Yitong Technology YTMC-51N2-M3 User manual

Coaxial-to-Ethernet
Conversion Kit
YTMC-51N2-M3
MoCA 2.5 Adapter
Model#YTMC-51N2-M3
User Guide

Table of Contents
Table of Contents 1
Getting Started 1
Introduction 1
Package Contents 1
Requirements 1
Features 2
Connecting the Adapters 2
Connecting the First Adapter 2
Connecting Additional Adapters 5
Web Management 7
Specifications 8
Notices 9
Warranty 9
Important Safety Instructions 9
FCC Class B Equipment 1 0
CE 1 0
Technical Support 1 1

YTMC-51N2-M3 MoCA 2.5 Adapter
1
Getting Started
Introduction
Congratulations for purchasing the YTMC-51N2-M3 MoCA 2.5 Adapter. The Adapter
is a simple, flexible solution for extending a home network. By leveraging the
ubiquity of coaxial cabling within the modern home, the Adapter provides an
Ethernet Internet port anywhere a coaxial connection is available. It also features a
TV (TV/STB Out) coaxial port to allow for existing connections at the coaxial wall port.
This user manual explains the procedures needed to connect the Adapter.
PackageContents
• YTMC-51N2-M3 MoCA 2.5 Adapter
• Coaxial cable
• Power adapter
• Quick Start Guide
• Ethernet cable
Requirements
• Available coaxial port in installation areas
• Available electrical wall socket in installation areas

YTMC-51N2-M3 MoCA 2.5 Adapter
2
Features
• Ethernet port (gigabit)
• MoCA (Coax In) coaxial port
• TV (TV/STB Out) coaxial port
• Power, MoCA, System and Ethernet LEDs:
- Power LED: glows solid green when Adapter is powered up.
- MoCA LED: glows solid green with connection on the MoCA port.
- System LED: glows solid green when the system is online.
- Ethernet LEDs: glows green for 1000Mbps link; glows yellow for 10/100Mbps
link; blinks when data is transferred across port.
Connecting the Adapters
Connecting the Adapter is a relatively simple process. First, connect one Adapter
to the TV or set-top box, the broadband modem or router, and the coaxial
network to establish the Internet signal. Then, additional Adapters can be installed
throughout the home or office at any location Ethernet Internet access is needed,
and an available coaxial port is available.
Connecting the FirstAdapter
The first Adapter must be connected to the TV or set-top box, the broad band
modem or router,and the coaxial network. This Adapter takes the Internet signal
from the modem/router and delivers it to the coaxial network, while keeping the
TV/set-top box connected.
Toconnect the first Adapter:
1. Remove the end of the coaxial cable connected to the TV or set-top box
from its coaxial wall port.
2. Connect the end of the coaxial cable removed in step 1 to the TV coaxial port
on the side of the Adapter

YTMC-51N2-M3 MoCA 2.5 Adapter
3
3. Connect another coaxial cable into the coaxial wall port left
unconnected in step 1.
4. Connect the other end of the coaxial cable installed in step 3 to the
MoCA coaxial port on the side of the Adapter
5. Connect one end of an Ethernet cable into the Ethernet port of the
modem/router.
6. Connect the other end of the Ethernet cable into the Ethernet port on the side

YTMC-51N2-M3 MoCA 2.5 Adapter
4
of the Adapter.
7. Plug the provided power adapter into the Power port on the side of the
Adapter.
8. Plug the other end of the power adapter (external) into an electrical outlet.
When complete, the setup should look similar to the figure below:
The Internet signal is now being delivered across the coaxial network.

YTMC-51N2-M3 MoCA 2.5 Adapter
5
ConnectingAdditionalAdapters
If necessary, additional Adapter scan be placed at locations around the home or
office that need an Ethernet Internet connection, but currently only have a
coaxial port.
Toconnect additional Adapters:
1. Find a coaxial wall port near the desired location and unplug the
coaxial cable connected to the TV or set-top box. If no device is
plugged into this coaxial wall port, skip to step 3.
2. Connect the end of the coaxial cable removed in step 1 to the TV
coaxial port on the side of the Adapter.
3. Connect a coaxial cable into the coaxial wall port indicated in
step 1.
4. Connect the other end of the coaxial cable installed in step 3 to
the MoCA port on the side of the Adapter.
5. Connect one end of an Ethernet cable into the Ethernet port of
the device to connect to the Internet.
6. Connect the other end of the Ethernet cable into the Ethernet
port on the side of the Adapter.
7. Plug the provided power adapter into the Power port on the side
of the Adapter.
8. Plug the other end of the power adapter (external) into an
electrical outlet.
9. Make sure the Power, Ethernet and MoCA lights are solid green.

YTMC-51N2-M3 MoCA 2.5 Adapter
6
When complete, the setup should look similar to the figure below:
The device connected to the Ethernet port is now connected to the Internet via the
coaxial network. Repeat this process to install additional Adapters through out the
home.

YTMC-51N2-M3 MoCA 2.5 Adapter
7
Web Management
Each adapter has a web interface for management. You can visit the website to
inquire, manage and upgrade.
The default IP address of the adapter is 192.168.144.200. To connect to a given
adapter, make sure the IP address of your computer is 192.168.144.x (1-254
except 200) and connect provided Ethernet cable between your computer and
LAN port of the adapter.
Enter http://192.168.144.200 into your web browser direction setting. You can
login from a web page and set some configurations such as frequency range
modification, transmission rate option, IP address configuration, Ethernet
information.
Default connection values are:
IP address
192.168.144.200
Login
admin
Password
maxlinear

YTMC-51N2-M3 MoCA 2.5 Adapter
8
Specifications
Model Number
YTMC-51N2-M3
IP
LAN MoCA (v.2.5; up to 2.5 Gbps throughput) LAN Ethernet Port
10/100/1000 (2)
LANConnections
MoCA Frequency Range - Extended D-band: 1125MHz~1675MHz
TV Frequency Range - 5MHz~1002MHz
LED Indicators
Power,MoCA, System, LAN1, LAN2
Power
External, 5VDC, 1A, 1.3 mm diameter connector plug
Regulatory
FCC, CE, IC
Environmental
Ambient temperature - 0ºC to 40ºC (32ºF to 104ºF)
Storage temperature -- 20ºC to 85ºC (-4ºF to 185ºF)
Operating humidity - 10% to 85% non-condensing
Storage humidity - 5% to 90% non-condensing
Note: Specifications are subject to change without notice

YTMC-51N2-M3 MoCA 2.5 Adapter
9
Notices
Warranty
This product has a one-year Limited Hardware Warranty and 120-day free software
updates from date of purchase.
Local Law
This Limited Warranty Statement gives the customer specific legal rights. The
customer may also have other rights which vary from state to state in the United
States, from province to province in Canada, and from country to country
elsewhere in the world.
Tothe extent that this Limited Warranty Statement is in consistent with local law,
this Statement shall be deemed modified to be consistent with such local law.
Under such local law,certain disclaimers and limitations of this Warranty Statement
may not apply to the customer.
ImportantSafetyInstructions
Basic safety precautions should always be followed to reduce the risk of fire,
electrical shock, and personal injury, including the following:
• Do not use this product near water–for example, near a bathtub, kitchen
sink, laundry tub, or swimming pool, or in a wet basement; only clean
with dry cloth.
• Do not block any ventilation openings. Install in accordance with the
manufacturer's instructions. Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus including amplifiers that
produce heat.
• Do not use the telephone to report a gas leak in the vicinity of the leak.
• Use only the power cord and batteries indicated in this manual if
applicable. Note: you may need to reword for batteries or adapters.
• Do not dispose of batteries in fire, as they may explode –check with local
codes for possible special disposal instructions if applicable.

YTMC-51N2-M3 MoCA 2.5 Adapter
10
Coaxial Cable
If applicable, the coaxial cable screen shield needs to be connected to the Earth at
the building entrance per ANSI/NFPA70, the National Electrical Code (NEC), in
particular Section 820.93, “Grounding of Outer Conductive Shield of a Coaxial
Cable,”or in accordance with local regulation.
FCCClass B Equipment
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try and correct the
interference by implementing one or more of the following measures:
• Reorient or relocate the device;
• Increase the separation between the equipment and receiver;
• Connect the equipment to an outlet on a circuit different from that to which
the receiver is connected (applicable only to power line products);
• Consult the dealer or an experience radio or television technician for help.
Declaration of Conformity for Products Marked with
the FCC logo–USA Only
This device complies with Part 15 of the FCC Rules license-exempt RSS standard(s).
Operation is subject to the following two conditions:
1. This device may not cause harmful interference;
2. This device must accept any interference received, including
interference that may cause undesired operation of the device.
CE
EN 55032: Electromagnetic compatibility of multimedia equipment -Emission
requirements
EN 55035: Electromagnetic compatibility of multimedia equipment - Immunity
requirements

YTMC-51N2-M3 MoCA 2.5 Adapter
11
TechnicalSupport
Reset and Factory Reset
To reset the device, press the reset button available under YTMC-51N2-M3. To
reset the device into factory default settings, press the reset button available
under YTMC-51N2-M3 for 10 seconds.
The MoCA status LED is not lit after installing 2 adapters:
This indicates that no coax network has been formed. Try the following: Confirm
that the MoCA port on the adapter is connected to the coax outlet on the wall
Try another coax outlet in a different room to see if the adapters connect Check
to see if a cable or terrestrial TV signal is available on both cable wall outlets
Check your cable junction box to make sure the rooms are connected on the
same splitter
My cable modem or set-top box does not work correctly after
installing the adapter:
The adapter may be incompatible with your cable device - don’t use the TV port.
Use a coax splitter to go from the coax outlet to the splitter and then run separate
coax cables to the cable modem/STB and another coax to the adapter.
If you are still having problems, try using a “MoCA POE (point of Entry) Filter” at the
input of the cable modem/STB, this filter blocks the MoCA signal from passing
through to the device. MoCA POE Filters are available online.
I have DirecTV or DISH network:
These Ethernet-to-Coax adapters are designed for use with Cable TV or Terrestrial
(rabbit ears) TV. Connect your satellite operator for adapters that are compatible
with your TV system.
