This instruction manual covers Σ-II series SGDH fully closed I/F Unit (hereinafter called
FC100 Unit), which is an option unit to be connected to Σ-II series SGDH SERVO-
PACK.With a FC100 Unit properly mounted, the SGDH SERVOPACK can be used for fully
closed encoder.
To properly use the FC100 Unit, read this manual thoroughly and retain for easy reference
for inspections and maintenance etc.
Reference materials are listed below:
Manual Titles manual No.
Σ−II series SGMjH/SGDH User’s Manual
Servo Selection and Data Sheets
SIE-S800-32.1
Σ−II series SGMjH/SGDH User’s Manual
Design and Maintenance
SIE-S800-32.2
Σ−II series SGDH full-closed I/F User’s Manual SIE-C718-5
AC SERVOMOTOR INSTRUCTIONS TOE-C231-2
Σ−II series SGDH Instruction Manual TOB-S800-32
General Precautions
SSome drawings in this manual are shown with the protective cover or shields removed, in order to
describe the detail with more clarity. Make sure all covers and shields are replaced before oper-
ating this product.
SSome drawings in this manual are shown as typical example and may differ from the shipped
product.
SThis manual may be modified when necessary because of improvement of the product, modifica-
tion or changes in specifications.
Such modification is made as a revision by renewing the manual No.
STo order a copy of this manual, if your copy has been damaged or lost, contact your YASKAWA
representative listed on the last page stating the manual No. on the front cover.
SYASKAWA is not responsible for accidents or damages due to any modification of the product
made by the user since that will void our guarantee.
