Z Microsystems COMMAND CONSOLE 14 User manual

Doc# 27-0001UM Issued 7/99 Rev. 1.2
Z Microsystems
COMMAND
CONSOLE
14
User Manual
FIELD-READY
All manuals and user guides at all-guides.com
all-guides.com

Doc# 27-0001UM Issued 7/99 Rev. 1.2
1. Use the power and
video cab es supp ied
with the Command
Conso e to he p
prevent interference
with radio and
te evision reception.
The use of cab es
and adapters may
cause interference
with e ectronic
equipment in the
vicinity of this unit.
2. This equipment has
been tested and
found to comp y with
the imits for C ass
A digita devices,
pursuant to certain
imits imposed by
Part 15 of the FCC
ru es. These imits are designed to provide
reasonab e protection against harmfu
interference in when equipment is operated in
commercia
environments. This
equipment generates,
uses and can radiate
radio frequency
energy, and, if not
insta ed and used in
accordance with the
instruction manua ,
may cause harmfu
interference to radio
communications.
3. Operation of this
equipment in a
residentia area is
ike y to cause
interference in which
case the user wi be
required to correct the
interference at his
own expense.
Changes or modifications not express y
approved by Z Microsystems cou d void
users authority to operate the equipment
FCC INFORMATION
Regulatory
2
COMMAND
CONSOLE
14
All manuals and user guides at all-guides.com

Doc# 27-0001UM Issued 7/99 Rev. 1.2
STARTING POINT 4
Shipment Contents 4
User Manua 4
System Requirements 4
Product Description 5
PREPARATION 6
INSTALL RAILS 7
INSTALL CONSOLE 8
FINAL ADJUSTMENTS 9
CABLES 9
SETUP 11
C osing Conso e 12
OPERATION 13
MONITOR ADJUSTMENTS 14
REFERENCE 18
TROUBLESHOOTING 20
SPECIFICATIONS 22
APPENDICES 23
SUPPORT 24
Further He p 24
Rep acing Parts 25
Providing Feedback 25
Y2K Comp iance 26
DRAWINGS 27
HARDWARE INSTALLATION 29
Contents
3
All manuals and user guides at all-guides.com

Doc# 27-0001UM Issued 7/99 Rev. 1.2
The User Manua comes in two
formats: printed hardcopy or CD-
ROM. This Manua is a so avai ab e
on the Z Microsystems website
(www.zmicro.com).
We recommend you read this manua
as fo ows:
Carefu y fo ow the instructions in the
Insta ation and Testing chapter for
hookup and initia contro settings.
Refer to the Operation chapter for a
comp ete description of a the user
contro s, and the Maintenance and
Troub eshooting chapters for care and
correcting any unforeseen prob ems
with the system. The Appendices and
References chapters are provided for
quick y finding technica information
about the Command Conso e.
SYSTEM REQUIREMENTS
The Command Conso e works with
any computer system that provides
industry standard screen formats from
640 x 480 to 1024 x 768, with up to
75 Hz vertica sync. See the Specifica-
tions Tab e of this Manua for a
comp ete isting of a reso utions
supported.
The Command Conso e requires a
computer with a suitab e onboard
subsystems for Video Adapter Card
that can support XGA 1024 x 768,
SVGA 800 x 600, or VGA 640 x 480
at 60 Hz
The Command Conso e shipping box
contains the fo owing:
 The Command Conso e Unit
 Video Signa Cab e
 AC/DC Power Supp y Brick with
attached DC cab e
 AC Power Cab e
 Setup Diskette
 User Manua
Remember to save your origina
shipping container and packing
materia to transport or ship the
Command Conso e.
SHIPMENT CONTENTS
4
All manuals and user guides at all-guides.com

Doc# 27-0001UM Issued 7/99 Rev. 1.2
PRODUCT DESCRIPTION
The Command
Conso e provides
a iquid crysta
disp ay, a desk
work surface and
storage for any
size keyboard
and mouse in a
3.5" high (2U)
standard 19"
rack or transit
case.
Specia y de-
signed ocks on
each side of the
Command
Conso e ho d the
compact fo ded
unit secure y in
p ace during
storage.
Re ease of the
two Z-Locks on
the front sides of
the Conso e
a ow it to s ide
out and the LCD
disp ay to quick y
swing up into a
reading position
By ifting up the
desktop, the
keyboard and
mouse can be
easi y removed
and set on top.
The ightweight and durab e a umi-
num construction provides exceptiona
strength in fie d app ications.
The high qua ity LCD screen provides
fu co or and features up to 1024 x
768 pixe reso ution.
The LCD screen has a back ight
contro that reduces power and
extends the ife of the monitor.
The side-viewing ang e is up to 160
degrees. It can be easi y adjusted to
any vertica -viewing ang e up to 100
degrees. The disp ay works effective y
with any workstation.
An e ectrostatica y-app ied and
baked-on finish is used for extreme
durabi ity for shipboard, airborne,
fie d dep oyments, and industria or
ab app ications where weight and
size are very critica .
5
All manuals and user guides at all-guides.com

Doc# 27-0001UM Issued 7/99 Rev. 1.2
TOOLS REQUIRED
PRECAUTIONS
Required Too s and Equipment
 F athead screwdriver with about 10"
shaft.
 Phi ips screwdriver with about 10"
shaft.
 Computer Setup Diskette
In preparation to insta the Com-
mand Conso e, take the fo owing
precautionary steps:
Turn off the e ectrica power to your
computer.
Verify the Command Conso e power
switch is off. If the Conso e is off, the
ight wi not be i uminated.
DANGER: To avoid shock hazard:
 Do not remove the covers around
the Command Console.
 Do not connect or disconnect the
Command Console during an
electrical storm.
 The power cord plug must be
connected to a properly wired
and grounded power outlet.
 Any equipment to which the
Command Console will be
attached must also be connected
to properly wired and grounded
power outlets.
OTE: For the fastest and easiest
installation of the
Command Console, follow
these steps in the sequence
they are presented.
Starting Point
6
All manuals and user guides at all-guides.com
all-guides.com

Doc# 27-0001UM Issued 7/99 Rev. 1.2
SLIDE REMOVAL
With the Conso e sitting
on a workbench with the
front facing towards
you, press down to
re ease the Z-Locks on
each side of the front of
the Conso e to s ide the
side rai s back.
The s ide rai wi reach
a stop about ha f way
back.
This is a safety stop to
prevent the Conso e
s iding out too far whi e
mounted to the rack.
Simu taneous y press in
the safety catches on
each s ide rai and s ide
the side rai s a the way
off the back of the
Conso e.
The s ides shou d now
be separated from the
Conso e.
Each s ide unit inc udes
the s ide rai , with the
front Z- ock mount and
the rear mount.
On the front of the
cabinet frame, use three
Phi ips screws ((V) see
page 30 - Insta
hardware ) on each side
to secure the right and
eft Z-Lock mounts.
DO NOT tighten these
screws to a ow for
adjustment of the
Conso e within the
cabinet frame.
On the rear of the
cabinet frame, use the
three Phi ips screws ((W)
see page 30 - Insta
hardware) to oose y
secure the right and eft
rear s ide mount to the
cabinet frame.
DO NOT tighten these
screws fu y at this time.
On the s ide rai s, using
a s ot screwdriver,
oosen off the s ide
extension rai screw ((U)
see page 30 - Insta
hardware ). Repeat on
each side.
INSTALL THE SLIDES IN THE CABINET FRAME
Install Rails
7
All manuals and user guides at all-guides.com

Doc# 27-0001UM Issued 7/99 Rev. 1.2
Install Rails
Go back on the rear of
the cabinet frame, and
fu y tighten the three
Phi ips screws ((W) see
page 30 - Insta
hardware) ho ding the
s ide extension rai to
the cabinet frame.
Make sure you ho d the
s ide mounts hard
against the rack rai .
8
All manuals and user guides at all-guides.com

Doc# 27-0001UM Issued 7/99 Rev. 1.2
INSTALL THE COMMAND CONSOLE IN THE SLIDES
Pu the two Conso e
s ides out unti they ock.
Ho d the Conso e by
each side, with the front
toward you.
Feed the four cab es
coming out of the
Conso e back through
the cabinet frame.
Guide the Conso e into
the s ides and s ide the
Conso e in unti it stops.
Simu taneous y press in
the catches on each
s ide and s ide the
Conso e a the way into
the cabinet frame.
The Conso e shou d
s ide in and out easi y.
S ide the Conso e in
and out severa times.
The Conso e shou d
easi y c ose comp ete y.
To be sure the s ide and
mount assemb y are
a igned proper y, s ide
the Conso e in and out
severa times.
If the Conso e binds
during s iding, do the
fo owing:
Because of variances in
cabinet frames, there
may need to be some
adjustments of the
Conso e s ide system for
best fit and movement
of the Conso e in and
out.
TEST INSTALLATION AND MAKE ADJUSTMENTS
Install Console
9
All manuals and user guides at all-guides.com

Doc# 27-0001UM Issued 7/99 Rev. 1.2
Loosen the screws on
each of the front Z-Lock
mounts.
FINAL ADJUSTMENTS OF THE COMMAND CONSOLE
S ide the Conso e
partia y out.
Use a f athead screw
driver to s ight y move
the Z-Locks out away
from the Conso e.
Tighten a the screws on
the front Z-Lock mounts.
S ide the Conso e in and
out to see if it moves
smooth y.
Go back to the rear of
the rack and fu y
tighten the s ide
extension rai screw ((U)
see page 30 - Insta
hardware ).screws.
Note: A wrench may be
necessary to hold the
nut on the other side.
Install Console
