Yokekon KC-MH-2301W User manual

KC-MH-2301W
User Manual
Thanks for your purchase.
We provide a one-year warranty.
If any quality issues,
replacement or refund is available.
Please feel free to contact us via E-mail:
[email protected]

Precautions
Thank you for purchasing our humidifier KC-MH-2301W.
Please read this manual carefully before using
and keep it for future reference.
All pictures shown are for illustration purposes only.
Actual products may vary due to product enhancement.

Safety Guide
Attention
Components
Placement
Installation
How to Use
Water filling&Use of Essential Oil
Control Panel& Remote Control
Maintenance
FAQ
Product Specifications
Warranty
1
2-3
4
5
6
7
8-9
10-12
13-15
15-16
17
18
Contents

0101
Safety Guide
0101
01010101
Do not disassemble or modify the machine.
Do not subject the machine to strong impacts.
Do not allow liquids such as water or (flammable) detergent to enter the air inlet and
outlet to avoid electric shock or fire.
Do not connect the machine to a socket that exceeds the rated voltage or use an
extension cable, as this may cause fire or electric shock.
Do not unplug the power plug with wet hands, as this may cause electric shock or injury.
Do not block the outlet or add water to the mist outlet, as this may cause water leakage,
deformation, or failure.
Do not use acidic detergents in the main body, as they may produce toxic gas.
Do not put essential oil into the main body or water tank, as this may cause water
leakage, deformation, or failure.
Do not turn or move the product if it's filled with water and under working condition.
Do not remove the main motor when the product is in working condition.
Do not hit the product with a hard object.
Do not insert your fingers, water or other objects into the air inlet and outlet.
Do not use this product near gas appliances, heating devices or stoves.
Do place the humidifier 2 meters away from furniture and electronic devices.
Do not use this product in a humid or hot environment such as a bathroom, toilet or
kitchen.
The water temperature inside the tank will heat up during the heater operation of the
warm mist function. Please don't touch it directly as there is a risk of burns.

02
Attention
02
02
Please check that the
plug and power cord
are intact to avoid the
risk of electric shock.
Keep the power cord away from
heat sources.
This product is for household use
only; do not use it
outdoors.
Do not immerse the product in
water or any other liquids, and
do not touch the machine with
wet hands to prevent
electrical leakage
accidents.
Ensure that the power source
is properly grounded and the
local voltage matches the
voltage indicated on the
product.
Avoid placing the product
on a hot surface.
120V~

Attention
03
professional repair personnel are
prohibited from disassembling
or repairing it, as it may
result in fire, electric
shock, or injury accidents.
Do not modify the product, and non-
If the power cord or plug of the product
is damaged or if the product has been
dropped on the ground, do not
continue using it. If the power
cord is damaged, please
contact the after-sales
team for assistance.
Always disconnect the power before
cleaning the product.
If the product malfunctions, please stop
using it immediately and disconnect the
power. Contact the after-sales
team by email.
and individuals with impaired abilities.
Children and individuals with impaired
abilities should use this product under
adult supervision.
Keep this product out of reach of children
When discarding the product, it is
recommended to cut off the power
cord. Also, take similar precautions
for any parts that may pose a
danger, especially those that
could be hazardous to children.

Components
04
Mist Outlet Cover
Display
Tank Handle
Main Body
Water Pipe
Water Pump
Power Cord
Sensor
Water Viewport
Water Tank
Base
Float
Main Body Inside Remote Control
Atomizer
Water Overflow Port Fan Outlet
Water Outlet
Absorption Pad
Heating Element
Essential Oil Tray

Place the humidifier on a level, dry surface that is free from any inclinations. Ensure
that it is horizontally positioned at a distance of more than 50 cm from any furniture,
walls, appliances, or other items.
Avoid using the humidifier in the following situations to prevent water leakage,
signal jamming, damage, or injury:
Please follow these guidelines carefully to ensure the safe and proper operation of
your humidifier. If you have any questions or concerns, please refer to the user
manual or contact customer support.
In direct sunlight.
On an unstable platform.
In high temperatures, humidity, or dust.
Near heat sources like air conditioners,
heaters, stoves, or any other objects that emit
heat.
Under tables, curtains, carpets, bedding, or
any other similar objects to avoid dampness.
Near objects that emit radio waves such as
radios.
Near precision instruments like mobile phones,
computers, and other electronic devices.
Placement
05

1. Take the main body out of the packaging and remove the remote control
and other accessories from the water tank.
2. Before using the remote control, remove the insulating plastic sheet.
3. Before use, please remove the packaging bag of the water pump and
check if the water pipe is connected to both ends of the water pump and
the main body's interface.
4. Place the main body on the water tank properly.
Installation
06

Before adding water, you must first remove the protective cover on the water pump.
Make sure to disconnect the power before adding water.
1. Place the machine on a level surface. First, remove the protective cover on the water
pump by lifting the machine head. Then, add water to the water tank. There are two
ways to add water, as shown in the figures below (Fig. 1 and Fig. 2). Fill the water tank
up to the "MAX" mark indicated.
2. Place the machine's base stably on the water tank, and after covering the small cap of
the water inlet, plug the power cord of the machine into the socket. Before turning on
the power, make sure that the voltage of the machine matches the voltage of the power
source being used.
3. When the water level in the machine's water tank is too low, the machine will
automatically stop the atomization function and stop working. At the same time, a
corresponding water shortage prompt will appear. If you need to add water to the water
tank, please unplug the power cord first.
Fig. 1 :
You can directly add water to
the machine at the top grid.
Fig. 1 :
Lift the machine head and add
water to the water tank.
How to Use
07

Water Filling & Use of Essential Oil
08
Add water slowly from the top without
opening the lid.
Remove the main body and add water to
the water tank directly.
Add water below 40°C to the water tank.
Distilled water or RO water is recommended.
Please do not exceed the maximum water mark.
Please do not allow water to enter the mist outlet, or water may enter the inside and cause
the machine to malfunction.
Please do not add mineral water, plasma water or tap water that has not been used for a
long time. If mold or impurities grow, it may cause health problems.
When the water is insufficient, the machine will prompt water shortage and automatically
shut down. Please refill with water and turn it on.
Regarding water accumulation in the base: The humidifier uses ultrasonic vibration of the
misting plate to disperse liquid water into a mist. The water tank is merely a transitional
water storage tool, and all humidifiers' base reservoirs will accumulate water. Please use it
with confidence.

Water Filling & Use of Essential Oil
09
To use essential oil, pull out the essential oil box located on the left side of the machine
head.
Place a tissue or sponge underneath before adding essential oil.
Drip a few drops of it on the cotton to enjoy the fragrance. (DO NOT put too much
essential oil, otherwise, the humidifier will crack due to corrosion). Essential oil can only
be used inside the essential oil box.
Turn on the humidifier. The humidifier will automatically diffuse aroma when used.
Do not put essential oil directly into the water tank or sink, as it may cause water leakage,
deformation or failure.
This humidifier uses a small heat-based aroma diffuser. The aroma is intended to be light.

10
Control Panel& Remote Control
Child Lock
Indicator
Temperature
Indicator
Mist Level
Indicator
Humidity
Set Indicator
Interval Mist Function Indicator
Interval Mist
Function Button Power Button
Mist Level Button
Sleep Mode
Button
Humidity Setting Button
Child Lock Button Warm Mist Function Button
Timer Button
Sleep Indicator
Relative Humidity(RH)
Percentage Indicator
Warm Mist Indicator Water Shortage Indicator
Timer Function Indicator
Timer Indicator
F

11
Control Panel& Remote Control
After the machine is connected to the power supply, the buzzer will emit
a "beep" sound. Then, lightly touch this button, and the display screen
will light up, indicating that the machine is in operation with the mist level
set to maximum. To turn off the machine, lightly touch this button again.
Display & Buttons Remote Control
Lightly touch this button to select the interval mist mode with the following
cycles: mist for 1 minute, stop for 2 minutes; mist for 1 minute, stop for 4
minutes; mist for 1 minute, stop for 6 minutes. To exit the interval mist
mode, lightly touch the button again. The display will show the corresponding
values: MIN 2-4-6.
During the operation of the machine, lightly touch this button to activate the
constant humidity function. Set the humidity range from 45% to 95% and
then exit. Press the button to increase the humidity level by 5% increments.
The current operation will be automatically set as the default after 3 seconds.
The display will show the corresponding values. The function is initially
turned off by default when the machine is powered on.
Power
Interval Mist
Humidity
FF

12
During the operation of the machine, lightly touch this button to set the
misting time range from 1 to 12 hours. The current operation will be
automatically set as the default after 3 seconds. The display will show the
corresponding values. The function is initially turned off by default when
the machine is powered on.
Timer
Control Panel& Remote Control
In the working state of the machine, lightly touch this button to activate the
sleep function. The sleep mode icon will be dimly lit on the screen. Press
any button to exit the sleep mode. The sleep mode is set to be off by
default when turning on the machine.
Press and hold the button for about 3 seconds to enable or disable the Child
Lock function. The default setting is off when the machine is powered on.
In the working state of the machine, lightly touch this button to turn the
heating function on or off. The corresponding icon will light up or go out
accordingly. The heating function is set to be off by default when turning
on the machine.
In the power-on state, press this button to cycle between low mist, medium
mist, and high mist settings. The corresponding indicator on the display will
light up accordingly.
● Before using the remote control, please remove the insulation plastic sheet.
● Point the infrared emitter of the remote control towards the humidifier's control panel.
● If there is water around the machine during use, it indicates that the room humidity is too
high. Please adjust the mist level accordingly.
Sleep
Child Lock
Max-Min
Warm

External
Water Sink& tank
Maintenance
Clean the external surface of the humidifier 1-2 times a
week using a clean cloth to remove dust and dirt.
If the dirt is stubborn, soak the cloth in a neutral detergent
before wiping.
Make sure the main body is completely dry before use.
Clean the water sink and tank 1-2 times a week as water
can cause minerals and organic matter to accumulate,
affecting the function of the humidifier.
Use a soft cloth or brush to clean the internal surfaces of
the sink and tank.
For stubborn dirt, soak the cloth in white vinegar or baking
soda before wiping.
13

Maintenance
Water Pump
If you notice sediment in the water pipe, you can clean it using a slim brush or contact our
customer service to request a replacement. Follow these steps to clean or replace the
water pipe:
1. Unplug the water pipe from the humidifier.
2. Clean the water pipe using a slim brush, or replace it if necessary.
3. Reinstall the water pipe by plugging it back into the humidifier.
4. If the water pipe is too long, you can cut it to a suitable length before reinstalling it.
Note:
Always disconnect the power plug before performing any maintenance on the humidifier.
Do not directly flush the whole machine with water as this can cause short circuit and failure.
Use mild detergent and make sure to remove any residue to avoid harm to health.
If the humidifier will not be used for more than 24 hours, pour out the water from the tank
and sink to avoid mold or impurities that may be harmful to health.
14

Q：Why does the humidifier emit mist even when the display is dark?
A：There may be a power issue or the electricity is not connected properly. Reconnect
the power supply as a solution. If you are still having problems, please get in touch
with our customer care team.
Q：Why is there no mist despite the display lighting up?
A1: The water level in the water sink may be excessively high. Drain some water from
the water tank or upper sink area before replacing the cover.
A2: Is the water pipe loose or disconnected? Please securely fit the water pipe back
onto the water pump and the main body's interface.
FAQ
Maintenance
15

Q：Why is there so little mist?
A：There could be several reasons, such as unclean water, a dirty atomizer plate, or a
clogged air intake. Clean the atomizer plate, replace the water with clean water,
and then check if the air inlet is blocked.
Q：Why is there unusual noise?
A：There could be too little water or the humidifier may be placed on an unstable
surface. Place the humidifier on a solid and sturdy surface and fill the water tank
with water.
Q：Why is there white powder around the humidifier?
A：Tap water contains minerals that can adhere to objects. Clean the water tank
regularly and keep precision instruments away from the humidifier to avoid
damage.
FAQ
Q：Why is there scale in the water sink or tank?
A：Tap water contains minerals that can adhere to objects. Clean the water sink
and tank regularly.
Q：Why is the floor wet or there is water around the humidifier?
A：The humidity may be too high or the humidifier may be placed in a non-ventilated
place, causing the mist to not fully evaporate.
Q：Why is there interference with the TV remote control signal?
A：Keep the humidifier 1m away from the TV or other objects that emit radio waves.
16

17
Product Name Cool and Warm Mist Humidifier
Model Number KC-MH-2301W
Operation Mode Low Medium High
25W (Cool Mist）
500 ml/h (Warm Mist)
Rated Power
280W (Warm Mist)
1-12 hours timer
Waterless auto shut-off
Automatic shutdown when falling
Product Specifications
Max. Mist Output 300 ml/h (Cool Mist）
Noise <35dB
Tank Capacity 3.4Gal/13L
Size 8.27 inches*11.02 inches*31.50 inches
Net weight 3.0 kg
Gross weight
Safety Functions
4.2 kg
Rated Voltage 120V~
Rated Frequency 60Hz
