Ibanez DP1 Quick setup guide

Preamp Information
DP1

1
➤➤
① ②
③④
DP1
Body Top
Body Back
Basic Controls
①Undersaddle Pickup VOLUME
Adjusts the volume of the Undersaddle Pickup.
②Contact Pickup VOLUME
Adjusts the volume of the Contact Pickup.
③Endpin Output Jack
④1/4" Output Jack
■Monaural Output (Fig.1)
When only plugged in to the Endpin Output Jack ③, the signals of
the Undersaddle Pickup and Contact Pickup are mixed to produce
monaural output. You can adjust the volume of each pickup using the
onboard control knobs installed on the side.
■Stereo Output (Fig.2)
When plugged into both output jacks ③and ④, the signals of the
Undersaddle Pickup ③and the Contact Pickup ④output separately.
You can adjust the volume of each pickup using the onboard control
knobs installed on the side.
* When only plugged in to the 1/4" Output Jack ④, the circuit
switches to stereo output and only the signal from the Contact Pickup
outputs.
Mix : Undersaddle Pickup + Contact Pickup
Contact Pickup
Undersaddle Pickup
Fig.1
Fig.2

2
➤➤
The battery used in the preamp must be changed regularly. If you notice any deterioration in sound quality or a
drop in volume, you need to change the batteries.
※Dispose of used batteries in accordance with local regulations.
※Appearance and specications are subject to change without notice.
Notes
