Yamaha ZUMA 2022 User manual

OWNER’S MANUAL


Read this manual carefully
before operating this vehicle.
MOTORCYCLE
LIT-11626-35-10 BJC-F8199-10
GQX125N
Location of important labels
Safety information
Description
Instrument and control functions
For your safety – pre-operation checks
Operation and important riding points
Periodic maintenance and adjustment
Scooter care and storage
Specifications
Consumer information
Index
1
2
3
4
5
6
7
8
9
10
11
NewstyleUS-Ecover.indd1NewstyleUS-Ecover.indd1 2021/01/069:58:032021/01/069:58:03
Downloaded from ManualsNet.com search engine

EAU10045
Operating, servicing and
maintaining a passenger vehicle or off-road vehicle can
expose you to chemicals including engine exhaust,
carbon monoxide, phthalates, and lead, which are
known to the State of California to cause cancer and
birth defects or other reproductive harm. To minimize
exposure, avoid breathing exhaust, do not idle the
engine except as necessary, service your vehicle in a
well-ventilated area and wear gloves or wash your
hands frequently when servicing your vehicle. For more
information go to
www.P65Warnings.ca.gov/passenger-vehicle
Read this manual carefully before operating the vehicle. This manual should stay with the vehicle if it is sold.
BJC-9-10-E0.book 1 ページ ２０２１年３月２６日 金曜日 午前１０時５２分
Downloaded from ManualsNet.com search engine

Introduction
EAU10093
Congratulations on your purchase of the Yamaha GQX125N. This model is the result of Yamaha’s vast experience in the
production of fine sporting, touring, and pacesetting racing machines. It represents the high degree of craftsmanship and
reliability that have made Yamaha a leader in these fields.
This manual will give youan understanding of the operation, inspection, and basic maintenance of this scooter. If youhave
any questions concerning the operation or maintenance of your scooter, please consult a Yamaha dealer.
The design and manufacture of this Yamaha scooter fully comply with the emissions standards for clean air applicable at the
date of manufacture. Yamaha has met these standards without reducing the performance or economy of operation of the
scooter. To maintain these high standards, it is important that youand your Yamaha dealer pay close attention to the rec-
ommended maintenance schedules and operating instructions contained within this manual.
Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the most cur-
rent product information available at the time of printing, there may be minor discrepancies between your scooter and this
manual. If there is any question concerning this manual, please consult a Yamaha dealer.
WARNING
EWA12582
Please read this manual and the “YOU AND YOUR MOTORCYCLE: RIDING TIPS” booklet carefully and completely
before operating this scooter. Do not attempt to operate this scooter until you have attained adequate knowledge
of its controls and operating features and until you have been trained in safe and proper riding techniques. Regular
inspections and careful maintenance, along with good riding skills, will ensure that you safely enjoy the capabilities
and reliability of this scooter.
BJC-9-10-E0.book 1 ページ ２０２１年３月２６日 金曜日 午前１０時５２分
Downloaded from ManualsNet.com search engine

Important manual information
EAU10134
Particularly important information is distinguished in this manual by the following notations:
*Product and specifications are subject to change without notice.
This is the safety alert symbol. It is used to alert you to potential personal injury
hazards. Obey all safety messages that follow this symbol to avoid possible injury
or death.
A WARNING indicates a hazardous situation which, if not avoided, could result in
death or serious injury.
A NOTICE indicates special precautions that must be taken to avoid damage to the
vehicle or other property.
A TIP provides key information to make procedures easier or clearer.
WARNING
NOTICE
TIP
BJC-9-10-E0.book 1 ページ ２０２１年３月２６日 金曜日 午前１０時５２分
Downloaded from ManualsNet.com search engine

Important manual information
EAUT2192
GQX125N
OWNER’S MANUAL
©2022 by Yamaha Motor Corporation, U.S.A.
1st edition, April 2021
All rights reserved.
Any reprinting or unauthorized use
without the written permission of
Yamaha Motor Corporation, U.S.A.
is expressly prohibited.
Printed in Taiwan.
P/N LIT-11626-35-10
BJC-9-10-E0.book 2 ページ ２０２１年３月２６日 金曜日 午前１０時５２分
Downloaded from ManualsNet.com search engine

Table of contents
Location of important labels........... 1-1
Safety information ........................... 2-1
Further safe-riding points................ 2-5
Description ....................................... 3-1
Left view......................................... 3-1
Right view....................................... 3-2
Controls and instruments................ 3-3
Instrument and control functions... 4-1
Main switch/steering lock ............... 4-1
Keyhole cover................................. 4-2
Indicator lights and warning lights .. 4-2
Multi-function meter unit ................. 4-3
Handlebar switches ........................ 4-7
Front brake lever ............................ 4-8
Rear brake lever ............................. 4-8
Fuel tank cap .................................. 4-9
Fuel................................................. 4-9
Fuel tank breather hose and
overflowhose ............................ 4-11
Catalytic converter........................ 4-11
Seat .............................................. 4-12
Passenger footrest ....................... 4-13
Helmet holders ............................. 4-13
Storage compartments ................. 4-14
Adjusting the shock absorber
assemblies ................................ 4-15
Front and rear carriers.................. 4-16
Luggage holder............................. 4-16
USB jack ...................................... 4-17
Sidestand ..................................... 4-17
Ignition circuit cut-off system........ 4-18
For your safety – pre-operation
checks .............................................. 5-1
Operation and important riding
points................................................ 6-1
Engine break-in .............................. 6-1
Starting the engine ......................... 6-2
Starting off...................................... 6-2
Acceleration and deceleration........ 6-3
Braking ........................................... 6-3
Tips for reducing fuel
consumption ............................... 6-4
Parking ........................................... 6-4
Periodic maintenance and
adjustment ....................................... 7-1
Periodic maintenance chart for the
emission control system ............. 7-3
General maintenance and
lubrication chart .......................... 7-4
Removing and installing panels ..... 7-8
Checking the spark plug................. 7-9
Canister ....................................... 7-10
Engine oil and oil strainer............. 7-10
Why Yamalube............................. 7-12
Final transmission oil.................... 7-13
Coolant......................................... 7-14
Air filter and V-belt case air filter
elements................................... 7-15
Checking the engine idling
speed........................................ 7-18
Checking the throttle grip free
play........................................... 7-18
Valve clearance ........................... 7-19
Tires............................................. 7-19
Cast wheels ................................. 7-21
Checking the front brake lever free
play........................................... 7-21
Checking the rear brake lever free
play........................................... 7-21
Checking the front and rear brake
pads.......................................... 7-22
Checking the brake fluid level...... 7-23
Changing the brake fluid.............. 7-24
Checking and lubricating the
cables ....................................... 7-24
Checking and lubricating the
throttle grip and cable............... 7-24
Lubricating the front and rear
brake levers.............................. 7-25
Checking and lubricating the
centerstand and sidestand ....... 7-25
Checking the front fork................. 7-26
Checking the steering .................. 7-27
Checking the wheel bearings....... 7-27
Battery ......................................... 7-27
Replacing the fuses ..................... 7-29
Replacing a headlight bulb.......... 7-29
BJC-9-10-E0.book 1 ページ ２０２１年３月２６日 金曜日 午前１０時５２分
Downloaded from ManualsNet.com search engine

Table of contents
Replacing the auxiliary light
bulb........................................... 7-30
Tail/brake light .............................. 7-30
Replacing a turn signal light
bulb........................................... 7-31
Replacing a license plate light
bulb........................................... 7-31
Troubleshooting............................ 7-32
Troubleshooting chart................... 7-33
Scooter care and storage................ 8-1
Matte color caution ......................... 8-1
Care................................................ 8-1
Storage........................................... 8-3
Specifications .................................. 9-1
Consumer information .................. 10-1
Identification numbers .................. 10-1
Diagnostic connector.................... 10-3
Vehicle data recording.................. 10-3
Reporting safety defects............... 10-4
Motorcycle noise regulation.......... 10-5
Maintenance record...................... 10-6
YAMAHA MOTOR
CORPORATION, U.S.A. 2020
AND LATER MODEL SCOOTER
LIMITED WARRANTY .............. 10-8
YAMAHA EXTENDED SERVICE
(Y.E.S.) ................................... 10-10
Index ............................................... 11-1
BJC-9-10-E0.book 2 ページ ２０２１年３月２６日 金曜日 午前１０時５２分
Downloaded from ManualsNet.com search engine

1-1
1
2
3
4
5
6
7
8
9
10
11
12
Location of important labels
EAU10385
Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of
your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label
is available from your Yamaha dealer.
1 4 115,6,7,8,9,1032
BJC-9-10-E0.book 1 ページ ２０２１年３月２６日 金曜日 午前１０時５２分
Downloaded from ManualsNet.com search engine

Location of important labels
1-2
1
2
3
4
5
6
7
8
9
10
11
12
5
6
7
8
9
1
2
3
4
10
11
RKRSEH9Y5NA000104
12/20
BJC-F811U-00
MFD. BY YAMAHA MOTOR TAIWAN CO., LTD. MADE IN TAIWAN
GVWR 292 kg (644 lbs) [MOTORCYCLE]
GAWR F ; 85kg (187 lbs) WITH 120/70-12 51L TIRE,
J12 x MT2.75 DOT RIM, AT 150kPa(22 psi) COLD
GAWR R ; 207kg (456 lbs) WITH 130/70-12 56L TIRE,
J12 x MT3.00 DOT RIM, AT 200kPa (29 psi) COLD
THIS VEHICLE CONFORMS TO ALL APPLICABLE FEDERAL MOTOR
VEHICLE SAFETY STANDARDS IN EFFECT ON THE DATE OF
MANUFACTURE SHOWN ABOVE.
LOAD LIMIT 1.5 kg (3 lbs)
BJC-F118K-00
WARNING
BEFORE YOU OPERATE THIS VEHICLE, READ
THE OWNER’S MANUAL AND ALL LABELS.
ALWAYS WEAR AN APPROVED MOTORCYCLE
HELMET, eye protection, and protective clothing.
LOAD LIMIT
HOOK 1.5 kg{3 lbs}
COMPARTMENT 1.5 kg{3 lbs}
BJC-F839Y-00
WARNING
Improper loading can cause loss of control.
Read owner’s manual for proper loading.
BJC-F8446-00
LOAD LIMIT
5 kg {11 lbs}
BJC-F4876-00
TIRE INFORMATION
Cold tire normal pressure should be set as
follows.
Up to 90kg (198lbs) load
FRONT : 150kpa, {1.50kgf/cm2}, 22psi
REAR : 200kpa, {2.00kgf/cm2}, 29psi
90 kg (198lbs)~maximum load
FRONT : 150kpa, {1.50kgf/cm2}, 22psi
REAR : 200kpa, {2.00kgf/cm2}, 29psi
BJC-F1668-00
VEHICL EMISSION CONTROL INFORMATION YAMAHA MOTOR TAIWAN CO.,LTD
ENG: NYMXC. 125GCD PERM: NYMXPMETALFF, NYMXPP402BFF EVAP: NYMXU0008YDB
TUNE-UP SPECIFICATIONS AND ADJUSTMENTS (REFERTO YOUR OWNER’S MANUAL)
DISPLACEMENT: 125 cm
3
EXHAUST EMISSION CONTROL SYSTEM:TWC(2); SFI; H02S
SPARK PLUG GAP : 0.8-0.9 mm VALVE LASH : IN 0.10-0.14 mm, EX 0.21-0.25 mm
IDLE SPEED : 1600 r/min IN NEUTRAL AT NORMAL OPERATING TEMPERATURE
FUEL: UNLEADED GASOLINE 91 RON MIN ENGINE OIL: SAE 10W-40
NO OTHER ADJUSTMENTS NEEDED.
THIS VEHICE CONFORMS TO US EPA AND CALIFORNIA REGULATIONS APPLICABLE TO 2022 MODEL YEAR NEWMCs.
AND IS CERTIFIED TO HC 1.0 AND CO 12.0 (g/km) ENGINE EXHAUST EMISSION STANDARDS.
THIS MC MEETS 1986 AND LATER EPA NOISE EMISSION REQUIREMENTS OF THE FED. TEST PROCEDURES.
MODIFICATIONSWHICH CAUSE THIS MC TO EXCEED FED. NOISE ST’D ARE PROHIBITED BY FED. LAW
SEE OWNER’S MANUAL. LIMIT/CLOSING : 80 dBA/ 7600 r/min MODEL CODE:YAMBJC0125
BJC-F176P-00
○BCJ1-010
●B
LOAD LIMIT
5 kg {11 lbs}
BJC-F4876-00
BJC-9-10-E0.book 2 ページ ２０２１年３月２６日 金曜日 午前１０時５２分
Downloaded from ManualsNet.com search engine

2-1
1
2
3
4
5
6
7
8
9
10
11
12
Safety information
EAU1026B
Be a Responsible Owner
As the vehicle’s owner, youare respon-
sible for the safe and proper operation
of your scooter.
Scooters are single-track vehicles.
Their safe use and operation are de-
pendent upon the use of proper riding
techniques as well as the expertise of
the operator. Every operator should
knowthe following requirements before
riding this scooter.
He or she should:
Obtain thorough instructions from
a competent source on all aspects
of scooter operation.
Observe the warnings and mainte-
nance requirements in this Own-
er’s Manual.
Obtain qualified training in safe
and proper riding techniques.
Obtain professional technical ser-
vice as indicated in this Owner’s
Manual and/or when made neces-
sary by mechanical conditions.
Never operate a scooter without
proper training or instruction. Take
a training course. Beginners
should receive training from a cer-
tified instructor. Contact an autho-
rized scooter dealer to find out
about the training courses nearest
you.
Safe Riding
Perform the pre-operation checks each
time youuse the vehicle to make sure it
is in safe operating condition. Failure to
inspect or maintain the vehicle properly
increases the possibility of an accident
or equipment damage. See page 5-1
for a list of pre-operation checks.
This scooter is designed to carry
the operator and a passenger.
The failure of motorists to detect
and recognize scooters in traffic is
the predominating cause of auto-
mobile/scooter accidents. Many
accidents have been caused by an
automobile driver who did not see
the scooter. Making yourself con-
spicuous appears to be very effec-
tive in reducing the chance of this
type of accident.
Therefore:
•Wear a brightly colored jacket.
• Use extra caution when youare
approaching and passing
through intersections, since in-
tersections are the most likely
places for scooter accidents to
occur.
• Ride where other motorists can
see you. Avoid riding in another
motorist’s blind spot.
•Never maintain a scooter with-
out proper knowledge. Contact
an authorized scooter dealer to
inform youon basic scooter
maintenance. Certain mainte-
nance can only be carried out by
certified staff.
Many accidents involve inexperi-
enced operators. In fact, many op-
erators who have been involved in
accidents do not even have a cur-
rent driver’s license.
• Make sure that youare qualified
and that youonly lend your
scooter to other qualified opera-
tors.
•Knowyour skills and limits.
Staying within your limits may
help youto avoid an accident.
•We recommend that youprac-
BJC-9-10-E0.book 1 ページ ２０２１年３月２６日 金曜日 午前１０時５２分
Downloaded from ManualsNet.com search engine

Safety information
2-2
1
2
3
4
5
6
7
8
9
10
11
12
tice riding your scooter where
there is no traffic until youhave
become thoroughly familiar with
the scooter and all of its con-
trols.
Many accidents have been caused
by error of the scooter operator. A
typical error made by the operator
is veering wide on a turn due to ex-
cessive speed or undercornering
(insufficient lean angle for the
speed).
•Always obey the speed limit and
never travel faster than warrant-
ed by road and traffic conditions.
•Always signal before turning or
changing lanes. Make sure that
other motorists can see you.
The posture of the operator and
passenger is important for proper
control.
• The operator should keep both
hands on the handlebar and
both feet on the operator foot-
rests during operation to main-
tain control of the scooter.
• The passenger should always
hold onto the operator, the seat
strap or grabbar, if equipped,
with both hands and keep both
feet on the passenger footrests.
Never carry a passenger unless
he or she can firmly place both
feet on the passenger footrests.
Never ride under the influence of
alcohol or other drugs.
This scooter is designed for
on-road use only. It is not suitable
for off-road use.
Protective Apparel
The majority of fatalities from scooter
accidents are the result of head inju-
ries. The use of a safety helmet is the
single most critical factor in the preven-
tion or reduction of head injuries.
Always wear an approved helmet.
Wear a face shield or goggles.
Wind in your unprotected eyes
could contribute to an impairment
of vision that could delay seeing a
hazard.
The use of a jacket, substantial
shoes, trousers, gloves, etc., is ef-
fective in preventing or reducing
abrasions or lacerations.
Never wear loose-fitting clothes,
otherwise they could catch on the
control levers or wheels and cause
injury or an accident.
Always wear protective clothing
that covers your legs, ankles, and
feet. The engine or exhaust sys-
tem become very hot during or af-
ter operation and can cause burns.
A passenger should also observe
the above precautions.
Avoid Carbon Monoxide Poisoning
All engine exhaust contains carbon
monoxide, a deadly gas. Breathing car-
bon monoxide can cause headaches,
dizziness, drowsiness, nausea, confu-
sion, and eventually death.
Carbon Monoxide is a colorless, odor-
less, tasteless gas which may be pres-
ent even if youdo not see or smell any
engine exhaust. Deadly levels of car-
bon monoxide can collect rapidly and
youcan quickly be overcome and un-
able to save yourself. Also, deadly lev-
els of carbon monoxide can linger for
hours or days in enclosed or poorly
ventilated areas. If youexperience any
symptoms of carbon monoxide poison-
ing, leave the area immediately, get
fresh air, and SEEK MEDICAL TREAT-
BJC-9-10-E0.book 2 ページ ２０２１年３月２６日 金曜日 午前１０時５２分
Downloaded from ManualsNet.com search engine

Safety information
2-3
1
2
3
4
5
6
7
8
9
10
11
12
MENT.
Do not run engine indoors. Even if
youtry to ventilate engine exhaust
with fans or open windows and
doors, carbon monoxide can rap-
idly reach dangerous levels.
Do not run engine in poorly venti-
lated or partially enclosed areas
such as barns, garages, or car-
ports.
Do not run engine outdoors where
engine exhaust can be drawn into
a building through openings such
as windows and doors.
Loading
Adding accessories or cargo to your
scooter can adversely affect stability
and handling if the weight distribution of
the scooter is changed. To avoid the
possibility of an accident, use extreme
caution when adding cargo or accesso-
ries to your scooter. Use extra care
when riding a scooter that has added
cargo or accessories. Here, along with
the information about accessories be-
low, are some general guidelines to fol-
lowif loading cargo to your scooter:
The total weight of the operator, pas-
senger, accessories and cargo must
not exceed the maximum load limit.
Operation of an overloaded vehicle
could cause an accident.
When loading within this weight limit,
keep the following in mind:
Cargo and accessory weight
should be kept as lowand close to
the scooter as possible. Securely
pack your heaviest items as close
to the center of the vehicle as pos-
sible and make sure to distribute
the weight as evenly as possible
on both sides of the scooter to min-
imize imbalance or instability.
Shifting weights can create a sud-
den imbalance. Make sure that ac-
cessories and cargo are securely
attached to the scooter before rid-
ing. Check accessory mounts and
cargo restraints frequently.
• Properly adjust the suspension
for your load (suspension-ad-
justable models only), and
check the condition and pres-
sure of your tires.
•Never attach any large or heavy
items to the handlebar, front
fork, or front fender. Such items
can create unstable handling or
a slowsteering response.
This vehicle is not designed to
pull a trailer or to be attached to
a sidecar.
Genuine Yamaha Accessories
Choosing accessories for your vehicle
is an important decision. Genuine
Yamaha accessories, which are avail-
able only from a Yamaha dealer, have
been designed, tested, and approved
by Yamaha for use on your vehicle.
Many companies with no connection to
Yamaha manufacture parts and acces-
sories or offer other modifications for
Yamaha vehicles. Yamaha is not in a
position to test the products that these
aftermarket companies produce.
Therefore, Yamaha can neither en-
dorse nor recommend the use of ac-
cessories not sold by Yamaha or
modifications not specifically recom-
mended by Yamaha, even if sold and
installed by a Yamaha dealer.
Maximum load:
164 kg (362 lb)
BJC-9-10-E0.book 3 ページ ２０２１年３月２６日 金曜日 午前１０時５２分
Downloaded from ManualsNet.com search engine

Safety information
2-4
1
2
3
4
5
6
7
8
9
10
11
12
Aftermarket Parts, Accessories,
and Modifications
While youmay find aftermarket prod-
ucts similar in design and quality to
genuine Yamaha accessories, recog-
nize that some aftermarket accessories
or modifications are not suitable be-
cause of potential safety hazards to you
or others. Installing aftermarket prod-
ucts or having other modifications per-
formed to your vehicle that change any
of the vehicle’s design or operation
characteristics can put youand others
at greater risk of serious injury or death.
Youare responsible for injuries related
to changes in the vehicle.
Keep the following guidelines in mind,
as well as those provided under “Load-
ing” when mounting accessories.
Never install accessories or carry
cargo that would impair the perfor-
mance of your scooter. Carefully
inspect the accessory before using
it to make sure that it does not in
any way reduce ground clearance
or cornering clearance, limit sus-
pension travel, steering travel or
control operation, or obscure lights
or reflectors.
• Accessories fitted to the handle-
bar or the front fork area can
create instability due to improper
weight distribution or aerody-
namic changes. If accessories
are added to the handlebar or
front fork area, they must be as
lightweight as possible and
should be kept to a minimum.
•Bulky or large accessories may
seriously affect the stability of
the scooter due to aerodynamic
effects. Wind may attempt to lift
the scooter, or the scooter may
become unstable in cross
winds. These accessories may
also cause instability when
passing or being passed by
large vehicles.
• Certain accessories can dis-
place the operator from his or
her normal riding position. This
improper position limits the free-
dom of movement of the opera-
tor and may limit control ability,
therefore, such accessories are
not recommended.
Use caution when adding electri-
cal accessories. If electrical acces-
sories exceed the capacity of the
scooter’s electrical system, an
electric failure could result, which
could cause a dangerous loss of
lights or engine power.
Aftermarket Tires and Rims
The tires and rims that came with your
scooter were designed to match the
performance capabilities and to provide
the best combination of handling, brak-
ing, and comfort. Other tires, rims, siz-
es, and combinations may not be
appropriate. Refer to page 7-19 for tire
specifications and more information on
replacing your tires.
Transporting the Scooter
Be sure to observe following instruc-
tions before transporting the scooter in
another vehicle.
Remove all loose items from the
scooter.
Point the front wheel straight
ahead on the trailer or in the truck
bed, and choke it in a rail to pre-
vent movement.
Secure the scooter with tie-downs
or suitable straps that are attached
BJC-9-10-E0.book 4 ページ ２０２１年３月２６日 金曜日 午前１０時５２分
Downloaded from ManualsNet.com search engine

Safety information
2-5
1
2
3
4
5
6
7
8
9
10
11
12
to solid parts of the scooter, such
as the frame or upper front fork tri-
ple clamp (and not, for example, to
rubber-mounted handlebars or
turn signals, or parts that could
break). Choose the location for the
straps carefully so the straps will
not rub against painted surfaces
during transport.
The suspension should be com-
pressed somewhat by the
tie-downs, if possible, so that the
scooter will not bounce excessive-
ly during transport.
EAU57600
Further safe-riding points
Be sure to signal clearly when
making turns.
Braking can be extremely difficult
on a wet road. Avoid hard braking,
because the scooter could slide.
Apply the brakes slowly when
stopping on a wet surface.
Slowdown as youapproach a cor-
ner or turn. Once youhave com-
pleted a turn, accelerate slowly.
Be careful when passing parked
cars. A driver might not see you
and open a door in your path.
Railroad crossings, streetcar rails,
iron plates on road construction
sites, and manhole covers be-
come extremely slippery when
wet. Slowdown and cross them
with caution. Keep the scooter up-
right, otherwise it could slide out
from under you.
The brake pads or linings could get
wet when youwash the scooter.
After washing the scooter, check
the brakes before riding.
Always wear a helmet, gloves,
trousers (tapered around the cuff
and ankle so they do not flap), and
a brightly colored jacket.
Do not carry too much luggage on
the scooter. An overloaded scoot-
er is unstable. Use a strong cord to
secure any luggage to the carrier
(if equipped). A loose load will af-
fect the stability of the scooter and
could divert your attention from the
road. (See page 2-3.)
BJC-9-10-E0.book 5 ページ ２０２１年３月２６日 金曜日 午前１０時５２分
Downloaded from ManualsNet.com search engine

3-1
1
2
3
4
5
6
7
8
9
10
11
12
Description
EAU10411
Left view
1410 11
9
7 8
56
23
1. Fuel tank (page 4-9)
2. Sidestand (page 4-17)
3. Seat (page 4-12)
4. Centerstand (page 7-25)
5. Air filter (page 7-15)
6. Rear shock absorber (page 4-15)
7. Brake/tail light (page 7-30)
8. Rear turn signal light (page 7-31)
9. License plate light (page 7-31)
10.Final transmission oil filler cap (page 7-13)
11.Rear wheel
BJC-9-10-E0.book 1 ページ ２０２１年３月２６日 金曜日 午前１０時５２分
Downloaded from ManualsNet.com search engine

Description
3-2
1
2
3
4
5
6
7
8
9
10
11
12
EAU10421
Right view
81234
567 91011
1. Muffler (page 4-11)
2. Engine oil filler cap (page 7-10)
3. Rear storage compartment (page 4-14)
4. Passenger footrest (page 4-13)
5. Battery (page 7-27)
6. Helmet holder (page 4-13)
7. Coolant level check window(page 7-14)
8. Auxiliary light (page 7-30)
9. Front turn signal light (page 7-31)
10.Headlight (page 7-29)
11.Front wheel
BJC-9-10-E0.book 2 ページ ２０２１年３月２６日 金曜日 午前１０時５２分
Downloaded from ManualsNet.com search engine

Description
3-3
1
2
3
4
5
6
7
8
9
10
11
12
EAU10431
Controls and instruments
1 85 72 11 123 10 4 96 13 14
1. Luggage holder (page 4-16)
2. Rear brake lever (page 4-8)
3. Left handlebar switches (page 4-7)
4. Rear brake fluid reservoir (page 7-23)
5. Fuel tank cap (page 4-9)
6. Multi-function display (page 4-3)
7. Main switch/steering lock (page 4-1)
8. USB jack (page 4-17)
9. Front brake fluid reservoir (page 7-23)
10.Right handlebar switches (page 4-7)
11.Front brake lever (page 4-8)
12.Throttle grip (page 7-18)
13.Keyhole cover (page 4-2)
14.Front storage compartment (page 4-14)
BJC-9-10-E0.book 3 ページ ２０２１年３月２６日 金曜日 午前１０時５２分
Downloaded from ManualsNet.com search engine

4-1
1
2
3
4
5
6
7
8
9
10
11
12
Instrument and control functions
EAUU0353
Main switch/steering lock
The main switch/steering lock controls
the ignition and lighting systems, and is
used to lock the steering, and is used to
open the seat also. The various main
switch positions are described below.
TIP
The main switch is equipped with a key-
hole cover. (See page 4-2 for keyhole
cover opening and closing proce-
dures.)
EAUT5480
ON
All electrical circuits are supplied with
power; the meter lighting, taillight, li-
cense plate light and auxiliary light
come on, and the engine can be start-
ed.
TIP
The headlight comes on automatically
when the engine is started and stays on
until the main switch is turned to “OFF”,
even if the engine stalls.
EAU10662
OFF
All electrical systems are off. The key
can be removed.
WARNING
EWA10062
Never turn the key to “OFF” or
“LOCK” while the vehicle is moving.
Otherwise the electrical systems will
be switched off, which may result in
loss of control or an accident.
EAU1068B
LOCK
The steering is locked and all electrical
systems are off. The key can be re-
moved.
To lock the steering
1. Turn the handlebars all the way to
the left.
2. With the key in the “OFF” position,
push the key in and turn it to
“LOCK”.
3. Remove the key.
TIP
If the steering will not lock, try turning
the handlebars back to the right slightly.
ON
OFF
LOCK
1. Push.
2. Turn.
2
1
BJC-9-10-E0.book 1 ページ ２０２１年３月２６日 金曜日 午前１０時５２分
Downloaded from ManualsNet.com search engine

Instrument and control functions
4-2
1
2
3
4
5
6
7
8
9
10
11
12
To unlock the steering
From the “LOCK” position, push the
key in and turn it to “OFF”.
EAUU0822
Keyhole cover
To open the keyhole cover
Insert the key head into the keyhole
cover receptacle as shown, and then
turn the key to the right to open the cov-
er.
To close the keyhole cover
Press the “PUSH SHUT” button to
close the keyhole cover.
EAU4939P
Indicator lights and warning
lights
EAU11033
Turn signal indicator lights “ ” and
“”
Each indicator light will flash when its
corresponding turn signal lights flash.
EAU11081
High beam indicator light “ ”
This indicator light comes on when the
high beam of the headlight is switched
on.
1. Push.
2. Turn.
2
1
1. “PUSH SHUT” button
2. Key head
3. Keyhole cover receptacle
132
1. Turn signal indicator lights “ ” and “ ”
2. Engine trouble warning light “ ”
3. High beam indicator light “ ”
4. Coolant temperature warning light “ ”
1 1 42 3
BJC-9-10-E0.book 2 ページ ２０２１年３月２６日 金曜日 午前１０時５２分
Downloaded from ManualsNet.com search engine

Instrument and control functions
4-3
1
2
3
4
5
6
7
8
9
10
11
12
EAU11449
Coolant temperature warning light
“”
This warning light comes on when the
engine is overheating. If this occurs,
stop the engine immediately and allow
the engine to cool. (See page 7-34.)
For vehicles with a radiator fan, the ra-
diator fan(s) automatically switch on or
off according to the coolant tempera-
ture.
TIP
When the vehicle is turned on, the light
will come on for a fewseconds, and
then go off. If the light does not come
on, or if the light remains on, have a
Yamaha dealer check the vehicle.
NOTICE
ECA10022
Do not continue to operate the en-
gine if it is overheating.
EAU77562
Engine trouble warning light “ ”
This warning light comes on if a prob-
lem is detected in the engine or other
vehicle control system. If this occurs,
have a Yamaha dealer check the
on-board diagnostic system.
TIP
When the vehicle is turned on, this light
should come on for a fewseconds and
then go off. Otherwise, have a Yamaha
dealer check the vehicle.
EAU86812
Multi-function meter unit
WARNING
EWA12423
Be sure to stop the vehicle before
making any setting changes to the
multi-function meter unit. Changing
settings while riding can distract the
operator and increase the risk of an
1. SEL switch
2. RES switch
3. Tachometer
4. Speedometer
5. Odometer
6. Tripmeter indicator “TRIP1”/“TRIP2”
7. Fuel meter
8. VVA (variable valve actuation) indicator
9. Clock
10.Oil change indicator “OIL CHANGE”
1 7 9 10 82 563 4
BJC-9-10-E0.book 3 ページ ２０２１年３月２６日 金曜日 午前１０時５２分
Downloaded from ManualsNet.com search engine
