YIC Technologies EVK-YIC31009EBGG User manual

Evaluation Kit for YIC31009EB Series
EVK-YIC31009EBGG
User Guide
www.yic.com.tw
Y
YI IC C

Yuechung International Corp. (YIC) 2
URL: www.yic.com.tw E-mail: servic[email protected]
Y
YI IC C
EVK-1009EB
1. Contents of EVK-YIC31009EBGG
Item
Description
1.
YIC-GPS-EVK-1009EB
Main Board
2.
YIC-GPS-EVK-1009EB
Adaptor Board
3.
USB Cable
USB Type B to USB Type A
4.
ATGG4336M-SMA-3
Single Band GNSS L1 Antenna
5.
YIC31009EBGG
GPS+GLONASS Module

Yuechung International Corp. (YIC) 3
URL: www.yic.com.tw E-mail: servic[email protected]
Y
YI IC C
EVK-1009EB
2. Install the PL2303 USB driver to PC
3.1 Install the PL2303 USB driver, open the computer control panel,
check the corresponding serial port.
3. Connection diagram
3.1 Carefully slide the DUT GPS module into main board, pin 1 of the module corresponds
to the arrow on main board.
3.2 Test connection
The driver has been installed successfully

Yuechung International Corp. (YIC) 4
URL: www.yic.com.tw E-mail: servic[email protected]
Y
YI IC C
EVK-1009EB
4. Install test software & start
4.1 For YIC31009EB series (Goke chip based)
4.1-1 Install test software: naviTrack
4.1-2 Software setting
①Select the corresponding serial port
②Select the corresponding baud rate (9600 or 115200,……)
③Click Connect to start the test

Yuechung International Corp. (YIC) 5
URL: www.yic.com.tw E-mail: servic[email protected]
Y
YI IC C
EVK-1009EB
5. LED and Push Button description
5.1 Adaptor Board
①Red LED: POWER, always on when power on
②Blue LED: RXD, often light while DUT GPS module receiving data
③Green LED: TXD, flash once per second when DUT GPS module start sending data
④Push Button: POWER, push to power on and off the EVK
5.2 Main Board
PPS LED: Flash once per second after satellite position fixed
