YOKOGAWA YPP6300 User manual

2 Dart Road • Newnan, Georgia 30265
770-253-7000 • 800-888-6400
Fax: [phone] • www.yokogawa-usa.com
YPP6300 Pulse Input Rate/Totalizer
Instruction Manual
Pulse, Open Collector, NPN, PNP, TTL, Switch Contact,
Sine Wave (Coil), Square Wave Inputs
Gate Function for Rate Display of Slow Pulse Rates
NEMA 4X, IP65 Front
Universal 85-265 VAC, or 12/24 VDC Input Power Models
Large Dual-Line 6-Digit Display, 0.60" & 0.46"
Isolated 24 VDC @ 200 mA Transmitter Power Supply
Programmable Displays & Function Keys
Sunlight Readable Display Models
Rate Displayed as Units per Second, Minute, Hour, or Day
Total, Grand Total or Non-Resettable Grand Total
9-Digit Totalizer with Total Overflow Feature
K-Factor Calibration or Scale with up to 32-Point Linearization
2 or 4 Relays + Isolated 4-20 mA Output for Rate or Total
External 4-Relays & Digital I/O Expansion Modules
USB, RS-232 & RS-485 Serial Communication Options
Modbus®RTU Communication Protocol Standard
Free PROPLUS Software for Operation, Monitoring,
and Programming

Model YPP6300 Pulse Input Rate/Totalizer Instruction Manual
2
Disclaimer
The information contained in this document is subject to change
without notice. Yokogawa Corporation of America makes no
representations or warranties with respect to the contents hereof
and specifically disclaims any implied warranties of merchantability
or fitness for a particular purpose.
!
CAUTION: Read complete
instructions prior to
installation and operation
of the meter.
WARNING: Risk of
electric shock or
personal injury.
Warning!
This product is not recommended for life support applications or
applications where malfunctioning could result in personal injury or
property loss. Anyone using this product for such applications does
so at his/her own risk. Yokogawa Corporation of America shall not
be held liable for damages resulting from such improper use.
Limited Warranty
Yokogawa Corporation of America warrants this product against
defects in material or workmanship for the specified period under
“Specifications” from the date of shipment from the factory.
Yokogawa’s liability under this limited warranty shall not exceed the
purchase value, repair, or replacement of the defective unit.
Registered Trademarks
All other trademarks mentioned in this document are the property of
their respective owners.
© 2011 Yokogawa Corporation of America. All rights reserved.
www.yokogawa-usa.com

Model YPP6300 Pulse Input Rate/Totalizer Instruction Manual
3
Table of Contents
INTRODUCTION ------------------------------------------------------------- 7
ORDERING INFORMATION ---------------------------------------------- 8
SPECIFICATIONS ----------------------------------------------------------- 9
General-------------------------------------------------------------------------------9
Rate Input ------------------------------------------------------------------------- 10
Rate/Totalizer -------------------------------------------------------------------- 11
Relays ------------------------------------------------------------------------------ 12
Isolated 4-20 mA Transmitter Output ------------------------------------ 13
Modbus®RTU Serial Communications---------------------------------- 14
YPPA1044 Digital Input & Output Expansion Module-------------- 14
COMPLIANCE INFORMATION ---------------------------------------- 15
Safety ------------------------------------------------------------------------------- 15
Electromagnetic Compatibility--------------------------------------------- 15
SAFETY INFORMATION ------------------------------------------------ 16
INSTALLATION ------------------------------------------------------------ 17
Unpacking------------------------------------------------------------------------- 17
Panel Mounting Instructions------------------------------------------------ 17
Configuration for 12 or 24 VDC Power Option------------------------ 19
Transmitter Supply Voltage Selection (P+, P-) ----------------------- 20
Connections---------------------------------------------------------------------- 20
Connectors Labeling--------------------------------------------------------- 21
Power Connections ---------------------------------------------------------- 21
Signal Connections ---------------------------------------------------------- 22
Modbus RTU Serial Communications ----------------------------------- 24
Relay Connections ----------------------------------------------------------- 24
Switching Inductive Loads-------------------------------------------------- 25
4-20 mA Output Connections---------------------------------------------- 26
Analog Output Transmitter Power Supply------------------------------ 26
External Relay & Digital I/O Connections ------------------------------ 27
Interlock Relay Feature ----------------------------------------------------- 28
SETUP AND PROGRAMMING----------------------------------------- 29
Front Panel Buttons and Status LED Indicators --------------------- 30
Display Functions and Messages----------------------------------------- 31
Main Menu ------------------------------------------------------------------------ 35
Setting Numeric Values ------------------------------------------------------ 36
Reset Menu (reset) ------------------------------------------------------------ 36
Control Menu (Contrl)-------------------------------------------------------- 36

Model YPP6300 Pulse Input Rate/Totalizer Instruction Manual
4
Setting Up the Rate/Totalizer Meter (setup) --------------------------- 37
Setting the Input Signal (Input) ------------------------------------------ 38
Setting the Totalizer Features (total)---------------------------------- 38
Setting the Decimal Point (dEc pt)-------------------------------------- 38
Programming the Rate/Totalizer (prog) -------------------------------- 39
K-Factor Calibration (Factor) ----------------------------------------- 40
Multi-Point Calibration & Scaling-------------------------------------- 40
PROPLUS Software ------------------------------------------------------- 41
Scaling the Meter (SCALE) ---------------------------------------------- 42
Gate Function (Gate) ---------------------------------------------------- 43
Contact De-Bounce Filter (FiLter) ---------------------------------- 44
Time Base, Total Conversion Factor & Total Reset-------------- 45
Calibrating the Meter with External Source (Cal)----------------- 46
Setting the Display Parameter & Intensity (dsplay) ----------------- 47
Display Setup Menu --------------------------------------------------------- 48
Character Set for Engineering Units Display (d unit)-------------- 49
Setting the Relay Operation (relay) ------------------------------------- 50
Relay Assignment (Assign) ----------------------------------------------- 51
Setting the Relay Action ---------------------------------------------------- 52
Programming Set and Reset Points ------------------------------------- 53
Setting Fail-Safe Operation ------------------------------------------------ 53
Programming Time Delay -------------------------------------------------- 53
Relay and Alarm Operation Diagrams ----------------------------------- 54
High Alarm Operation (Set > Reset)------------------------------------- 54
Low Alarm Operation (Set < Reset)-------------------------------------- 55
High Alarm with Fail-Safe Operation (Set > Reset)------------------ 56
Low Alarm with Fail-Safe Operation (Set < Reset)------------------- 57
Alternation Control Operation --------------------------------------------- 58
Rate Relay Sampling Operation ------------------------------------------ 59
Total Relay Sampling Operation------------------------------------------ 59
Time Delay Operation ------------------------------------------------------- 60
Relay Operation Details ------------------------------------------------------ 61
Overview------------------------------------------------------------------------ 61
Relays Auto Initialization---------------------------------------------------- 61
Fail-Safe Operation ---------------------------------------------------------- 61
Front Panel LEDs------------------------------------------------------------- 62
Latching and Non-Latching Relay Operation -------------------------- 62
Non-Latching Relay (Auto)------------------------------------------------- 63
Non-Latching Relay (A-nman) --------------------------------------------- 63
Latching Relay (LatcH) ----------------------------------------------------- 63
Latching Relay (Lt-Clr)---------------------------------------------------- 64
Acknowledging Relays ------------------------------------------------------ 64
Setting Up the Interlock Relay (Force On) Feature ------------------ 65

Model YPP6300 Pulse Input Rate/Totalizer Instruction Manual
5
Scaling the 4-20 mA Analog Output (Aout) ---------------------------- 66
Setting Up the Password (pass) ------------------------------------------- 67
Protecting or Locking the Meter------------------------------------------- 67
Total Reset Password & Non-Resettable Total ----------------------- 68
Making Changes to a Password Protected Meter-------------------- 69
Disabling Password Protection-------------------------------------------- 69
Advanced Features Menu---------------------------------------------------- 70
Advanced Features Menu & Display Messages ---------------------- 71
Modbus RTU Serial Communications (serial) ---------------------- 74
Select Menu (SElEct) ------------------------------------------------------- 75
Signal Input Conditioning (Functn) -------------------------------------- 75
Multi-Point Linearization (Linear)---------------------------------------- 76
Low-Flow Cutoff (CutofF) -------------------------------------------------- 77
Analog Output Programming (AoutPr)---------------------------------- 77
Programmable Function Keys User Menu (user)-------------------- 78
Meter Copy Function (Copy) ----------------------------------------------- 79
METER OPERATION ----------------------------------------------------- 81
Front Panel Buttons Operation -------------------------------------------- 81
Function Keys Operation ---------------------------------------------------- 81
Maximum/Minimum Readings---------------------------------------------- 82
TROUBLESHOOTING---------------------------------------------------- 83
Diagnostics Menu (diag)----------------------------------------------------- 83
Determining Software Version -------------------------------------------- 83
Reset Meter to Factory Defaults ------------------------------------------- 84
Factory Defaults & User Settings----------------------------------------- 85
Troubleshooting Tips --------------------------------------------------------- 88
Alphabetical List of Display Functions & Messages --------------- 89

Model YPP6300 Pulse Input Rate/Totalizer Instruction Manual
6
Table of Figures
Figure 1: 1/8 DIN Panel Cutout and Mounting................................... 17
Figure 2: Meter Dimensions - Side View............................................ 18
Figure 3: Meter Dimensions - Top View............................................. 18
Figure 4: Jumper Configuration for 12/24 VDC Power ..................... 19
Figure 5: Transmitter Supply Voltage Selection............................... 20
Figure 6: Connector Labeling for Fully Loaded YPP6300................ 21
Figure 7: Power Connections............................................................. 21
Figure 8: Flowmeter Powered by Internal Power Supply................. 22
Figure 9: Flowmeter Powered by External Supply ........................... 22
Figure 10: Self-Powered Magnetic Pickup Coil Flowmeter.............. 22
Figure 11: Relay Connections ............................................................ 24
Figure 12: AC and DC Loads Protection ........................................... 25
Figure 13: Low Voltage DC Loads Protection................................... 25
Figure 14: 4-20 mA Output Connections ........................................... 26
Figure 15: Expansion Modules & DIN Rail Mounting Kit.................. 27
Figure 16: External Relays Module Connections ............................. 27
Figure 17: Digital I/O Module Connections ....................................... 28
Figure 18: Interlock Connections....................................................... 28
Figure 19: Acknowledge Relays w/Function Key or Digital Input ... 64
Figure 20: Meter Copy Connection .................................................... 79
Figure 21: 1/8 DIN Panel Cutout Template ........................................ 95

Model YPP6300 Pulse Input Rate/Totalizer Instruction Manual
7
INTRODUCTION
The PROPLUS YPP6300 is a multipurpose, easy to use pulse rate/totalizer ideal
for flow rate, total, and control applications. It accepts pulse (e.g. ±40 mV to ±8 V),
square wave (0-5 V, 0-12 V, or 0-24 V), open collector, NPN, PNP, TTL or switch
contact signals. Three of the front panel buttons can be custom-programmed for
specific operation.
The basic model includes an isolated 24 VDC transmitter power supply that can
be used to power the input transmitter or other devices. An additional isolated
24 VDC power supply is included with the 4-20 mA output option.
A fully loaded YPP6300 pulse rate/totalizer meter has the following: four SPDT
relays, 4-20 mA output, and two 24 VDC power supplies. The YPP6300 capabilities
may be enhanced by adding the following external expansion modules: four SPST
relays (creating an eight-relay rate/totalizer), two digital I/O modules with four inputs
and four outputs each, and RS-232 or RS-485 communication adapters.
The eight relays can be used for alarm indication or process control applications.
The 4-20 mA isolated output, Modbus RTU serial communications, and digital I/O
options make the YPP6300 an excellent addition to any system.

Model YPP6300 Pulse Input Rate/Totalizer Instruction Manual
8
ORDERING INFORMATION
Standard Models
85-265 VAC
Model
12/24 VDC
Model Options Installed
YPP6300-6R0 YPP6300-7R0 No options
YPP 6300-6R2 YPP6300-7R2 2 relays
YPP 6300-6R3 YPP6300-7R3 4-20 mA output
YPP 6300-6R4 YPP6300-7R4 4 relays
YPP 6300-6R5 YPP6300-7R5 2 relays & 4-20 mA output
YPP 6300-6R7 YPP6300-7R7 4 relays & 4-20 mA output
SunBright Display Models
85-265 VAC
Model
12/24 VDC
Model Options Installed
YPP6300-6H0 YPP6300-7H0 No options
YPP6300-6H2 YPP6300-7H2 2 relays
YPP6300-6H3 YPP6300-7H3 4-20 mA output
YPP6300-6H4 YPP6300-7H4 4 relays
YPP6300-6H5 YPP6300-7H5 2 relays & 4-20 mA output
YPP6300-6H7 YPP6300-7H7 4 relays & 4-20 mA output
Accessories
Model Description
YPPA1002 DIN rail mounting kit for two expansion modules
YPPA1004 4 SPST (Form A) relays
YPPA1044 4 digital inputs & 4 digital outputs (2 may be connected)
YPPA1200 Meter copy cable
YPPA1232 RS-232 serial adapter
YPPA1485 RS-485 serial adapter
YPPA8008 USB serial adapter
YPPA7485-I RS-232 to RS-422/485 isolated converter
YPPA7485-N RS-232 to RS-422/485 non-isolated converter
YPPA8232-N USB to RS-232 non-isolated converter
YPPA8485-I USB to RS-422/485 isolated converter
YPPA8485-N USB to RS-422/485 non-isolated converter
YPPX6901 Suppressor (snubber): 0.01 µF/470 Ω, 250 VAC
Enclosures
Model Description
YPPA2811 1 Meter Plastic NEMA 4X Enclosure
YPPA2812 2 Meter Plastic NEMA 4X Enclosure

Model YPP6300 Pulse Input Rate/Totalizer Instruction Manual
9
SPECIFICATIONS
Except where noted all specifications apply to operation at +25°C.
General
DISPLAY Main display: 0.6" (15 mm) high, red LEDs
Second display: 0.46" (12 mm) high, red LEDs
6 digits: each (-99999 to 999999), with lead zero blanking.
DISPLAY
INTENSITY
Eight user selectable intensity levels
DISPLAY
UPDATE RATE
Rate: 10 per second; up to 1 per 100 seconds (and is a
function of Low Gate setting)
Total: 10 per second (fixed)
OVERRANGE Display flashes 999999
DISPLAY
ASSIGNMENT
The main (Big) and small (Little) displays may be assigned
to rate, total, grand total, alternate rate & total, max/min,
units (small display only), set points, and Modbus input.
PROGRAMMING
METHODS
Four front panel buttons, digital inputs, PC and PROPLUS
software, Modbus registers, or cloning using Copy function.
RECALIBRATION All ranges are calibrated at the factory to read frequency in
Hz. No recalibration required.
MAX/MIN
DISPLAY
Max/min readings reached by the process are stored until
reset by the user or until power to the meter is turned off.
PASSWORD Three programmable passwords restrict modification of
programmed settings and two prevent resetting the totals.
Pass 1: Allows use of function keys and digital inputs
Pass 2: Allows use of function keys, digital inputs and editing set/reset points
Pass 3: Restricts all programming, function keys, and digital inputs.
Total: Prevents resetting the total manually
Gtotal: Prevents resetting the grand total manually
NON-VOLATILE
MEMORY
All programmed settings are stored in non-volatile memory
for a minimum of ten years if power is lost.
POWER
OPTIONS
85-265 VAC 50/60 Hz, 90-265 VDC, 20 W max
or jumper selectable 12/24 VDC 10%, 15 W max
FUSE Required external fuse: UL Recognized, 5 A max, slow
blow; up to 6 meters may share one 5 A fuse
ISOLATED
TRANSMITTER
POWER SUPPLY
Terminals P+ & P-: 24 VDC 10% @ 200 mA max (standard),
(12/24 VDC powered models rated @ 100 mA max).
5 or 10 VDC @ 50 mA max, selectable with internal jumper J4.
ISOLATION 4 kV input/output-to-power line
500 V input-to-output or output-to-P+ supply

Model YPP6300 Pulse Input Rate/Totalizer Instruction Manual
10
OVERVOLTAGE
CATEGORY
Installation Overvoltage Category II:
Local level with smaller transient overvoltages than
Installation Overvoltage Category III.
ENVIRONMENTAL Operating temperature range: -40 to 65°C
Storage temperature range: -40 to 85°C
Relative humidity: 0 to 90% non-condensing
CONNECTIONS Removable screw terminal blocks accept 12 to 22 AWG
wire, RJ45 for external relays, digital I/O, and serial
communication adapters.
ENCLOSURE 1/8 DIN, high impact plastic, UL 94V-0, color: black
MOUNTING 1/8 DIN panel cutout required:
3.622" x 1.772" (92 mm x 45 mm)
Two panel mounting bracket assemblies are provided.
TIGHTENING
TORQUE
Screw terminal connectors: 5 lb-in (0.56 Nm)
OVERALL
DIMENSIONS
4.68" x 2.45" x 5.64" (119 mm x 62 mm x 143 mm)
(W x H x D)
WEIGHT 9.5 oz (269 g)
WARRANTY 3 years parts & labor
Rate Input
INPUTS Field selectable: Pulse or square wave 0-5 V, 0-12 V, or
0-24 V @ 30 kHz; TTL; open collector 4.7 kpull-up to 5 V
@ 30 kHz; NPN or PNP transistor, switch contact 4.7 k
pull-up to 5 V @ 40 Hz; Modbus PV (Slave)
LOW VOLTAGE
MAG PICKUP
(Isolated)
Sensitivity: 40 mVp-p to 8Vp-p
MINIMUM INPUT
FREQUENCY
0.001 Hz
Minimum frequency is dependent on high gate setting.
MAXIMUM INPUT
FREQUENCY
30,000 Hz (10,000 for low voltage mag pickup)
INPUT
IMPEDANCE
Pulse input: Greater than 300 k@ 1 kHz.
Open collector/switch input: 4.7 kpull-up to 5 V.
ACCURACY ±0.03% of calibrated span ±1 count
TEMPERATURE
DRIFT
Rate display is not affected by changes in temperature.
MULTI-POINT
LINEARIZATION
2 to 32 points
LOW-FLOW
CUTOFF
0-999999 (0 disables cutoff function)

Model YPP6300 Pulse Input Rate/Totalizer Instruction Manual
11
DECIMAL POINT Up to five decimal places or none:
d.ddddd, d.dddd, d.ddd, d.dd, d.d,or dddddd
CALIBRATION May be calibrated using K-factor, internal calibration, or by
applying an external calibration signal.
K-FACTOR Field programmable K-factor converts input pulses to rate in
engineering units. May be programmed from 0.00001 to
999,999 pulses/unit.
CALIBRATION
RANGE
Input 1 signal may be set anywhere in the range of the
meter; input 2 signal may be set anywhere above or below
input 1 setting.
Minimum input span between any two inputs is 10 Hz.
An error message will appear if the input 1 and input 2
signals are too close together.
FILTER Programmable contact de-bounce filter: 40 to 999 Hz
maximum input frequency allowed with low speed filter.
TIME BASE Second, minute, hour, or day
GATE Low gate: 0.1-99.9 seconds
High gate: 2.0-999.9 seconds
Rate/Totalizer
DISPLAY
ASSIGNMENT
The main (Big) and small (Little) displays may be assigned
to rate, total, grand total, alternate R & T, units, and set
point.
RATE DISPLAY
INDICATION
-99999 to 999999, lead zero blanking. “R” LED illuminates
while displaying rate or frequency.
TOTAL DISPLAY
& TOTAL
OVERFLOW
0 to 999,999; automatic lead zero blanking. “T” LED is
illuminated while displaying total or grand total.
Up to 999,999,999 with total-overflow feature. “oF” is
displayed to the left of total overflow and ▲LED is
illuminated.
ALTERNATING
DISPLAY
Either display may be programmed to alternate between
rate and total or rate and grand total every 10 seconds.
TOTAL
DECIMAL POINT
Up to five decimal places or none:
d.ddddd, d.dddd, d.ddd, d.dd, d.d,or dddddd
Total decimal point is independent of rate decimal point.
TOTALIZER Calculates total based on rate and field programmable
multiplier to display total in engineering units. Time base
must be selected according to the time units in which the
rate is displayed.
TOTALIZER
ROLLOVER Totalizer rolls over when display exceeds 999,999,999.
Relay status reflects display.

Model YPP6300 Pulse Input Rate/Totalizer Instruction Manual
12
TOTAL
OVERFLOW
OVERRIDE
Program total reset for automatic with 0.1 second delay and
set point 1 for 999,999
TOTALIZER
PRESETS
Up to eight, user selectable under setup menu. Any set
point can be assigned to total and may be programmed
anywhere in the range of the meter for total alarm
indication.
PROGRAMM-
ABLE DELAY
ON RELEASE
0.1 and 999.9 seconds; applied to the first relay assigned to
total or grand total.
If the meter is programmed to reset total to zero
automatically when the preset is reached, then a delay will
occur before the total is reset.
TOTAL RESET Via front panel button, external contact closure on digital
inputs, automatically via user selectable preset value and
time delay, or through serial communications.
TOTAL RESET
PASSWORD
Total and grand total passwords may be entered to prevent
resetting the total or grand total from the front panel.
NON-
RESETTABLE
TOTAL
The grand total can be programmed as a non-resettable
total by entering the password “050873”.
!
Caution!
Once the Grand Total has been programmed
as “non-resettable” the feature cannot be
disabled.
Relays
RATING 2 or 4 SPDT (Form C) internal and/or 4 SPST (Form A)
external; rated 3 A @ 30 VDC and 125/250 VAC resistive
load; 1/14 HP (≈50 W) @ 125/250 VAC for inductive loads
NOISE
SUPPRESSION
Noise suppression is recommended for each relay contact
switching inductive loads; see page 25 for details.
RELAY
ASSIGNMENT
Relays may be assigned to rate, total, or grand total.
DEADBAND 0-100% of span, user programmable
HIGH OR LOW
ALARM
User may program any alarm for high or low trip point.
Unused alarm LEDs and relays may be disabled (turn off).
RELAY
OPERATION
Automatic (non-latching)
Latching (requires manual acknowledge)
Sampling (based on time)
Alternation control (2 to 8 relays)
Off (disable unused relays and enable Interlock feature)
Manual on/off control mode

Model YPP6300 Pulse Input Rate/Totalizer Instruction Manual
13
RELAY RESET User selectable via front panel buttons, digital inputs, or PC
1. Automatic reset only (non-latching), when the
input passes the reset point or total is reset to
zero.
2. Automatic + manual reset at any time (non-latching)
3. Manual reset only, at any time (latching)
4. Manual reset only after alarm condition has cleared
(L)
Note: Front panel button or digital input may be assigned to
acknowledge relays programmed for manual reset.
TIME DELAY 0 to 999.9 seconds, on & off relay time delays
Programmable and independent for each relay.
FAIL-SAFE
OPERATION
Programmable and independent for each relay.
Note: Relay coil is energized in non-alarm condition.
In case of power failure, relay will go to alarm state.
AUTO
INITIALIZATION
When power is applied to the meter, relays will reflect the
state of the input to the meter.
Isolated 4-20 mA Transmitter Output
OUTPUT
SOURCE
Rate/process, total, grand total, max, min, set points 1-8,
Modbus input or manual control mode
SCALING RANGE 1.000 to 23.000 mA for any display range.
CALIBRATION Factory calibrated: 0.0 to 1000.0 = 4-20 mA output
ANALOG OUT
PROGRAMMING
23.000 mA maximum for all parameters:
Overrange, underrange, max, min, and break
ACCURACY ± 0.1% FS ± 0.004 mA
TEMPERATURE
DRIFT
0.4 µA/C max from 0 to 65C ambient,
0.8 µA/C max from -40 to 0C ambient
Note: Analog output drift is separate from input drift.
ISOLATED
TRANSMITTER
POWER SUPPLY
Terminals I+ & R: 24 VDC 10% @ 40 mA maximum; may
be used to power the 4-20 mA output or other devices.
Refer to Figure 6 on page 21 and Figure 14 on page 26.
EXTERNAL LOOP
POWER SUPPLY
35 VDC maximum
OUTPUT LOOP
RESISTANCE
Power supply Minimum Maximum
24 VDC 10 700 
35 VDC (external) 100 1200 

Model YPP6300 Pulse Input Rate/Totalizer Instruction Manual
14
Modbus®RTU Serial Communications
SLAVE ID 1 – 247 (Meter address)
BAUD RATE 300 - 19,200 bps
TRANSMIT
TIME DELAY
Programmable between 0 and 199 ms
DATA 8 bit (1 start bit, 1 or 2 stop bits)
PARITY Even, Odd, or None with 1 or 2 stop bits
BYTE-TO-BYTE
TIMEOUT
0.01 – 2.54 second
TURN AROUND
DELAY
Less than 2 ms (fixed)
Note: Refer to the PROPLUS Modbus Register Tables located at
www.yokogawa-usa.com for details.
YPPA1044 Digital Input & Output Expansion Module
CHANNELS 4 digital inputs & 4 digital outputs per module
SYSTEM Up to 2 modules for a total of 8 inputs & 8 outputs
DIGITAL INPUT
LOGIC HIGH
3 to 5 VDC
DIGITAL INPUT
LOGIC LOW
0 to 1.25 VDC
DIGITAL OUTPUT
LOGIC HIGH
3.1 to 3.3 VDC
DIGITAL OUTPUT
LOGIC LOW
0 to 0.4 VDC
SOURCE
CURRENT
10 mA maximum output current
SINK
CURRENT
1.5 mA minimum input current
+5 V
TERMINAL
To be used as pull-up for digital inputs only.
Connect normally open contacts across +5 V & DI 1-4.

Model YPP6300 Pulse Input Rate/Totalizer Instruction Manual
15
COMPLIANCE INFORMATION
Safety
UL & c-UL LISTED USA & Canada
UL 508 Industrial Control Equipment
UL FILE NUMBER E348677
FRONT PANEL UL Type 4X, NEMA 4X, IP65; panel gasket provided
LOW VOLTAGE
DIRECTIVE
EN 61010-1:2001
Safety requirements for measurement, control, and
laboratory use
Electromagnetic Compatibility
EMISSIONS EN 55022:2006/A1:2007
Class A ITE emissions requirements
Radiated
Emissions
Class A
AC Mains
Conducted
Emissions
Class A
IMMUNITY EN 61326-1:2006
Measurement, control, and laboratory equipment
EN 61000-6-2:2005
EMC heavy industrial generic immunity standard
RFI - Amplitude
Modulated
80 -1000 MHz 10 V/m 80% AM (1 kHz)
1.4 - 2.0 GHz 3 V/m 80% AM (1 kHz)
2.0 - 2.7 GHz 1 V/m 80% AM (1 kHz)
Electrical Fast
Transients
±2kV AC mains, ±1kV other
Electrostatic
Discharge
±4kV contact, ±8kV air
RFI - Conducted 10V, 0.15-80 MHz, 1kHz 80% AM
AC Surge ±2kV Common, ±1kV Differential
Surge 1KV (CM)
Power-Frequency
Magnetic Field
3 A/m 70%V for 0.5 period
Voltage Dips 40%V for 5 & 50 periods
70%V for 25 periods
Voltage
Interruptions
<5%V for 250 periods

Model YPP6300 Pulse Input Rate/Totalizer Instruction Manual
16
Note:
Testing was conducted on YPP6300 meters installed through the
covers of grounded metal enclosures with cable shields grounded at
the point of entry representing installations designed to optimize
EMC performance.
Declaration of Conformity available at www.yokogawa-usa.com
SAFETY INFORMATION
!
CAUTION: Read complete
instructions prior to
installation and operation
of the meter.
WARNING: Risk of
electric shock or
personal injury.
Warning!
Hazardous voltages exist within enclosure.
Installation and service should be performed only by
trained service personnel.

Model YPP6300 Pulse Input Rate/Totalizer Instruction Manual
17
INSTALLATION
There is no need to remove the meter from its case to complete
the installation, wiring, and setup of the meter for most
applications. Instructions are provided for setting up a
12/24 VDC powered meter to operate from 12 VDC and for
changing the transmitter power supply to output 5 or 10 VDC
instead of 24 VDC, see page 19.
Unpacking
Remove the meter from box. Inspect the packaging and
contents for damage. Report damages, if any, to the carrier.
If any part is missing or the meter malfunctions, please contact
your supplier or the factory for assistance.
Panel Mounting Instructions
Prepare a standard 1/8 DIN panel cutout – 3.622" x 1.772" (92 mm x
45 mm). Refer to Figure 1 for more details.
Clearance: allow at least 6.0" (152 mm) behind the panel for wiring.
Panel thickness: 0.04" - 0.25" (1.0 mm - 6.4 mm).
Recommended minimum panel thickness to maintain Type 4X
rating: 0.06" (1.5 mm) steel panel, 0.16" (4.1 mm) plastic panel.
Remove the two mounting brackets provided with the meter (back-off the two
screws so that there is ¼" (6.4 mm) or less through the bracket. Slide the
bracket toward the front of the case and remove).
Insert meter into the panel cutout.
Install mounting brackets and tighten the screws against the panel. To
achieve a proper seal, tighten the mounting bracket screws evenly until
meter is snug to the panel along its short side. DO NOT OVER TIGHTEN, as
the rear of the panel may be damaged.
Note: See Figure 21 on page 95 for 1/8 DIN Panel Cutout Template
3.622" (92mm)
1.772"
(45mm) Panel Cutout
to DIN 43700
Square Corners to 0.060"
(1.5mm) Max Radius
A
B
Tolerances:
A: +0.032 (+0.8mm)
-0.000 (-0.0mm)
B: +0.024 (+0.6mm)
-0.000 (-0.0mm)
Panel
Gasket
Mounting
Bracket
Mounting
Screw
Removable
Connectors
Figure 1: 1/8 DIN Panel Cutout and Mounting

Model YPP6300 Pulse Input Rate/Totalizer Instruction Manual
18
Dimensions
Figure 2: Meter Dimensions - Side View
Figure 3: Meter Dimensions - Top View

Model YPP6300 Pulse Input Rate/Totalizer Instruction Manual
19
Configuration for 12 or 24 VDC Power Option
Warning!
Do not exceed voltage rating of the selected
configuration.
Meters equipped with the 12/24 VDC power option are shipped from
the factory ready to operate from 24 VDC.
To configure the meter for 12 VDC power:
1. Remove all the connectors.
2. Unscrew the back cover.
3. Slide the back cover about 1 inch.
4. Configure the J9 jumper, located behind the power connector, for 12
V as shown below.
MAIN BOARD
24 VDC
12 VDC
POWER
J9
12 V 24 V
J9 CONFIGURATION
Factory
Default
M-LINK
+
_
Figure 4: Jumper Configuration for 12/24 VDC Power

Model YPP6300 Pulse Input Rate/Totalizer Instruction Manual
20
Transmitter Supply Voltage Selection (P+, P-)
All meters, including models equipped with the 12/24 VDC power
option, are shipped from the factory configured to provide 24 VDC
power for the transmitter or sensor.
If the transmitter requires 5 or 10 VDC excitation, the internal jumper
J4 must be configured accordingly.
To access the voltage selection jumper:
1. Remove all the connectors.
2. Unscrew the back cover.
3. Slide the back cover about 1 inch.
4. Configure the J4 jumper, located behind the input signal connector,
for the desired excitation voltage as shown.
MAIN BOARD
INPUT
SIGNAL
J4
5 V 10 V 24 V
J4 CONFIGURATION
Factory Default
P+
P-
COM
S-
S+
Figure 5: Transmitter Supply Voltage Selection
Connections
All connections are made to removable screw terminal connectors
located at the rear of the meter.
!
Caution!
Use copper wire with 60°C or 60/75°C insulation
for all line voltage connections. Observe all
safety regulations. Electrical wiring should be
performed in accordance with all applicable
national, state, and local codes to prevent
damage to the meter and ensure personnel
safety.
