Yamaha Wolverine X2 User manual

DIC183
OWNER’S MANUAL
BAN-F8199-10LIT-11626-33-48
YXE85WPSL/YXE85WPHL
YXE85WPAL/YXE85WPBL
READ THIS MANUAL CAREFULLY!
It contains important safety information.
NOTICE: The removal or modification of evaporative
emission-related parts on this OHRV is illegal.
Violators may be subject to civil and/or criminal
penalties as provided under California and federal law.

EBU31032
Operating, servicing and
maintaining a passenger vehicle or off-road vehicle can
expose you to chemicals including engine exhaust,
carbon monoxide, phthalates, and lead, which are
known to the State of California to cause cancer and
birth defects or other reproductive harm. To minimize
exposure, avoid breathing exhaust, do not idle the
engine except as necessary, service your vehicle in a
well-ventilated area and wear gloves or wash your
hands frequently when servicing your vehicle. For more
information go to
www.P65Warnings.ca.gov/passenger-vehicle
Read this manual carefully before operating this vehicle. This manual should stay with this ve-
hicle if it is sold.
UBAN10E0.book Page 1 Thursday, August 8, 2019 10:46 AM

EBU31040
INTRODUCTION
EBU38911
Congratulations on your purchase of the Yamaha YXE85WPSL / YXE85WPHL / YXE85WPAL /
YXE85WPBL. It represents the result of many years of Yamaha experience in the production of
fine sporting, touring, and pace-setting racing vehicles. With the purchase of this Yamaha, you
can now appreciate the high degree of craftsmanship and reliability that have made Yamaha a
leader in these fields.
This manual will provide you with a good basic understanding of the features and operation of
this vehicle. It also includes basic maintenance and inspection procedures. If you have any ques-
tions regarding the operation or maintenance of your vehicle, please consult a Yamaha dealer.
WARNING
EWB04330
Read this manual carefully before operating this vehicle. Do not attempt to operate this
vehicle until you have attained adequate knowledge of its controls and operating fea-
tures.
For YXE85WPSL: Read the Winch Owner’s Manual carefully and completely before op-
erating the winch. Make sure you understand all instructions.
Regular inspections and careful maintenance, along with good operating techniques,
will help ensure that you safely enjoy the capabilities and reliability of this vehicle.
UBAN10E0.book Page 1 Thursday, August 8, 2019 10:46 AM

EBU31080
IMPORTANT MANUAL INFORMATION
EBU31070
FAILURE TO FOLLOW THE WARNINGS CONTAINED IN THIS MANUAL CAN RESULT IN SERI-
OUS INJURY OR DEATH.
Particularly important information is distinguished in this manual by the following notations:
* Product and specifications are subject to change without notice.
This is the safety alert symbol. It is used to alert you to poten-
tial personal injury hazards. Obey all safety messages that fol-
low this symbol to avoid possible injury or death.
A WARNING indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
A NOTICE indicates special precautions that must be taken to
avoid damage to the vehicle or other property.
A TIP provides key information to make procedures easier or clear-
er.
WARNING
NOTICE
TIP
UBAN10E0.book Page 1 Thursday, August 8, 2019 10:46 AM

EBU31090
IMPORTANT NOTE ABOUT USE
EBU31101
This vehicle is designed and manufactured for off-road use only. Use on public streets,
roads, or highways is not only illegal in most areas, it also increases the risk of an acci-
dent involving other vehicles. This vehicle does not meet federal motor vehicle safety
standards for on-road use.
Check the laws and regulations in force before choosing where to operate this vehicle.
It is illegal to operate this vehicle on public lands where vehicles its size are prohibited.
This vehicle complies with all state off-highway noise level and spark arrester laws and
regulations.
EBU31111
YXE85WPSL / YXE85WPHL / YXE85WPAL / YXE85WPBL
OWNER’S MANUAL
©2020 by Yamaha Motor Corporation, U.S.A.
1st edition, July 2019
All rights reserved.
Any reprinting or unauthorized use
without the written permission of
Yamaha Motor Corporation, U.S.A.
is expressly prohibited.
Printed in U.S.A.
P/N LIT-11626-33-48
UBAN10E0.book Page 1 Thursday, August 8, 2019 10:46 AM

EBU31120
CONTENTS
VEHICLE IDENTIFICATION ..................... 1-1
Identification numbers..........................1-1
LOCATION OF THE WARNING AND
SPECIFICATION LABELS ....................... 2-1
SAFETY INFORMATION ......................... 3-1
DESCRIPTION......................................... 4-1
Left view ............................................... 4-1
Right view............................................. 4-2
Controls and instruments ..................... 4-3
INSTRUMENT AND CONTROL
FUNCTIONS............................................5-1
Main switch .......................................... 5-1
Indicator lights and warning lights ....... 5-2
Multi-function meter unit ...................... 5-7
Speed Management System.............. 5-13
Light switch ........................................ 5-15
Winch switch (YXE85WPSL) .............. 5-15
On–Command drive knob
“2WD/4WD/DIFF. LOCK” ................. 5-16
Accelerator pedal ............................... 5-17
Brake pedal ........................................ 5-17
Parking brake lever ............................ 5-18
Drive select lever................................ 5-18
Fuel tank cap...................................... 5-19
Doors.................................................. 5-19
Passenger seat cushion ..................... 5-20
Adjusting the driver seat position....... 5-20
Adjusting the steering wheel
position............................................. 5-21
Seat belts ........................................... 5-22
Glove compartment ........................... 5-22
Storage compartments ...................... 5-23
Cup holders........................................ 5-24
Cargo bed .......................................... 5-25
Front shock absorbers
(YXE85WPBL)................................... 5-27
Front shock absorbers
(YXE85WPSL / YXE85WPHL /
YXE85WPAL).................................... 5-28
UBAN10E0.book Page 1 Thursday, August 8, 2019 10:46 AM

Rear shock absorbers
(YXE85WPBL) ................................... 5-33
Rear shock absorbers
(YXE85WPSL / YXE85WPHL /
YXE85WPAL) ....................................5-35
Winch (YXE85WPSL)..........................5-40
Trailer hitch bracket and receiver.......5-41
Auxiliary DC jack ................................5-42
Yamaha Adventure Pro powered by
Magellan®.........................................5-43
FOR YOUR SAFETY –
PRE-OPERATION CHECKS.................... 6-1
Front and rear brakes ...........................6-3
Fuel.......................................................6-3
Engine oil..............................................6-5
Transmission ........................................6-5
Coolant.................................................6-6
Final gear.............................................. 6-6
Differential gear .................................... 6-6
Accelerator pedal .................................6-6
Seat belts ............................................. 6-6
Passenger handhold ............................6-7
Steering ................................................6-7
Fittings and fasteners ...........................6-7
Instruments, lights and switches ..........6-7
Control cables ......................................6-7
Tires ......................................................6-7
OPERATION ............................................7-1
Engine break-in.....................................7-1
Starting the engine ...............................7-2
Drive select lever operation and
reverse driving ....................................7-3
On-Command drive knob .....................7-6
Parking..................................................7-8
Loading.................................................7-8
BASIC GUIDE FOR SAFE USE...............8-1
KNOW YOUR VEHICLE ........................8-1
LEARNING TO OPERATE YOUR
VEHICLE ...........................................8-11
PERIODIC MAINTENANCE AND
ADJUSTMENT .........................................9-1
Owner’s Manuals and Tool kit ..............9-2
UBAN10E0.book Page 2 Thursday, August 8, 2019 10:46 AM

Maintenance charts.............................. 9-4
Hood................................................... 9-10
Engine oil and oil filter ........................9-11
Why Yamalube ...................................9-19
Transmission oil ................................. 9-20
Final gear oil ....................................... 9-23
Differential gear oil ............................. 9-25
Coolant............................................... 9-27
Axle boots .......................................... 9-29
Checking the spark plugs .................. 9-29
Air filter maintenance.......................... 9-31
Air filter check hoses .......................... 9-35
V-belt case drain plug ........................9-36
Cleaning the spark arrester ................ 9-36
Valve clearance .................................. 9-38
Brakes ................................................ 9-38
Checking the front and rear brake
pads.................................................. 9-38
Checking the parking brake pads ......9-39
Checking the brake fluid level ............ 9-39
Brake fluid replacement ..................... 9-41
Checking the brake pedal .................. 9-41
Checking the accelerator pedal .........9-41
Parking brake lever free play
adjustment ........................................9-42
Brake light switch adjustment ............9-42
Cable inspection and lubrication ........9-43
Pedal lubrication.................................9-44
Checking the stabilizer bushes...........9-44
Rear knuckle upper and lower pivot
lubrication (left and right) ..................9-45
Steering shaft lubrication....................9-45
Wheel removal ....................................9-46
Tire replacement.................................9-46
Wheel installation................................9-47
Battery ................................................9-48
Jump-starting .....................................9-52
Fuse replacement ...............................9-53
Headlights...........................................9-55
Headlight beam adjustment ...............9-56
Brake/tail light.....................................9-56
Troubleshooting..................................9-57
Troubleshooting charts.......................9-58
CLEANING AND STORAGE ..................10-1
Cleaning..............................................10-1
UBAN10E0.book Page 3 Thursday, August 8, 2019 10:46 AM

Storage...............................................10-2
SPECIFICATIONS .................................11-1
CONSUMER INFORMATION ................ 12-1
Vehicle Emission Control Information
label ..................................................12-1
Emission Regulation (California)......... 12-1
NOISE REGULATION .........................12-2
MAINTENANCE RECORD ..................12-3
YAMAHA MOTOR CORPORATION,
U.S.A. 2020 AND LATER MODEL
SIDE-BY-SIDE LIMITED
WARRANTY......................................12-4
YAMAHA EXTENDED SERVICE
(Y.E.S.) .............................................. 12-6
INDEX....................................................13-1
UBAN10E0.book Page 4 Thursday, August 8, 2019 10:46 AM

1-1
1
EBU38890
VEHICLE IDENTIFICATION
EBU32781
Identification numbers
Record the vehicle identification number,
model label information and key identification
number in the spaces provided below.
VEHICLE IDENTIFICATION NUMBER:
MODEL LABEL INFORMATION:
KEY IDENTIFICATION NUMBER:
EBU32800
Vehicle identification number
The vehicle identification number is stamped
into the frame.
The vehicle identification number is used to
identify your vehicle.
EBU32811
Model label
The model label is affixed at the location
shown.
1. Vehicle identification number
1
UBAN10E0.book Page 1 Thursday, August 8, 2019 10:46 AM

1-2
1
Your specific model can be identified by
checking the model type code found on the
model label.
EBU32790
Key identification number
The key identification number is stamped on
the key, as shown in the following illustration.
This number can be used for ordering a new
key.
1. Model label
1
1. Model type code
2. Production code
3. Color code
*
****
-***
1
3
2
UBAN10E0.book Page 2 Thursday, August 8, 2019 10:46 AM

1-3
1
1. Key identification number
1
UBAN10E0.book Page 3 Thursday, August 8, 2019 10:46 AM

2-1
2
EBU31130
LOCATION OF THE WARNING AND SPECIFICATION LABELS
1
4 4 4
2 3 2
11
5 6 87
4
10
9
UBAN10E0.book Page 1 Thursday, August 8, 2019 10:46 AM

2-2
2
16 17 18
14
13 13
12
15
19
UBAN10E0.book Page 2 Thursday, August 8, 2019 10:46 AM

2-3
2
EBU31142
Read and understand all of the labels on your vehicle. They contain important information for safe
and proper operation of your vehicle.
Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a
replacement label is available from your Yamaha dealer.
UBAN10E0.book Page 3 Thursday, August 8, 2019 10:46 AM

2-4
2
YAMAHA 1XD-K8483-00
WARNING
Do not rest hands or arms on door or shoulder bolster.
To avoid Injury, keep hands and arms completely
Inside the vehicle by holding the steering wheel or handhold.
WARNING
This unit contains high pressure nitrogen gas.
Mishandling can cause explosion.
Read owner’s manual for instructions.
Do not incinerate, puncture or open.
1HP-F2259-01
YAMAHA MOTOR CORPORATION U.S.A.
6555 Katella Avenue, Cypress,
California 90630-5101, U.S.A.
B85-F4164-00
The original-equipment overhead structure on
this vehicle meets US OSHA and ISO 3471
requirements for rollover protection structures
m=800Kg for ISO3471
1
24
3
UBAN10E0.book Page 4 Thursday, August 8, 2019 10:46 AM

2-5
2
YAMAHA BAN-F1696-00
WARNING
• Improper tire pressure or overloading this vehicle may
cause severe injury or death from loss of control or
rollover.
• Never set or allow tire pressure to be below the minimum.
Tire may dislodge from rim.
• VEHICLE LOAD of 0 lb (0 kg) ~ 441 lbs (200 kg)
Recommended: FRONT:
REAR:
Minimum: FRONT:
REAR:
12 psi
14 psi
11 psi
13 psi
(83 kPa)
(97 kPa)
(76 kPa)
(90 kPa)
*
Vehicle load is weight of operator, passengers,
accessories, cargo, and (if applicable) trailer tongue
weight. Do not exceed maximum vehicle load.
Gross Vehicle Weight Rating: 2866 lbs (1300 kg)
maximum including vehicle, weight of operator,
passengers, accessories, cargo, and (if applicable)
trailer tongue weight.
OPERATING TIRE PRESSURE: With tires cold, set as follows.
• VEHICLE LOAD of 441 lbs (200 kg) ~ 1187 lbs (538.5 kg)
Recommended: FRONT:
REAR:
Minimum: FRONT:
REAR:
14 psi
22 psi
13 psi
21 psi
(97 kPa)
(152 kPa)
(90 kPa)
(145 kPa)
8 YXE85WPSL
YAMAHA MOTOR CORPORATION U.S.A. certifies this ROV
complies with the American National Standard for Recreational
Off-Highway Vehicles, ANSI/ROHVA-1-2016 Standard.
Date of manufacture **/**
B5F-F4163-00
BAS-F8459-00
7
6 YXE85WPSL
5 YXE85WPSL
UBAN10E0.book Page 5 Thursday, August 8, 2019 10:46 AM

2-6
2
YAMAHA B8K-F1696-00
WARNING
• Improper tire pressure or overloading this vehicle may
cause severe injury or death from loss of control or
rollover.
• Never set or allow tire pressure to be below the minimum.
Tire may dislodge from rim.
• VEHICLE LOAD of 0 lb (0 kg) ~ 441 lbs (200 kg)
Recommended: FRONT:
REAR:
Minimum: FRONT:
REAR:
14 psi
14 psi
13 psi
13 psi
(97 kPa)
(97 kPa)
(90 kPa)
(90 kPa)
*
Vehicle load is weight of operator, passenger,
accessories, cargo, and (if applicable) trailer tongue
weight. Do not exceed maximum vehicle load.
Gross Vehicle Weight Rating: 2866 lbs (1300 kg)
maximum including vehicle, weight of operator,
passenger, accessories, cargo, and (if applicable)
trailer tongue weight.
OPERATING TIRE PRESSURE: With tires cold, set as follows.
• VEHICLE LOAD of 441 lbs (200 kg) ~ 1270 lbs (576 kg)
Recommended: FRONT:
REAR:
Minimum: FRONT:
REAR:
14 psi
23 psi
13 psi
22 psi
(97 kPa)
(159 kPa)
(90 kPa)
(152 kPa)
YAMAHA BG4-F151K-00
WARNING
Improperly loading a trailer
or pulling an object can
affect handling, stability, and
risk of overturn or other
accidents.
• Secure load to prevent it
from shifting.
• Never load more than 620 N
(63 kgf)/141 lbf tongue
weight on towing bracket.
• Do not tow more than
8888 N(907 kgf)/2000 lbf
rolling weight (trailer plus
cargo).
• Tow or pull only from hitch
bracket.
• Read Owner’s Manual
before loading, towing, or
pulling objects.
8 YXE85WPHL/ YXE85WPAL/YXE85WPBL 9
UBAN10E0.book Page 6 Thursday, August 8, 2019 10:46 AM

2-7
2
YAMAHA 5UG-F151J-00
MAX 7.3 INCH
(185MM)
BG4-F1684-00
INTAKE MANIFOLD
#1
PRESS. SENSOR
THROTTLE BODY
SOLENOID VALVE
#1
#2 ROLL OVER
VALVE
CANISTER
TO ATMOSPHERE
FROM FUEL TANK
VACUUM HOSE ROUTING
EMISSION HOSE ROUTING
10 11
UBAN10E0.book Page 7 Thursday, August 8, 2019 10:46 AM

2-8
2
YAMAHA BAN-F4897-00
WARNING
• Load or trailer may affect handling and stability.
• Do not exceed the maximum load ratings for the
cargo bed , trailer tongue, or vehicle.
• When loaded with cargo or towing a trailer:
• Reduce speed and allow more room to stop.
• Turn gradually and slowly.
• Avoid hills and rough terrain.
• Secure cargo so that it will not shift - a loose load
could change handling unexpectedly or be thrown
forward and strike occupants.
• Keep weight in the cargo bed centered side to side and
as low as possible. Top-heavy loads increase the risk of a
rollover.
• Do not tow or pull objects from any point other than
the trailer hitch bracket or winch (if installed).
•
Read Owner’s Manual before loading, towing, or pulling objects.
Improper use of cargo area, rear
seats, and/or cage/frame
can result in severe
injury or death from
loss of control, overturn
or other accidents.
Maximum Load in Cargo Bed: 600 lbs (272 kg)
Maximum Vehicle Load: 1187 lbs (538.5 kg)
Never carry
passengers
in cargo bed.
YAMAHA B8K-F4897-00
WARNING
• Load or trailer may affect handling and stability.
• Do not exceed the maximum load ratings for the
cargo bed , trailer tongue, or vehicle.
• When loaded with cargo or towing a trailer:
• Reduce speed and allow more room to stop.
• Turn gradually and slowly.
• Avoid hills and rough terrain.
• Secure cargo so that it will not shift - a loose load
could change handling unexpectedly or be thrown
forward and strike occupants.
• Keep weight in the cargo bed centered side to side and
as low as possible. Top-heavy loads increase the risk of a
rollover.
• Do not tow or pull objects from any point other than
the trailer hitch bracket or winch (if installed).
•
Read Owner’s Manual before loading, towing, or pulling objects.
Improper use of cargo area, rear
seats, and/or cage/frame
can result in severe
injury or death from
loss of control, overturn
or other accidents.
Maximum Load in Cargo Bed: 600 lbs (272 kg)
Maximum Vehicle Load: 1270 lbs (576 kg)
Never carry
passengers
in cargo bed.
12 YXE85WPSL 12 YXE85WPHL/ YXE85WPAL/YXE85WPBL
UBAN10E0.book Page 8 Thursday, August 8, 2019 10:46 AM
