YORKVILLE PULSE PS218P User manual

U.S.A.
Yorkville Sound Inc.
4625 Witmer Industrial Estate
Niagara Falls, New York
14305 USA
Voice: [phone]
Fax: [phone]
WORLD HEADQUARTERS
WEB ACCESS: http://www.yorkville.com
CANADA
Yorkville Sound
550 Granite Court
Pickering, Ontario
L1W-3Y8 CANADA
Voice: [phone]
Fax: [phone]
Quality and Innovation Since 1963
Printed in Canada
SERVICE MANUAL
PS218P

INSTRUCTIONS PERTAINING TO A RISK
OF FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
Read Instructions:
The
Owner’s Manual
should be read and understood
before operation of your unit. Please, save these
instructions for future reference.
Packaging:
Keep the box and packaging materials, in case the unit
needs to be returned for service.
Warning:
When using electric products, basic precautions should
always be followed, including the following:
Power Sources:
Your unit should be connected to a power source only of the
voltage specified in the owners manual or as marked on the unit.
This unit has a polarized plug. Do not use with an extension cord or
receptacle unless the plug can be fully inserted. Precautions should
be taken so that the grounding scheme on the unit is not defeated.
Hazards:
Do not place this product on an unstable cart, stand, tripod, bracket or
table. The product may fall, causing serious personal injury and serious
damage to the product. Use only with cart, stand, tripod, bracket, or table
recommended by the manufacturer or sold with the product. Follow the
manufacturer’s instructions when installing the product and use mounting
accessories recommended by the manufacturer.
The apparatus should not be exposed to dripping or splashing
water; no objects filled with liquids should be placed on the
apparatus.
Terminals marked with the “lightning bolt” are hazardous live;
the external wiring connected to these terminals require installation
by an instructed person or the use of ready made leads or cords.
No naked flame sources, such as lighted candles, should be
placed on the apparatus.
Power Cord:
The AC supply cord should be routed so that it is unlikely that it will
be damaged. If the AC supply cord is damaged DO NOT
OPERATE THE UNIT.
Service:
The unit should be serviced only by qualified service personnel.
INSTRUCTIONS RELATIVES AU RISQUE
DE FEU, CHOC ÉLECTRIQUE, OU
BLESSURES AUX PERSONNES.
AVIS:
AFIN DE REDUIRE LES RISQUE DE CHOC ELECTRIQUE,
N’ENLEVEZ PAS LE COUVERT (OU LE PANNEAU
ARRIERE). NE CONTIENT AUCUNE PIECE REPARABLE
PAR L’UTILISATEUR.
CONSULTEZ UN TECHNICIEN QUALIFIE
POUR L’ENTRETIENT.
Veuillez lire le manuel:
Il contient des informations qui devraient êtres comprises avant
l’opération de votre appareil. Conservez S.V.P. ces instructions
pour consultations ultérieures
Emballage:
Conservez la boite au cas ou l’appareil devait être
retourner pour réparation.
Attention:
Lors de l’utilisation de produits électrique,
assurez-vous d’adhérer à des précautions de bases
incluant celle qui suivent:
Alimentation:
L’appareil ne doit être branché qu’à une source d’alimentation
correspondant au voltage spécifié dans le manuel ou tel qu’indiqué
sur l’appareil. Cet appareil est équipé d’une prise d’alimentation
polarisée. Ne pas utiliser cet appareil avec un cordon de
raccordement à moins qu’il soit possible d’insérer complètement les
trois lames. Des précautions doivent êtres prises afin d’eviter que le
système de mise à la terre de l’appareil ne soit désengagé.
Risque:
Ne pas placer cet appareil sur un chariot, un support, un trépied ou une
table instables. L’appareil pourrait tomber et blesser quelqu’un ou subir des
dommages importants. Utiliser seulement un chariot, un support, un trépied
ou une table recommandés par le fabricant ou vendus avec le produit.
Suivre les instructions du fabricant pour installer l’appareil et utiliser les
accessoires recommandés par le fabricant.
Il convient de ne pas placer sur l’appareil de sources de flammes
nues, telles que des bougies allumées.
L’appeil ne doit pas être exposé à des égouttements d’eau ou des
éclaboussures et qu’aucun objet rempli de liquide tel que des vases
ne doit être placé sur l’appareil.
Les dispositifs marqués d’une symbole “d’éclair” sont des parties
dangereuses au toucher et que les câblages extérieurs connectés à
ces dispositifs de connection extérieure doivent être effectivés par un
opérateur formé ou en utilisant des cordons déjà préparés.
Cordon d’alimentation:
Évitez d’endommager le cordon d’alimentation. N’UTILISEZ PAS
L’APPAREIL si le cordon d’alimentation est endommagé.
Service:
Consultez un technicien qualifié pour l’entretien de votre appareil.
IMPORTANT SAFETY INSTRUCTIONS
safety-4v0.pdf 04/29/03

PS218P Parts List 1/18/2005
YS # Description Qty. YS # Description Qty. YS # Description Qty.
6405 RED 3MM LED 1V7 5MA BRT 2 8693 S ROTARY KNOB GREY 1 8770 1/4-20 X 1 5/16 TRUSS PH MS JS500 10
6410 GRN 3MM LED 1V7 5MA CLEAR BRT 2 3468 8' 3/16 SJT AC LINE CORD STRIP 17" 1 8740 5/16-18 X 3 GRD 5 HEX BOLT JS500 1
6419 BRIDGE 35A 400V WIRE LEAD GI3504 2 3821 HEYCO #1200 STRAIN RELIEF 1 3741 .5 SPACER ID-.171 OD-.25 #912-500 6
6425 BAV21 200V 0A25 DIODE T&R 8 8246 PULSE LARGE LEXAN LABEL 1 8657 6-32 X 3/8" HEX SPACER ALUMINUM 4
6825 1N4148 75V 0A45 DIODE T&R 22 8243 "Y" LOGO PULSE SERIES LARGE 1 7267 18" 4R 300WPGM SPEAKER SUBWOOFER 2
6438 1N4007 400V 1A0 DIODE T&R 16 8900 YORKVILLE WARRANTY CARD 2-YR UNLTD. 1 8818 3/4 OD X 3/8 ID X .080 THICK WASHER 1
6479 MUR415 150V 4A0 DIODE FASREC 12 3521 SIDE ENTRY PCB CONN .156 8POS 1 3511 #6 FLAT WASHER NYLON 2
5121 MZ4615RL 2V0 W25 ZENER 5% T&R 2 3607 SIDE ENTRY PCB CONN. 9 POS. 1 8485 #6 SPLIT WASHER ZINC 2
6440 1N750ARL 4V7 0W5 ZENER 5% T&R 4 3674 9 CIR CABLE HOLDER .098 1 8820 #8 FLAT WASHER JS500 20
6461 1N5240BRL 10V0 0W5 ZENER 5% T&R 6 8800 6-32 KEPS NUT ZINC 14 8473 #10 BLACK CUPWASHER SWF-10BK 1
6450 1N5242B 12V0 0W5 ZENER 5% T&R 2 8602 1/4-20 T NUT 10 3436 DPDT PUSH SW PCMT H BREAK B4 MAKE 2
6465 1N5250B 20V0 0W5 ZENER 5% T&R 1 8797 5/16-18 KEPS NUT JS500 1 3585 DPDT ROKR SW QUIK 250" AC/PWR IEC65 1
6856 NJM7815FA TO220 P 15V0 REG IS V1 1 4597 22AWG STRAN TC WIR JMP 6 3399 THERMO/BRKR:N/CLOSED OPEN@96C 1
6857 NJM7915FA TO220 N 15V0 REG IS V2 1 4599 22AWG SOLID SC WIR T&R JMP 23 8468 VELCRO STRAP 3/4"X22CM (VELSTRAP) 1
5101 BC550C TO92 NPN TRAN T&R TB 9 5299 24AWG SOLID SC WIR RAD JMP 23 1287 PPW /EPW 120VAC 60HZ T'RD 1
5102 BC560C TO92 PNP TRANSISTOR T&R TB 5 4745 5.0W 0R1 5% BLK RES 6
5109 MPSA43 TO92 NPN TRAN TA 10 4688 1/2W 2R2 5% T&R RES 4
5114 MPSA92 TO92 PNP TRAN T&R TA 14 4748 2.0W 3R9 5% T&R 4
5119 2N5638 TO92 NCH JFET T&R TC 4 4675 1/2W 10R 5% T&R RES 2
6928 IRFP250 TO247 NCH MFET TM 6 2013 1/8W 22R1 1%FLAME PROOF T&R RES 2
6991 MJL21193 TO3P PNP TRAN TK 2 2019 1/8W 100R0 1%FLAME PROOF T&R RES 2
6882 TL072CP IC FET DUAL OP AMP 4 4921 1/4W 100R 5% .2"U T&R RES 6
6884 NE5532N IC DUAL OP AMP 1 4909 1/4W 200R 5% T&R RES 2
6745 LM13600N IC XCONDUCTANCE AMP 1 4932 1/4W 200R 5% .2"U T&R RES 8
6470 MAC15A6FP TO220 15A TRIAC 400V 2 4857 1/4W 220R 5% T&R RES 4
6472 4K7 3% 0W0 THERMISTOR 2 2024 1/8W 249R 2%FLAME PROOF T&R RES 4
6473 68K 3% 0W0 THERMISTOR 4 2025 1/8W 274R 1%FLAME PROOF T&R RES 4
6482 115R 20% 0W0 PTC THERMISTOR 2 2028 1/8W 475R 1%FLAME PROOF T&R RES 4
5405 _27P 200V 5%CAP T&R RAD CER.2"NPO 2 4933 1/4W 470R 5% .2"U T&R RES 2
5199 100P 100V 2%CAP T&R RAD CER.2"NPO 4 2030 1/8W 681R 1%FLAME PROOF T&R RES 2
5197 220P 100V 2%CAP T&R RAD CER.2"NPO 2 4923 1/4W 680R 5% .2"U T&R RES 3
5201 470P 100V 5%CAP T&R RAD CER.2"NPO 10 4758 1/4W 953R 1% T&R RES 8
5816 680P 100V 5%CAP T&R RAD CER.2"NPO 2 4823 1/4W 1K 5% T&R RES 3
5275 __3N3 100V 5%CAP T&R RAD .2"FLM 6 4934 1/4W 1K 5% .2"U T&R RES 1
5209 __4N7 250V 5%CAP T&R RAD .2"FLM 2 4854 1/4W 1K2 5% T&R RES 1
6451 __4N7 250V 20%CAP BLK 'Y' 10MM AC 1 4824 1/4W 1K5 5% T&R RES 2
5840 _22N 400V 10%CAP BLK RAD POLY FLM 1 4936 1/4W 2K7 5% .2"U T&R RES 10
6435 _22N 275V 20%CAP BLK 'X2' 15MM AC 1 4764 1/4W 2K740 0.1% *** T&R RES 2
5224 _47N 100V 10%CAP T&R RAD .2"FLM 3 4826 1/4W 3K3 5% T&R RES 1
5228 100N 100V 5%CAP T&R RAD .2"FLM 17 4827 1/4W 4K7 5% T&R RES 1
5314 100N 50V 10%CAP T&R BEAD X7R 1 4943 1/4W 4K7 5% .2"U T&R RES 5
5231 220N 63V 10%CAP T&R RAD .2"FLM 7 4939 1/4W 5K1 5% .2"U T&R RES 2
5318 220N 50V 10%CAP T&R BEAD X7R 1 4685 1.0W 5K6 5% T&R RES 2
5259 __4U7 63V 20%CAP T&R RAD .2"EL 2 4862 1/4W 5K6 5% T&R RES 8
5281 _10U 16V 20%CAP T&R RAD .2"NP 4 4762 1/4W 9K760 0.1% *** T&R RES 2
5945 _10U 63V 20%CAP T&R RAD .2"EL 2 4829 1/4W 10K 5% T&R RES 5
5260 _22U 50V 20%CAP T&R RAD .2"EL 6 4940 1/4W 10K 5% .2"U T&R RES 8
5961 _33U 16V 20%CAP T&R RAD .2"NP 6 4630 1/2W 15K 5% T&R RES 3
5265 _68U 25V 20%CAP T&R RAD .2"EL 5 4830 1/4W 15K 5% T&R RES 1
5267 100U 25V 20%CAP T&R RAD .2"EL 1 4832 1/4W 22K 5% T&R RES 6
5914 100U 63V 20%CAP BLK 10X13MM EL 2 4941 1/4W 30K 5% .2"U T&R RES 8
5621 470U 63V 20%CAP BLK 12X25MM EL 4 4917 1/4W 31K6 1% T&R RES 6
5859 4700U 50V 20%CAP BLK 25X36MM ELS 2 4840 1/4W 33K 5% T&R RES 5
5890 5600U 100V 20%CAP RAD 35X50MM ELS 4 4947 1/4W 33K 5% .2"U T&R RES 1
4403 _10K 5B LIN 16MM P14 1 4878 1/4W 43K 5% T&R RES 2
3819 ___5UH COIL 18AWG R000 AIR CORE 2 4835 1/4W 56K 5% T&R RES 2
8545 RECESSED RUBBER BUMPER WITH WASHER 2 4836 1/4W 68K 5% T&R RES 1
8579 4000 SERIES RIGID CASTER 2 4772 1/4W 82K5 1% T&R RES 6
3489 CLIP 250X032 18-22AWG DISCO/INSL 1 4838 1/4W 100K 5% T&R RES 4
3490 CLIP 250X032 14-16AWG DISCO/INSL 6 4841 1/4W 220K 5% T&R RES 5
3491 CLIP 205/187X020 18-22AWG DISCO/INS 4 4842 1/4W 330K 5% T&R RES 1
3494 CLIP 205/187X020 14-16AWG DISCO/INS 1 4843 1/4W 470K 5% T&R RES 2
3601 RING TERMINAL 16AWG WIRE & #8 SCREW 1 4844 1/4W 1M 5% T&R RES 4
3682 250 MALE PCB TAB REEL 10 4888 1/4W 4M7 5% T&R RES 1
3498 1/4" JCK PCB MT HORZ 4 3608 10" 9C-24AWG RIBBON HITMP 0.1" 1
3451 EYELET SMALL 0.089 OD PLATED 58 8742 4-40 X 3/8 PAN PH TAPTITE JS500 18
3412 LOWPROFILE FUSEHOLDER FOR .25X1.25 1 8799 #6 X 1/4 PAN PH TYPE B JS500 1
3414 INTERNATIONAL PC MOUNT FUSEHOLDER 8 8832 6-32 X 1/4 PAN PH TAPTITE JS500 2
2427 5.0 AMP SLO-BLO .25X1.25 FUSE 1 8801 6-32 X 3/8 PAN PH TAPTITE JS500 2
2438 12.0 AMP SLO-BLO .25X1.25 FUSE 4 8823 6-32 X 1 PAN PH TAPTITE JS500 9
8560 POCKET HANDLE, PLASTIC, RECTANGULAR 2 8998 6-32 X 1 FLAT PH MS ZINC CLEAR 4
8604 10-32 T NUT 16 8812 #6 X 1 1/8 FLAT SQ. SOCKT CLEAR ZNC 10
3501 B52200F006 COMP WASH #4 SMALL 2 8803 8-32 X 3/8 PAN QUAD TAPTITE JS500 4
3556 XSISTOR HOLD SPRING-BAR (PLATED) 4 8785 #8 X 3/4 OVAL PH TYPE A BLACK OXIDE 5
3800 BELLY BUTTON #BB1 CORDS CANADA 8 8815 8-32 X 3/4 PAN PH TAPTITE JS500 6
3862 SIL PAD 400 1.5X6.75 2 8875 #8 X 1 1/2 PAN PH TYPE A JS500 6
3795 #8 GROUND LUG ZIERICK 505-169 1 8749 10-32 X 1/2 QDX PH TAPTITE JS500 2
3803 NYLON SECUR-A-TACH MINI PLASTIC TIE 1 8707 #10 X 7/8 (#8 HEAD)FLAT PHIL TYPE A 16
3810 4" NYLON CABLE TIE 18 8727 #10 X 1" PAN PH TYPE A JS500 BLACK 16
8661 BUTTON KNOB FLAT GREY 2 8786 10-32 X 1 1/4 PAN QD MS JS500 BLACK 16

YORKVILLE NAME: PCB#&VER:
MODELS: SCH ISSUE:
TITLE:
DATE:
M508
PS218P
ES700P
M508A.SCH
MAR/30/98
PWR_AMP
1.40
D1
10V 3n3
C18
5K6
R51
680R
R64
680R
R1
220K
R2
100v
3n3
C20
1N4004
D15
100R
R36
274R
R4
PILOT
RED
LD1
4K7
R5
S
G
D
N
IRFP250
Q19
5K6
1W
R41
220K
R6
MC2
2
953R
R7
25v 27p
C19
22K
R9
953R
R10
68U16V
C1
68U16V
C2
MC2
1
274R
R54
12v
500mW
D22
475R
R55
BC550
Q8
249R
R13
MPSA93
Q9
30K
R52
MPSA43
Q3
MPSA43
Q4
2K7
R14
2K7
R15
BC550
Q10
200R
R16
4K7
R23
249R
R17
BC550
Q11
16V
33U
C6
D4
D5
10K
R18
10K
R42
BAV21
D32
BC550
Q12
10V 3N3
C10
10K
R19
60v
470P
C11
S
G
D
N
IRFP250
Q15
S
G
D
N
IRFP250
Q16
0R1
5W
R45
0R1
5W
R46
25v 680P
C12
63v
220n
C14
MUR415
D9
10K
R20
500mW
10v
D10
500mW
10v
D11
MPSA43
Q2
MPSA93
Q13
MPSA43
Q21
100R
R21
10v 100N
C15
200R
R22
MPSA93
Q22
BAV21
D21
BC560
Q14
16V
33U
C7
BAV21
D14
2K7
R24
2K7
R25
475R
R26
470R
R59
2V0
250mW
D12
5K1
R11
100u 63v
C4
D6
D7
56K
R28
43K
R29
100R
R30
16V
33U
C5
31K6
R32
68K
R47
68K
R48
5K6
R44
25v 100p
C9
25v 100P
C13
100R
R34
5uH
L1
2N5638
Q25
953R
R40
D2
MPSA43
Q1
30K
R50
MPSA93
Q7
MPSA93
Q6
16v
10u
C8
MT1
MT2
G
TRIAC_MAC15A4FP
Q17
MT1
G
MT2
MBS4992
Q18
953R
R43
4K7
R56
D33
1M
R33
MPSA93
Q5
MUR415
D30
2K7
R27
2N5638
Q24
1N4004
D16
22R
R39
10R
0.5W
R49
30K
R35
5K6
R3
22u
16v
C25
BAV21
D17
30K
R57
10v
500mW
D23
200R
R58
MUR415
D24
MJL21193
Q20
470u
63v
C23 5600u
100v
C26
1N4004
D28
1N4004
D29 MUR415
D25
MUR415
D26
1N4004
D31
470u
63v
C24
5600u
100v
C27
D18
D19
D20
MPSA93
Q23
1M
R60
31K6
R61
31K6
R8
MUR415
D27
2R2
0.5W
R62
2R2
0.5W
R63
63v
220n
C28
63v
220n
C29
MC3
2
MC1
1
MC3
4
MC1
5
63v
220n
C30
60v
470P
C33
5K6
R65
4u7 63v
C34
3R9
0.5W
R12
63v
100n
C3
200R
R31
63v
4n7
C22
25v
470p
C31
25v
470p
C32
G
MT2 MT1
MAC15A4FP BC550C
CBE
BC560C MPSA43
EBC
MPSA93
DSG
2N5638
MT1
NC
MT2
MBS4992
200R
R53
50v
470p
C21
MJL21193
ECB
4.7V
1N750A
D36
4.7V
1N750A
D35
IRFP250
SDG
IAMP_IN
POS_IN_R
VMID+
NEG_IN_L
NEG_IN_L
VA_OUT
NEG_IN_R VH-
VMID-
CLIP_R
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
FET_CNTL
POS_IN_L
POS_IN_L
CLIP_L
CLIP_L
VH+
VH+
CONNECTED TO M509 MX1
9
8
7
6
5
4
3
2
1
SERVICE WARNING: POTENTIALS GREATER THAN 130VDC PRESENT.
USE EXTREME CAUTION.
AMPLIFIER
THE LEFT CHAN
CONNECTIONS TO
1.7mA
7.5mA
OUTPUTS
MC2
MC1
*
A

VCD
.020"
.012"
.008"
.005"
.020"
.012" .008"
.005"
SHEARSHEAR
SHEAR SHEAR
SHEAR SHEAR
SOLDERSIDE M508-5.00
BLANK SIZE=17.35"X8.625"
M508-5.00
2 oz COPPER
VCD
DRILL DETL M508-5.00
D1L
4148
D14L BAV21
D2L
4148
Q1L
A43
Q2L
A43
Q3L
A43
Q4L
A43
Q5L
A93
Q6L
A93
Q7L
A93
R36L
100R
R7L
953R
R11L
5K1
D33R
4148 D36R
4V7
R55L
475R
R19L
10K
C3R
100n
R20L
10K
R22L
200R R18L
10K
C18L
3N3
R14L
2K7
R30L
100R
R57R30K
R5R
4K7
R44L
5K6
R10R 953R
J6L
D15L
4004
R27L
2K7
R6L
220K
R33R 1M
R31L200R
R24L
2K7
R35L 30K
R25L
2K7
R21L
100R
R15L
2K7
MC1_B
FUNCTION
R56R 4K7
R28L
56K
R2L
220K
R29L
43K
R39L
22R1
LD1L
R
C4L
63V
100U
Q8L
550
Q13L
A93
Q10L
550
Q11L
550
Q12L
550
R60L
1M
Q14L
560
R52L
30K
D18R
4148
C11L
470P
C12L
680P
C13L
100P
C10L
3N3
C14L
220N
C33L
470P
R17R 249R
R17L
249R
C20L
3N3
R40R 953R
R7R 953R
R26L
475R
R33L
1M
R49L
0.5W
10R
C15L
100N
R47L
68K
R48L
68K
R65R
5K6
Q24L
2N5638
C8L
10U 16V
J13
C1L
68U
16V
C2L
68U
16V
C29L
220n
D11L
10V
Q18L
MBS4992
Q9L A93
C5L
33U 16V
D35R
4V7
C7L
33U 16V
R32L
31K6
C22L
4N7
R50L
30K
R62L
0.5WATT
2R2
C6L
33U 16V
DOWN
BAR
D24L
MUR415
C21L
470p
R26R
475R
R23L
4K7
L1L
5UH
R51L
5K6
D5L 4148
Q15R
PART#6928
IRFP250
D7R
4148
J7L
DOWN
BAR
D27L
MUR415
R45L
0R1
5WATTS
C30L
220n
H1R
D34L
4004
D28L
4004
D12L
2V0
DOWN
BAR
D9L
MUR415
C32R
470P
D4L
4148
DOWN
BAR
D25L
MUR415
J5L
D32L
BAV21
R40L
953R
D33L
4148
D18L
4148
J2
WC1
J4
C24L
470u
63v
C27
PART#
5600U
100V
Q17L
#XXXX TRIAC
MAC15A4FP
YYY
D28R
4004
D17R
BAV21
R65L 5K6
C28R
220n
C34L
22U
50V
C25R
16v
22u
C31L
470P
Q16L
PART#
IRFP250
R41L
1WATT
5K6
D34R 4004
R3L 5K6
R46L
0R1
5WATTS
D10L
10V
DOWN
BAR
D26L
MUR415
Q23L
A93
Q22L
A93
Q21L
A43
D23L
10v
D22L
12V
C23L
470u
63v
R12L
3R9
2_WATTS
DOWN
BAR
D30L
MUR415
R62R
0.5WATT
2R2
Q20L
MJL21193
Q19L
PART#6928
IRFP250
R9R 22K
Q25L
2N5638
R58L
200R
H6R
R57L
30K
R56L
4K7
R43R 953R
R10L
953R
R53L
200R
R58R 200R
Q15L
PART#6928
IRFP250
D7L
4148
H1L
D19R
4148
RTV
D17L
BAV21
C28L
220n
R3R
5K6
C25L
16v
22u
R9L
22K
J15
C21R
470p
C26
PART#
5600U
100V
R12R
3R9
2_WATTS
H6L
J9
R50R
30K
R53R
200R
Q25R
2N5638
R61R
31K6
Q19R
PART#6928
IRFP250
Q20R
MJL21193
R52R
30K
R63L
0.5WATT
2R2
D2R
4148
C23R
470u
63v
D22R
12V
D23R
10v
Q21R
A43
Q22R
A93
Q23R
MPSA93
DOWN
BAR
D26R
MUR415
D10R
10V
R46R
0R1
5WATTS
D21R
BAV21
D15R
4004
R41R
1WATT
5K6
Q16R PART#
IRFP250
R44R
5K6
D16R
4004
Q17R
#XXXX TRIAC
MAC15A4FP
YYY
C24R
470u
63v
D20R
4148
R16L
200R
J5R
DOWN
BAR
D25R
MUR415
D4R
4148
C20R
3N3
DOWN
BAR
D9R
MUR415
D12R
2V0
D31R
4004
D29L
4004
C30R
220n
EY6R
R45R
0R1
5WATTS
DOWN
BAR D27R
MUR415
J11
EY7R
EY8R
D5R
4148
D6L
4148
R51R
5K6
L1R
5UH
R23R
4K7
D35L
4V7
C33R
470p
DOWN
BAR
D24R
MUR415
C6R
33U
16V
R59R
470R
C7R
33U
16V
C22R
4N7
C5R
33U 16V
Q9R
A93
Q18R
MBS4992
D11R
10V
C29R
220n
C2R
68U 16V
C1R
68U 16V
C8R
10U 16V
Q24R
2N5638
R32R
31K6
R48R
68K
R47R
68K
C15R 100N
R49R
0.5W
10R
R55R
475R
D36L
4V7
R54R
274R
R13R
249R
C10R
3N3
R13L
249R
C13R
100P
C14R
220N
C12R
680P
C11R
470P
C18R
3N3
C3L 100n
C9L
100P
R15R
2K7
Q14R
560
Q12R
550
Q11R
550
Q10R 550
Q13R
A93
Q8R
550
C4R
63V
100U
LD1R
R
R61L
31K6
R29R
43K
C19L
27p
R28R
56K
R21R
100R
R25R
2K7
R35R
30K
R24R 2K7
R31R
200R
R4R
274R
R27R
2K7
R34L 100R R6R
220K
R34R
100R
D16L
4004
J6R
R30R
100R
R1L
681R
R14R
2K7
R18R
10K
R59L
470R
R22R 200R
R20R 10K
R19R 10K
R11R
5K1
D19L
4148
R5L
4K7
R60R
1M
D32R
BAV21
R36R
100R
R43L
953R
R42L
10K
Q7R
A93
Q6R
A93
Q5R
A93
Q4R A43
Q3R
A43
Q2R
A43
Q1R
A43
D6R
4148
D14R
BAV21
D1R 4148
J12
FUNCTION PART#
RTV
1
FUNCTION
J3
WC2
J18
J10
RTV
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
# DESCRIPTION OF CHANGEVER#DATE
MODEL(S):-
M508/A/C.PCB_DATABASE_HISTORY
ES700P_PS218_PS210PX
SOME_TRACES_ALTERED.PADS_FOR_MOLEX
CHANGED_FROM_S100_TO_R120.
ROUTING_BY_FILTER_CAPS_CHANGED.
PC#XXXX_FILTER_CAPS_CHANGED
PC#4409_Q11R_MOVED
PC#XXXX_Q1L/R_Q2L/R_MOVED
J10_RADIAL->AXIAL
N
N
N
N
N
N
N
N
N
N
N
N
N
3.40
.
.
4.00
.
.
5.00
V
V
V
V
V
V
V
V
V
V
V
V
V
FEB/24/95
.
.
AUG/27/97
.
SEP/05/97
MAR/25/98
D
D
D
D
D
D
D
D
D
D
D
D
D
GUIDE
ETCH
GUIDE
ETCH
J14
MC1_A
FUNCTION
DOWN
BAR
D30R
MUR415
R63R
0.5WATT
2R2
R2R
220K
C19R
27p
R42R
10K
C31R
470P
R64R
680R
C32L
470P
D20L
4148
#3638
FROM_M1055
PART#
R64L
680R
D21L
BAV21
C9R
100P
C34R
22u 50V
D29R
4004
D31L
4004
R16R200R
R54L
274R
R4L 274R
R39R
22R1
R8L
31K6 R8R 31K6
R1R
681R
1
FUNCTION
RTV
9POS.RT.ANGLE_MOLEX
VMID-
RREF
OUTPUT_A
RSIG
VH+ VH+
VH+
VH+ VH+
LCLIP
GND
GND
GND
GND
GND
GND
GND
VMID+
VMID+
LSIG
LREF
RCLIP
POUTR
VH-
VH-
POUT
OUTPUT_B
ASSEMBLY M508-5.00
BLANK SIZE=17.35"X8.625"
PCB MECH M508-5.00
VER. 5.00M508
BOARD ASSEMBLY
Q1L/Q1R, Q2L/Q2R
AUTO-INSERTION
THE SAME BATCH (MANUFACTURERS LOT # )
THE ABOVE TRANSISTORS MUST BE FROM
BEND THERMISTORS R23L/R OVER FLAT TO PCB.
7.
C7L/R,C26L/R.
BEFORE IT IS PUT INTO THE STRAIN RELIEF
.
ADD RTV UNDER THE MOLEX RIBBON CABLE
6.
C34L/R, C5L/R, C1L/R, C2L/R, L1L/R
RTV’D IN PLACE
LD1L/R ARE BENT OVER FLAT TO PCB AND
5.
4.
3.
USE #8799 SCREW TO MOUNT Q17L/R.
SOLDER.
ADD TOOTH PICKS TO EYELETS BEFORE WAVE
TIES.
AND HELD IN POSITION WITH NYLON CABLE
CORRECT POSITION. THESE CAPS ARE RTV’D
SOLDER AND SOLDERED MANUALLY TO THEIR
C26 AND C27 ARE BROKEN AWAY AFTER WAVE
2.
ADD RTV BETWEEN C23L/R , C24L/R AND
R45L/R, R46L/R, C6L/R, C8L/R, C25L/R
ADD RTV TO THE FOLLOWING COMPONENTS
1.
1.
PRODUCTION NOTES
0.125" UP 0.125" UP
MOUNT R48 MOUNT R48
NO CLIP#3491 CLIP
M508A /ES700P/PS218/PS210P
ES700P
PS210P
ES700PPS210P
33" BLACK
33" RED
#3491 CLIP
#3491 CLIP
#3491 CLIP
9 1/2" RED
PS218P
PS218P
27" BLACK
27" RED
250 CLIP 250 CLIP250 CLIP
30" RED
9" GREEN 9" GREEN
12" RED
12" BLACK
RTV RTV
RTV
RTV
RTV
RTV
#3491 CLIP
NO CLIP
THIS JUMPER FOR
P:\508VR.PRN

15K R51
22u
16V
C18
1K R50
4K7 R52
1K R49
33K R48
220K R47
470K
R46
68u
16V
C16
100u
16V
C15
10K R45
100K R42
BC550
Q4
1K2 R38
10K R41 10K R40
BC560
Q5
BC560
Q6
1K5 R34
22K R32
22K R19
OUT
IN
SW1
1
2
3
2K74
R11
OUT
IN
SW1
4
5
6
82K5
R10
33K R31
220R
R29
GREEN
LD2
16V10u
C32
220R
R27
220R R26
SW3
33K R28
1/2
TLO72
U4
6 5
7
47n C12
1/2
NE5532
U3
6 5
7
100n C11
22K R23
PIN 11
D
IABC
1/2 LM13600 U1
4 2 3
1
587
22K R22
100K R21
1/2
NE5532
U3
2 3
1
33K R18
1/2
TLO72
U2
6 5
747n
C10
100K
R24
470K
R33
CW
VOLUME
10K
LINP1
330K
R20
4K7 R15
PIN 11
D
IABC
1/2 LM13600 U1
13 15 14
16
12 910
82K5
R9
2K74
R14
82K5
R13
82K5
R12
1K
R53
1/2
TLO72
U5
2 3
1
82K5
R8
82K5
R7
SRT
IN
RIGHT
JB3 1
2
3 4
5 6
SRT
OUT
LEFT
JB2 1
2
3 4
5 6
1/2
TLO72
U2
2 3
1
220R
R30
1/2
TLO72
U5
6 5
7
47n C9
1/2
TLO72
U4
2 3
1
YSL_PT#1287
120VAC
60Hz
XXXVA
680R R17
POWER_ON
GREEN
LD1
4u7
35v
C5
4M7
R2
D3
12A-SB/250V
F1
WC8
1
1N4004 D1
10u
50V
C8
10u
50V
C7
IN
REF
OUT
7815Q1
1
2
3
IN
REF
OUT
7915Q2
2
1
3
20v
500mW
D4
#7267
18"
4R-300W
1K R16
OUT
IN
SW2
4
5
6
12A-SB/250V
F3
13AMP
DB1
3 4
1
2
13AMP
DB2
3 4
1
25600u
100V
C4
4700u
50v
C1
4700u
50v
C2
5600u
100V
C3
EY2
WC3
1
EY4
CSA 4n7
C29
WC4
1
1N4004 D2
CSA 22n
C28
1N4004
D6
1N4004
D5
WC6
1
100K
R1
3K3
R3
T12A/250V
4u7
35v
C6
EY1
WC9
1
EY3 EY5
15K
0.5W
R4
OUT
IN
GND/LIFT
SW2
1
2
3
1K8
0.5W
R6
MX1
1 2 3 4 5 6 7 8 9
100n C23
100n C21
SRT
OUT
RIGHT
JB4 1
2
3 4
5 6
SRT
LEFT
IN
JB1 1
2
3 4
5 6
REF
IN
OUT
7915
IN
REF OUT
7815
100n C19
100n C20
100n C22
100n C24
100n C27
100n C26
22u
16V
C17
WC5
1
WC7
1
13A/205C
BR1
9K76
R61
220p C30
220p C31
9K76
R60
10K R59
10K R58
BC560
Q7
12A-SB/250V
F4
16V10u
C13
15K
0.5W
R56 15K
0.5W
R57
O
T
115R
RV1
11
O
T
115R
RV2
11
12
11
10
9
8
7
6
5
4
3
2
1
# DESCRIPTION OF CHANGEVER#DATE
MODEL(S):-
DEC/20/00
JAN/25/99
OCT/27/98
.
AUG/06/98
JUN/26/97
MAY/30/97
MAR/25/97
MAR/12/97
JAN/31/97
V
1.40
1.30
.
1.20
.
1.10
V
1.50 PC#6314_CE_FUSE_T,5A->T3,15
CE_XFMR_WIRE_COLOURS_UPDATED
PC#5867_R51_33K->15K
NA_8A-SB->5A-SB
PC#5785_PRIMARY_FUSE_CE_T5A->T2,5A
CORRECTIONS_TO_CLARIFY
PC#5391_R38_2K2->1K2
PC#5349_U3_TL072-->NE5532
R38_1K-->2K2_U5A_NOT_USED_MX1_ALTRD
.
PS218P-PS218PE
M531.SCH_DATABASE_HISTORY
BC550C
CBE
BC560C
100n C25
"P14"
STYLE
275v
22n
T12A/250V
5A-SB/230V
F5
T12A/250V T12A/250V
T3,15A/230V
WC1
100n C34
100n C33
0.1R
5W
R36
0.1R
5W
R37
1/2
TLO72
U6
2 3
1
33K R25
68K R63
33K R62
100n C35
1/2
TLO72
U6
6 5
7
100n C36
YORKVILLE NAME:
MODELS: SCH ISSUE:
TITLE:
DATE: PS218PE
PS218P
M531V14.SCH DEC/20/2000
PS218P_PRE-AMP/POWER_SUPPLY
1.50
13A/205C
CSA 22n 12A-SB/250V
F2
#7267
18"
4R-300W
#3438_AC_SKT
TAB9
CSA 4n7
4148
D7
230/245VAC
50Hz
#1287E
GND
GND GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
FET_CTRL
FET_CTRL
L&R_AMP
VH-
V-
V-
CHASSIS
WHITE
VM-
VM- VH+
V+
V+
V+
V+
VM+
VM+
REPLACE WITH SAME BUSSMAN GDC TYPE FUSE YS PT#2475
230V
245V
BRN/BLK
BRN
BLUE
REPLACE WITH SAME TYPE FUSE REPLACE WITH SAME TYPE FUSE
REPLACE WITH SAME TYPE FUSE
GREY
YELL
GREY
GREY YELL GREY
LEFT RIGHT
M508 AMP
GRN
TO M508
GRN/YEL
RED RED
IS OFF-PCB
ENCLOSED CIRCUITRY
BLACK
CONNECTOR MC1
HIGH CURRENT TO M508
TO M508 MC2 CONNECTOR
BLK BLK RED
RED RED
RED
RED
SPEAKER/LINE
SPEAKER/LINE
TURN ON/OFF FET CTRL
NEG_IN_L POS_IN_L CLIP_L GND GND CLIP_R POS_IN_R NEG_IN_R
IN
IS OFF-PCB
ENCLOSED CIRCUITRY
GREEN
POWER SUPPLY
ENCLOSED CIRCUITRY IS OFF-PCB
BLUE WHITE BLACK YELLOW RED
ALL UNMARKED DIODES ARE 1N4148.
BLK
BLK
120 VAC 60 Hz LINE
.
FIRST PROTYPE
PRODUCTION NOTES
-
- + +
U:\M531V16.PRN

VCD
3.00
M531
BLANK SIZE=12.250" X 10.200"
C18
16V 22u
R37
5W
0R1
Q4
BC550
WC5
.
LD2
GRN
U4
TLO72
U1
LM13600
JB3
LINE_IN
D2
4004
Q1
+15V 7815
Q2
-15V
7915
D7
4148
J8
C4
5889 100V
5600u
C1
5859
50v
4700u
"P14"
STYLE
C29
4n7
250V
R4
0.5W
15K
Q7
BC560
R50
1K
R52
4K7
R49
1K
C49
22N
400V
R51
15K
SW1
SPKR./LINE
3436
R982K5
R58
10K
J29
J13
R40
10K
J26
R19
22K
R13
82K5
RV1115R R34 1K5
R29 220R
R33K3
R27
220R R26
220R
R59
10K
R23
22K
R22
22K
R21
100K
RV2115R
R24 100K
R32 22K
R20
330K
R18
33K
R8 82K5
R14
2K74
R53
1K
TAB9
.
.
R30 220R
R16
1K
R38
1K2
R15
4K7
R1
100K
J23
R57
0.5W
15K
C16
16V 68u
C15
16V
100u
C5
35v
4u7
C8
50V
10u
C7
50V
10u
C6
35v
4u7
C17
16V 22u
R36
5W
0R1
D3
4148
J32
Q5
BC560
Q6
BC560
C12
47n
C11 100n
C10
47n
C21
100n
C23
100n
R47220K
C19
100n
C20100n
C22
100n
C24
100n
C27 100n
C26
100n
-
+
LD1
R609K76
U3
NE5532
U2
TLO72
U5
TLO72
JB2
LINE_OUT
JB4
LINE_OUT
JB1
LINE_IN
R1282K5
WC6
.
WC7
.
_WC6
.
_WC8
.
R46470K
WC9
.
C25 100n
D6
4004
D5
4004
J6
C3
5889 100V
5600u
C2
5859
50v
4700u
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
# DESCRIPTION OF CHANGEVER#DATE
MODEL(S):-
D
D
D
.
JUL/02/02
.
OCT/06/99
OCT/27/98
MAY/30/97
APR/23/97
MAR/25/97
.
.
MAR/12/97
FEB/17/97
FEB/97
V
V
V
.
3.00
.
2.00
1.02
1.01
1.00
1.P3
.
.
.
1.P2
1.P1
N
N
N
NEW_PADS_FOR_TABS
PC#6179_REMOVE_COPPER_ATJ4,J8
PC#6109_REDO_GND_LIFT_SW_ADD_C33
PC#6130_MOVE_R3_AWAY_FROM_R2
PC#5867_R51_33K->15K
PC#5391_R38_2K2->1K2
FIRST_PRODUCTION
PC#5349_U3_TL072-->NE5532
REVERSED
DELETED_POLARITY_L&R_AT_MX1
R38_1K->2K2_R35,R39,R43,C14,D8,Q3
AMP-INS_REPLACED_BY_EYELETS
1ST_PROTOTYPE
PS218P
M531.PCB_DATABASE_HISTORY
TAB8
.
AC_WHT
TAB10
.
.
C28 22n
400V
J18
J16
J15
J14
C9
47n
R42100K
R6
1K5
R45
10K
J20
J17
R17
680R
TAB2
.
AC_WHT
F3
#3414
F2
#3414
F1
#3414
J7
J5
J4
D4
20V
TAB1
.
.
R31 33K
J24
J19
J21
J28
C32
10u_NP
16V
P1
10K
LIN
VOLUME
4403
J11
J12
SW2
GND_LIFT
3436
J9
LEADS UP
DB1
KBPC__-W
LEADS UP
DB2
KBPC__-W
R4833K
J2
J3J1
R41
10K
J10
D1
4004
F4
#3414
R11 2K74
MC1
8POS.RT.ANGLE_MOLEX
#3521
TO_M508_MC1
J25
R28
33K
J27
R56
0.5W
15K
C13
10u_NP
16V
C30
220p
C31
220p
R7
82K5
R10 82K5
R33 470K
R61
9K76
J22
WC1
.
TAB7
.
.
WC3
.
TAB4
.
.
TAB5
.
.
TAB3
.
.
TAB6
.
.
U6
TLO72
C36
100n
R25
33K
C34
100n
C33
100n
R62 33K
R63
68K
J30
C35 100N
J31
J33
R24M7
.
CSA-12A-SB/125V
CE-T12A/230V
CSA-12A-SB/125V
CE-T12A/230V
CSA-12A-SB/125V
CE-T12A/230V
CSA-12A-SB/125V
CE-T12A/230V
WC8
.
WC4
.
CHAS.GND
.
_WC4
.
_WC9
._WC3
.
MX1
MOLEX
9_PIN
L&R_AMP FET_CTRL
AMP_L
M531 VER:3.00
GRN
NEUTRAL
HOT BLK
BLK
WHT
RED
RED
BLU
BLK
WHT
RED
YEL
BLUE
RED
RED
GND
GND
VH-
VH-
VH+
VH+
VM-
VM-
VM+
VM+
ASSEMBLY M531-3.00
ONLY
WIRING DEPT
ARE FOR
THESE WIRES
7" GREEN
BLK
M508
RED
RED
GRN
FOR Q1 Q2 USE #8742 THREAD-FORMING
PRODUCTION NOTES
RED TO WC5
BLK TO WC7
INSERT 35" SPKR WIRES
WITH A #3501 BELL WASHER
BLANK SIZE=12.250" X 10.200"
HOLE
AZ
GRN
TO M508 INPUT...9POS_3538
PCBMECH M531-3.00
P:\531CMP.PRN

M508
YEL
WHTBLK
BLU RED
WC5
.
GRN
D2
R34
TAB9
.
.
WC6
.
WC7
.
WC9
.
TAB8
.
AC_WHT
TAB10
.
.
TAB2
.
AC_WHT
TAB1
.
.
WC1
.
TAB7
.
.
WC3
.
TAB4 .
.
TAB5
.
.
TAB3
.
.
TAB6
.
.
WC8
.
WC4
.
CHAS.GND
.
GRN
M531 VER:1.00
NEUTRAL
HOT
BLK
BLK
WHT
RED
RED
BLU
BLK
WHT
RED
YEL
BLUE
RED
RED
GND
PS218P WIRES NA VERSION
MAY 01, 2001

M508
YEL
WHTBLK
BLU RED
WC5
.
GRN
D2
R34
TAB9
.
.
WC6
.
WC7
.
WC9
.
TAB8
.
AC_W HT
TAB10
.
.
TAB2
.
AC_WHT
TAB1
.
.
WC1
.
TAB7
.
.
WC3
.
TAB4
.
.
TAB5
.
.
TAB3
.
.
TAB6
.
.
WC8
.
WC4
.
CHAS.GND
.
GRN
M531 VER:1.00
NEUTRAL
HOT
BLK
BLK
WHT
RED
RED
BLU
BLK
WHT
RED
YEL
BLUE
RED
RED
GND
PS218P WIRES CE VERSION
MAY 01, 2001
4" BLACK
6" BLACK
20" BLACK
19" WHITE
4" WHITE
7" GREEN
ON E4-PLUG BRN & BLK FOR 245V
ON E2-PLUG BRN FOR 230V
PUT 3487 CLIP ON UNUSED PIN
PUT CE LOGO ONLY ON 220 +CE SER#
NO CE ON 240 USE E4 SER#
SHOWN WIRED FOR 230V

M508
YEL
WH T
BLK
BLU RED
WC5
.
GRN
D2
R34
TAB9
.
.
WC6
.
WC7
.
WC9
.
TAB8
.
AC_W HT
TAB10
.
.
TAB2
.
AC_WHT
TAB1
.
.
WC1
.
TAB7
.
.
WC3
.
TAB4
.
.
TAB5
.
.
TAB3
.
.
TAB6
.
.
WC8
.
WC4
.
CHAS.GND
.
GRN
M531 VER:1.00
NEUTRAL
HOT
BLK
BLK
WHT
RED
RED
BLU
BLK
WHT
RED
YEL
BLUE
RED
RED
GND
PS218P WIRES CE VERSION
MAY 01, 2001
4" BLACK
6" BLACK
20" BLACK
19" WHITE
4" WHITE
7" GREEN
ON E4-PLUG BRN & BLK FOR 245V
ON E2-PLUG BRN FOR 230V
PUT 3487 CLIP ON UNUSED PIN
PUT CE LOGO ONLY ON 220 +CE SER#
NO CE ON 240 USE E4 SER#
SHOWN WIRED FOR 245V
