SERVICE MANUAL

PA 011610 HAMAMATSU, JAPAN

CONTENTS

SPECIFICATIONS ................................................. 3

PERFORMANCE GRAPH .......................................... 4

PANEL LAYOUT ...................................... 4

CIRCUIT BOARD LAYOUT ................. 5

DIMENSIONS ............................................................ 5

WIRING ............................................................... 6

BLOCK DIAGRAM ........................... 7

DISASSEMBLY PROCEDURE .............................. 8

IC BLOCK DIAGRAM ................................... 11

CIRCUIT BOARDS ......................................... 11

INSPECTIONS ....................................................... 14/15

OVERALL CIRCUIT DIAGRAM

PARTS LIST

SW500
