Yamaha YFZ 50 2020 User manual

DIC183
BW4-F8199-14LIT-11626-34-07
This ATV should not be ridden by anyone under 6 years of age.
WARNING
YFZ05YYXM
OWNER’S MANUAL
READ THIS MANUAL CAREFULLY!
It contains important safety information.

EBU37021
Operating, servicing and
maintaining a passenger vehicle or off-road vehicle can
expose you to chemicals including engine exhaust,
carbon monoxide, phthalates, and lead, which are
known to the State of California to cause cancer and
birth defects or other reproductive harm. To minimize
exposure, avoid breathing exhaust, do not idle the
engine except as necessary, service your vehicle in a
well-ventilated area and wear gloves or wash your
hands frequently when servicing your vehicle. For more
information go to
www.P65Warnings.ca.gov/passenger-vehicle
Read this manual carefully before operating this vehicle. This manual should stay with this ve-
hicle if it is sold.
UBW414E0.book Page 1 Wednesday, January 22, 2020 9:28 AM

EBU17171
INTRODUCTION
EBU17183
Congratulations on your purchase of the Yamaha YFZ05YYXM. This ATV represents the result of many
years of Yamaha experience in the production of fine sporting, touring, and pacesetting racing machines.
With the purchase of this Yamaha, you can now appreciate the high degree of craftsmanship and reliability
that have made Yamaha a leader in these fields.
This manual will provide you with a good basic understanding of the features and operation of this ATV.
This manual includes important safety information. It provides information about special techni-
ques and skills necessary to ride the ATV. It also includes basic maintenance and inspection proce-
dures. If you have any questions regarding the operation or maintenance of your ATV, please consult a
Yamaha dealer.
AN IMPORTANT SAFETY MESSAGE:
Read this manual together with TIPS FOR THE ATV RIDER carefully and completely before operating
your ATV. Make sure you understand all instructions.
Pay close attention to the warning and notice labels on the ATV.
Never operate an ATV without proper training or instruction. Free training is available to anyone who
buys a new ATV. Call 1-800-887-2887 for more information.
This ATV should not be operated by a child under 6 years of age.
UBW414E0.book Page 1 Wednesday, January 22, 2020 9:28 AM

AN IMPORTANT NOTE TO PARENTS:
This ATV is not a toy. Before you let your child ride this ATV, you should understand the instructions and
warnings in this Owner’s Manual. Then be sure your child understands and will follow them. Children differ
in skills, physical abilities and judgment. Some children may not be able to operate an ATV safely. Parents
should supervise their child’s use of the ATV at all times. Parents should permit continued use only if they
determine that the child has the ability to operate the ATV safely.
Your ATV was delivered with an adjustable speed limiter. Yamaha recommends that all beginners start off
to limit the amount of speed available while they learn. The adjusting screw may be gradually turned out
as the beginner becomes more familiar with operating the ATV. Parents should decide when to adjust the
ATV for more power as their youngster’s riding skills improve. Once the ATV rider can operate with skill at
the top speed permitted by adjusting the vehicle speed limiter alone, the engine speed limiter plate can be
removed. Since removal of this limiter will result in a significant increase in power, turn the vehicle speed
limiter adjusting screw completely back in again; adjust it out in stages as done previously.
If your child is a beginner or is inexperienced, he or she should take a training course. See the previous
page for information about the free training available to purchasers of new ATVs.
UBW414E0.book Page 2 Wednesday, January 22, 2020 9:28 AM

EBU17331
IMPORTANT MANUAL INFORMATION
EBU17344
FAILURE TO FOLLOW THE WARNINGS CONTAINED IN THIS MANUAL CAN RESULT IN SERIOUS IN-
JURY OR DEATH.
Particularly important information is distinguished in this manual by the following notations:
TIP
Product and specifications are subject to change without notice.
The ATV you have purchased may differ slightly from the figures shown in this manual.
This is the safety alert symbol. It is used to alert you to potential per-
sonal injury hazards. Obey all safety messages that follow this sym-
bol to avoid possible injury or death.
A WARNING indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
A NOTICE indicates special precautions that must be taken to avoid
damage to the vehicle or other property.
A TIP provides key information to make procedures easier or clearer.
WARNING
NOTICE
TIP
UBW414E0.book Page 1 Wednesday, January 22, 2020 9:28 AM

EBU17351
IMPORTANT NOTICE
EBU17363
This ATV is designed and manufactured for off-road use only. It is illegal and unsafe to operate this ATV
on any public street, road or highway.
This ATV complies with all applicable off-road noise level and spark arrester laws and regulations in effect
at the time of manufacture.
Please check your local riding laws and regulations before operating this ATV.
EBU34380
YFZ05YYXM
OWNER’S MANUAL
©2021 by Yamaha Motor Corporation, U.S.A.
1st edition, December 2019
All rights reserved.
Any reprinting or unauthorized use
without the written permission of
Yamaha Motor Corporation, U.S.A.
is expressly prohibited.
Printed in Taiwan.
P/N LIT-11626-34-07
UBW414E0.book Page 1 Wednesday, January 22, 2020 9:28 AM

WARNING
EWB00012
Indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
EBU17421
TABLE OF CONTENTS
VEHICLE IDENTIFICATION ............................1-1
Identification numbers ................................1-1
LOCATION OF THE WARNING AND
SPECIFICATION LABELS ..............................2-1
SAFETY INFORMATION ................................3-1
DESCRIPTION................................................ 4-1
Left view......................................................4-1
Right view....................................................4-1
Controls and instruments............................4-2
INSTRUMENT AND CONTROL
FUNCTIONS................................................... 5-1
Main switch ................................................. 5-1
Handlebar switches ....................................5-2
Engine stop switch with lanyard................. 5-2
Throttle lever............................................... 5-3
Speed limiter............................................... 5-4
Front brake lever......................................... 5-6
Rear brake lever ......................................... 5-6
Parking brake ............................................. 5-6
Kickstarter .................................................. 5-7
Fuel tank cap .............................................. 5-9
Fuel ........................................................... 5-10
Fuel cock .................................................. 5-11
Starter (choke) ......................................... 5-12
Seat .......................................................... 5-13
Rear shock absorber ................................ 5-14
PRE-OPERATION CHECKS .......................... 6-1
Fuel ............................................................. 6-3
Engine oil .................................................... 6-3
Transmission oil.......................................... 6-3
Front and rear brakes ................................. 6-3
Throttle lever............................................... 6-3
Drive chain.................................................. 6-3
Tires ............................................................ 6-3
Chassis fasteners ....................................... 6-6
Instruments and switches........................... 6-6
OPERATION .................................................. 7-1
Starting a cold engine................................. 7-1
UBW414E0.book Page 1 Wednesday, January 22, 2020 9:28 AM

Starting a warm engine ...............................7-3
Engine break-in ........................................... 7-3
Parking ........................................................7-3
Parking on a slope ......................................7-4
Accessories and loading .............................7-5
RIDING YOUR ATV ........................................ 8-1
GETTING TO KNOW YOUR ATV ................8-2
RIDE WITH CARE AND GOOD
JUDGMENT ..............................................8-2
BE CAREFUL WHERE YOU RIDE...............8-9
TURNING YOUR ATV................................8-12
CLIMBING UPHILL ...................................8-14
RIDING DOWNHILL ..................................8-17
CROSSING A SLOPE................................8-18
CROSSING THROUGH SHALLOW
WATER....................................................8-19
RIDING OVER ROUGH TERRAIN .............8-20
SLIDING AND SKIDDING..........................8-21
WHAT TO DO IF........................................8-22
PERIODIC MAINTENANCE AND
ADJUSTMENT................................................9-1
Owner’s Manual and tool kit .......................9-2
Periodic maintenance chart: Emission
control system ..........................................9-3
Periodic maintenance chart: General
maintenance and lubrication .................... 9-5
Removing and installing the panel.............. 9-9
Checking the spark plug............................. 9-9
Engine oil .................................................. 9-11
Why Yamalube.......................................... 9-14
Transmission oil........................................ 9-15
Cleaning the air filter element ................... 9-16
Cleaning the spark arrester ...................... 9-19
Adjusting the carburetor ........................... 9-20
Adjusting the engine idling speed ............ 9-20
Adjusting the throttle lever free play......... 9-22
Valve clearance......................................... 9-22
Brakes....................................................... 9-22
Checking the front and rear brake
shoes ...................................................... 9-23
Adjusting the front brake lever free play... 9-24
Adjusting the rear brake lever free play.... 9-26
Drive chain slack....................................... 9-26
Cleaning and lubricating the drive
chain ....................................................... 9-29
Checking and lubricating the cables ........ 9-29
Checking and lubricating the front and
rear brake levers ..................................... 9-30
Checking the wheel hub bearings ............ 9-30
Lubricating the front arm pivots ............... 9-31
Lubricating the front knuckle pivots ......... 9-31
UBW414E0.book Page 2 Wednesday, January 22, 2020 9:28 AM

Lubricating the steering shaft ................... 9-32
Battery.......................................................9-32
Replacing the fuse ....................................9-35
Removing a wheel..................................... 9-36
Installing a wheel.......................................9-36
Troubleshooting ........................................9-37
Troubleshooting chart...............................9-38
CLEANING AND STORAGE .........................10-1
Cleaning ....................................................10-1
Storage......................................................10-2
SPECIFICATIONS ........................................11-1
CONSUMER INFORMATION ....................... 12-1
Vehicle Emission Control Information
label.........................................................12-1
Noise regulation ........................................12-2
Maintenance record ..................................12-3
YAMAHA MOTOR CORPORATION,
U.S.A. 2020 AND LATER MODEL ATV
LIMITED WARRANTY .............................12-4
YAMAHA EXTENDED SERVICE (Y.E.S.) ... 12-6
INDEX...........................................................13-1
UBW414E0.book Page 3 Wednesday, January 22, 2020 9:28 AM

1-1
1
EBU38860
VEHICLE IDENTIFICATION
EBU26016
Identification numbers
Record the vehicle identification number, model
label information and key identification number in
the spaces provided below.
VEHICLE IDENTIFICATION NUMBER:
MODEL LABEL INFORMATION:
KEY IDENTIFICATION NUMBER:
EBU26032
Vehicle identification number
The vehicle identification number is stamped into
the frame. This 17-digit number is used to identify
your individual ATV.
EBU26053
Model label
The model label is affixed at the location shown.
1. Vehicle identification number
1
UBW414E0.book Page 1 Wednesday, January 22, 2020 9:28 AM

1-2
1
Your specific model can be identified by checking
the model type code found on the model label.
EBU26021
Key identification number
The key identification number is stamped into the
key. Record this number in the space provided
and use it for reference when ordering a new key.
1. Model label
1. Model type code
2. Production code
3. Color code
1
*
****
-***
1
3
2
1. Key identification number
1
UBW414E0.book Page 2 Wednesday, January 22, 2020 9:28 AM

2-1
2
EBU17661
LOCATION OF THE WARNING AND SPECIFICATION LABELS
1
45
2 3
UBW414E0.book Page 1 Wednesday, January 22, 2020 9:28 AM

2-2
2
EBU17673
Read and understand all of the labels on your ATV. These labels contain important information for safe and
proper operation.
Never remove any labels from your ATV. If a label becomes difficult to read or comes off, request a re-
placement label from your Yamaha dealer.
UBW414E0.book Page 2 Wednesday, January 22, 2020 9:28 AM

2-3
2
BD3-F1568-00
ll
ll
l
l
l
l
ll
ll
II
I
I
l
I
ll
I
l
l
I
ll
l
I
I
WARNING
UNDER
6
Operation of this ATV by children
under the age of 6 increases the
risk of severe injury or death.
Adult supervision required for children
under age 16.
NEVER permit children under age 6
to operate this ATV.
BW4-F816L-00
12
UBW414E0.book Page 3 Wednesday, January 22, 2020 9:28 AM

2-4
2
2017
BD3-F817J-60
BD3-F151H-00
l
l
I
I
l
2.2 15
2.2 15
1.7 12
1.7 12
90 41
BW4-F816M-20
34
5
UBW414E0.book Page 4 Wednesday, January 22, 2020 9:28 AM

3-1
3
EBU17432
SAFETY INFORMATION
SAFETY INFORMATION
EBU36513
AN ATV IS NOT A TOY AND CAN BE HAZARD-
OUS TO OPERATE.
An ATV handles differently from other vehicles, in-
cluding motorcycles and cars. A collision or roll-
over can occur quickly, even during routine
maneuvers such as turning and riding on hills or
over obstacles, if you fail to take proper precau-
tions.
SEVERE INJURY OR DEATH can result if you do
not follow these instructions:
Read this manual and all labels carefully and fol-
low the operating procedures described.
Never operate an ATV without proper training or
instruction. Take a Training Course. Beginners
should receive training from a certified instruc-
tor. Contact an authorized ATV dealer or call 1-
800-887-2887 to find out about the training
courses nearest you.
Always follow the age recommendation:
– A child under 6 years old should never operate
an ATV with engine size greater than 50 cc.
– A child under 12 years old should never oper-
ate an ATV with engine size greater than 70 cc.
– A child under 16 years old should never oper-
ate an ATV with engine size greater than 90 cc.
Never allow a child under age 16 to operate an
ATV without adult supervision, and never allow
continued use of an ATV by a child if he or she
does not have the abilities to operate it safely.
Never carry a passenger on an ATV.
Always avoid operating an ATV on any paved
surfaces, including sidewalks, driveways, park-
ing lots and streets.
Never operate an ATV on any public street, road
or highway, even a dirt or gravel one.
Never operate an ATV without wearing an ap-
proved motorcycle helmet that fits properly.
You should also wear eye protection (goggles
or face shield), gloves, boots, a long-sleeved
shirt or a jacket, and long pants.
Never consume alcohol or drugs before or while
operating this ATV.
UBW414E0.book Page 1 Wednesday, January 22, 2020 9:28 AM

3-2
3
Never operate at speeds too fast for your skills
or the riding conditions. Always go at a speed
that is proper for the terrain, visibility, operating
conditions, and your experience.
Never attempt wheelies, jumps, or other stunts.
Always inspect your ATV each time you use it to
make sure it is in safe operating condition. Al-
ways follow the inspection and maintenance
procedures and schedules described in this
manual.
Always keep both hands on the handlebars and
both feet on the footrests of the ATV during op-
eration.
Always go slowly and be extra careful when op-
erating on unfamiliar terrain. Always be alert to
changing terrain conditions when operating the
ATV.
Never operate on excessively rough, slippery or
loose terrain until you have learned and prac-
ticed the skills necessary to control the ATV on
such terrain. Always be especially cautious on
these kinds of terrain.
Always follow proper procedures for turning as
described in this manual. Practice turning at low
speeds before attempting to turn at faster
speeds and never turn at excessive speeds.
Never operate the ATV on hills too steep for the
ATV or for your abilities. Practice on smaller hills
before attempting larger hills.
Always follow proper procedures for climbing
hills as described in this manual. Check the ter-
rain carefully before you start up any hill. Never
climb hills with excessively slippery or loose
surfaces. Shift your weight forward. Never open
the throttle suddenly or make sudden gear
changes. Never go over the top of a hill at high
speed.
Always follow proper procedures for going
down hills and for braking on hills as described
in this manual. Check the terrain carefully before
you start down any hill. Shift your weight back-
ward. Never go down a hill at high speed. Avoid
going down a hill at an angle that would cause
the vehicle to lean sharply to one side. Go
straight down the hill where possible.
Always follow proper procedures for crossing
the side of a hill as described in this manual.
Avoid hills with excessively slippery or loose
surfaces. Shift your weight to the uphill side of
the ATV. Never attempt to turn the ATV around
on any hill until you have mastered the turning
UBW414E0.book Page 2 Wednesday, January 22, 2020 9:28 AM

3-3
3
technique described in this manual on level
ground. Avoid crossing the side of a steep hill if
possible.
Always use proper procedures if you stall or roll
backwards when climbing a hill. If you stall or
roll backwards, follow the special procedure for
braking described in this manual. Apply the
front brake or dismount on the uphill side or to
a side if pointed straight uphill. Turn the ATV
around and remount, following the procedure
described in this manual.
Always check for obstacles before operating in
a new area.
Never attempt to operate over large obstacles,
such as large rocks or fallen trees. Always follow
proper procedures when operating over obsta-
cles as described in this manual.
Always be careful when skidding or sliding.
Learn to safely control skidding or sliding by
practicing at low speeds and on level, smooth
terrain. On extremely slippery surfaces, such as
ice, go slowly and be very cautious in order to
reduce the chance of skidding or sliding out of
control.
Never operate an ATV in fast flowing water or in
water deeper than that recommended in this
manual. Remember that wet brakes may have
reduced stopping ability. Test your brakes after
leaving water. If necessary, apply them several
times to let friction dry out the linings.
Always use the size and type of tires specified in
this manual.
Always maintain proper tire pressure as de-
scribed in this manual.
Never exceed the stated load capacity for an
ATV. Cargo should be properly distributed and
securely attached. Reduce speed and follow in-
structions in this manual for carrying cargo or
pulling a trailer. Allow greater distance for brak-
ing.
Do not operate your ATV during darkness un-
less it is equipped with a properly functioning
headlight. Off-road riding is inherently danger-
ous and additionally, off-road trails do not have
streetlights to guide you.
Never maintain an ATV without proper knowl-
edge. Contact an authorized ATV dealer to in-
form you on basic ATV maintenance. Certain
maintenance can only be carried out by certified
staff.
UBW414E0.book Page 3 Wednesday, January 22, 2020 9:28 AM

3-4
3
In the event of an accident
1. If serious injuries are incurred, you may be
safer staying next to your vehicle; it may
shield you from oncoming riders. Depending
on your injuries and position in the trail; you
must make a judgment call as to whether you
should move to a position off the trail. If you
have sustained head, neck, or back injuries,
or cannot feel your limbs, you should not
move. Keep your helmet on and remain mo-
tionless. Lie down next to your vehicle and
wait for help.
2. If less serious injuries are incurred and you
can walk, then move to a position off the trail.
Check yourself for injuries and apply first aid
as needed.
3. If your injuries are light, when safe to do so,
move your vehicle off the trail to avoid colli-
sions with oncoming riders. Check for injuries
and apply first aid as necessary. If you can
physically operate your vehicle, inspect your
vehicle. If the vehicle is in safe operating con-
dition and you can safely operate it, restart it
and ride gently back to camp or other known
location where you can receive medical at-
tention. If necessary, contact your riding party
or local authorities to let them know where
you are and what has happened.
In the event of a breakdown
1. If your vehicle will not restart or is not in safe
operating condition, turn off the main switch
and engine stop switch. If the breakdown oc-
curs at twilight or night, leave the main switch
on so that your lights may warn other riders of
your stopped vehicle.
2. Get out of danger. Check for oncoming vehi-
cles and when safe, push your vehicle to the
side of the trail or even off the main trail to
avoid any possible collisions with oncoming
riders. If you cannot move your vehicle by
yourself, when safe, walk to the nearest van-
tage point and signal an oncoming rider to
help you push your vehicle to a safe place off
the trail.
3. Inspect your vehicle for any immediate haz-
ardous conditions. The most obvious hazard-
ous conditions are leaking fuel and
ungrounded or broken wiring. Visually check
for broken wiring and leaking fuel. Leaking
fuel can be confirmed by the odor of gasoline.
UBW414E0.book Page 4 Wednesday, January 22, 2020 9:28 AM

3-5
3
4. Once immediate safety hazards are con-
firmed not to exist, you may remove your hel-
met to more closely inspect your vehicle.
Check for external signs of wear, broken
parts, fluid leaks, cracks in the frame, sus-
pension damage, wheel damage, and so on.
Fuel, oil, and coolant usually give off a notice-
able odor.
5. If your vehicle will not restart or if it is unsafe
to ride, then turn off all vehicle systems (en-
gine stop switch, main switch, and fuel cock),
and then signal or go for help.
Aftermarket Parts, Accessories, and Modifica-
tions
While you may find aftermarket products similar in
design and quality to genuine Yamaha accesso-
ries, recognize that some aftermarket accessories
or modifications are not suitable because of po-
tential safety hazards to you or others. Installing
aftermarket products or having other modifica-
tions performed to your vehicle that change any of
the vehicle’s design or operation characteristics
can put you and others at greater risk of serious
injury or death. You are responsible for injuries re-
lated to changes in the vehicle. Keep the following
guidelines in mind, as well as those found in the
Loading section (page 7-6) when mounting acces-
sories.
Never install accessories that would impair the
performance of your ATV. Carefully inspect the
accessory before using it to make sure that it
does not in any way reduce ground clearance,
limit suspension travel, steering travel or control
operation.
Accessories fitted to the ATV can create insta-
bility due to improper weight distribution.
Bulky or large accessories may seriously affect
the stability of the ATV.
Certain accessories can displace the operator
from his or her normal riding position. This im-
proper position limits the freedom of movement
of the operator and may limit control ability,
therefore, such accessories are not recom-
mended.
Use caution when adding electrical accesso-
ries. If electrical accessories exceed the capac-
ity of the ATV’s electrical system, an electric
failure could result, which could cause a dan-
gerous loss of lights or engine power. Also, the
battery tends to discharge more quickly if elec-
trical accessories are added.
UBW414E0.book Page 5 Wednesday, January 22, 2020 9:28 AM
