SERVICE MANUAL
PS210PX

INSTRUCTIONS PERTAINING TO A RISK
OF FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
Read Instructions:
The
Owner’s Manual
should be read and understood
before operation of your unit. Please, save these
instructions for future reference.
Packaging:
Keep the box and packaging materials, in case the unit
needs to be returned for service.
Warning:
When using electric products, basic precautions should
always be followed, including the following:
Power Sources:
Your unit should be connected to a power source only of the
voltage specified in the owners manual or as marked on the unit.
This unit has a polarized plug. Do not use with an extension cord or
receptacle unless the plug can be fully inserted. Precautions should
be taken so that the grounding scheme on the unit is not defeated.
Hazards:
Do not place this product on an unstable cart, stand, tripod, bracket or
table. The product may fall, causing serious personal injury and serious
damage to the product. Use only with cart, stand, tripod, bracket, or table
recommended by the manufacturer or sold with the product. Follow the
manufacturer’s instructions when installing the product and use mounting
accessories recommended by the manufacturer.
The apparatus should not be exposed to dripping or splashing
water; no objects filled with liquids should be placed on the
apparatus.
Terminals marked with the “lightning bolt” are hazardous live;
the external wiring connected to these terminals require installation
by an instructed person or the use of ready made leads or cords.
No naked flame sources, such as lighted candles, should be
placed on the apparatus.
Power Cord:
The AC supply cord should be routed so that it is unlikely that it will
be damaged. If the AC supply cord is damaged DO NOT
OPERATE THE UNIT.
Service:
The unit should be serviced only by qualified service personnel.
INSTRUCTIONS RELATIVES AU RISQUE
DE FEU, CHOC ÉLECTRIQUE, OU
BLESSURES AUX PERSONNES.
AVIS:
AFIN DE REDUIRE LES RISQUE DE CHOC ELECTRIQUE,
N’ENLEVEZ PAS LE COUVERT (OU LE PANNEAU
ARRIERE). NE CONTIENT AUCUNE PIECE REPARABLE
PAR L’UTILISATEUR.
CONSULTEZ UN TECHNICIEN QUALIFIE
POUR L’ENTRETIENT.
Veuillez lire le manuel:
Il contient des informations qui devraient êtres comprises avant
l’opération de votre appareil. Conservez S.V.P. ces instructions
pour consultations ultérieures
Emballage:
Conservez la boite au cas ou l’appareil devait être
retourner pour réparation.
Attention:
Lors de l’utilisation de produits électrique,
assurez-vous d’adhérer à des précautions de bases
incluant celle qui suivent:
Alimentation:
L’appareil ne doit être branché qu’à une source d’alimentation
correspondant au voltage spécifié dans le manuel ou tel qu’indiqué
sur l’appareil. Cet appareil est équipé d’une prise d’alimentation
polarisée. Ne pas utiliser cet appareil avec un cordon de
raccordement à moins qu’il soit possible d’insérer complètement les
trois lames. Des précautions doivent êtres prises afin d’eviter que le
système de mise à la terre de l’appareil ne soit désengagé.
Risque:
Ne pas placer cet appareil sur un chariot, un support, un trépied ou une
table instables. L’appareil pourrait tomber et blesser quelqu’un ou subir des
dommages importants. Utiliser seulement un chariot, un support, un trépied
ou une table recommandés par le fabricant ou vendus avec le produit.
Suivre les instructions du fabricant pour installer l’appareil et utiliser les
accessoires recommandés par le fabricant.
Il convient de ne pas placer sur l’appareil de sources de flammes
nues, telles que des bougies allumées.
L’appeil ne doit pas être exposé à des égouttements d’eau ou des
éclaboussures et qu’aucun objet rempli de liquide tel que des vases
ne doit être placé sur l’appareil.
Les dispositifs marqués d’une symbole “d’éclair” sont des parties
dangereuses au toucher et que les câblages extérieurs connectés à
ces dispositifs de connection extérieure doivent être effectivés par un
opérateur formé ou en utilisant des cordons déjà préparés.
Cordon d’alimentation:
Évitez d’endommager le cordon d’alimentation. N’UTILISEZ PAS
L’APPAREIL si le cordon d’alimentation est endommagé.
Service:
Consultez un technicien qualifié pour l’entretien de votre appareil.
IMPORTANT SAFETY INSTRUCTIONS
safety-4v0.pdf 04/29/03

PS210PX Parts List 1/18/2005
YS # Description Qty. YS # Description Qty. YS # Description Qty.
6405 RED 3MM LED 1V7 5MA BRT 2 3810 4" NYLON CABLE TIE 11 8742 4-40 X 3/8 PAN PH TAPTITE JS500 16
6410 GRN 3MM LED 1V7 5MA CLEAR BRT 2 8661 BUTTON KNOB FLAT GREY 2 8861 4-40 X 3/8 PAN PH MS JS500 2
6419 BRIDGE 35A 400V WIRE LEAD GI3504 2 8693 S ROTARY KNOB GREY 2 8799 #6 X 1/4 PAN PH TYPE B JS500 1
6425 BAV21 200V 0A25 DIODE T&R 8 3468 8' 3/16 SJT AC LINE CORD STRIP 17" 1 8832 6-32 X 1/4 PAN PH TAPTITE JS500 2
6825 1N4148 75V 0A45 DIODE T&R 23 3821 HEYCO #1200 STRAIN RELIEF 1 8801 6-32 X 3/8 PAN PH TAPTITE JS500 2
6438 1N4007 400V 1A0 DIODE T&R 16 8245 PULSE SMALL LEXAN LABEL 1 8823 6-32 X 1 PAN PH TAPTITE JS500 9
6479 MUR415 150V 4A0 DIODE FASREC 12 8242 "Y" LOGO PULSE SERIES SMALL 1 8998 6-32 X 1 FLAT PH MS ZINC CLEAR 4
5121 MZ4615RL 2V0 W25 ZENER 5% T&R 2 3521 SIDE ENTRY PCB CONN .156 8POS 1 8803 8-32 X 3/8 PAN QUAD TAPTITE JS500 4
6440 1N750ARL 4V7 0W5 ZENER 5% T&R 4 3607 SIDE ENTRY PCB CONN. 9 POS. 1 8815 8-32 X 3/4 PAN PH TAPTITE JS500 10
6461 1N5240BRL 10V0 0W5 ZENER 5% T&R 6 3674 9 CIR CABLE HOLDER .098 1 8875 #8 X 1 1/2 PAN PH TYPE A JS500 4
6450 1N5242B 12V0 0W5 ZENER 5% T&R 2 8701 4-40 KEPS NUT ZINC 2 8749 10-32 X 1/2 QDX PH TAPTITE JS500 2
6465 1N5250B 20V0 0W5 ZENER 5% T&R 1 8800 6-32 KEPS NUT ZINC 14 8781 #10 X 7/8 FLAT PHIL TYPE A JS500BLK 22
6856 NJM7815FA TO220 P 15V0 REG IS V1 1 8797 5/16-18 KEPS NUT JS500 1 8727 #10 X 1" PAN PH TYPE A JS500 BLACK 16
6857 NJM7915FA TO220 N 15V0 REG IS V2 1 4597 22AWG STRAN TC WIR JMP 8 8862 #10 X 1 1/2 PAN PH TYPE A JS500 8
5101 BC550C TO92 NPN TRAN T&R TB 11 4599 22AWG SOLID SC WIR T&R JMP 33 8751 10-32 X 2 PAN PH MS JS500 8
5102 BC560C TO92 PNP TRANSISTOR T&R TB 8 5299 24AWG SOLID SC WIR RAD JMP 18 8777 #14 X 1FLAT PH TYPE A JS500 M6 HEAD 4
5109 MPSA43 TO92 NPN TRAN TA 10 4745 5.0W 0R1 5% BLK RES 5 8740 5/16-18 X 3 GRD 5 HEX BOLT JS500 1
5114 MPSA92 TO92 PNP TRAN T&R TA 14 4688 1/2W 2R2 5% T&R RES 4 3741 .5 SPACER ID-.171 OD-.25 #912-500 6
5119 2N5638 TO92 NCH JFET T&R TC 4 4748 2.0W 3R9 5% T&R 4 8657 6-32 X 3/8" HEX SPACER ALUMINUM 4
6928 IRFP250 TO247 NCH MFET TM 6 4675 1/2W 10R 5% T&R RES 2 7265 10" 8R 300WPGM SPEAKER 2
6991 MJL21193 TO3P PNP TRAN TK 2 2013 1/8W 22R1 1%FLAME PROOF T&R RES 2 8818 3/4 OD X 3/8 ID X .080 THICK WASHER 1
6882 TL072CP IC FET DUAL OP AMP 5 2019 1/8W 100R0 1%FLAME PROOF T&R RES 2 3511 #6 FLAT WASHER NYLON 2
6884 NE5532N IC DUAL OP AMP 2 4852 1/4W 100R 5% T&R RES 1 8485 #6 SPLIT WASHER ZINC 2
6745 LM13600N IC XCONDUCTANCE AMP 2 4921 1/4W 100R 5% .2"U T&R RES 6 8820 #8 FLAT WASHER JS500 4
5190 MBS4992 TO92 8V5 TRNSISTR DIAC T&R 2 4909 1/4W 200R 5% T&R RES 2 8473 #10 BLACK CUPWASHER SWF-10BK 1
6470 MAC15A6FP TO220 15A TRIAC 400V 2 4932 1/4W 200R 5% .2"U T&R RES 8 3436 DPDT PUSH SW PCMT H BREAK B4 MAKE 2
6472 4K7 3% 0W0 THERMISTOR 2 4857 1/4W 220R 5% T&R RES 4 3585 DPDT ROKR SW QUIK 250" AC/PWR IEC65 1
6473 68K 3% 0W0 THERMISTOR 4 4944 1/4W 220R 5% .2"U T&R RES 4 3705 4P3T SLID SW PCMT H 1
6482 115R 20% 0W0 PTC THERMISTOR 2 2024 1/8W 249R 2%FLAME PROOF T&R RES 4 3399 THERMO/BRKR:N/CLOSED OPEN@96C 1
5405 _27P 200V 5%CAP T&R RAD CER.2"NPO 2 2025 1/8W 274R 1%FLAME PROOF T&R RES 4 8468 VELCRO STRAP 3/4"X22CM (VELSTRAP) 1
5199 100P 100V 2%CAP T&R RAD CER.2"NPO 4 2028 1/8W 475R 1%FLAME PROOF T&R RES 4 1287 PPW /EPW 120VAC 60HZ T'RD 1
5197 220P 100V 2%CAP T&R RAD CER.2"NPO 2 4933 1/4W 470R 5% .2"U T&R RES 2
5201 470P 100V 5%CAP T&R RAD CER.2"NPO 10 2030 1/8W 681R 1%FLAME PROOF T&R RES 2
5816 680P 100V 5%CAP T&R RAD CER.2"NPO 2 4923 1/4W 680R 5% .2"U T&R RES 3
5275 __3N3 100V 5%CAP T&R RAD .2"FLM 6 4758 1/4W 953R 1% T&R RES 8
5209 __4N7 250V 5%CAP T&R RAD .2"FLM 2 4823 1/4W 1K 5% T&R RES 4
6451 __4N7 250V 20%CAP BLK 'Y' 10MM AC 1 4934 1/4W 1K 5% .2"U T&R RES 4
5840 _22N 400V 10%CAP BLK RAD POLY FLM 1 4791 1/4W 1K54 1% T&T RES 2
6435 _22N 275V 20%CAP BLK 'X2' 15MM AC 1 4825 1/4W 1K8 5% T&R RES 1
5224 _47N 100V 10%CAP T&R RAD .2"FLM 5 4936 1/4W 2K7 5% .2"U T&R RES 10
5226 _68N 100V 5%CAP T&R RAD .2"FLM 1 4826 1/4W 3K3 5% T&R RES 1
5228 100N 100V 5%CAP T&R RAD .2"FLM 17 4943 1/4W 4K7 5% .2"U T&R RES 5
5231 220N 63V 10%CAP T&R RAD .2"FLM 8 4982 1/4W 4K7 5%MINI T&R RES 4
5318 220N 50V 10%CAP T&R BEAD X7R 1 4939 1/4W 5K1 5% .2"U T&R RES 2
5255 __1U 63V 20%CAP T&R RAD .2"EL 1 4685 1.0W 5K6 5% T&R RES 2
5259 __4U7 63V 20%CAP T&R RAD .2"EL 2 4862 1/4W 5K6 5% T&R RES 8
5281 _10U 16V 20%CAP T&R RAD .2"NP 6 4762 1/4W 9K760 0.1% *** T&R RES 2
5945 _10U 63V 20%CAP T&R RAD .2"EL 2 4829 1/4W 10K 5% T&R RES 6
5260 _22U 50V 20%CAP T&R RAD .2"EL 8 4940 1/4W 10K 5% .2"U T&R RES 12
5961 _33U 16V 20%CAP T&R RAD .2"NP 6 4953 1/4W 12K 5% .2"U T&R RES 1
5265 _68U 25V 20%CAP T&R RAD .2"EL 6 4901 1/4W 13K 5% T&R RES 1
5267 100U 25V 20%CAP T&R RAD .2"EL 2 4630 1/2W 15K 5% T&R RES 3
5914 100U 63V 20%CAP BLK 10X13MM EL 2 4979 1/4W 15K 5%MINI T&R RES 5
5621 470U 63V 20%CAP BLK 12X25MM EL 4 4784 1/4W 17K40 0.1% *** T&R RES 4
5859 4700U 50V 20%CAP BLK 25X36MM ELS 2 4954 1/4W 18K 5% .2"U T&R RES 2
5890 5600U 100V 20%CAP RAD 35X50MM ELS 4 4832 1/4W 22K 5% T&R RES 2
4403 _10K 5B LIN 16MM P14 2 6118 1/4W 22K 5%MINI T&R RES 6
3819 ___5UH COIL 18AWG R000 AIR CORE 2 4890 1/4W 30K 5% T&R RES 1
8483 ADAPTOR,SPEAKER STAND,METAL,BLACK 1 4941 1/4W 30K 5% .2"U T&R RES 8
8547 PLASTIC FOOT BLACK, POLYETHYLENE 4 4917 1/4W 31K6 1% T&R RES 6
3489 CLIP 250X032 18-22AWG DISCO/INSL 3 4840 1/4W 33K 5% T&R RES 7
3490 CLIP 250X032 14-16AWG DISCO/INSL 6 4947 1/4W 33K 5% .2"U T&R RES 7
3491 CLIP 205/187X020 18-22AWG DISCO/INS 4 4868 1/4W 36K 5% T&R RES 1
3601 RING TERMINAL 16AWG WIRE & #8 SCREW 1 4878 1/4W 43K 5% T&R RES 1
3682 250 MALE PCB TAB REEL 12 4927 1/4W 47K 5% .2"U T&R RES 3
3498 1/4" JCK PCB MT HORZ 4 4835 1/4W 56K 5% T&R RES 1
3660 XLR FEML PCB MT HORZ 1 4836 1/4W 68K 5% T&R RES 2
3451 EYELET SMALL 0.089 OD PLATED 62 4838 1/4W 100K 5% T&R RES 5
3412 LOWPROFILE FUSEHOLDER FOR .25X1.25 1 4942 1/4W 100K 5% .2"U T&R RES 1
3414 INTERNATIONAL PC MOUNT FUSEHOLDER 8 6120 1/4W 100K 5%MINI T&R RES 1
2427 5.0 AMP SLO-BLO .25X1.25 FUSE 1 4839 1/4W 150K 5% T&R RES 1
2438 12.0 AMP SLO-BLO .25X1.25 FUSE 4 4849 1/4W 180K 5% T&R RES 1
8537 TEARDROP HANDLE "YORKVILLE" BLUE 2 4949 1/4W 180K 5% .2"U T&R RES 1
8604 10-32 T NUT 8 4841 1/4W 220K 5% T&R RES 5
3501 B52200F006 COMP WASH #4 SMALL 2 4843 1/4W 470K 5% T&R RES 3
3556 XSISTOR HOLD SPRING-BAR (PLATED) 4 6127 1/4W 470K 5%MINI T&R RES 1
3800 BELLY BUTTON #BB1 CORDS CANADA 8 4844 1/4W 1M 5% T&R RES 6
3862 SIL PAD 400 1.5X6.75 2 4888 1/4W 4M7 5% T&R RES 1
3795 #8 GROUND LUG ZIERICK 505-169 1 3608 10" 9C-24AWG RIBBON HITMP 0.1" 1
3803 NYLON SECUR-A-TACH MINI PLASTIC TIE 1 8729 #4 X 3/8 FLAT QUAD TYPE A JS500 BLK 2
