YORKVILLE Custom Valve YCV50 User manual

# Part# Description
Labeled Components
1 8264 TRAYNOR LOGO
2 7081 12" 8R 60WPGM SPKR CELEST VINT30
3 Z357 YCV40/YCV50 GRILLE* ‡
48563 CORNER, 2 LEGS NOTCED BLK PLASTIC
5 8522 RUBBER BUMPER WITH WASHER -SMALL-
63438 IEC PWR SOC W/.205TAB &FUSE 10A250V
76397 JEWELED PILOT LAMP AMBER REG
88451 10" STRAP HANDLE,BLACK METAL ENDCAP
98770 1/4-20 X 1 5/16 TRUSS PH MS JS5
10 8430 CHICKEN-BEAK KNOB
11 3921 1/4" JCK PCB MT VERT STER RT SWT
12 3450 & 3450NUT 1/4" ALL GOLD PC MNT JK SKT
13 3698 SPST ROKR SW QUIK 180" AC PWR
14 TFS-2B TRAYNOR DUAL FOOTSWCH 10' CORD
15 3428 8' 3/18 SJT AC LINE CORD REMOVABLE
16 8638 PUSH SW BUTTON GREY
17 3731 SPRING RETAINER FOR OUTPUT TUBE
18 3537 ACC# 4EB3C1B LONG REVERB
19 3890 36" PREFAB. CABLE (RED/BLACK)
20 7025AOR 7025B 12AX7 DUAL TRIODE PREAMP TUBE
21 EL34 POWER OUTPUT TUBES
*NOTE: Replacement grilles are 'Special-Order' and are only available while the model is in production.
‡ Grilles & Support replacements are for CURRENT models only.
8
3
1
2
6
710
9
REVERB CABLE AND UNIT
18/19
PUSH BUTTON CAPS16
TUBES
20/21
4
5
11
14 15
12
13
PUSH BUTTON CAPS17
Parts-Serv-YCV50BLUE-1v0.xls ftp.yorkville.com Speaker Enclosure
