OWNER’S MANUAL
MTN1000D
BW8-28199-E00
qRead this manual carefully before operating this vehicle.
BW8-9-E0_1_Euro_E_Hyoshi.indd 1 2016/12/13 11:10:32

EAU70091
Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.
Date of issue:
Signature of Responsible Person:
April 28, 2016
Product: IMMOBILIZER
Model: 1MC-00
Supplied by
YAMAHA MOTOR ELECTRONICS
CO.,LTD.
1450-6 Mori, Mori-machi Shuchi-gun
Shizuoka 437-0292 Japan
EN 60950-1: 2006 + Amd.11:2009 + Amd.1:2010 +
Amd.12: 2011 + Amd.2:2013
EN 62479: 2010
Hiroshi Kamiiizaka
GENERAL MANAGER
QUALITY ASSURANCE DIV.
97/24/EC from 17.06.1997
EN 300 330-1 V1.8.1
EN 300 330-2 V1.6.1
Technical Construction File held by
YAMAHA MOTOR ELECTRONICS
CO.,LTD.
1450-6 Mori, Mori-machi Shuchi-gun
Shizuoka 437-0292 Japan
R&TTE Directive
(Article 3.1(a) Safety)
R&TTE Directive
(Article 3.1(b) EMC)
R&TTE Directive
(Article 3.2 Spectrum)
DECLARATION of CONFORMITY
For
YAMAHA MOTOR ELECTRONICS CO., LTD.
1450-6, Mori, Mori-machi, Shuchi-gun, Shizuoka-ken, 437-0292 Japan
Standard used for comply
Means of Conformity
We declare under our sole responsibility that the Product (s) is conformity with the essential
requirements and other relevant requirements of the
Radio and Telecommunication Terminal Equipment (R&TTE) Directive (1999/5/EC).
BW8-9-E0_1_Euro_E_Hyoshi.indd 2 2016/12/13 11:10:32

Introduction
EAU10103
Welcome to the Yamaha world of motorcycling!
As the owner of the MTN1000D, you are benefiting from Yamaha’s vast experience and newest technology regarding the
design and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.
Please take the time to read this manual thoroughly, so as to enjoy all advantages of your MTN1000D. The Owner’s Manual
does not only instruct you in how to operate, inspect and maintain your motorcycle, but also in how to safeguard yourself and
others from trouble and injury.
In addition, the many tips given in this manual will help keep your motorcycle in the best possible condition. If you have any
further questions, do not hesitate to contact your Yamaha dealer.
The Yamaha team wishes you many safe and pleasant rides. So, remember to put safety first!
Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the most cur-
rent product information available at the time of printing, there may be minor discrepancies between your motorcycle and this
manual. If there is any question concerning this manual, please consult a Yamaha dealer.
WARNING
EWA10032
Please read this manual carefully and completely before operating this motorcycle.
BW8-9-E0_1.book 1 ページ ２０１６年１２月１３日 火曜日 午前１０時３９分

Important manual information
EAU10134
Particularly important information is distinguished in this manual by the following notations:
*Product and specifications are subject to change without notice.
This is the safety alert symbol. It is used to alert you to potential personal injury
hazards. Obey all safety messages that follow this symbol to avoid possible injury
or death.
A WARNING indicates a hazardous situation which, if not avoided, could result in
death or serious injury.
A NOTICE indicates special precautions that must be taken to avoid damage to the
vehicle or other property.
A TIP provides key information to make procedures easier or clearer.
WARNING
NOTICE
TIP
BW8-9-E0_1.book 1 ページ ２０１６年１２月１３日 火曜日 午前１０時３９分

Important manual information
EAU10201
MTN1000D
OWNER’S MANUAL
©2016 by Yamaha Motor Co., Ltd.
1st edition, October 2016
All rights reserved.
Any reprinting or unauthorized use
without the written permission of
Yamaha Motor Co., Ltd.
is expressly prohibited.
Printed in Japan.
BW8-9-E0_1.book 2 ページ ２０１６年１２月１３日 火曜日 午前１０時３９分

Table of contents
Safety information ........................... 1-1
Description ....................................... 2-1
Left view ......................................... 2-1
Right view....................................... 2-2
Controls and instruments................ 2-3
Special features ............................... 3-1
YRC (Yamaha Ride Control) .......... 3-1
Glossary ......................................... 3-3
Cruise control system..................... 3-3
Instrument and control functions... 4-1
Immobilizer system......................... 4-1
Main switch/steering lock................ 4-2
Handlebar switches ........................ 4-3
Indicator lights and warning
lights............................................ 4-5
Display............................................ 4-8
MENU screen ............................... 4-13
Clutch lever................................... 4-27
Shift pedal..................................... 4-27
Brake lever ................................... 4-27
Brake pedal .................................. 4-28
ABS .............................................. 4-28
Fuel tank cap ................................ 4-29
Fuel............................................... 4-30
Fuel tank overflow hose................ 4-32
Catalytic converter........................ 4-32
Seat .............................................. 4-33
Adjusting the front fork.................. 4-33
Adjusting the shock absorber
assembly................................... 4-34
Luggage strap holders ................. 4-36
EXUP system ............................... 4-36
Auxiliary DC jack .......................... 4-36
Sidestand ..................................... 4-37
Ignition circuit cut-off system........ 4-38
For your safety – pre-operation
checks .............................................. 5-1
Operation and important riding
points................................................ 6-1
Starting the engine ......................... 6-1
Shifting ........................................... 6-2
Tips for reducing fuel
consumption ............................... 6-3
Engine break-in .............................. 6-3
Parking........................................... 6-4
Periodic maintenance and
adjustment ....................................... 7-1
Owner’s tool kits............................. 7-2
Periodic maintenance chart for the
emission control system ............. 7-3
General maintenance and
lubrication chart .......................... 7-5
Checking the spark plugs............... 7-9
Canister........................................ 7-10
Engine oil and oil filter cartridge ... 7-10
Coolant......................................... 7-13
Air filter element........................... 7-17
Checking the engine idling
speed........................................ 7-17
Checking the throttle grip free
play........................................... 7-17
Valve clearance ........................... 7-18
Tires............................................. 7-18
Cast wheels ................................. 7-20
Adjusting the clutch lever free
play........................................... 7-21
Checking the brake lever free
play........................................... 7-21
Brake light switches..................... 7-22
Checking the front and rear
brake pads................................ 7-22
Checking the brake fluid level...... 7-23
Changing the brake fluid.............. 7-24
Drive chain slack.......................... 7-24
Cleaning and lubricating the
drive chain................................ 7-26
Checking and lubricating the
cables....................................... 7-26
Checking and lubricating the
throttle grip and cable............... 7-27
Checking and lubricating the
brake and shift pedals .............. 7-27
Checking and lubricating the
brake and clutch levers ............ 7-28
Checking and lubricating the
sidestand.................................. 7-28
BW8-9-E0_1.book 1 ページ ２０１６年１２月１３日 火曜日 午前１０時３９分

Table of contents
Lubricating the swingarm
pivots......................................... 7-29
Checking the front fork ................. 7-29
Checking the steering................... 7-30
Checking the wheel bearings ....... 7-30
Battery .......................................... 7-30
Replacing the fuses...................... 7-32
Vehicle lights ................................ 7-35
Supporting the motorcycle............ 7-35
Troubleshooting............................ 7-35
Troubleshooting charts................. 7-37
Motorcycle care and storage .......... 8-1
Matte color caution ......................... 8-1
Care................................................ 8-1
Storage........................................... 8-4
Specifications .................................. 9-1
Consumer information .................. 10-1
Identification numbers .................. 10-1
Diagnostic connector.................... 10-2
Vehicle data recording.................. 10-2
Index ............................................... 11-1
BW8-9-E0_1.book 2 ページ ２０１６年１２月１３日 火曜日 午前１０時３９分

1-1
1
2
3
4
5
6
7
8
9
10
11
12
Safety information
EAU1028B
Be a Responsible Owner
As the vehicle’s owner, you are respon-
sible for the safe and proper operation
of your motorcycle.
Motorcycles are single-track vehicles.
Their safe use and operation are de-
pendent upon the use of proper riding
techniques as well as the expertise of
the operator. Every operator should
know the following requirements before
riding this motorcycle.
He or she should:
Obtain thorough instructions from
a competent source on all aspects
of motorcycle operation.
Observe the warnings and mainte-
nance requirements in this Own-
er’s Manual.
Obtain qualified training in safe
and proper riding techniques.
Obtain professional technical ser-
vice as indicated in this Owner’s
Manual and/or when made neces-
sary by mechanical conditions.
Never operate a motorcycle with-
out proper training or instruction.
Take a training course. Beginners
should receive training from a cer-
tified instructor. Contact an autho-
rized motorcycle dealer to find out
about the training courses nearest
you.
Safe Riding
Perform the pre-operation checks each
time you use the vehicle to make sure it
is in safe operating condition. Failure to
inspect or maintain the vehicle properly
increases the possibility of an accident
or equipment damage. See page 5-1
for a list of pre-operation checks.
This motorcycle is designed to car-
ry the operator and a passenger.
The failure of motorists to detect
and recognize motorcycles in traf-
fic is the predominating cause of
automobile/motorcycle accidents.
Many accidents have been caused
by an automobile driver who did
not see the motorcycle. Making
yourself conspicuous appears to
be very effective in reducing the
chance of this type of accident.
Therefore:
• Wear a brightly colored jacket.
• Use extra caution when you are
approaching and passing
through intersections, since in-
tersections are the most likely
places for motorcycle accidents
to occur.
• Ride where other motorists can
see you. Avoid riding in another
motorist’s blind spot.
• Never maintain a motorcycle
without proper knowledge. Con-
tact an authorized motorcycle
dealer to inform you on basic
motorcycle maintenance. Cer-
tain maintenance can only be
carried out by certified staff.
Many accidents involve inexperi-
enced operators. In fact, many op-
erators who have been involved in
accidents do not even have a cur-
rent motorcycle license.
• Make sure that you are qualified
and that you only lend your mo-
torcycle to other qualified opera-
tors.
• Know your skills and limits.
Staying within your limits may
help you to avoid an accident.
• We recommend that you prac-
BW8-9-E0_1.book 1 ページ ２０１６年１２月１３日 火曜日 午前１０時３９分

Safety information
1-2
1
2
3
4
5
6
7
8
9
10
11
12
tice riding your motorcycle
where there is no traffic until you
have become thoroughly famil-
iar with the motorcycle and all of
its controls.
Many accidents have been caused
by error of the motorcycle opera-
tor. A typical error made by the op-
erator is veering wide on a turn
due to excessive speed or under-
cornering (insufficient lean angle
for the speed).
• Always obey the speed limit and
never travel faster than warrant-
ed by road and traffic conditions.
• Always signal before turning or
changing lanes. Make sure that
other motorists can see you.
The posture of the operator and
passenger is important for proper
control.
• The operator should keep both
hands on the handlebar and
both feet on the operator foot-
rests during operation to main-
tain control of the motorcycle.
• The passenger should always
hold onto the operator, the seat
strap or grab bar, if equipped,
with both hands and keep both
feet on the passenger footrests.
Never carry a passenger unless
he or she can firmly place both
feet on the passenger footrests.
Never ride under the influence of
alcohol or other drugs.
This motorcycle is designed for
on-road use only. It is not suitable
for off-road use.
Protective Apparel
The majority of fatalities from motorcy-
cle accidents are the result of head in-
juries. The use of a safety helmet is the
single most critical factor in the preven-
tion or reduction of head injuries.
Always wear an approved helmet.
Wear a face shield or goggles.
Wind in your unprotected eyes
could contribute to an impairment
of vision that could delay seeing a
hazard.
The use of a jacket, heavy boots,
trousers, gloves, etc., is effective in
preventing or reducing abrasions
or lacerations.
Never wear loose-fitting clothes,
otherwise they could catch on the
control levers, footrests, or wheels
and cause injury or an accident.
Always wear protective clothing
that covers your legs, ankles, and
feet. The engine or exhaust sys-
tem become very hot during or af-
ter operation and can cause burns.
A passenger should also observe
the above precautions.
Avoid Carbon Monoxide Poisoning
All engine exhaust contains carbon
monoxide, a deadly gas. Breathing car-
bon monoxide can cause headaches,
dizziness, drowsiness, nausea, confu-
sion, and eventually death.
Carbon Monoxide is a colorless, odor-
less, tasteless gas which may be pres-
ent even if you do not see or smell any
engine exhaust. Deadly levels of car-
bon monoxide can collect rapidly and
you can quickly be overcome and un-
able to save yourself. Also, deadly lev-
els of carbon monoxide can linger for
hours or days in enclosed or poorly
ventilated areas. If you experience any
symptoms of carbon monoxide poison-
ing, leave the area immediately, get
fresh air, and SEEK MEDICAL TREAT-
BW8-9-E0_1.book 2 ページ ２０１６年１２月１３日 火曜日 午前１０時３９分

Safety information
1-3
1
2
3
4
5
6
7
8
9
10
11
12
MENT.
Do not run engine indoors. Even if
you try to ventilate engine exhaust
with fans or open windows and
doors, carbon monoxide can rap-
idly reach dangerous levels.
Do not run engine in poorly venti-
lated or partially enclosed areas
such as barns, garages, or car-
ports.
Do not run engine outdoors where
engine exhaust can be drawn into
a building through openings such
as windows and doors.
Loading
Adding accessories or cargo to your
motorcycle can adversely affect stabili-
ty and handling if the weight distribution
of the motorcycle is changed. To avoid
the possibility of an accident, use ex-
treme caution when adding cargo or
accessories to your motorcycle. Use
extra care when riding a motorcycle
that has added cargo or accessories.
Here, along with the information about
accessories below, are some general
guidelines to follow if loading cargo to
your motorcycle:
The total weight of the operator, pas-
senger, accessories and cargo must
not exceed the maximum load limit.
Operation of an overloaded vehicle
could cause an accident.
When loading within this weight limit,
keep the following in mind:
Cargo and accessory weight
should be kept as low and close to
the motorcycle as possible. Se-
curely pack your heaviest items as
close to the center of the vehicle as
possible and make sure to distrib-
ute the weight as evenly as possi-
ble on both sides of the motorcycle
to minimize imbalance or instabili-
ty.
Shifting weights can create a sud-
den imbalance. Make sure that ac-
cessories and cargo are securely
attached to the motorcycle before
riding. Check accessory mounts
and cargo restraints frequently.
• Properly adjust the suspension
for your load (suspension-ad-
justable models only), and
check the condition and pres-
sure of your tires.
• Never attach any large or heavy
items to the handlebar, front
fork, or front fender. These
items, including such cargo as
sleeping bags, duffel bags, or
tents, can create unstable han-
dling or a slow steering re-
sponse.
This vehicle is not designed to
pull a trailer or to be attached to
a sidecar.
Genuine Yamaha Accessories
Choosing accessories for your vehicle
is an important decision. Genuine
Yamaha accessories, which are avail-
able only from a Yamaha dealer, have
been designed, tested, and approved
by Yamaha for use on your vehicle.
Many companies with no connection to
Yamaha manufacture parts and acces-
sories or offer other modifications for
Yamaha vehicles. Yamaha is not in a
position to test the products that these
aftermarket companies produce.
Therefore, Yamaha can neither en-
Maximum load:
170 kg (375 lb)
BW8-9-E0_1.book 3 ページ ２０１６年１２月１３日 火曜日 午前１０時３９分

Safety information
1-4
1
2
3
4
5
6
7
8
9
10
11
12
dorse nor recommend the use of ac-
cessories not sold by Yamaha or
modifications not specifically recom-
mended by Yamaha, even if sold and
installed by a Yamaha dealer.
Aftermarket Parts, Accessories,
and Modifications
While you may find aftermarket prod-
ucts similar in design and quality to
genuine Yamaha accessories, recog-
nize that some aftermarket accessories
or modifications are not suitable be-
cause of potential safety hazards to you
or others. Installing aftermarket prod-
ucts or having other modifications per-
formed to your vehicle that change any
of the vehicle’s design or operation
characteristics can put you and others
at greater risk of serious injury or death.
You are responsible for injuries related
to changes in the vehicle.
Keep the following guidelines in mind,
as well as those provided under “Load-
ing” when mounting accessories.
Never install accessories or carry
cargo that would impair the perfor-
mance of your motorcycle. Care-
fully inspect the accessory before
using it to make sure that it does
not in any way reduce ground
clearance or cornering clearance,
limit suspension travel, steering
travel or control operation, or ob-
scure lights or reflectors.
• Accessories fitted to the handle-
bar or the front fork area can
create instability due to improper
weight distribution or aerody-
namic changes. If accessories
are added to the handlebar or
front fork area, they must be as
lightweight as possible and
should be kept to a minimum.
• Bulky or large accessories may
seriously affect the stability of
the motorcycle due to aerody-
namic effects. Wind may at-
tempt to lift the motorcycle, or
the motorcycle may become un-
stable in cross winds. These ac-
cessories may also cause
instability when passing or being
passed by large vehicles.
• Certain accessories can dis-
place the operator from his or
her normal riding position. This
improper position limits the free-
dom of movement of the opera-
tor and may limit control ability,
therefore, such accessories are
not recommended.
Use caution when adding electri-
cal accessories. If electrical acces-
sories exceed the capacity of the
motorcycle’s electrical system, an
electric failure could result, which
could cause a dangerous loss of
lights or engine power.
Aftermarket Tires and Rims
The tires and rims that came with your
motorcycle were designed to match the
performance capabilities and to provide
the best combination of handling, brak-
ing, and comfort. Other tires, rims, siz-
es, and combinations may not be
appropriate. Refer to page 7-18 for tire
specifications and more information on
replacing your tires.
Transporting the Motorcycle
Be sure to observe following instruc-
tions before transporting the motorcy-
cle in another vehicle.
Remove all loose items from the
motorcycle.
BW8-9-E0_1.book 4 ページ ２０１６年１２月１３日 火曜日 午前１０時３９分

Safety information
1-5
1
2
3
4
5
6
7
8
9
10
11
12
Check that the fuel cock (if
equipped) is in the “OFF” position
and that there are no fuel leaks.
Point the front wheel straight
ahead on the trailer or in the truck
bed, and choke it in a rail to pre-
vent movement.
Shift the transmission in gear (for
models with a manual transmis-
sion).
Secure the motorcycle with
tie-downs or suitable straps that
are attached to solid parts of the
motorcycle, such as the frame or
upper front fork triple clamp (and
not, for example, to rubber-mount-
ed handlebars or turn signals, or
parts that could break). Choose
the location for the straps carefully
so the straps will not rub against
painted surfaces during transport.
The suspension should be com-
pressed somewhat by the
tie-downs, if possible, so that the
motorcycle will not bounce exces-
sively during transport.
BW8-9-E0_1.book 5 ページ ２０１６年１２月１３日 火曜日 午前１０時３９分

2-1
1
2
3
4
5
6
7
8
9
10
11
12
Description
EAU10411
Left view
1 2, 3 4
56789
1. Headlight (page 7-35)
2. ERS coupler (page 4-33)
3. Spring preload adjusting bolt (page 4-33)
4. Battery (page 7-30)
5. Spring preload adjusting ring (page 4-34)
6. Shift pedal (page 4-27)
7. Engine oil level check window (page 7-10)
8. Engine oil filter cartridge (page 7-10)
9. Fuse box (page 7-32)
BW8-9-E0_1.book 1 ページ ２０１６年１２月１３日 火曜日 午前１０時３９分

Description
2-2
1
2
3
4
5
6
7
8
9
10
11
12
EAU10421
Right view
8911 10 7
1, 2 4
35, 6
1. Main fuse (page 7-32)
2. ABS motor fuse (page 7-32)
3. Owner’s tool kit (page 7-2)
4. Fuel tank cap (page 4-29)
5. ERS coupler (page 4-33)
6. Spring preload adjusting bolt (page 4-33)
7. Coolant reservoir (page 7-13)
8. Engine oil filler cap (page 7-10)
9. Coolant drain bolt (page 7-14)
10.Brake pedal (page 4-28)
11.Rear brake fluid reservoir (page 7-23)
BW8-9-E0_1.book 2 ページ ２０１６年１２月１３日 火曜日 午前１０時３９分

Description
2-3
1
2
3
4
5
6
7
8
9
10
11
12
EAU10431
Controls and instruments
12 4567893
1. Clutch lever (page 4-27)
2. Left handlebar switches (page 4-3)
3. Auxiliary DC jack (page 4-36)
4. Main switch/steering lock (page 4-2)
5. Instrument panel (page 4-5, 4-8)
6. Front brake fluid reservoir (page 7-23)
7. Right handlebar switches (page 4-3)
8. Throttle grip (page 7-17)
9. Brake lever (page 4-27)
BW8-9-E0_1.book 3 ページ ２０１６年１２月１３日 火曜日 午前１０時３９分

3-1
1
2
3
4
5
6
7
8
9
10
11
12
Special features
EAU78262
YRC (Yamaha Ride Control)
Yamaha Ride Control is a system that
incorporates numerous sensors and
controls to support an improved riding
experience. The functions listed below
represent individual YRC items which
can be turned on/off or adjusted to suit
various riders and riding conditions. For
setting details see MENU screen on
page 4-13.
WARNING
EWA18910
The Yamaha Ride Control (YRC) sys-
tem is not a substitute for the use of
proper riding techniques or the ex-
pertise of the operator. This system
cannot prevent loss of control
caused by rider errors such as trav-
eling faster than warranted by road
and traffic conditions, including loss
of traction due to excessive speed
when entering turns, when acceler-
ating hard at a sharp lean angle, or
while braking, and it cannot prevent
front wheel slipping. As with any
motorcycle, always ride within in
your limits, be aware of surrounding
conditions, and ride appropriately
for those conditions. Become thor-
oughly familiar with the way the mo-
torcycle handles with various YRC
settings before attempting more ad-
vanced maneuvers.
PWR
The power delivery mode system con-
sists of three different control maps
which regulate throttle valve opening in
relation to the degree of throttle grip op-
eration, thus providing you with a selec-
tion of modes to fit your preferences
and the riding environment.
TCS
The traction control system helps main-
tain traction when accelerating. If sen-
sors detect that the rear wheel is
starting to slip (uncontrolled spinning),
the traction control system assists by
regulating engine power as needed un-
til traction is restored. The traction con-
trol system indicator light flashes to let
the rider know that traction control has
engaged.
WARNING
EWA15432
The traction control system is not a
substitute for riding appropriately
for the conditions. Traction control
cannot prevent loss of traction due
to excessive speed when entering
turns, when accelerating hard at a
sharp lean angle, or while braking,
and cannot prevent front wheel slip-
ping. As with any motorcycle, ap-
proach surfaces that may be
slippery with caution and avoid es-
pecially slippery surfaces.
NOTICE
ECA16801
Use only the specified tires. (See
page 7-18.) Using different sized
tires will prevent the traction control
system from controlling tire rotation
accurately.
TIP
Turn the traction control system off to
help free the rear wheel if the motorcy-
cle gets stuck in mud, sand, or other
soft surfaces.
In certain conditions, the traction con-
BW8-9-E0_1.book 1 ページ ２０１６年１２月１３日 火曜日 午前１０時３９分

Special features
3-2
1
2
3
4
5
6
7
8
9
10
11
12
trol system may be automatically dis-
abled. Should this happen, both the
“ ” indicator light and the “ ” warn-
ing light will come on.
Resetting the traction control sys-
tem
The traction control system will auto-
matically disable when:
the front wheel or rear wheel
comes off the ground while riding.
excessive rear wheel spin is de-
tected while riding.
either wheel is rotated with the key
turned to “ON” (such as when per-
forming maintenance).
If the traction control system is dis-
abled, both the “ ” indicator light and
the “ ” warning light will come on.
Should this occur, try resetting the sys-
tem as follows.
1. Stop the vehicle and turn the key
to “OFF”.
2. Wait a few seconds and then turn
the key back to “ON”.
3. The “ ” indicator light should turn
off and the system be enabled.
TIP
If the “ ” indicator light remains on af-
ter resetting, the vehicle may still be rid-
den; however, have a Yamaha dealer
check the vehicle as soon as possible.
4. Have a Yamaha dealer check the
vehicle and turn off the “ ” warn-
ing light.
QSS
The quick shift system allows for
full-throttle, clutch lever-less, electroni-
cally-assisted upshifts. When the
switch positioned on the shift lever rod
detects motion in the shift lever, engine
power output is adjusted and drive
torque is momentarily cancelled out to
allow for the gear change to occur.
TIP
QSS operates when traveling at
least 20 km/h (12 mi/h) with an en-
gine speed of 2000 r/min or higher
and only when accelerating.
QSS does not operate when the
clutch lever is pulled.
ERS
The Electronic Racing Suspension by
Öhlins features electrically-controlled
suspension damping. The system is
controlled by the SCU which makes in-
dependent adjustments of both the
front and rear suspension’s compres-
sion stroke and rebound stroke damp-
ing forces. There are two modes,
automatic and manual. Automatic
mode is an active suspension control
system which actively adjusts suspen-
sion damping forces based on running
conditions. Manual mode is a finely-tu-
neable traditional suspension set-up.
BW8-9-E0_1.book 2 ページ ２０１６年１２月１３日 火曜日 午前１０時３９分

Special features
3-3
1
2
3
4
5
6
7
8
9
10
11
12
EAU78271
Glossary
ABS - Anti-lock Brake System
ABS ECU - Anti-lock Brake System
Electronic Control Unit
ECU - Engine Control Unit
ERS - Electronic Racing Suspension
PWR - Power delivery mode
QS - Quick Shift
QSS - Quick Shift System
SCU - Suspension Control Unit
TCS - Traction Control System
YRC - Yamaha Ride Control
EAU74041
Cruise control system
This model is equipped with a cruise
control system designed to maintain a
set cruising speed.
The cruise control system operates
only when riding in 4th, 5th or 6th gear
at speeds between about 50 km/h (31
mi/h) and 180 km/h (112 mi/h).
WARNING
EWA16341
Improper use of the cruise con-
trol system may result in loss of
control, which could lead to an
accident. Do not activate the
cruise control system in heavy
traffic, poor weather conditions,
or among winding, slippery,
hilly, rough or gravel roads.
When traveling uphill or down-
hill, the cruise control system
may not be able to maintain the
set cruising speed.
To prevent accidentally activat-
ing the cruise control system,
turn it off when not in use. Make
sure that the cruise control sys-
tem indicator light “ ” is off.
Activating and setting the cruise
control system
1. Push the cruise control power
1. Cruise control setting indicator light “SET”
2. Cruise control system indicator light “ ”
1. Cruise control setting switch “RES+/
SET–”
2. Cruise control power switch “ ”
12
RES
SET
MODE
1
2
BW8-9-E0_1.book 3 ページ ２０１６年１２月１３日 火曜日 午前１０時３９分

Special features
3-4
1
2
3
4
5
6
7
8
9
10
11
12
switch “ ” located on the left han-
dlebar. The cruise control system
indicator light “ ” will come on.
2. Push the “SET–” side of the cruise
control setting switch to activate
the cruise control system. Your
current traveling speed will be-
come the set cruising speed. The
cruise control setting indicator light
“SET” will come on.
Adjusting the set cruising speed
While the cruise control system is oper-
ating, push the “RES+” side of the
cruise control setting switch to increase
the set cruising speed or the “SET–”
side to decrease the set speed.
TIP
Pushing the setting switch once will
change the speed in increments of ap-
proximately 2.0 km/h (1.2 mi/h). Hold-
ing the “RES+” or “SET–” side of the
cruise control setting switch down will
increase or decrease the speed contin-
uously until the switch is released.
You can also manually increase your
traveling speed using the throttle. After
you have accelerated, you can set a
new cruising speed by pushing the
“SET–” side of the setting switch. If you
do not set a new cruising speed, when
you return the throttle grip, the vehicle
will decelerate to the previously set
cruising speed.
Deactivating the cruise control sys-
tem
Perform one of the following operations
to cancel the set cruising speed. The
“SET” indicator light will go off.
Turn the throttle grip past the
closed position in the deceleration
direction.
Apply the front or rear brake.
Disengage the clutch.
Push the power switch to turn off the
cruise control system. The “ ” indica-
tor light and the “SET” indicator light will
go off.
TIP
Traveling speed decreases as soon as
the cruise control system is deactivat-
ed; unless the throttle grip is turned.
Using the resume function
Push the “RES+” side of the cruise con-
trol setting switch to reactivate the
cruise control system. The traveling
speed will return to the previously set
cruising speed. The “SET” indicator
light will come on.
WARNING
EWA16351
It is dangerous to use the resume
function when the previously set
cruising speed is too high for cur-
rent conditions.
TIP
Pushing the power switch while the
system is operating will turn the system
off completely and erase the previously
1. Closed position
2. Cruise control cancel direction
1
2
BW8-9-E0_1.book 4 ページ ２０１６年１２月１３日 火曜日 午前１０時３９分

Special features
3-5
1
2
3
4
5
6
7
8
9
10
11
12
set cruising speed. You will not be able
to use the resume function until a new
cruising speed has been set.
Automatic deactivation of the cruise
control system
The cruise control system for this mod-
el is electronically controlled and is
linked with the other control systems.
The cruise control system will automat-
ically become deactivated under the
following conditions:
The cruise control system is not
able to maintain the set cruising
speed.
Wheel slip or wheel spin is detect-
ed. (If the traction control system
has not been turned off, the trac-
tion control system will work.)
The start/engine stop switch is set
to the “ ” position.
The engine stalls.
The sidestand is lowered.
When traveling with a set cruising
speed, if the cruise control system is
deactivated under the above condi-
tions, the “ ” indicator light will go off
and the “SET” indicator light will flash
for 4 seconds, and then go off.
When not traveling with a set cruising
speed, if the start/engine stop switch is
set to the “ ” position, the engine
stalls, or the sidestand is lowered, then
the “ ” indicator light will go off (the
“SET” indicator light will not flash).
If the cruise control system is automati-
cally deactivated, please stop and con-
firm that your vehicle is in good
operating condition.
Before using the cruise control system
again, activate it using the power
switch.
TIP
In some cases, the cruise control sys-
tem may not be able to maintain the set
cruising speed when the vehicle is trav-
eling uphill or downhill.
When the vehicle is traveling up-
hill, the actual traveling speed may
become lower than the set cruising
speed. If this occurs, accelerate to
the desired traveling speed using
the throttle.
When the vehicle is traveling
downhill, the actual traveling
speed may become higher than
the set cruising speed. If this oc-
curs, the setting switch cannot be
used to adjust the set cruising
speed. To reduce the traveling
speed, apply the brakes. When the
brakes are applied, the cruise con-
trol system will become deactivat-
ed.
