User’s
Manual Model 735454
Optical Transceiver Module
IM 735454-01EN 1/2
6th Edition
Thank you for purchasing the 735454 Optical Transceiver Module. This manual focuses on the handling
precautions of the 735454.To ensure correct use, please read this manual thoroughly before operation.
Keep this manual in a safe place.
For information on the optical transceiver module, see also the manual of the AQ1300 and AQ1301 (IM
AQ1300-02EN).
Checking the Package Contents
After receiving the product and opening the package, check the following contents before use.
Manuals
IM 735454-01EN(this manual)
IM 735454-92Z1
PIM113-01Z2
XFP Module
735454-SR
735454-LR
735454-ER
SFP Module
735454-SX
735454-LX
Optical Transceiver Module
Name Model or Component Number Notes
Optical Transceiver
Module
735454-SR 10GBASE-SR XFP module 850nm
735454-LR 10GBASE-LR XFP module 1310nm
735454-ER 10GBASE-ER XFP module 1550nm
735454-SX 1000BASE-SX SFP module 850nm
735454-LX 1000BASE-LX SFP module 1310nm
Manuals IM 735454-01EN This manual.
IM 735454-92Z1 A manual for China.
PIM113-01Z2 List of worldwide contacts
To Use the Optical Transceiver Module Safely
This product is designed to be used by a person with specialized knowledge. Be sure to follow the safe-
ty precautions listed below. This manual is part of the product and contains important information. Store
this manual in a safe place close to the instrument so that you can refer to it immediately. Yokogawa Test
& Measurement Corporation assumes no liability for the customer’s failure to comply with these require-
ments.
The following symbols are used on this product.
Handle with care. Refer to the attached safety information.
Make sure to comply with the precautions below. Failure to do so could lead to damage to the
instrument, injury, or death.
WARNING
This optical transceiver module is designed specifically for the AQ1300 and AQ1301. Do not
install this instrument in other devices.
French
AVERTISSEMENT
Ce module d’émetteur-récepteur optique est spécialement conçu pour les dispositifs AQ1300
et AQ1301. Ne pas installer cet instrument dans d’autres appareils.
Note
The SFP module and XFP module are components of the AQ1300/AQ1301. Use the SFP module and XFP module by installing
them into the AQ1300/AQ1301. If you install them in other devices, the product functions and performance are not guaranteed.
Additionally, using these modules voids your warranty.
6th Edition: December 2021 (YMI)
All Rights Reserved, Copyright © 2014 Yokogawa Test & Measurement Corporation
Printed in Japan

IM 735454-01EN 2/2
Safety Precautions for Laser Products
When optical transceiver module (XFP module or SFP module ) is installed in the AQ1300 or AQ1301,
AQ1300 or AQ1301 is a Class 1 laser product as defined by IEC60825-1 Safety of Laser Products—
Part1: Equipment classification and requirements. In addition, this instrument complies with 21 CFR
1040.10, 1040.11 except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007.
It is designated for use solely as a component of such electronic product and therefore does not com-
ply with the appropriate requirements of 1040.10 and 1040.11 for complete laser products.
Model (optical
transceiver
module)
Class Center
Wavelength
Maximum
Output
Power1
Beam Divergence
(full angle at 1/e2)
Pulse Duration and
Repetition Rate
Supplier Code
(XXX: There is a case of
change.)
735454-SR 1 850 nm 0.78 mW 23.1° CW TRF2001FN-GAXXX
1 850 nm 0.7 mW 20° CW FTLX8512D3BCL
735454-LR 1 1310 nm 15.6 mW 11.5° CW TRF5016FN-GA
XXX
,
TRF5017FN-GA
XXX
,*2
or FTLX1413D3BCL*3
735454-ER 1 1550 nm 10.0 mW 11.5° CW TRF7053FN-GAXXX
or FTLX1612M3BTL*3
735454-SX 1 850 nm 2.4 mW 23.1° Pulse 625 MHz HNGEP-100
735454-LX 1 1310 nm 3.0 mW 11.5° Pulse 625 MHz HNGEP-200
*1 Under single fault conditions.
*2 Valid from firmware version R01.11.01.002 or later of AQ1300/AQ1301.
*3 Valid from firmware version R01.11.01.003 or later of AQ1300/AQ1301.
Waste Electrical and Electronic Equipment
(EU WEEE Directive valid only in the EEA* and UK WEEE Regulation in the UK)
This product complies with the WEEE Directive marking requirement. This marking indicates
that you must not discard this electrical/electronic product in domestic household waste.
When disposing of products in the EEA or UK, contact your local Yokogawa office in the
EEA or UK respectively.
* EEA: European Economic Area
Authorized Representative in the EEA
Yokogawa Europe B.V. is Authorized Representative of Yokogawa Test & Measurement Corporation in
the EEA for this Product. To contact Yokogawa Europe B.V., see the separate list of worldwide contacts,
PIM 113-01Z2.
