Z3 Technology Z3-DM8169-VI-RPS User manual

CONFIDENTIAL Z3-DM8169-VI-RPS
___________________________________________________________________________________________
V1.03.00
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. ♦ +1.402.323.0702
1
Video Infrastructure 1080p60 System
DM8169 Rapid Prototyping System
Version 1.03.00
August 7, 2012
Model Name: Z3-DM8169-VI-RPS
High Definition Video Processor Module

CONFIDENTIAL Z3-DM8169-VI-RPS
___________________________________________________________________________________________
V1.03.00
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. ♦ +1.402.323.0702
2
Revision History
Version
Date
Change Note
Author
0.1
10/13/11
Original Z3-DM8169-VI-RPS System
CH
0.2
12/12/11
Updated Z3-DM8169-VI-RPS Demos, Layout, Formatting
CH
1.0
12/15/11
Updated demo diagrams
CH
1.1
02/17/12
Added UDP Streaming Option
CH
1.02.00
04/23/12
Updated software version. Included DM8169 part number
CH
1.02.00a
05/11/12
Updated Web Server Option
CH
1.02.00b
07/16/12
Address Update
NS
1.03.00
08/07/12
Updated software version; added test configurations & fixed pictures
NC

CONFIDENTIAL Z3-DM8169-VI-RPS
___________________________________________________________________________________________
V1.03.00
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. ♦ +1.402.323.0702
3
CONTENTS
1. General Description.......................................................................................................................................4
2. Features.......................................................................................................................................................... 5
3. Applications...................................................................................................................................................5
4. Thermal Considerations.................................................................................................................................6
5. Serial Control.................................................................................................................................................7
5.1 Serial.....................................................................................................................................................7
5.2 Encode Menu ........................................................................................................................................7
5.3 System Menu Control (Encode)............................................................................................................8
5.4 Decode Menu........................................................................................................................................9
5.5 System Menu Control (Decode) ......................................................................................................... 10
6. Web Server Control ..................................................................................................................................... 11
6.1 Web Server.......................................................................................................................................... 11
6.2 Encode Menu ......................................................................................................................................12
6.3 System Menu Control (Encode)..........................................................................................................12
6.4 Decode Menu......................................................................................................................................12
6.5 Decode Menu......................................................................................................................................13
7. Demos..........................................................................................................................................................14
7.1 Encode & Stream with PC VLC Decode............................................................................................ 14
7.2 Encode & Stream with Z3-MVP-02 Decode (RTP ONLY)......................................................................18
7.3 Encode & Stream with Z3-MVP-02 Decode; Back-to-Back ASI Demo............................................ 22
8. Installing the Released Materials................................................................................................................. 22
8.1 Building the Code..................................................................................................................................... 23
9. Configuring the Target for Your Own Development Environment.............................................................23
9.1 U-boot Startup Scripts......................................................................................................................... 25
9.2 U-boot Update Scripts.........................................................................................................................25
10. Building the Code....................................................................................................................................25
11. UBIFS ...................................................................................................................................................... 27
12. Dependencies........................................................................................................................................... 28
13. Updating Firmware.......................................................................................................................................28
13.1 Web Server..............................................................................................................................................28
14. Troubleshooting....................................................................................................................................... 28

CONFIDENTIAL Z3-DM8169-VI-RPS
___________________________________________________________________________________________
V1.03.00
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. ♦ +1.402.323.0702
4
1. General Description
The Z3-DM8169-VI-RPS development system consists of both hardware and software. The hardware
provided includes one Z3-DM8169-MOD system on module card and a carrier or application board, the Z3-
DM8169-APP-3x (x is the HW release version), which provides advanced video input capabilities. The
bundled software includes all necessary components for the user to develop its own advanced multimedia,
graphics and DSP applications.
Measuring 88mm x 108mm, the Z3-DM8169-MOD is a compact OEM module, supporting H.264 codec at up
to two channels of 1080p at 60 fps (frames per second) encode and stream, decode from stream or store in
applications such as real time transcoding, broadcast video encoding and decoding, digital signage and video
kiosks, medical and industrial video, video conference terminal and MCU and high definition embedded video
sub-systems. The Z3-DM8169-MOD features a unique expansion interface comprised of five high density
connectors providing access to the greatest majority of interface signals available from the DM8169 processor.
Figure 1 below shows the Z3-DM8169-MOD system on module.
An application board, Z3-DM8169-APP-3X,is available from Z3 Technology and is included with the Z3-
DM8169-VI-RPS system.This application board uses the I/O expansion capability of the Z3-DM8169-MOD
to implement additional functions not present in the base module. The Z3-DM8169-APP-3X application
board has an HDMI input, 3G SDI input/output, ASI input/output, YPbPr input and two analog stereo audio
inputs. Figure 2 below shows an image of a Z3-DM8169-APP-3X application board.
A/V Out
YPbPr Out
Boot Mode
Selection
Console
Power switch
and LED
JTAG
HDMI Out
GigE
SATA
SATA
USB (x2)
Power
108mm
88mm
Figure 1

CONFIDENTIAL Z3-DM8169-VI-RPS
___________________________________________________________________________________________
V1.03.00
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. ♦ +1.402.323.0702
5
A Linux-based media SDK license, additional design services and support are available from Z3 Technology.
Please contact Z3 at http://www.z3technology.com or e-mail at [e-mail].
2. Features
High Density connectors to interface to all signals
Supports output of video and audio at up to 1080p60 resolution
1 GB DDR3 and 256MB NAND Flash
Composite video and audio output
H.264 BP & MP, MPEG-4 SP and MJPEG video encoding up to 1080p, 60 fps
H.264 BP & MP, MPEG-4 SP and MJPEG video decoding up to 1080p, 60 fps
RJ45 jack from on-module PHY, supporting 1GB Ethernet
Dual SATA interface supporting 3Gbps drives
Dual USB 2.0 type A (host) jacks
RS232 serial console port
JTAG debug port
3. Applications
The Z3-DM8169-MOD is designed to facilitate the implementation of video and audio functions on media-
embedded applications such as broadcast video encoding and decoding, real time transcoding at 1080p60,
video security and industrial DVR, medical and industrial video and video conferencing terminal and MCU.
218mm
90mm
Figure 2

CONFIDENTIAL Z3-DM8169-VI-RPS
___________________________________________________________________________________________
V1.03.00
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. ♦ +1.402.323.0702
6
Its versatile design allows the system designer to focus on the end application, with confidence that the Z3-
DM8169-MOD will handle all audio and video media operations required with little or no additional
engineering effort.
Whether the end application requires encode or decode media from storage or streaming, the readily available,
production-ready Z3-DM8169-MOD will simplify the overall system design, reducing time to market and
costs.
4. Thermal Considerations
The main processor on the Z3-DM8169-MOD generates a large amount of heat, and is cooled by a fan heat
sink type cooler. The heat sink may reach temperatures in excess of 75 degrees C during work. Please make
sure that the airflow for the heat sink is free and unimpeded at all times. Hot air must have a place to escape to
allow for room air to be used to cool the chip. Failure to do so may result in permanent damage to the
processor.
The maximum continuous power consumption by the whole Z3-DM8169-MOD system during normal
operation should be less than 18W, with up to 12W dissipated by the main processor. Please plan the cooling
strategy appropriately.

CONFIDENTIAL Z3-DM8169-VI-RPS
___________________________________________________________________________________________
V1.03.00
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. ♦ +1.402.323.0702
7
5. Serial Control
5.1 Serial
1.) Plug-in a supplied serial cable from the Z3-DM8169-VI-RPS to your PC
2.) Set up Teraterm on the PC for 115k, 8, N, 1, N, 1ms/char, 50ms/line
3.) Connect to the proper COM port
4.) Connect the supplied 12V power to the Z3-DM8169-VI-RPS
5.) Power-on the Z3-DM8169-VI-RPS
6.) Output should come immediately to the Teraterm console
5.2 Encode Menu
+==============================================================
| Z3 Technology, LLC DM8169-VI-RPS 1.03.00
+==============================================================
| + -- Set Device Name [ DM8169-VI-RPS ]
| = -- Set Password [ BLANK ]
|~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
| 0 -- Operating Mode [ Encoder ]
|~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
| 1 -- Video Source [ HDMI1 ]
| 2 -- Audio Source [ Automatic ]
| 3 -- Audio Codec [ AAC-LC ADTS ]
| 4 -- Audio Bitrate [ 192 kbits ]
| 5 -- Video Resolution [ ]
| 6 -- Rate Control [ VBR ]
| 7 -- Video Bitrate [ 12000k ]
| 8 -- Video Profile [ High ]
| 9 -- Video Frame Rate [ 60 ]
| A -- Gop Size [ 60 Frames ]
| B -- Video Burst Size [ 1000ms ]
| C -- B-Frame GOP Structure [ open [IBB] ]
| D -- B-Frame Interval [ 3 ]
| E -- B-Frame Temporal Layer [ 1 ]
|~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
| F -- Output Interface [ Ethernet ]
| G -- Video Passthru [ HDMI ]

CONFIDENTIAL Z3-DM8169-VI-RPS
___________________________________________________________________________________________
V1.03.00
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. ♦ +1.402.323.0702
8
| H -- Output Format [ MPEG-2 TS ]
| I -- Dest IP Address [ 225.1.2.3 ]
| J -- Dest Port [ 8888 ]
|~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
| K -- Local IPAddress [ 192.168.81.68 ]
| L -- Local Netmask [ 255.255.0.0 ]
| M -- Default Gateway [ 192.168.0.1 ]
+==============================================================
| T -- Stop S -- Start
|~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
| U -- Load User Settings R -- Refresh Menu
| W -- Save User Settings X -- Exit
| Y -- Load Factory Default Settings
+==============================================================
---- enter option:
5.3 System Menu Control (Encode)
Encoder Setup
Video Source
HDMI, SDI, Composite
Audio Source
Automatic, Analog Jacks
Audio Bit Rate
96 kbits, 128 kbits, 192
kbits
Audio Codec
AAC-LC ADTS, None
Video Resolution
Follow Input, De-interlace
Rate Control
CBR, VBR
Video Bit Rate
Custom
Video Profile
Baseline, Main, High
Frame Rate
Custom

CONFIDENTIAL Z3-DM8169-VI-RPS
___________________________________________________________________________________________
V1.03.00
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. ♦ +1.402.323.0702
9
Gop Size
10 Frames, 12 Frames, 15
Frames, 25 Frames, 30
Frames, 50 Frames, 60
Frames, 100 Frames, 120
Frames, 200 Frames, 240
Frames
Video Burst Size
150ms, 200ms, 300ms,
400ms, 500ms, 1000ms,
1200ms, 1400ms, 1600ms,
1800ms, 2000ms
B-Frame GOP Structure
Open [IBB], Close [BBI]
B-Frame Interval
Custom (default: 3)
B-Frame Temporal Layer
Custom (default: 1)
Output Setup
Output Interface
Ethernet, DVB-ASI
Video Passthru
HDMI, SDI
Output Format
RTP, MPEG-2 TS
Destination IPAddress
192.168.X.XX (Use IP
address of your PC)
Destination Port
8888
Local IP Setup
Local IPAddress
192.168.X.XX (Default IP
of the system)
Local Netmask
255.255.0.0
Default Gateway
192.168.0.1
5.4 Decode Menu
+==============================================================
| Z3 Technology, LLC DM8169-VI-RPS 1.03.00

CONFIDENTIAL Z3-DM8169-VI-RPS
___________________________________________________________________________________________
V1.03.00
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. ♦ +1.402.323.0702
10
+==============================================================
| + -- Set Device Name [ DM8169-VI-RPS ]
| = -- Set Password [ BLANK ]
|~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
| 0 -- Operating Mode [ Decoder ]
|~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
| 1 -- Input Interface [ Ethernet ]
| 2 -- Input format [ RTP ]
| 3 -- RTP IP:Port [ 225.1.2.3:8888 ]
| 4 -- STC-PCR Offset(ms) [ 0 ]
| 5 -- Output Interface [ HDMI ]
| 6 -- Display Resolution [ 1080p-60 (1920x1080) ]
|~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
| 7 -- Video Codec [ h264 ]
| 8 -- Audio Codec [ AAC ]
|~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
| 9 -- Local IP Address [ 192.168.81.68 ]
| A -- Local Netmask [ 255.255.0.0 ]
| B -- Default Gateway [ 192.168.0.1 ]
+==============================================================
| T -- Stop S -- Start
|~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
| U -- Load User Settings R -- Refresh Menu
| W -- Save User Settings X -- Exit
| Y -- Load Factory Default Settings
+==============================================================
---- enter option:
5.5 System Menu Control (Decode)
Input Selection
Input Interface
Ethernet, DVB-ASI
Input Format
RTP, MPEG-2 TS
RTP:IP Port
Custom
STC-PCR Offset (ms)
Custom

CONFIDENTIAL Z3-DM8169-VI-RPS
___________________________________________________________________________________________
V1.03.00
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. ♦ +1.402.323.0702
11
Decoder Setup
Video Codec
H.264
Audio Codec
AAC, None
Stream Format
Auto detect, 1080p
(1920x1080), 1080i
(1920x1080), 720p
(1280x720), NTSC
(720x480), PAL (720X576)
Output Setup
Output Interface
HDMI, HD-SDI,
Component
Display Resolution
1080p-60 (1920x1080),
1080p-50 (1920x1080),
1080i-60 (1920x1080),
1080i-50 (1920x1080),
720p-60 (1280x720), 720p-
50 (1280x720), 480p
(720x480), 576p (720x576)
Local IP Setup
Local IPAddress
192.168.X.XX (Default IP
of the system)
Local Netmask
255.255.0.0
Default Gateway
192.168.0.1
6. Web Server Control
6.1 Web Server
1.) Power on the Z3-DM8169-VI-RPS
2.) Connect the Ethernet cable from the Z3-DM8169-VI-RPS unit directly to the PC
3.) Disable all wireless connections
4.) For a client PC to access the Z3-DM8169-VI-RPS factory default settings, set the IP address of the

CONFIDENTIAL Z3-DM8169-VI-RPS
___________________________________________________________________________________________
V1.03.00
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. ♦ +1.402.323.0702
12
PC to 192.168.81.XX (As the IP address of the Z3-DM8169-VI-RPS is 192.168.81.68)
5.) Open Firefox or Internet Explorer 8 (or above) as your web browser
6.) Type the IPaddress of the Z3-DM8169-VI-RPS in your web browser (http://192.168.81.68) and
the Z3-DM8169-VI-RPS web configuration menu will appear.
6.2 Encode Menu
6.3 System Menu Control (Encode)
**Please see section 5.3 above which will contain the exact same information for each of these parameters**

CONFIDENTIAL Z3-DM8169-VI-RPS
___________________________________________________________________________________________
V1.03.00
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. ♦ +1.402.323.0702
13
6.4 Decode Menu
6.5 Decode Menu
**Please see section 5.5 above which will contain the exact same information for each of these parameters**

CONFIDENTIAL Z3-DM8169-VI-RPS
___________________________________________________________________________________________
V1.03.00
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. ♦ +1.402.323.0702
14
7. Demos
7.1 Encode & Stream with PC VLC Decode
The encode and stream to PC demo can support inputs from HDMI and 3G SDI. The connections are labeled
below.
The video source (we use a Brite-View box, Model: BV-5005HD Mini CT) must be a NON-HDCP source for
HDMI input. In order to test 3G SDI, you will need a HDMI to 3G SDI converter (we use a TV One converter,
Model: 1T-FC-766).
Tested Input Resolutions:
3G-SDI: 1080p60, 1080i60, 720p60, 480p, 480i
HDMI: 1080p60, 1080i60, 720p60, 480p
Component: 1080i60, 720p60, 480p, 480i
The System can be controlled via serial port on Z3-DM8169-MOD.
1. Plug-in serial cable and NULL modem connector from Z3-DM8169-MOD to PC’s COM port.
2. Setup teraterm on PC for 115k, 8, N, 1, 0ms/char, 100ms/line.
3. Connect the other end of the serial cable to the console port on Z3-DM8169-MOD board.
The console port is the 2.5mm jack next to the power switch.
4. Connect power supply to Brite-View Box.
5. Connect USB stick with content to Brite-View Box.
6. Set Brite-View Box to play videos at 1080p60.
Top: Pb In
Bottom: Pr In
Top: SDI In
Bottom: Y In
Top: SDI Out
Bottom: ASI Out 2
Top: ASI In
Bottom: ASI Out 1
Stereo Analog Jacks
HDMI In
Serial

CONFIDENTIAL Z3-DM8169-VI-RPS
___________________________________________________________________________________________
V1.03.00
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. ♦ +1.402.323.0702
15
7. Connect HDMI out of Brite-View Box to the HDMI in of the TV One 3G SDI converter.
8. Connect Ethernet from Z3-DM8169-MOD to a PC.
9. Set the PC IP address to 192.168.1.110 –This is the default address the Z3-DMx8169-VI-RPS streams
to.
10. Connect 12V Power supply to the Z3-DM8169-MOD.
*Before powering up the Z3-DM8169-VI-RPS system, make sure the Brite-View Box and TV One
converter are running.
11. Open up a console window
12. Power on the Z3-DM8169-VI-RPS system
13. After booting up and running through the beginning of the sequence, a menu will appear. You will have
the option to manually change the mode of the system to encode or decode mode. Below is a
screenshot of a terminal console of the system in encode mode. To change the mode to decode mode,
press “M”.
+==============================================================
| Z3 Technology, LLC DM8169-VI-RPS 1.03.00
+==============================================================
| + -- Set Device Name [ DM8169-VI-RPS ]
| = -- Set Password [ BLANK ]
|~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
| 0 -- Operating Mode [ Encoder ]
|~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
| 1 -- Video Source [ HDMI1 ]
| 2 -- Audio Source [ Automatic ]
| 3 -- Audio Codec [ AAC-LC ADTS ]
| 4 -- Audio Bitrate [ 192 kbits ]
| 5 -- Video Resolution [ ]
| 6 -- Rate Control [ VBR ]
| 7 -- Video Bitrate [ 12000k ]
| 8 -- Video Profile [ High ]
| 9 -- Video Frame Rate [ 60 ]
| A -- Gop Size [ 60 Frames ]
| B -- Video Burst Size [ 1000ms ]
| C -- B-Frame GOP Structure [ open [IBB] ]
| D -- B-Frame Interval [ 3 ]
| E -- B-Frame Temporal Layer [ 1 ]
|~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~

CONFIDENTIAL Z3-DM8169-VI-RPS
___________________________________________________________________________________________
V1.03.00
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. ♦ +1.402.323.0702
16
| F -- Output Interface [ Ethernet ]
| G -- Video Passthru [ HDMI ]
| H -- Output Format [ MPEG-2 TS ]
| I -- Dest IP Address [ 225.1.2.3 ]
| J -- Dest Port [ 8888 ]
|~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
| K -- Local IPAddress [ 192.168.81.68 ]
| L -- Local Netmask [ 255.255.0.0 ]
| M -- Default Gateway [ 192.168.0.1 ]
+==============================================================
| T -- Stop S -- Start
|~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
| U -- Load User Settings R -- Refresh Menu
| W -- Save User Settings X -- Exit
| Y -- Load Factory Default Settings
+==============================================================
---- enter option:
For RTPStreaming:
14. On the encoder menu, press I to change the URL to your computer's static IP, and then press “S” to
start streaming.
15. Open VLC
16. Under Media, press “Open File” and open the SDP file (provided by Z3 Technology on your Z3 Server
Account).
17. You should now see video playing on VLC.
*It is possible that you may need to reboot if you do not see video in VLC
For UDP (MPEG-2 TS) Streaming:
14. On the encoder menu, press I to change the URL to your computer's static IP, and then press “S” to
start streaming.
15. Open VLC
16. Under Media, press “Open Network Stream” and type “udp://@:port number (ex. 8888, 5050)
17. You should now see video playing on VLC.
*It is possible that you may need to reboot if you do not see video in VLC

CONFIDENTIAL Z3-DM8169-VI-RPS
___________________________________________________________________________________________
V1.03.00
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. ♦ +1.402.323.0702
17

CONFIDENTIAL Z3-DM8169-VI-RPS
___________________________________________________________________________________________
V1.03.00
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. ♦ +1.402.323.0702
18
7.2 Encode & Stream with Z3-MVP-02 Decode (RTP ONLY)
The encode and stream to Z3-MVP-02 demo can support inputs from HDMI and 3G SDI. The connections are
labeled below.
The video source (we use a Brite-View box, Model: BV-5005HD Mini CT) must be a NON-HDCP source for
HDMI input. In order to test 3G SDI, you will need a HDMI to 3G SDI converter (we use a TV One converter,
Model: 1T-FC-766).
First, control the Z3-DM8169-VI-RPS system via serial port on Z3-DM8169-MOD.
1. Plug-in serial cable and NULL modem connector from Z3-DM8169-MOD to PC’s COM port
2. Setup teraterm on PC for 115k, 8, N, 1, 0ms/char, 100ms/line
3. Connect the other end of the serial cable to the console port on Z3-DM8169-MOD board
The console port is the 2.5mm jack next to the power switch
4. Connect power supply to Brite-View Box
5. Connect USB stick with content to Brite-View Box
6. Set Brite-View Box to play videos at 1080p60
7. Connect HDMI out of Brite-View Box to the HDMI in of the TV One 3G SDI converter
8. Connect 12V Power supply to the Z3-DM8169-MOD
*Before powering up the Z3-DM8169-VI-RPS system, make sure the Brite-View Box and TV One
converter are running
9. Connect Ethernet cable from Z3-DM8169-VI-RPS to Z3-MVP-02
10. Open up a console window
11. Power on the Z3-DM8169-VI-RPS system
Top: Pb In
Bottom: Pr In
Top: SDI In
Bottom: Y In
Top: SDI Out
Bottom: ASI Out 2
Top: ASI In
Bottom: ASI Out 1
Stereo Analog Jacks
HDMI In
Serial

CONFIDENTIAL Z3-DM8169-VI-RPS
___________________________________________________________________________________________
V1.03.00
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. ♦ +1.402.323.0702
19
12. After booting up and running through the beginning of the sequence, a menu will appear. You will have
the option to manually change the mode of the system to encode or decode mode. Below is a
screenshot of a terminal console of the system in encode mode. To change the mode to decode mode,
press “M”.
+==============================================================
| Z3 Technology, LLC DM8169-VI-RPS 1.03.00
+==============================================================
| + -- Set Device Name [ DM8169-VI-RPS ]
| = -- Set Password [ BLANK ]
|~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
| 0 -- Operating Mode [ Encoder ]
|~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
| 1 -- Video Source [ HDMI1 ]
| 2 -- Audio Source [ Automatic ]
| 3 -- Audio Codec [ AAC-LC ADTS ]
| 4 -- Audio Bitrate [ 192 kbits ]
| 5 -- Video Resolution [ ]
| 6 -- Rate Control [ VBR ]
| 7 -- Video Bitrate [ 12000k ]
| 8 -- Video Profile [ High ]
| 9 -- Video Frame Rate [ 60 ]
| A -- Gop Size [ 60 Frames ]
| B -- Video Burst Size [ 1000ms ]
| C -- B-Frame GOP Structure [ open [IBB] ]
| D -- B-Frame Interval [ 3 ]
| E -- B-Frame Temporal Layer [ 1 ]
|~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
| F -- Output Interface [ Ethernet ]
| G -- Video Passthru [ HDMI ]
| H -- Output Format [ MPEG-2 TS ]
|I -- Dest IP Address [ 225.1.2.3 ]
| J -- Dest Port [ 8888 ]
|~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
| K -- Local IPAddress [ 192.168.81.68 ]
| L -- Local Netmask [ 255.255.0.0 ]
| M -- Default Gateway [ 192.168.0.1 ]

CONFIDENTIAL Z3-DM8169-VI-RPS
___________________________________________________________________________________________
V1.03.00
Z3 Technology, LLC ♦ 100 N 8th ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. ♦ +1.402.323.0702
20
+==============================================================
| T -- Stop S -- Start
|~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
| U -- Load User Settings R -- Refresh Menu
| W -- Save User Settings X -- Exit
| Y -- Load Factory Default Settings
+==============================================================
---- enter option:
13. On the encoder menu, press I to change the URL to your receiver’s (We are using our Z3-MVP-02)
static IP, and then press “S” to start streaming
Now, control the Z3-MVP-02 system via serial port.
1. Plug-in serial cable and NULL modem connector from Z3-MVP-02 to PC’s COM port
2. Setup teraterm on PC for 115k, 8, N, 1, 0ms/char, 100ms/line
3. Connect 12V Power supply to the Z3-MVP-02
4. Open up a console window
5. Connect an HDMI cable from the Z3-MVP-02 HDMI out to the HDMI in on a monitor
6. Power on the Z3-MVP-02
7. After booting up and running through the beginning of the sequence the H.264 decode demo menu will
appear. Below is a screenshot of the H.264 decode demo terminal console:
+==============================================================
| Z3 Technology, LLC DM8169-VI-RPS 1.03.00
+==============================================================
| + -- Set Device Name [ DM8169-VI-RPS ]
| = -- Set Password [ BLANK ]
|~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
| 0 -- Operating Mode [ Decoder ]
|~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
| 1 -- Input Interface [ Ethernet ]
| 2 -- Input format [ RTP ]
| 3 -- RTP IP:Port [ 225.1.2.3:8888 ]
| 4 -- STC-PCR Offset(ms) [ 0 ]
| 5 -- Output Interface [ HDMI ]
| 6 -- Display Resolution [ 1080p-60 (1920x1080) ]
|~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
