Yamaha A-S2100 User manual

eYAMAHA
A-52100
IntegratedAmplifier
AmplificateurIntegre
OWNER'S MANUAL
MODE D'EMPLOI

2En
A Living Tradition in Sound
A piano comes into this world through the perfect synergy
of
advanced technical
skill and artistry. Such a piano can create sound that truly reflects the player's
feelings.
The final stage in piano production is called "voicing". It is here that the
instrument is given its soul.
A highly skilled expert concentrates his mind and sensitivity on the sound
of
each
key, finely adjusting the dynamic feel
of
the hammers, bringing the tone and
vibrancy
of
all 88 keys together perfectly; a truly stunning achievement.
It is a quality
of
sound that can only be determined by
an
astute, sensitive ear. We
apply this very same concept to the manufacture
of
our audio products. The
technician performs exhaustive listening tests and every component is considered,
in order to finally achieve the ideal sound.
Yamaha's tradition
of
audio quality stretches back over 125 years, and continues to
Jive
on in all Yamaha products today.

1920-
1960s
1970s
1980s
1990s
2000s
2010s
Excellence
in
Audio Achievement
FirstHiFi System introduced in
1920
We
introduced numerous HiFi components
(turntables, FMJAM tuners, integrated
amplifiers, preamplifiers, power amplifiers
and speakers) in 1955- 1965.
Natural Sound SpeakerSeries introduced
in
1967
NS-20 Monitor Speaker
CA-1000 Integrated Amplifier
F
ea
turing A-Class operation, the CA-1000 set
the standard for integrated amplifiers.
NS-690 Natural Sound Speaker
NS-1
OOOM
Monitor Speaker
A truly legendary speaker still rev
ere
d by HiFi
enthusiasts.
8-1 Power Amplifier
An
innovative pow
er
amp that used vertical FETs in all
stag
es
.
C-2 Control Amplifier
Received top prize at the Milan Interna
ti
onal Music
and HiFi Sho
w.
NS-10M Studio Monitor Speaker
Became
of
the most popular studio monitors
in
the world.
A-1
Integrated Amplifier
PX-2 Thrntable
Ya
mah
a's
first straight arm turntable.
8-6
PowerAmplifier
P
y
r
a
mid~sh
a
p
e
d
power amplifier.
GT-2000/LThrntable
NS-
20
NS-
690
B-1
B-6
FirstCD Player(CD-1) introduced in
1983
MX-1
0000
CA
-
1000
NS-1
000
M
C-2
NS
-1
0M
A-
1
B-
2x
-
-
--
~-
-
~
--
•
- -
--
::::
1!
8-2x
Power Amplifier
cx
-1
oo
oo
MX-10000Power Amplifier
and
CX-10000 Control Amplifier
Redefined the
ca
pabilities of separate
co
mponents.
AX-1 Integrated Amplifier
GT
-
CD1
CD Player
MX-1 Power Amplifier and
CX-1 Preamplifier
Soavo-1
and
Soavo-2 Natural Sound
Speaker Systems
A-S2000 Integrated Amplifier and
CD-S2000 CD Player
NP-S2000 Network Player
A-S3000 Integrated Amplifier
and
CD-S3000 CD Play
er
NP-S
2
000
A-
S3
000
S
oa
v
o-1
C
D-
53
000
3En

A-52100
+ Fullfloating
and
balancedcircuitdesign achieves the
full
potential
of
analogue amplification
An
entirely new floating and balanced power amplifier achieves complete symmetry and permits full balanced
transmission (amplification) from the input
jack
to just before the speakerjack.
+ Full-stage balancedsignaltransmission
The integrated amplifier offers full stage balanced transmission, combining high power output with good sound texture
and outstanding
SIN
performance.
+ Parallel volume
and
tone control
+ Largepower supply with
four
separate circuits
+ Left-rightsymmetrical design with rigid, stable construction
+ Discrete phono amplifier
+ High-quality headphone amplifier with low-impedance drive
• Supplied accessories
Please check that you have received all
of
the following parts.
• Remote control
• Batteries (AAA, R03, UM-4) (x
2)
• Power cable
• SAFETY BROCHURE
Contents
Controls
and
functions.......................................•......................................................•........................................... 6
Connections.......................................................................................................................................................... 16
Specifications...........................................•........................................................................................••................. 24
Troubleshooting........................................................................•.......................................................................... 28
•
About
this
manual
•
o<il<
indicates a tip for your operation.
• Photographs and illustrations are for explanatory purposes, and may differ from the actual unit.
• Read the "SAFETY BROCHURE" before using this unit.
4En

Controls and
functions
In
this
chapter, you
will
learn the
controls
and
functions
of
A-52100.

• Front panel (pages 6 to 9)
@YAMAHA
STANDBY/ON PHONES -- TRIM SPEAKERS METER
OFF
A B OFF
oPEfK o VU
0 ° 0
...
(g
cBI·WIRUtG
OFF
dB
""==
4
CD STANDBY/ON, OFF switch
Turns on or off this unit.
5 6
STANDBY/ON (upper position): In this position,
you can select STANDBY orON,
using the
<.9 AMP key on the remote control.
OFF (Jower position): The power of this unit is
turned off.
: : r2f!$ ~
• When you turn on this unit, it will take a few seconds
before this unit can reproduce sound.
•
If you disconnectthe power cable from the AC outlet and
connect
it again when this unit is in STANDBY mode, the
power
of the unit is turned on. If the unit is not to be
operated for a long time, set the STANDBY/ON, OFF
switch to OFF.
® STANDBY/ON indicator
Lit brightly: Shows that the power of the unit is ON.
In this condition, you can switchthe unit to
STANDBY mode by pressing the
<.9 AMP key on
the remote control.
Lit dimly: Shows that the unit is in STANDBY mode.
6En
In this condition, you can switch the unit on by
pressing the <.9 AMP key on the remote control.
LEFT RIGHT
-50 -40 -30 -20 -10 0 +6
\\\1\11/ // //
-50 -40 -30 -20 -10 0 •6
\\\\\111111/
7
dB dB
BASS TREBLE BALANCE
_o
0
_o
0+
L
' 'R +
8 9
10
Off: Shows that the power of the unit is OFF. In this
condition, you can turn the power on only
by
pressing the STANDBY/ON, OFF switch on the
front panel.
@ PHONES jack
Outputs audio for private listening with headphones.
• When headphones are plugged in:
-Both speaker setsconnectedtothe SPEAKERS L/R CH
terminals are turned off.
-No signals are output at the PRE OUTjacks.
-You cannot select MAIN DIRECT as the input source.
• lfheadphones are plugged into the PHONES
jack while
MAINDIRECT is selected as the input source, no audio is
output at the PHONES jack.

@
TRIM selector
Adjusts the volume level when headphones are
plugged in to avoid sudtilen changes
in
volume.
Choices:
-6
dB, 0 dB,
+6
dB, +12
dB
®
SPEAKERS selector
Turns
on
or
off
the sets
of
speakers connected to the
SPEAKERS L/R CH A and/
or
B terminals on the rear
panel, as follows.
OFF: Both sets
of
speakers are off.
AlB: The set
of
speakers connectedto the A or B
terminals is on.
A+B BI-WIRING: Both sets
of
speakers are on.
Caution
If
you usetwo sets (A and B), the impedance
of
each speaker
must
be
8 Q
or
higher.
®
METER selector
Switches the display
of
the meter to OFF, PEAK or
vu.
OFF: Turns
off
the meter and the illumination.
PEAK: Switches the meterto a peak level meter. The
peak level meter shows a momentarily highest
audio output level.
VU:
Switches the meter to a VU (Volume Unit) level
meter. The
VU
level meter shows
an
effective
audio output value that is similar to human senses.
(]) Meter displays (LEFT/RIGHT)
Show the audio output level
of
the left (LEFT) and
right (RIGHT) channels in VU
or
PEAK meter mode.
The VU or PEAK meter can be selected by the
METER selector.
®
BASS control
Increases or decreases the low frequency response.
The 0 position produces a flat response.
Control range:
-10
dB to
+
10 dB
®
TREBLE control
Increases or decreases the high frequency response.
The 0 position produces a flat response.
Control range:
-10
dB to
+
10
dB
@
BALANCE control
Adjusts the audio output balance
of
the left and right
speakers to compensate for sound imbalances caused
by speaker locations
or
listening room conditions.
• When both the BASS and TREBLE controls are set to the 0
position, audio signal bypasses the tone control circuitry.
•
The
BASS, TREBLE and BALANCE controls do not affect the
signals input at the MAIN
IN
jacks and signals output at the
LINE 2 RECjacks.
7En I

• Front panel (pages 6 to 9)
@YAMAHA
~~--------------------------------·1------
11
@ Remote control sensor
Receives signals from the remote control.
@ INPUT selector/indicator
Selects the input source to be played back. The
indicator
of the input source selected with the INPUT
selector lights.
The audio signals
of the selected input source are also
output at the LINE 2 REC jacks.
MAIN DIRECT: Selects the componentconnectedto
the MAIN INjacks.
When MAIN DIRECT is selected as the input
source, the audio signals are not output at the PRE
OUT, LINE 2 REC and PHONES jacks.
LINE 1/LINE 2: Selects the component connected to
the LINE 1 or LINE 2 jacks.
8En
BAL: Selects the component connected to the BAL
jacks (balanced XLRjacks).
CD: Selects the CD player connected to the CD jacks
(unbalanced RCAjacks).
TUNER: Selects the tuner connected to the TUNER
jacks.
PHONO: Selectsthe turntable connected to the
PHONOjacks.
When LINE 2 is selected, the audio signals are not output at
the LINE 2 RECjacks.

VOLUME
PHONO AUDIO MUTE
MM
MC
_ __,7
13
14 15 16
@ PHONO switch
Selects the type of cartridge of the turntable connected
to the
PHONO jacks on the rearpaneL
MM: Choose this setting if the connected turntable
uses
an moving magnet (MM) cartridge.
MC: Choose this setting if the connected turntable
uses
an moving coil (MC) cartridge.
,,,
~<i>-=-
When you replace the cartridge, be sure to rum off this unit.
@ AUDIO MUTE switch
Press downwardto reduce the current volume level by
approximately 20 dB. Press againto restore the audio
output
to the previous volume level.
,,,
~<i>-=-
You can also rotate the VOLUME control on the front panel
orpress the
VOLUME+ or -key on the remote control to
resume the audio output.
@ AUDIO MUTE indicator
Lights when the mute function is turned on with the
AUDIO MUTE switch.
@ VOLUME control
Controls the volume level. This does not affectthe
output level at the LINE 2 REC jacks.
The VOLUME control does not affect when you select
MAIN DIRECT as the input source. Adjust the volume level
using the volume control
on the external amplifierconnected
to theMAIN INjacks.
9 En I

• Rear panel
L--------rt=======~
..
~.U~T======~r~NORMAL(E'"",.-,
----I----
See
page
16 for connection information.
CD
BAL (balanced) input jacks
One set
ofbalanced
input
jacks
isprovided.
Set the ATfENUATOR selector and PHASE selector
appropriately for the playback component that is
connected. For details on these switches, refer to page 20.
® PRE
OUT
jacks
:-'ci'~
• The
PRE
OUTjacks output the same channel signal as the
SPEAKERS L/R
CH
terminals.
• When you connect a stereo cable
to
the PRE
OUT
jacks to
drive the speakers usingan external amplifier,
it
is not
necessary
to
use the SPEAKERS
L/R
CH
terminals.
• The signal output at the
PRE
OUTjacks are affected by the
BASS and TREBLE control settings.
@
SPEAKERS
LJR
CH terminals
0
TUNER input jacks
10En
ATTENUATOR
PHASE w
BYPASS
1
riiTT·
-
1
riNV.
+HOT
, GND
1·
6dB)
Q} Q}
·COLD
LINE2-,
®
PHONO input jacks
®
CD
input jacks
(j)
GND (Ground) terminal
®
LINE 1 input jacks
®
LINE 2 jacks
I
PB(playback) input
jacks
andREC (recording) output
jacks
are provided.
@)
MAIN IN jacks
Use these
jacks
to connect
an
external component
equipped with a volume control.
~'4'-:
When
you
select MAIN DIRECT as the input source, the
volume level is fixed.
Adjust the volume level using the volume control
on
the
external amplifierconnected
to
theMAIN IN
jack
s whenyou
select
MAIN
DIRECT as the input source.
Forthe connection to the
MAIN
IN
ja
cks, see pages 16 and
17
.

® AUTO POWER STANDBY switch
ON: The unit enters STANDBY mode automatically
if not operated for 8 hours.
OFF: The unit does not enter STANDBY mode
automatically.
@ TRIGGER IN jack
Usethis
jack to connect anexternal component for the
trigger function.
For details on the connection, see page 22.
@ REMOTE IN/OUT jacks
Use these
jacks to connect an external component for
remote control.
For details on the connection, seepage 21.
@ SYSTEM CONNECTOR
Use this connectorto connect a product testing device
for servicing.
@ AC IN inlet
Use this inlet to plug
in the supplied power cable.
For details on the connection, see page 19.
@Foot
The feet of this unit include built-in spikes. Using the
spikes can reduce the effect
of vibrations on the set.
Whenusing the spikes, removethe transporttape, then
remove the magnet foot
by pulling it.
Transport ---¥\
tape
Caution
¢~··;~
~Magnet
foot
• Take care that the magnet foot is not accidentally
swallowed by small children.
• When using the feet's built-in spikes, the spikes may
scratch the shelforfloor
on which this unit is installed. Use
the magnet feet or appropriate supports whenplacing this
unit
on expensive furniture, etc.
,,,
:<t>~
If this unitis unstable, you can adjust the foot height by
rotating it.
11 En I

• Remote control
12En
AMP
OPEN/CLOSE
CD
®---f--0
0
0+~
BAL
0
LINE 1 LINE 2
0 0
PHONO
MAIN
DIRECT
0 0
CD
TUNER
0 0
BAND
4)---+---1
0
I
0-PRESET-0
~
DD
D
-=====
SOURCE LAYER
0 0
8
VOLUME
1---:---<8
8
MUTE
O
r--
--;-----®
CD
Infrared
signal
transmitter
Outputs infrared control signals.
®
(!)AMP
key
Turns this unit ON or switches it to STANDBY mode.
For details
on
STANDBY mode, see "Front panel"
(page 6).
@
Input
select
keys
Selects the input source to be played back.
The audio signals
of
the selected input source are
output at the LINE 2 RECjacks.
,,,
:<i>~
When LINE 2 is selected as the input source, the audio
signals are not output at the LINE 2 RECjacks.
BAL: Selects the component connected to the BAL
jacks (balanced XLRjacks).
LINE:
Selects the component connected to the
LINE
I
or LINE 2 jacks.
PHONO:
Selects the turntable connected to the
PHONOjacks.
MAIN
DIRECT:
Selectsthe component connectedto
the MAIN
IN
jacks. When MAIN DIRECT is
selected as the input source, the audio signals are
not output at the PRE OUT, LINE 2 REC and
PHONES jacks.
CD: Selects the CDplayer connected to the CDjacks
(unbalanced RCA jacks).
TUNER:
Selects the tuner connected to the TUNER
jacks
G)
Yamaha
tuner
control
buttons
Control functions
of
Yamaha tuner. Refer to the
owner's manual
of
your tuner for details.
Some Yamaha tuners cannot
be
controlled by this remote
control.

@<!)CD
key
Turns the Yamaha
CD
player ON or switches it to
STANDBY mode.
@
~
OPEN/CLOSE key
Opens/closes the disc tray
of
the Yamaha CD player.
Refer to the owner's manual
of
your CD player for
details.
Some Yamaha
CD
players do not support the
<!)
CD
key and/
or~
OPEN/CLOSE key
of
this remote control.
(j)
Yamaha CD player control keys
Control various functions
of
Yamaha CDplayer. Refer
to the owner's manual
of
yourCD player for details.
t>
(Play): Starts playback.
1111
(Pause): Pauses playback. Press the
1:>
or
II II
to
resume playback.
D
(Stop): Stops playback.
I<J<J I
t>t>1
(Skip): Skips to the next track,
or
skips
back to the beginning
of
the current track.
SOURCE: Selects the source to be played on the
Yamaha CD player. The playback source changes
each time this key is pressed.
LAYER: Switches the playback layer
of
a hybrid SA-
CD between SA-CD and
CD
.
..
@
VOLUME +1- keys
Control the volume level.
The VOLUME keys do not affect when you select MAIN
DIRECT as the input source. Adjust the volume level on the
external amplifier connected to the MAIN INjacks.
®MUTE key
Reduces the current volume level by approximately
20 dB. Press again
to
restore the audio output to the
previous volume level. Pressing the
VOLUME+
or-
key also cancels muting.
13En
I

• Installing batteries in the remote control
1
Remove the battery compartment cover.
2 Insert
the
two batteries (AAA,
R03,
UM-4}
according
to
the
polarity
markings(+
and-}
on
the inside
of
the battery compartment.
3 Reinstall the battery compartmentcover.
14En
• Operating range
of
the remote control
Approximately
6m
(20ft)
0
0 0
Theremote control transmits a directional infrared beam.
Be
sure to aim the remote control directly at the remote control
sensor
on
the front panel
of
this unit during operation.

Connections
In this section, you will make connections between A-521 00, speakers,
and source components.

Speakers
A
(R
channel)
Speakers B
(R
channel)
il!!iJ]
Tuner
•
Do
not let the bare speaker wires touch each other
or
do not let
them touch any metal part
of
this unit. This could damage this
unit and/orthe speakers.
• All connections must be correct: L (left)
to
L, R (right)
toR,
"+"
to"
+",
and"
- "
to
"- ".
If
th
e connections are faulty, no
sound will beheard from the speakers, and
if
the polarity
of
the
speaker connections is incorrect, the sound will
be
unnatural
and lack bass. Also, refer to the owner's manual for each
of
your components.
16En
CD
player
or
network
player with
XLR
jacks
Turntable
ATTENUATOR
BYPASS}
r~-'i<B)
0>
Ground
CD
player with
RCA jacks
PHASE
NDRMAl1fiHV
.
0>
BD
player, etc.
• Use RCA unbalanced cablesto connect other components
except speakers. Use
XLR
balanced cables toconnect a CD
player ornetwork playerwith XLR balanced output
jack
s
to
the
BALjacks
of
this unit.
• Connect your turntable to the GND terminal to reduce noise in
the signal. However, y
ou
may hear less noise without the
connection to the GNDterminal for some turntables.

External amplifier or
active subwoofer
l+l :l il .II./IP'EIIII
Preamplifier,
CD recorder,
tape deck, etc.
AV receiver, etc.
~ ~ ~ t l! f~
• Because thepower amplifier of A-S2l00 is of the floating balancedtype, the
following types
of connections are not possible.
-Connecting with theleft channel "- " terminal andthe right channel "- " terminal
as well as "+" terminals (Fig. l).
-Connecting withtheleft channel "-"terminal andthe right channel "-" terminal
inverted (cross connection, Fig.
2) .
-Deliberately connecting with the left/right channel "- " terminals and metal part
on the rear panel
of this unit, as well as accidentally touchingthem.
• Do not connect your active subwoofer to the SPEAKERS L/RCH terminal.
Connect it to the PRE OUTjacks
of this unit.
• Do not connect a component with
no volume control, such as a CD player, to the
MAIN INjacks, as the volume level
of the signals input to the MAIN INjacks is
fixed.
If such equipment is connected, a soundmay burst, and the unit and/or
speaker may
be damaged.
Fig.1
Speakers A
(L channel)
Speakers B
(L channel)
Fig.2
I
17En

• Connecting the speakers
1
Remove approximately 10 mm
of
insulation
from
the
end
of
each speaker cable
and
twist
the
exposed wires
of
the
cable
together
to
prevent
short
circuits.
2
Unscrew
the
knob
and then
insert
the
bare
wire
into
the hole.
3 Tighten the knob.
Caution
Hole
for
speakercable:
6.0 mm dia.
When looseningthe knob
of
the speaker terminal, do not rotate it
excessively. Theknob may come
off
and posethe danger
ofbeing
swallowed by a child.
• Touching the speaker terminal with a metallic rack may cause
short circuit and damage this unit. When installing the unit
in
a
rack, maintain a sufficient clearance to prevent the speaker
terminals from touching the rack.
• To reduce the risk
of
electric shock, do not touch the speaker
terminal when the unit is turned on.
18En
• Connecting the banana
plug
(Except
for
Europe models)
First,tighten
the
knob
andthen
insert
the
banana
plug
into
the
end
of
the
corresponding terminal.
~~
.
Banana
plu~
Hole
for
banana plug.
r
3.95
mm
dla.
• Connecting theY-shaped
lug
1 Unscrew
the
knob
and
then sandwich
theY-
shaped
lug
between
the
ring
part
and base.
Y·shapedlu~
¢~
2
Tighten
the
knob.
Terminal screw
for
Y-shaped
lug: 5.8 mmdia.

• Bi-wire connection
The hi-wire connection separates the woofer from the
combined midrange and tweeter section. A hi-wire
compatible speaker has four binding post terminals. These
two sets
of terminals allow the speakerto be split into two
independent sections. This split connects the mid and high
frequency drivers
to one set of terminals and the low
frequency driver to the other pair.
Example of a bi-wiring connection (R channel)
Rear panel of A-S2100 Speaker
Caution
To use the hi-wire connections, ~e impedance of each speaker
must be 8 Q
or higher.
Remove the shortingbars or bridges to separate the LPF (low
pass filter) and HPF (highpass filter) crossovers.
,,,
~<i>:O
To use the hi-wire connections, switch the SPEAKERS selector
on the front panelto the A+B BI-WIRING position.
• Connecting the power cable
Plug the power cable into the AC IN inlet when all
connections are complete, and then plug in the power
cable to the AC outlet.
Rear panel of A-S21 00
ACIN
[OJ
Supplied power cable
to an AC outlet
19En
I

• Connecting to
the
BAL jacks
Connect your CD player
or
network player with the XLR
balanced outputjacks.
Set the ATIENUATOR selector and PHASE selector
located above the BAL
jacks
according to the component
to be connected.
ATTENUATOR selector:
Select the allowable input level for the
XLR
balanced
inputjacks.
If
sound from the connected component is
distorted, setthe ATTENUATOR selectorto
ATT.
(-6 dB).
PHASE selector:
Select the assignment
of
the
HOT
pin
of
the
XLR
balanced inputjacks(pin 2
HOT
or
pin 3
HOT)
.
NORMAL (pin
2
HOT)
2: hot
-llll@l~t-
1
o
o~'•~-
y 1: ground
3: cold
INV.
(pin
3
HOT)
2: cold
-llll@l~t-'
0
o~'•~-
y 1: ground
3: hot
Refer to the owner's manual supplied withthe connected
component and verify the assignment
of
the
HOT
pin
of
its
XLR
balanced outputjacks.
,,,
.:(jl~
Yamaha
CD
players are set to NORMAL (pin 2 HOT).
20En
XLR connectors:
When connecting, be sure to match the pins and insert the
connector
of
the "male" XLRbalanced cable until you
hear a "click". When disconnecting, pull
out
the "male"
XLR
balanced cable while holding down the lever
of
the
BALjack.
"Female" XLR connector Lever
BALjack
To selectthe component connectedtothe
BAL
jacks, settheinput
source
to
BAL.
