Installation du Pilote .......................................................................95
Dépannage .....................................................................................102
Hyper-Threading ...........................................................................104
Spécifications ................................................................................105
Contenidos
Aviso .............................................................................................109
Acerca de esta Guía del usuario concisa .......................................110
Instrucciones para el cuidado y funcionamiento ...........................111
Guía de inicio rápido .....................................................................116
No incluido ....................................................................................117
Mapa del sistema: Vista superior con el panel LCD abierto ........118
Mapa del sistema: Vista frontal ....................................................121
Mapa del sistema: Vista izquierda ................................................122
Mapa del sistema: Vistas derecha y posterior ...............................123
Mapa del sistema: Vista inferior ...................................................124
Módulos opcionales ......................................................................125
Características de vídeo ................................................................127
Funciones de administración de energía .......................................130
Instalación del controlador ............................................................131
Solución de problemas ..................................................................138
Hyper-Threading ...........................................................................140
Especificaciones ............................................................................141
Sommario
Avviso ...........................................................................................145
Informazioni sulla Guida rapida per l'utente .................................146
Istruzioni per la custodia e il funzionamento ................................147
Guida rapida ..................................................................................152
Elementi non inclusi ......................................................................153
Mappa del sistema: vista superiore con schermo LCD aperto ......154
Mappa del sistema: Vista anteriore ...............................................157
Mappa del sistema: Vista sinistra ..................................................158
Mappa del sistema: Vista posteriore e destra ................................159
Mappa del sistema: Vista inferiore ................................................160
Moduli opzionali ...........................................................................161
Funzionalità video .........................................................................163
Funzioni di Risparmio energia ......................................................166
Installazione dei driver ..................................................................167
Risoluzione dei problemi ..............................................................174
Hyper Threading ...........................................................................176
Specifiche tecniche ........................................................................177

Notice - 1
Concise User’s Guide
English
Notice
The company reserves the right to revise this publication or to change its contents without notice. Information con-
tained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any sub-
sequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this
publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this pub-
lication.
This publication and any accompanying software may not, in whole or in part, be reproduced, translated, transmitted
or reduced to any machine readable form without prior consent from the vendor, manufacturer or creators of this pub-
lication, except for copies kept by the user for backup purposes.
Brand and product names mentioned in this publication may or may not be copyrights and/or registered trademarks
of their respective companies. They are mentioned for identification purposes only and are not intended as an endorse-
ment of that product or its manufacturer.
©June 2003
Trademarks
This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents
and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copy-
right protection technology must be authorized by Macrovision Corporation, and is intended for home or other limited
viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is
prohibited.
Intel and Pentium are registered trademarks of Intel Corporation.

2 - About this Concise User Guide
Concise User’s Guide
English
About this Concise User Guide
This quick guide is a brief introduction to getting your system started. This is a supplement, and not a substitute for
the expanded User’s Manual supplied with your computer. The Device Drivers & Utilities + User’s Manual CD-
ROM contains the drivers and utilities necessary for the proper operation of the notebook, and also contains the User’s
Manual in Adobe Acrobat format.
Some or all of the computer’s features may already have been setup. If they aren’t, or you are planning to re-configure
(or re-install) portions of the system, refer to the expanded User’s Manual. The Device Drivers & Utilities + User’s
Manual CD-ROM does not contain an operating system.
Regulatory Information
Regulatory notices and information are contained in the expanded User’s Manual on the Device Drivers & Utilities
+ User’s Manual CD-ROM.

Instructions for Care and Operation - 3
Concise User’s Guide
English
Instructions for Care and Operation
The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions:
1. Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged.
2. Keep it dry, and don’t overheat it. Keep the computer and power supply away from any kind of heating element. This
is an electrical appliance. If water or any other liquid gets into it, the computer could be badly damaged.
Do not expose the computer
to any shock or vibration.
Do not place it on an unstable
surface.
Do not place anything heavy
on the computer.
Do not expose it to excessive
heat or direct sunlight.
Do not leave it in a place where
foreign matter or moisture may
affect the system.
Don’t use or store the computer
in a humid environment.
Do not place the computer on
any surface which will block the
vents.

4 - Instructions for Care and Operation
Concise User’s Guide
English
3. Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong
magnetic fields. These can hinder proper performance and damage your data.
4. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save
your work. Remember to periodically save your data as data may be lost if the battery is depleted.
5. Take care when using peripheral devices.
Do not turn off the power until
you properly shut down all pro-
grams.
Do not turn off any peripheral
devices when the computer is
on.
Do not disassemble the com-
puter by yourself.
Perform routine maintenance
on your computer.
Use only approved brands of
peripherals.
Unplug the power cord before
attaching peripheral devices.

Instructions for Care and Operation - 5
Concise User’s Guide
English
Power Safety
The computer has specific power requirements:
• Only use a power adapter approved for use with this computer.
• Your AC adapter may be designed for international travel but it still requires a steady,
uninterrupted power supply. If you are unsure of your local power specifications, con-
sult your service representative or local power company.
• The power adapter may have either a 2-prong or a 3-prong grounded plug. The third
prong is an important safety feature; do not defeat its purpose. If you do not have access
to a compatible outlet, have a qualified electrician install one.
• When you want to unplug the power cord, be sure to disconnect it by the plug head, not
by its wire.
• Make sure the socket and any extension cord(s) you use can support the total current
load of all the connected devices.
• Before cleaning the computer, make sure it is disconnected from any external power
supplies.
Do not plug in the power
cord if you are wet.
Do not use the power cord if
it is broken.
Do not place heavy objects
on the power cord.

Power Safety Warning
Before you undertake
any upgrade proce-
dures, make sure that
you have turned off the
power, and disconnect-
ed all peripherals and
cables (including tele-
phone lines). It is advis-
able to also remove your
battery in order to pre-
vent accidentally turning
the machine on.

6 - Instructions for Care and Operation
Concise User’s Guide
English
Battery Precautions
• Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer.
• Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode.
• Do not try to repair a battery pack. Refer any battery pack repair or replacement to your service representative or qual-
ified service personnel.
• Keep children away from, and promptly dispose of a damaged battery. Always dispose of batteries carefully. Batteries
may explode or leak if exposed to fire, or improperly handled or discarded.
• Keep the battery away from metal appliances.
• Affix tape to the battery contacts before disposing of the battery.
• Do not touch the battery contacts with your hands or metal objects.

Battery Disposal
The product that you have purchased contains a rechargeable battery. The battery is recyclable. At the end of its useful
life, under various state and local laws, it may be illegal to dispose of this battery into the municipal waste stream. Check
with your local solid waste officials for details in your area for recycling options or proper disposal.
Caution
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by
the manufacturer. Discard used battery according to the manufacturer’s instructions.

Instructions for Care and Operation - 7
Concise User’s Guide
English
Cleaning
• Do not apply cleaner directly to the computer, use a soft clean cloth.
• Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer.
Servicing
Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the com-
puter to electric shock. Refer all servicing to authorized service personnel. Unplug the computer from the power sup-
ply. Refer servicing to qualified service personnel under any of the following conditions:
• When the power cord is damaged or frayed.
• If the computer has been exposed to rain or other liquids.
• If the computer does not work normally when you follow the operating instructions.
• If the computer has been dropped or damaged (do not touch the poisonous liquid if the LCD panel breaks).
• If there is an unusual odor, heat or smoke coming from your computer.

8 - Quick Start Guide
Concise User’s Guide
English
Quick Start Guide
This guide assumes that you are already familiar with computers and can tell at a glance what and where all the key
components are. If you are not that comfortable with this type of device, then please refer to the following pages,
which give an overview of the system. You can review these steps, before taking any action.
1. Remove all packing materials, CDs/DVDs,
floppy disks, and any PC Cards.
2. Securely attach any peripherals you want to use
with the notebook (e.g. keyboard and mouse)
to their ports.
3. Attach the AC adapter to the DC-In jack at the
rear of the computer (see “Rear View” on
page 15), then plug the AC power cord into an
outlet, and connect the AC power cord to the
AC adapter.
4. Raise the lid/LCD to a comfortable viewing
angle.
5. Press the power button to turn “on”.

Peripheral Devices
Please note that peripherals (printers, digital cameras, etc.) which at-
tach to your computer by either USB or Mini-IEEE 1394 ports may be
connected after Windows is up and running. All other peripherals
must be connected before you turn on the system.

Not Included - 9
Concise User’s Guide
English
Not Included
Operating Systems (e.g. Windows XP) have their own manuals as do applications (e.g. word processing, spreadsheet
and database programs). If you have questions about the operating systems or programs then please consult the ap-
propriate manuals.
System Software
Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-
configuring your computer for a different system, you will find this manual refers to the Microsoft Windows XP op-
erating system. Further information on installing the drivers and utilities is available in Chapters 4 & 7 of the expand-
ed User’s Manual on the Device Drivers & Utilities + User’s Manual CD-ROM.

10 - System Map: Top View with LCD Panel Open
Concise User’s Guide
English
System Map: Top View with LCD Panel Open
The following pages are a general map of the system’s features. Detailed descriptions of the functions, setup and sys-
tem controls are covered in the expanded User’s Manual.
2
1
9
6
4
58
3
Figure 1
Top View with
LCD Panel Open
1. Optional PC Camera
2. LCD Panel
3. Built-In Microphone
4. LED Power &
Communication
Indicators
5. LED Status
Indicators
6. Hot-Key Buttons
7. Close Cover Switch
8. Power Button
9. Keyboard
10. TouchPad and
Buttons
11. Built-In Speakers
11
10
7
11

Concise User’s Guide
System Map: Top View with LCD Panel Open - 11
English
LED Power & Communication
Indicators
LED Status Indicators
Icon Color Description
Green The computer is on.
Blinking Green The computer is in Standby
mode.
Orange The battery is being charged.
Green The battery is fully charged.
Blinking Orange The battery has reached critically
low power status.
Blinking Half
Orange/ Half
Green
The battery has a serious
problem.
Blinking Green New mail has arrived.
Fast Blinking
Green
New mail has arrived from users
defined in the Special Group in
Auto Mail Checker.
Green The (optional) Wireless LAN
module is On.
Orange The (optional) Bluetooth module
is On.
Half Orange/Half
Green
Both the (optional) Wireless LAN
and Bluetooth modules are On.
Icon Color Description
Green The floppy/hard disk/CD device is in
use.
Green The numeric keypad is enabled.
Green Caps Lock is activated.
Green Scroll Lock is activated.
(to activate press Fn & Scr Lk)

Concise User’s Guide
12 - System Map: Top View with LCD Panel Open
English
Function Keys & Numeric Keypad
Function Keys
On the bottom-left of the keyboard is the Fn key or
Function key. The Fn key allows you to change oper-
ational features instantly. To use the functions press
and hold the Fn key, then press the appropriate func-
tion key (F3 - F9 etc.) located on your keyboard.
Numeric Keypad
The keyboard includes a numerical keypad (on the
right side of the keyboard) for easy numeric data input.
Activate the Number Lock feature by pressing the
Num Lk key at the top right of the keyboard.
Figure 2 - Function Keys & Numeric Keypad Hot-Key Buttons
Numeric Keypad
Fn Key
Function Keys
NumLk & ScrLk Keys
Keys Description
Fn Function Key
Fn + F3 Mute Toggle
Fn + F4 Sleep/Resume Toggle
Fn + F5 Decrease Audio Volume
Fn + F6 Increase Audio Volume
Fn + F7 Display Toggle
Fn + F8 Decrease LCD Brightness
Fn + F9 Increase LCD Brightness
Fn + F12 Multiple Wireless Modules Toggle
Fn + Scr Lk Scroll Lock Toggle
Hot-Key Function
Activate the default e-mail program.
Activate the default Internet browser.
Activate the user specified application e.g.
Microsoft Word or Excel.

System Map: Front View - 13
Concise User’s Guide
English
System Map: Front View
5 6 7
1
2
1
3
9 9

Infrared Communication
The Infrared transceiver operates on a
“Line of Sight”. Make sure nothing is
blocking the “Line of Sight” between your
system’s transceiver and the destina-
tion’s transceiver.
IEEE 1394
The Mini-IEEE 1394 port only supports
SELF POWERED IEEE 1394 devices.
Figure 3
Front View
1. LCD Latches
2. Consumer Infrared
Transceiver
(functions with the
optional TV Tuner)
3. Mini- IEEE 1394
Port
4. S/PDIF Out Port
5. Microphone-In Jack
6. Headphone-Out
Jack
7. Infrared Transceiver
8. Wireless Module
ON/OFF Switch
9. Built-In Speakers

Wireless Device Operation Aboard Aircraft
The use of any portable electronic transmis-
sion devices aboard aircraft is usually prohib-
ited. Make sure the modules are OFF if you
are using the computer aboard aircraft.
Communication Conflict
Do not try to use the 802.11b Wireless LAN
module and the Bluetooth module at the same
time, as this may cause a communication con-
flict.
4 8

14 - System Map: Left View
Concise User’s Guide
English
System Map: Left View
Figure 4
Left View
1. CD Device Bay
2. Emergency Eject
Hole
3. USB 2.0/1.1 Port
4. Floppy Disk Drive
5. PC Card Slot
6. PC Card Slot Eject
Button

Media Warning
Don’t try to remove a
floppy disk/CD while the
system is accessing it.
This may cause the sys-
tem to “crash”.
3
4
1 2
5 6

CD Emergency Eject
If you need to manually eject a CD/DVD (e.g. due to an unexpected power interruption)
you may push the end of a straightened paper clip into the emergency eject hole. Do
not use a sharpened pencil or similar object that may break and become lodged in the
hole.
DVD Regional Codes
DVD region detection is device dependent, not OS-dependent. You can select your
module’s region code 5 times. The fifth selection is permanent. This cannot be altered
even if you change your operating system or you use the module in another computer.

System Map: Right & Rear Views - 15
Concise User’s Guide
English
System Map: Right & Rear Views
Figure 5
Right View
1. Security Lock Slot
Figure 6
Rear View
1. Vent
2. DC-In Jack
3. 2 * USB 2.0/1.1 Ports
4. External Monitor
(CRT) Port
5. Parallel Port
6. Serial Port
7. S-Video-Out Port
8. PS/2 Type Port
9. RJ-11 Phone Jack
10. RJ-45 LAN Jack
3 4 5 6 7 8 9
12

Overheating
To prevent your comput-
er from overheating
make sure nothing
blocks the vent/fan out-
let while the computer is
in use.
1
10
1
